Vordon HT-X10 User manual

User Manual
HT-X10

Instruction for use
Thank you for purchasing this product, please read this manual carefully before using to ensure that you can use
the machine correctly. After reading the instructions, please keep it for future inspection.
Caveat
To prevent damage to the machince and to use the system safely, please
£ To prevent short ci r c u i t s , d o n o t o m i t m e t a l o b j e c t s(coins or ot h e r m e t a l ) i n s i d e t h e m a c h i n e
£ Do not install the unit in a way that hinders the driver’s sight or affects the driver’s operation. When you drive,
please do not pay attention. In the system, do not watch the screen for a long time.
£The machine consist of high-precision components, should avoid a strong impact, not to unauthorized removal
of the cover or adjust the parts, for maintenance, please go to a nearby professional service center consultation.
Before use
£ When you purchase optional accessories or make related system settings, please check with the dealer
whether they match the machine.
£ You can select your favorite language display in the language setup menu. For more information, see
Language Settings (Page 4 of the manual)
Portect the display
£ Protect the display from damage, do not use a ballpoint pen or sharp tool to touch the display.
£ When the machine panel or display screen is dirty, wipe with a soft cloth and a mild
£ You can not use hard cloth or alcohol and other corrosive thinner wipe the display or panel, so as to avoid the
display or panel damage, blurred, the screen disappeared and so on.
£ Please follow the instruction to use the machine, the damage caused by illegal operation is not covered by the
warranty.
The machine display screen you see may be inconsistent with the picture of the manual, which is due to
the unannounced software upgrade and update, does not affect the normal use.
Some function(DVD, color LED, TV,etc) is optional. The device which you purchase may not includes all
the functions that this manual listed.

Contents
Before Use Warning
Basic Operations.....................................01
Definition of the keys............................. 01
Open the system..........................................01
Turn off the system................................. 01
Time and date settings..........................02
Adjust the date and time manually.........02
Start logo Setup.......................................02
Language Setup.......................................02
Steering Wheel Control Setup................ 02
Navigation Operation
>Map Installation....................................02
>Navi Shortcut.........................................02
>Colorful lights set..................................02
Network Setup
Wi-Fi Setup...............................................03
Connect to Wi-Fi Hotspot.......................03
3G/4G Dongle Setup...............................03
Widget and Application Operation
Install and Uninstall APPS
> Install APPS...........................................04
> Uninstall APPS......................................04
Radio Operation
Radio Basic Operation............................04
RDS........................................................05
Stores Channel........................................05
Setting up................................................05
General settings......................................05
Display.....................................................05
About device...........................................05
Bluetooth control
>Connecting............................................06
>Hands-Free Call....................................06
>Phone Call.............................................06
>Bluetooth Setup....................................07
>Playing Bluetooth Audio Device............07
>Bluetooth Sync Contacts.......................07
Rear Camera...........................................08
Mirror Link..............................................09
>Android USB connect...........................09
>Android WIFI.........................................10
>Iphone WIFI connect.............................11
Split screen.............................................12
Wiring Diagram.......................................13
Trouble shooting.....................................22

Basic Operation
Definition of the keys
Open the system(manually)
Long press the power button 3 seconds , activate the system .
Turn off the system(manually)
When the system is on , long press the power button 3 seconds to turn off the system .
Serial
number
Name
Functional description
1
When device is working, press and hold about 1 second to power off
the system; Short press to mute.
2
MAP
Map card slot
3
MENU
Press to turn to home page
4
RETURN
Return to the previous interface
5
NAVI
Display navigation interface
6
RADIO
Display radio interface
7
Volume up
Volume down
8
USB
USB slot
9
Disc insert/eject
10
SD
SD slot
11
Reset(RST/RES)
When the machine is not working properly,press this button and the
machine will return to the factory settings.
12
Phone
Display the Bluetooth phone screen
13
DVD
Display the DVD interface
14
Video
Play videos from an SD card or USB device
15
Music
Play music from an SD card or USB device
16
Seek
▪ Search the previous chapter or the next chapter
▪ Search for the last channel or the next channel
17
Mute
Turn off sound , button for muting
18
Disc insert solt
Insert the disc into the slot
Note: This table summarizes the definition of most of the panel buttons , but not every model contains
all the keys , some of The model contains only a small number of keys , Which does not affect the use, if
you have questions, please consult the dealer.
which dose not affect the use , if you have questions , please consult the dealer .

Time and date settings
1. Press the button , Press the Setup icon , select Date & Time
1. As shown in the following two days, choose one.
Adjust the date and time manually
1. Touch the < Automatic date & Time> and the <Automatic time zone > to remove the check.
2. Tou c h < S e t date>, adjust the date , and touch done.
3. Tou c h < S e t time>, adjust t h e t i m e a n d t o u c h d o n e .
4. Tou c h < S e l cect time zone>, select a time zone.
5. Press the button
Start Logo Setup
Touch t h e , and touch the ES File Explorer , Select your car logo from the USB or SD device. (The image of
car logo must be BMP format, click the upper right corner, select Set As Bootlogo
Language Setup
Touch t h e , and touch the , touch “Language & input”, touch Language, select the language, and pull it on
top, then press the button.
Steering Wheel Control Setup
Click into key function learning:
1. Select the function you need.
2. Click your key on the steering wheel.
3. Repeat step A and B to set other Keys.
4. Press to end.
Remark: if you need to reset the keys, click then you can set again.
Navigation Operation
Map Installation
1. Copy the Navi file to SD card and put the SD card to the GPS slot.
2. Touch the , and select the ES File Explorer .
3. Touch SD, and select t h e e x t s d 1 .
4. Select the Navi File, and touch the file with suffix name”.apk” and install.
Navi Shortcut
1. GPS Shortcut on the front panel setting
Touch t h e , and touch the , touch “General”, touch “Navi Application Setting”, choose the Navi software
you prefer.
2. Navi shortcut on the Home Screen
Touch t h e , and press the Navi software like “Google maps” and drag it to the Navi key on the Home Screen.

Colorful lights set( If the stereo supports)
Press the button , then press the colorful lights, choose your favorite color, the car’s key light color changes.
Network Setup
Wi-Fi Setup
Connect to Wi-Fi access
Touch the Tou c h t h e “ S e t t i ngs” touch Wi-fi turn on the Wifi select network
type password connect
Connect to Wi-Fi hotsopt
Touch the To u c h t h e “ S e t t i n g s ” touch More Tethering&portable hotspot
Set up Wi-Fi hotspot enter the Security code Touch Save
3G/4G Dongle Setup
1. Connect the 3G/4G dongle to the USB slot on the back
2. The system will automatically recognize the 3G/4G dongle and connect
3. It connects when the icon displays on the status bar as picture below.
Note: for the 3G/4G dongle, please buy from the dealer to make sure the 3G/4G dongle works with the unit.

Widget and Application Operation
Install and Uninstall APPS
Install APPS
1. Online install:
Connect internet open the browser google.com enter Android market download the APK file
click NEXT to install
2. USB/SD install:
Download the APK file to the USB connect USB touch the ES File Explorer touch the local
choose USB file select the APK touch to install
Uninstall APPS
1. Touch the t o u c h t h e “Settings” to u c h the Apps select and touch the APP touch uninstall
touch OK uninstall finished.
2. Touch and hold t h e APP i c o n t i l l the an d t h e s h o w s and d r a g t h e APP t o t h e t r a s h
touch OK uninstall finished
Note: The means you can drag the APP to it and uninstall it. If only the displays, it means you can not uninstall
the APP, it comes with the system, you can stop use it, nut not uninstall it or delete it.
Radio Operation
Radio Basic Operation
1. Select the FM1, FM2, FM3,AM1 or AM2 band
2. Frequency display
Switches to previous frequency manually.
Switches to next frequency manually.
3. Displays the preset channel list, hold the key(P1-P6) to store the current broadcast frequency.
4. Multi function menu
Tunes in a station with good reception automatically.
Short touch for non stop seek tuning, touch again to cancel
Long touch for swicthing the preset channels, long touch again to cancel.
Change between Locate and DX mode.
Press to see more functions.
Touch <RDS > t o active the RDS functi o n
EQ and FAB setting, please see the EQ and FAB setting below.
5. Mono and DX
Displays LOC or DX.
Displays Mono or Stereo, decided by the radio IC.

RDS
TP
Shows the traffic station is on or not
AF
Tou c h AF to li gh t u p, RDS ca n s wi t ch t o s tr on g er signal frequency when the
current frequency is weak ,but keep the contents same,only frequency different.
TA
Tou c h TA t o l ig ht up , it c an so ur c e t he t ra f f i c in to e v er y m in u te ,a n d s to ps to
broadcast the traffic info once news come in.
PTY
Tou c h P TY t o s ea rch by type
Stores Channel
1.Press the P1 key and hold to the current channel to P1 key.
2.Press the P2 key and hold,then store the current channel to P2 key.If P3,then to P3 key etc.
Set up
General settings
Radio area: set general settings radio area
Button sound: set general settings button sound on/off
Display
Screen brightness: settings display brightness adjust the brightness confirm
Backup and reset
Backup the files and reset the system.
Set up Backup and reset reset Restore the factory settings
About device
1. Setting about device
2. Enter the device interface,you can view the version,host memory.
Bluetooth Control
Connecting
Rsgisting your bluetooth device
1. Active the Bluetooth on your phone
2. Tou c h s ea r ch t o s ea r ch th e Bl u et o ot h w ai tt i ng f or pa i ri ng
3. Tou c h t he B l ue to o t h De vi c e na m e (J J o r ot h er ) f or c on n ec t in g
4. Type the pin code(default code is 0000 or 1234) on your phone
Connecting a registered bluetooth manually
1. Active the Buetooth on your phone
2. Tou c h t he to see the registered Bluetooth device list
3. Kick the box of the Bluetooth device name to connect
4. Type the pin code(default code is 0000 or 1234) on your phone
Delete a registered device
1. Tou c h t he to see the registered Bluetooth device list
2. Cross the box of the device name
3. Touch the cross,and it t i ps”Do you want to unpair the Device?”
4. Touch Ok,the d evi c e delete d
Hands-Free Call
Phone call
Tou c h t he ,type the phone number,and click phone call success as
screen below,cancel the phone call by touch the ,and touch the to
switch to speaker.

Bluetooth Setup
1. Tou c h t he B u et o ot h t o ch a ng e t he Na m e
2. Tou c h t he P I N co d e t o c hange the PIN code
Playing Bluetooth Audio Device
Click into BT music and play music of the device connected by BT
Bluetooth Sync Contacts
1. Open Phone Bluetooth and connect the stereo(name beginning with AWC),then Sync
Contacts Button
2. Turn on Bluetooth Setting on stereo also and click the Sync button
Rear Camera
Note:The reverse cable(pink color) of the power cable must be connected to the
car’s parking or reversing wire,then parking or reversing,the parking screen will
automatically display.
Note: For Car Navigation for Volkswagen(VW) with CANBUS,the video
signal cable(5 red color) must be connected to the Reverse cable
of the power cable.For other models no need to connect the video
signal cable to reverse cable

Mirror Link
Android USB connect
Find the developer options of the mobile turn on the USB Debugging
turn on the BT of the mobile connect to the BT to the Unit BT connected
Tou c h t he ea sy co n ne c t S e le ct th e co n ne c ti ng me t ho d Co n n ec te d
Android WIFI
Uch the easy connect Select the connecting method connected
Note: For android mobile,the USB debugging must be turned on for mirror link function.
And the mirror link not supoort all android phone,and only support the android mobile
that with the USB debugging.

Iphone WIFI connect
Tou c h t he ea sy co n ne c t s el e ct t h e co n ne c ti ng me t ho d c o nn e ct e d
Split screen
1. Press the setup icon select display select navigation split screen
Open the button The dialog box select OK
2. Press the Navigation icon Press the Split screen icon
For WIFI connect must make sure
the mobile and the unit is connected
to the same wifi. Or make sure the
unit is connected the wifi-hotspot of
the mobile

Wiring Diagram
Diagram of power cable and RCA cable
Note:only work within DC 10.5V-16V power FM 87.5~108.0MHz Speaker prohibit grounding!
AM 522KHz~1620KHz
[1] Power cable Diagram
[2] RCA ouput socket

Wiring Diagram
Diagram of power cable and RCA cable
Note:only work within DC 10.5V-16V power FM 87.5~108.0MHz Speaker prohibit grounding!
AM 522KHz~1620KHz
[1] Power cable Diagram
[2] RCA ouput socket

Troubleshooting
malfuction
Solution
Cannot power up
Check the connection of ACC,B+,Ground.
1.connect ACC with ignition line.
2.connect B+ to the positive pole of the battery.
3.connect ground to ground.
Can not read discs
Remove the screws
No image when
reversing
Connect the car DVD’s reversing line with the car’s
reversing line,to ensure the reverse camera workable.
Navigation doesn’t
work
1.If map goes wrong,uninstall then re-install the map.
2.If map data destroyed,uninstall then re-install the map.
3.If GPS cannot search any signal please check GPS
antenna is well connected.
If well connected,makesure the GPS antenna is exposed
to the air.
If stil not working,please replace a new antenna.
The key light does not
light
1. check the headlight line connection.
2. Enable the button light on Setup.
