VAR11NistheprofessionalminiWiFirepeater,and together withminiWiFirouter and
WiFiintelligentbridgethatiselaboratelydevelopedbyHouTianNetwork, theoriginal
creationD/Atemperaturecompensatedautofrequencycontroltechnology (TAFC),
it solved thecommon failingofthetraditionalwifirouter orwifiproducts thateasilydrop
thenetwork, makesurethelastingstabilitytoensure thattheWiFisignalisnotdropped.
Thefollowingdescribes howto useit asWiFirouter:
Step 1:The connectionbetweenVAR11NandModem,therearetwo
ways, see thefollowing:
lMethod 1:Thedefault connection method, see thefollowingpictures:
Theabovepicture connection method isthefactorydefault connection, ifthere is
differentconnection environment,user cansetWAN,LAN portforconnection manually,
themethod ofswitching WAN,LAN port, pleasesee thefollowinguser guidance:
lMethod 2:Theconnection method ofWAN,LANportafter switching.
ADSL
(Modem)
RJ45 ethernethead,used as
LAN and connectthe ethernet
port ofcomputerto be
convenientforconfiguration
The powerhead paralleled
with the powerinterface of
VAR11N, afterconnecting
with the poweradapterwith
ADSLmodem, it can share
the poweradapter.
RJ45 ethernetport of
VAR11N,the default
isWAN port,used to
connectLAN port of
ADSLModem.
The powerhole of
VAR11N,powered by
the poweradapterof
ADSLmodem

Shenzhen HouTian Network Communication TechnologyCo., Ltd
http://www.vonets.com Tel:[phone] 26645879
1)Connectcomputer ethernetportaccordingto thedefault connection method of
method 1.
Inputthedefault IP(fit for4.0 version hardware) inIEaddress column: 192.168.1.254
Or inputconfigured domain (fit forabove4.0 version hardware): http://vonets.cfg
Login configured page:username:admin, password:admin.
fit for4.0 version hardware
fit forabove4.0 version hardware.
2)Click OperatingMode,chooseInterfaceMode:Ethernetcable WAN,
EthernetPort-LAN,see thefollowingpicture:

Shenzhen HouTian Network Communication TechnologyCo., Ltd
http://www.vonets.com Tel:[phone] 26645879
3) After switchingWAN,LAN port, connectADSLmodem, see thefollowing:
Step 2:ConfigureWAN connectiontype( Broadband Accesstype),
different broadbandprovidershavedifferent access methods,thereare
two commonways.
Usingthemethod described above, login configured page, selectWAN settings.
lMethod 1:DHCP(Auto config)
RJ45 ethernethead
ofVAR11N, can be
used asWANport
and to connectLAN
port ofADSL
modem
RJ45 ethernetport of
VAR11N, can beused
asLAN and toconnect
computerorLAN
extension

Shenzhen HouTian Network Communication TechnologyCo., Ltd
http://www.vonets.com Tel:[phone] 26645879
lMethod 2:PPPOE
This need to enter thePPPOE usernameand password provided bybroadband service
providers
Step 3:ConfigureWiFi
lConfigurethe SSIDofWiFihotspot.
Usingthemethod describedabove,loginconfiguredpage,chooseWiFi
Settings-->BasicSettings, configure theWiFiSSID thatyou need.

Shenzhen HouTian Network Communication TechnologyCo., Ltd
http://www.vonets.com Tel:[phone] 26645879
lConfigurethesecuritymethod ofWiFihotspot.
Choose WiFiSettings-->WiFisecurity, configurethesecuritymodeand
securitypassword thatyou need.
