Voltex FLB-CW/16W User manual

®
INSTALLATION GUIDE LED Flood Lights
16W, 24W, 50W, 72W, 120W and 200W
PIS20220511-RG
© Voltex Electrical 2022. All Rights Reserved.
Overview
LED flood light for general area lighting
Asymmetric light distribution to direct the light forward
High efficiency LED light source and driver
Corrosion resistant aluminum die-casting body, aluminium bracket, and stainless-steel
screws
IP66 rating
NOTE: Not suitable for MARINE applications

PIS20220511-RG
© Voltex Electrical 2022. All Rights Reserved.
Installation
Technical specification
Fasten the flood light bracket to the mounting surface with stainless steel bolts or similar
suitable mounting accessories
Adjust the flood light to direct the light output as required, then tighten the adjustment
screws on each side of the flood light
If hard-wiring the flood light, remove the 3-pin plug and connect the cable as follows:
∆Brown – Active/Live
∆Blue – Neutral
∆Yellow/Green – Earth
All hard-wiring connections must be protected by means of a suitable IP rated junction box
or connector
Ensure the flex is installed to minimise tension at all connection points
1
2
3
4
5
Note: All fixed wiring must be carried out by a licensed electrician.
Light Source LED
Driver Housed internally. Non-Dimmable
Colour Temperature Cool White (5700K), Warm white (3000K)
Beam Angle 120°
Life Span >50,000 hours
IP Rating IP66
Housing Colour Black
Glass Fascia Tempered, semi-frosted
Working Temperature -20C to +50C
Connection Cable 2m flex and plug
Product Code Power
(W)
H
(mm)
W
(mm)
D
(mm)
Lumen output
(lm)
Efficiency
(lm/W)
Net weight
(kg)
FLB-CW/16W
FLB-WW/16W 16 205 135 42 1600-1800 100-110 1.1
FLB-CW/24W
FLB-WW/24W 24 251 170 45 2400-2700 100-110 1.6
FLB-CW/50W 50 330 225 55 5000-5500 100-110 3.1
FLB-CW/72W 72 372 250 75 7000-7900 100-110 4.8
FLB-CW/120W 120 450 340 75 12000-13000 100-110 5.8
FLB-CW/200W 200 450 340 90 21000-22400 100-110 7.8

Product Code H1 H2 L1 L2 T D1 D2 W2 R Ø
FLB-CW/16W
FLB-WW/16W 175 205 135 150 42 31 8 8.5 4.25 8.5
FLB-CW/24W
FLB-WW/24W 220 251 170 200 45 35 9 10.5 5.25 10.5
FLB-CW/50W 290 330 225 243 55 40 9 11 5.5 12.5
FLB-CW/72W 330 372 250 265 75 40 9 11 5.5 12.5
FLB-CW/120W 400 450 340 360 75 48 20 13 6.5 13
FLB-CW/200W 400 450 340 360 90 48 20 13 6.5 13
Product Code
FLB-CW/16W
FLB-WW/16W 0.024mm²
FLB-CW/24W
FLB-WW/24W 0.037mm²
FLB-CW/50W 0.065mm²
FLB-CW/72W 0.083mm²
FLB-CW/120W 0.136mm²
FLB-CW/200W 0.136mm²
Product Code H (mm) W (mm) D (mm)
FLB-CW/16W
FLB-WW/16W 165 128 4
FLB-CW/24W
FLB-WW/24W 213 163 4
FLB-CW/50W 283 218 4
FLB-CW/72W 320 242 4
FLB-CW/120W 390 332 5
FLB-CW/200W 390 332 5
Dimensions
Maximum surface area
of the flood light
Orientation
Dimension of
Tempered Glass
The flood light can be installed on a wall, ceiling, or horizontal surface, as shown below.
PIS20220511-RG
© Voltex Electrical 2022. All Rights Reserved.
L2 T
L1
H1
D2 øD2
W2 W1
D1 D1
R
H2

IMPORTANT NOTES
All fixed wiring and installation must be carried out by a licensed electrician.
The light source of this flood light is not replaceable; when the light source reaches its end
of life, the whole flood light must be replaced.
If the supplied connection flex is damaged on arrival, please return the flood light to Voltex.
Do not disassemble the flood light to replace the flex.
Do not use chemicals or corrosive cleaners to clean the flood light.
The flood light must be Earthed.
The minimum distance from flammable objects to flood light must be kept at least 0.3m.
If the glass fascia is damaged, do not replace. Please return to Voltex.
The non-rewireable mains plug provided for connection of the flood light to the supply
does not have the equivalent IP rating of the flood light. Where the equivalent degree of
protection is required, remove the non-rewireable plug and replace it with a suitably rated
plug/socket combination or connect the lead (tails) to fixed wiring by means of a suitably
rated junction box.
