ROCKY –538TXV
Pentium™VGA
Single Board Computer
@Copyright 1997
All Rights Reserved.
Manual third edition Feb.01,1998
The information in this document is subject to change without prior notice in
order to improve reliability, design and function and does not represent a
commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or inability to use
the product or documentation, even if advised of the possibility of such
damages.
This document contains proprietary information protected by copyright. All
rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.
Trademarks
ROCKY-538TXV is registered trademarks of Acquire Inc.,IBM PC is a
registered trademark of International Business Machines Corporation. Intel is
a registered trademark of Intel Corporation. AMI is registered trademarks of
American Megatrends, Inc. Other product names mentioned herein are used
for identification purposes only and may be trademarks and/or registered
trademarks of their respective companies.

1
Contents
1. Introduction ..........................................................3
1.1 Specifications..............................................................................4
1.2 What You Have...........................................................................5
2. Installation............................................................6
2.1 ROCKY-538TXV's Layout............................................................6
2.2 Unpacking...................................................................................8
2.3 Setting the CPU of ROCKY-538TXV........................................... 9
2.4 System Memory DRAM..............................................................11
2.5 Watch-Dog Timer......................................................................12
2.6 DiskOnChip™Flash Disk ............................................................12
2.7 Clear CMOS Setup....................................................................14
2.8 Battery Backup for CMOS Setup ...............................................14
3. Connection.........................................................15
3.1 Floppy Disk Drive Connector......................................................15
3.2 PCI E-IDE Disk Drive Connector................................................16
3.3 Parallel Port...............................................................................17
3.4 Serial Ports................................................................................17
3.5 Keyboard Connector..................................................................18

2
3.6 External Switches and Indicators ...............................................18
3.7 External Speaker .......................................................................19
3.8 PS/2 Mouse 6-Pin Mini-DIN Connector ......................................19
3.9 External Battery Connector .......................................................20
3.10 USB Port Connector ..................................................................20
3.11 IrDA Infrared Interface Port .......................................................20
3.12 VGA Connector .........................................................................21
3.13 Fan Connector ..........................................................................21
3.14 Chassis Open Alarm Connector ................................................22
3.15 +5V Standby Connector for ATX Power Supply .........................22
3.16 ATX Power Switch / Soft Power Switch Connector .....................23
4. AWARD BIOS Setup .........................................24
4.1 Getting Start..............................................................................24
4.2 Standard CMOS Setup ..............................................................25
4.3 BIOS Features Setup.................................................................27
4.4 Chipset Features Setup..............................................................28
4.5 Integrated Peripherals ...............................................................29
4.6 Power Management Setup.........................................................30
4.7 PNP/PCI Configuration..............................................................31
5. E2Key Function..................................................32
Appendix A. Watch-Dog Timer..............................34

3
1
Introduction
Welcome to the ROCKY-538TXV Pentium™with VGA Single
Board Computer. The ROCKY-538TXV board is an ISA/PCI
form factor board, which comes equipped with high performance
Pentium CPU and advanced high performance multi-mode I/O,
designed for the system manufacturers, integrators, or VARs
that want to provide all the performance, reliability, and quality
at a reasonable price.
This board built-in DiskOnChip™(DOC) Flash Disk for embedded
application. The DOC Flash Disk is 100% compatible to hard
disk. User can use any DOS command without any extra
software utility. The DOC currently is available from 2MB to
72MB. There also have PROMDISK-Chip™can be used in the
same DOC socket as an alternative solution.
An advanced high performance super AT I/O chip –Winbond
W83977TF is used in the ROCKY-538TXV board. Both on-chip
UARTs are compatible with the NS16C550. The parallel port and
IDE interface are compatible with IBM PC/AT and XT
architecture's.
In addition, the ROCKY-538TXV provides four 72-pin SIMM
sockets and one 168-pin DIMM socket for its on-board DRAM.
The RAM module accepts 1MB, 2MB, 4MB, 8MB, 16MB, 32MB,
And 64MB. So,the total on-board memory can be configured
from 2MB to 256MB.
ROCKY-538TXV uses the advanced INTEL Chipset,430TX
which is 100% ISA/PCI compatible chipset.with PCI 2.1
standard.

4
1.1 Specifications :
The ROCKY-538TXV Pentium with VGA Single Board Computer
provides the following specification:
•CPU : Pentium™/MMX up to 233Mhz, AMD K5/K6 processor,
Cyrix 6x86 processor
•Bus : ISA bus and PCI 32-bit local bus,PCI 2.1 standard
•DMA channels : 7
•Interrupt levels : 15
•Chipset : Intel 430TX
•PCI VGA : with 2MB RAM
Resolution : 1280x1024,256 color,75Hz
1024x768, 64K color,75Hz
800x600,full color,90Hz
•Real-time clock/calendar : in 430TX chipset,backup by industrial
Li-battery,3V/850mAH. .
•RAM memory : 2MB to 256MB,SDRAM,EDO and standard DRAM
supported
•Second Cache memory : 512KB Pipelined Burst SRAM on board
•Ultra DMA/33 IDE Interface : up to four PCI Enhance IDE hard
drives. The Ultra DMA/33 IDE can handle data transfer up to
33MB/s. The best of all is that is new technology is compatible with
existing ATA-2 IDE specifications. So there is no need to do any
change for customer’s current accessory.
•Floppy disk drive interface : two 2.88 MB, 1.44MB, 1.2MB, 720KB,
or 360KB floppy disk drives.
•Two high speed Series ports : NS16C550 compatible UARTs
•Bi-directional Parallel Port

5
•IrDA port : Support Serial Infrared(SIR) and Amplitude Shift
Keyed IR(ASKIR) interface.
•USB port : Support two USB ports for future expansion.
•Watch-dog timer : can be set by 1,2,10,20,110 or 220 seconds
period. Reset or NMI was generated when CPU did not periodically
trigger the timer. Your program use hex 043 and 443 to control the
watch-dog and generate a system reset.
•Flash Disk - DiskOnChip™:or PROMDISK-Chip™: The Flash Disk
provide 100% compatible with hard disk. The built-in TrueFFS
Transparent Flash Block Management and Space Reclamation will
let customer to use the Flash Disk with DOS command, no need any
extra software utility.
•Keyboard connector
•Mouse : PS/2 Mouse Port on-board.
•Power Consumption : +5V @ 4.6A
( Pentium/MMX-200,16MB EDO RAM)
+12V @ 70mA , -12V@20mA
•Operating Temperature : 0°~ 55°C ( CPU needs Cooler)
1.2 What You Have
In addition to this User's Manual, the ROCKY-538TXV package
includes the following items:
•ROCKY-538TXV Pentium with Single Board Computer
•RS-232/Printer Cable
•FDD/HDD Cable
•6-pin Mini-Din to 5-pin Din Keyboard Adapter Cable
If any of these items is missing or damaged, contact the dealer
from whom you purchased the product. Save the shipping
materials and carton in case you want to ship or store the
product in the future.

6
2
Installation
This chapter describes how to install the ROCKY-538TXV. At
first, the layout of ROCKY-538TXV is shown, and the unpacking
information that you should be careful is described. The
jumpers and switches setting for the ROCKY-538TXV's
configuration, such as CPU type selection, system clock setting,
and watch dog timer, are also included.
2.1 ROCKY-538TXV's Layout
< reference next page >

7
2.2 Unpacking

8
Your ROCKY-538TXV Single Board Computer contains
sensitive electronic components that can be easily damaged by
static electricity.
In this section, we describe the precautions you should take
while unpacking, as well as during installation. It is very
important that the instructions be followed correctly, to avoid
static damage, and to successfully install the board.
The system board should be done on a grounded anti-static mat.
The operator should be wearing an anti-static wristband,
grounded at the same point as the anti-static mat.
Inspect the cardboard carton for obvious damage. Shipping and
handling may cause damage to your board. Be sure there are no
shipping and handing damages on the board before processing.
After opening the cardboard carton, exact the system board and
place it only on a grounded anti-static surface component side
up.
Again inspect the board for damage. Press down on all the
socketed IC's to make sure that they are properly seated.
Do this only with the board place on a firm flat surface.
Note : DO NOT APPLY POWER TO THE BOARD IF IT HAS
BEEN DAMAGED.
You are now ready to install your ROCKY-538TXV Single Board
Computer.

9
2.3 Setting the CPU of ROCKY-538TXV
•CPU Clock Setting :
CPU Speed/Clock JP 9
1-2 JP9 3-4 JP9 11-12 JP9 13-14
55MHz OPEN CLOSE CLOSE OPEN
60MHz OPEN CLOSE OPEN OPEN
66MHz OPEN OPEN OPEN OPEN
•CPU to Bus Multiple :
Multiplier JP 9
5-6 JP9 7-8 JP9 9-10
1.5 x OPEN OPEN OPEN
2x CLOSE OPEN OPEN
2.5x CLOSE CLOSE OPEN
3 x OPEN CLOSE OPEN
3.5 x OPEN OPEN OPEN
CPU Frequency = CPU Clock x Multiplier for example
Pentium 200MHz = 66MHz CPU Clock x 3
•CPU Core Voltage Selection :
Please check the CPU Core Voltage before you install the
CPU. Right now new Intel MMX CPU is dual voltages for
core and I/O,the I/O is 3.3V but the core is 2.8V. This kind
of CPU design will enhance the low power consumption
capability. As for the general Pentium CPU is one voltage for
I/O and Core - 3.3V,3.4V,or 3.5V

10
•JP16 CPU Core Voltage Setting :
CPU Core
Voltage JP16 1-2 JP16 3-4 JP16 5-6 JP16 7-8
3.5V(P54C/CS)
VRE CLOSE CLOSE CLOSE CLOSE
3.4V(P54C/CS)
STD OPEN CLOSE CLOSE CLOSE
3.3V CLOSE OPEN CLOSE CLOSE
3.2V OPEN OPEN CLOSE CLOSE
3.1V CLOSE CLOSE OPEN CLOSE
3.0V OPEN CLOSE OPEN CLOSE
2.9V CLOSE OPEN OPEN CLOSE
2.8V OPEN OPEN OPEN CLOSE
2.7V CLOSE CLOSE CLOSE OPEN
2.6V OPEN CLOSE CLOSE OPEN
2.5V CLOSE OPEN CLOSE OPEN
2.4V OPEN OPEN CLOSE OPEN
2.3V CLOSE CLOSE OPEN OPEN
2.2V OPEN CLOSE OPEN OPEN
2.1V CLOSE OPEN OPEN OPEN
2.0V OPEN OPEN OPEN OPEN
•
Dual / Single CPU Voltage setting :
Vcore & VIO JP11 JP12 JP13 JP14
Pentium
(P54C) CLOSE CLOSE OPEN OPEN
Pentium MMX
AMD K6
Cyrix 6x86MX
Dual Voltage
OPEN OPEN CLOSE CLOSE

11
•
Cyrix 6x86MX PR Rating Table
( Vcore : 2.9V,dual voltage )
PR Rating Bus MHz CPU Core
MHz Clock Multiplier
6x86MX-PR133 50 100 2x
6x86MX-PR133* 55 110 2x
6x86MX-PR150 60 120 2x
6x86MX-PR150 50 125 2.5x
6x86MX-PR166 66 133 2x
6x86MX-PR166 55 138 2.5x
6x86MX-PR166 50 150 3x
6x86MX-PR166 60 150 2.5x
6x86MX-PR200 55 165 3x
6x86MX-PR200 66 166 2.5x
6x86MX-PR200 60 180 3x
6x86MX-PR233 66 200 3x
6x86MX-PR266 66 233 3.5x
•
AMD K6 MMX Rating Table, dual voltage
Product Name Core Freq Vcore Bus MHz Multiplier
AMD-K6-233 233MHz 3.2V 66 3.5x
AMD-K6-200 200MHz 2.9V 66 3x
AMD-K6-166 166MHz 2.9V 66 2.5x
2.4 System Memory DRAM
There are four 72-pin SIMM sockets to accept Paged/EDO
1MB,2MB,4MB,8MB,16MB,32MB,or 64MB memory modules.
The total capacity is from 2MB to 256MB.Customers have to
install at least 2pcs RAM module on board,SIMM Socket 1,2
or 3,4. From right side to left side,the SIMM sockets are SIMM
1,SIMM 2,SIMM 3,SIMM 4. There also have a 168-pin DIMM
socket for SDRAM. When install the 168-pin DIMM,then will not
allow to install 72-pin SIMM1 and SIMM2.

12
2.5 Watch-Dog Timer
The Watch-Dog Timer is enabled by reading port 443H. It should
be triggered before the time-out period ends, otherwise it will
assume the program operation is abnormal and will issue a reset
signal to start again, or activate NMI to CPU. The Watch-Dog
Timer is disable by reading port 043H.
•JP6 : Watch-Dog Active Type Setting
JP6 DESCRIPTION
2-3 RESET WHEN WDT TIME-OUT
1-2 ACTIVATE NMI TO CPU WHEN WDT TIME-OUT
OPEN DISABLE WDT
•JP7: WDT Time-Out Period
PERIOD 1-2 3-4 5-6 7-8
1 sec. OPEN OPEN CLOSE OPEN
2 sec. OPEN OPEN CLOSE CLOSE
10 sec. OPEN CLOSE OPEN OPEN
20 sec. OPEN CLOSE OPEN CLOSE
110 sec. CLOSE OPEN OPEN OPEN
220 sec. CLOSE OPEN OPEN CLOSE
2.6 DiskOnChip™Flash Disk
The DiskOnChip™Flash Disk Chip(DOC) is produced by M-
Systems. Because the DOC is 100% compatible to hard disk and
DOS.Customer don‘t need any extra software utility. It is just
“plug
and play”,easy and reliable. Right now the DOC is available from
2MB to 72MB.There also have PROMDISK-Chip™can be used
with the same socket. There have two sockets for the DOC. Based
on the two sockets,customer could have two Flash Disk Drives.
And in the future the DOC and PROMDISK-Chip will upgrade
firmware to allow two flash disk chips combined to one drive.
At that time the total capacity will be up to 144MB.
The DiskOnChip will share only 8KB memory address for each
one

13
socket.
•JP15 : DiskOnChip Memory Address Setting
1. JP15 Pin 1-2 Close –main address C8000H
Flash Chip Address
U18 C8000H , Pin 7-8 close
U18 CC000H, Pin 9-10 close
U15 CA000H, Pin 11-12 close
U15 CE000H, Pin 13-14 close
2. JP15 Pin 3-4 Close –main address D0000H
Flash Chip Address
U18 D0000H , Pin 7-8 close
U18 D4000H, Pin 9-10 close
U15 D2000H, Pin 11-12 close
U15 D6000H, Pin 13-14 close
3. JP15 Pin 5-6 Close –main address D8000H
Flash Chip Address
U18 D8000H , Pin 7-8 close
U18 DC000H, Pin 9-10 close
U15 DA000H, Pin 11-12 close
U15 DE000H, Pin 13-14 close

14
2.7 Clear CMOS Setup
If want to clear the CMOS Setup(for example forgot the
password you should clear the setup and then set the password
again.),you should close the JP17 pin 2-3 about 3 seconds,then
open again. Set back to normal operation mode,close pin 1-2.
•JP17 : Clear CMOS Setup (Reserve Function)
JP17 DESCRIPTION
1-2 Normal Operation
3-4 Clear CMOS Setup
2.8 Battery Backup for CMOS Setup
There have one 4-pin header J9 using for battery backup
function.
When close the pin 1-2 will use the on board battery. When use
external battery you should take off the jumper and use the
connector as external battery connector.
•J9 : Battery Backup Function
J9 DESCRIPTION
1-2 CLOSE
3-4 OPEN Using Internal Battery
1-2 OPEN
3-4 OPEN Use as External Battery
Connector

15
3
Connection
This chapter describes how to connect peripherals, switches and
indicators to the ROCKY-538TXV board.
3.1 Floppy Disk Drive Connector
ROCKY-538TXV board equipped with a 34-pin daisy-chain
driver connector cable.
•J2 : FDC CONNECTOR
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1GROUND 2REDUCE WRITE
3GROUND 4N/C
5GROUND 6N/C
7GROUND 8INDEX#
9GROUND 10 MOTOR ENABLE A#
11 GROUND 12 DRIVE SELECT B#
13 GROUND 14 DRIVE SELECT A#
15 GROUND 16 MOTOR ENABLE B#
17 GROUND 18 DIRECTION#
19 GROUND 20 STEP#
21 GROUND 22 WRITE DATA#
23 GROUND 24 WRITE GATE#
25 GROUND 26 TRACK 0#
27 GROUND 28 WRITE PROTECT#
29 GROUND 30 READ DATA#
31 GROUND 32 SIDE 1 SELECT#
33 GROUND 34 DISK CHANGE#

16
3.2 PCI E-IDE Disk Drive Connector
You can attach four IDE( Integrated Device Electronics) hard
disk drives to the ROCKY-538TXV IDE controller.
J1(IDE 1) : Primary IDE Connector
J5(IDE 2) : Secondary IDE Connector
•J1/J5: IDE Interface Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1RESET# 2GROUND
3DATA 7 4DATA 8
5DATA 6 6DATA 9
7DATA 5 8DATA 10
9DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GROUND 20 N/C
21 N/C 22 GROUND
23 IOW# 24 GROUND
25 IOR# 26 GROUND
27 N/C 28 BALE - DEFAULT
29 N/C 30 GROUND - DEFAULT
31 INTERRUPT 32 IOCS16#-DEFAULT
33 SA1 34 N/C
35 SA0 36 SA2
37 HDC CS0# 38 HDC CS1#
39 HDD ACTIVE# 40 GROUND

17
3.3 Parallel Port
This port is usually connected to a printer, The ROCKY-538TXV includes
an on-board parallel port, accessed through a 26-pin flat-cable connector
J6.
•J6 : Parallel Port Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1STROBE# 2DATA 0
3DATA 1 4DATA 2
5DATA 3 6DATA 4
7DATA 5 8DATA 6
9DATA 7 10 ACKNOWLEDGE
11 BUSY 12 PAPER EMPTY
13 PRINTER SELECT 14 AUTO FORM FEED #
15 ERROR# 16 INITIALIZE
17 PRINTER SELECT LN# 18 GROUND
19 GROUND 20 GROUND
21 GROUND 22 GROUND
23 GROUND 24 GROUND
25 GROUND
3.4 Serial Ports
The ROCKY-538TXV offers two high speed NS16C550 compatible
UARTs with Read/Receive 16 byte FIFO serial ports.
•CN3 : Serial Port DB-9 Connector( ACE0 )
PIN NO. DESCRIPTION
1DATA CARRIER DETECT (DCD)
2RECEIVE DATA (RXD)
3TRANSMIT DATA (TXD)
4DATA TERMINAL READY (DTR)
5GROUND (GND)
6DATA SET READY (DSR)
7REQUEST TO SEND (RTS)
8CLEAR TO SEND (CTS)
9RING INDICATOR (RI)
•J10 : Serial Port 10-pin Header( ACE1)

18
Pin No. Description Pin No. Description
1 DCD 2 DSR
3 RXD 4 RTS
5 TXD 6 CTX
7 DTR 8 RI
9 GND 10 NC
3.5 Keyboard Connector
The ROCKY-538TXV provides two keyboard connectors.
•JP1 : 5-pin Header Keyboard Connector
PIN NO. DESCRIPTION
1KEYBOARD CLOCK
2KEYBOARD DATA
3N/C
4GROUND
5+5V
•CN4 : 6-pin Mini-DIN Keyboard Connector
PIN NO. DESCRIPTION
1KEYBOARD DATA
2N/C
3GROUND
4+5V
5KEYBOARD CLOCK
6N/C
3.6 External Switches and Indicators
There are many external switches and indicators for monitoring
and controlling your CPU board.
•
JP8 : KeyLock and Power LED
PIN NO. DESCRIPTION
1+5V
2N/C
3Ground
4KeyLock Signal
5Ground
•JP5 : RESET BUTTON
