VOSS.SONIC 2800 User manual

VOSS.sonic 2800
Art. 45341, 45343
Ultraschall-Abwehr
Ultrasonic Repeller
Ultrasoon afweer
Répulsif à ultrasons
10 / 2017
DE EN NL FR

VOSS GmbH & Co. KG | 25885 Wester-Ohrstedt | Germany
VOSS products are born from the passion
for excellent products at reasonable prices!
DE EN NL FR
VOSS.sonic 2800 Ultrasonic Repeller
Installation and instruction manual
We cordially congratulate you for purchasing the VOSS.sonic 2800
ultrasonic system. The VOSS.sonic 2800 is an ultrasonic system
of the latest generation. You can use this repeller to protect your
garden, carport, garage, warehouse, house, attic and many other
places against unwanted guests.
The combined use of selectable ultrasonic frequencies and a
switchable ashing light also repells persistent vermin.
The VOSS.sonic 2800 is an all-round device for repelling dogs,
cats, foxes, martens, hedgehogs, mice, rats, badgers, deer,
raccoons, hares/rabbits, herons and birds.Installation and positio-
ning

DE EN NL FR
During a simultaneous use of battery and mains adapter, the device
is also ready for operation in case of power failure. The device then
switches automatically to battery power.
Tip
In outdoor locations, the device should be approximately 15 cm
above the ground. This provides an ideal coverage area and
a good ultrasonic transmission.
Tip
Installation and positioning
The VOSS.sonic 2800 is splash-proof and can be used indoors as
well as outdoors.
In dry places that are protected against water, you can simply place
the VOSS.sonic 2800 on the ground. For outdoor installation (eg. in
the garden), we recommend the installation post supplied. A xing
slot on the back of the device makes a wall installation possible.
You can exibly use the VOSS.sonic 2800 in places where you
need it.
Please note: Ultrasound spreads straightforward and does not
penetrate any building materials. The ultrasonic signal is not
eective behind objects that are in the
sphere of inuence.
Under certain circumstances,
many devices should be
installed in order to ensure
a complete deterrence.
Preparation and function
The operation of the VOSS.sonic 2800 is done using 4x 1.5 V mono
D batteries or a 230 V mains adapter. A simultaneous operation
using battery and a 230 V mains adapter is possible.
Ensure that the device is switched o before you insert the batteries
or connect the mains adapter. Batteriebetrieb

A
B
CD
E
F
G
DE EN NL FR
Operation and application
When switching the device on, a red control LED on the upper half
of the viewing window lights up for approximately 5 seconds.
After 25 more than seconds, the device is totally ready for
operation.
The motion detector will now be triggered. After a short, acoustic
starting click, the device emits ultrasonic sounds for approximately
9 seconds. The signal lamp behind the motion detector also lights
up red as a visible function control.
The VOSS.sonic 2800 begins to work as soon as the motion detector
is triggered.
The device is now ready for operation.Battery operation
Battery operation
In order to open, push down the cover on the back of the device.
Insert the batteries according to the markings. Then carefully close
the cover again.
The lifetime of the batteries depends on many factors:
Number of releases, use of ash, surrounding temperature.
NOTE: Batteries that are not fully charged cannot release the ash.
This occurs when the voltage (system performance of the 4 batte-
ries) is lower than 3.6 V.
If the voltage drops below 3.4 volts, even the ultrasonic sounds will
not emit precisely enough. The batteries are very weak and have to
be replaced.
Operation - Mains adapter (230 V) (not included in Item-No.: 45340)
The mains adapter included in delivery is splash-proof, robust,
weather-resistant and appropriate for the outdoor use.
When you operate the device using the mains adapter, remove the
moisture prevention cover on the side of the unit and insert the
adapter pin completely.
Betrieb und Anwendung
Loudspeaker
Flashlight / Flash
Viewing window
with motion detector
LED control
On / O-switch &
frequency selection
On / O-switch Flashlight
Mains adapter connection
A
B
C
D
E
F
G

Mix 1 – 8
1
2
3
4
5
6
7
8
9
DE EN NL FR
We recommend to operate the device via a mains adapter
when using the ash function for a longer period of time.
Tip
Flashlight
The switchable ashlight increases the deterrence.
We recommend to switch it on especially in the dark.
Maintenance
• Please keep the device in a dry place when you are not using it
and remove the batteries.
• In winter, free the device from snow and ice in order to
ensure an optimal function.
Caution
A direct, long-term stay in the ultrasonic area that is less than one
meter away from the device should be avoided. You should then
switch o the device when you are working near it. Keep the device
out of the reach of children and unauthorized persons. Probleme
Frequencies
You can select between 9 dierent deterrent frequencies,
also see the back of the device. Setting 9 emits a mix of
frequencies from 1 – 8.

Mains adapter
only with 45345
Ultrasonic area up to approximately 200 m²
Coverage area IR-detector up to approximately 16 m
Battery operation 4 x 1.5 V Mono D
Mains operation 6 V mains adapter
Flash energy-saving SMD-lamps
Problems
In case of problems with the device, check if the energy supply via
battery or mains adapter is working. If this is not the cause,
please contact us.
Technical data
Delivery content
• VOSS.sonic 2800
• Mains adapter
(only with 45345)
• Two-part ground stake
Safety instructions
The device emits sound pressure that humans cannot hear or can
only scarcely hear. Keep away children from staying or playing in
the ultrasonic area.
The warranty will be lost if the device is opened.
DE - EC-mark/ EC declaration of conformity
The VOSS GmbH & Co. KG company hereby declares that the
product / device described in this manual is in accordance with
the fundamental requirements and the other relevant provisions
and guidelines. The EC Mark stands for the guidelines of the
European Union.

VOSS GmbH & Co. KG
Ohrstedt-Bhf Nord 5
25885 Wester-Ohrstedt
Germany
www.voss-group.eu
