Voltex CUBO PSF12W Manual

PRODUCT Front Cover and Door
Assembly Base Assembly Module Identification Label Spare brackets Pole Filler Set Sticker Label Set
PSF12W 1 1 1 1 1 1
PSF18W 1 1 1 1 1 1
PSF24W 1 1 2 1 2 1
PSF36W 1 1 3 1 2 1
TECHNICAL SPECIFICATION
© Voltex Electrical 2020. All Rights Reserved.
PRODUCT SUPPLIED NEUTRAL BARS SUPPLIED EARTH BARS
PSF12W (2x(35mm²)+8x(16mm²)) + 2x[4x(16mm2)] 2x(35mm²)+10x(16mm²)
PSF18W (2x(35mm²)+8x(16mm²)) + 3x[4x(16mm2)] 2x(35mm²)+16x(16mm²)
PSF24W 2 x [(2x(35mm²)+8x(16mm²)) + 2x[4x(16mm2)] 2 x [2x(35mm²)+10x(16mm²)]
PSF36W 2 x [(2x(35mm²)+8x(16mm²)) + 3x[4x(16mm2)] 2 x [2x(35mm²)+16x(16mm²)]
NEUTRAL BARS EARTH BARS
®
INSTRUCTION GUIDE
Flush Mount Switchboard IP40
PSF12W, PSF18W, PSF24W, PSF36W
CHANGING DOOR ORIENTATION
AU P: 1300 722 275
E: [email protected]
www.voltexelectrical.com.au
NZ P: 0800 55 66 33
E: [email protected]
www.voltexelectrical.co.nz
© Voltex Electrical 2020. All Rights Reserved.
II092920-SL
ITEMS INCLUDED
Rated Current of Earth and Neutral Bars = 125A

MOUNTING PROCEDURE
CHECK FOR STUDS BEFORE PROCEDING WITH THE INSTALLATION.
CHECK IF YOU NEED A PROTECTION PLATE. (PROTECTION PLATE IS SOLD SEPARATELY)
Make sure board is level.
1
Trace around frame perimeter and
through corner flange slots.
2
Cut hole in plasterboard.
3
Rotate clips within confines of board
4
Place board into hole, clamping brackets to
plasterboard by fastening 4x corner screws
5
0.8 Nm


Back
Model A (mm) B (mm) C (mm) D (mm)
PSF12W 316 284 290 259
PSF18W 424 284 398 259
PSF24W 316 449 290 424
PSF36W 316 574 290 549
DIMENSIONS (mm)
© Voltex Electrical 2020. All Rights Reserved.
