VPI SE-HD-5-LC User manual

SE-HD-5-LC
SE-HD-3-LC
HDMI VIDEO SWITCH- 5/3 PORT
User Manual
(Front and Rear View of SE-HD-5-LC)

1.0 DESCRIPTION
The HDMI video switch routes digital video and audio signals from multiple
HDMI sources to one HDMI display. The switch can be controlled via the front
panel buttons or IR remote control.
2.0 FEATURES
Eliminate duplicate purchases of expensive high definition displays.
Supports crystal clear HDTV resolutions to 1080p and computer
resolutions to 1920x1200 (WUXGA).
Supports 3D
Plug and play functionality - no new software or drivers required.
Eliminates the need to disconnect and then reconnect multiple HDMI
sources.
Compliant with HDMI 1.3b and HDCP standards.
Ideal solution for connecting multiple HD media devices such as video
game consoles, media PCs, set top boxes, DVRs, DVD players etc to
your home theater systems.
3.0 PACKAGING ACCESSORIES
HDMI switcher (5x1 or 3x1)
5V DC Power Adaptor (for 5x1 model only (3x1 is powered by video source))
User Manual
Remote Control
4.0 APPLICATION
It switches several routes of HDMI signals from source devices such as a DVD
player, Satellite Receiver, Set-top Box, DV Camera, A/V Receiver and other
HDMI enabled devices to a high-definition display device such as HDTV and
HDMI Flat Panel Display.
5.0 HOW IT WORKS
1. Connect a high definition display device such as HDTV to the HDMI
Switch's output port.
2. Connect source devices such as DVD and PS3 to the HDMI Switch's input
ports.
3. After all the connections have been successfully made, power the switch
ON.
4. Use the MANUAL SELECT switch or the Remote Control to select which
video/audio source to view or listen to.

Note: When the HDMI Switch is ON, make sure the source device and display
device cables are well connected. In order to make the relevant ports work
properly, first power ON the switch, then power ON the source device.
6.0 TECHNICAL SPECIFICATIONS
SE-HD-3-LC SE-HD-5-LC
HDMI Source Input Port 3 5
Display Device Output Port 1
Source Port Connector 19 PIN HDMI(ATYPE)
Display Device Port Connector 19 PIN HDMI(ATYPE)
HDCP Compliant YES
Source Device Selection Push Button IR Remote Control
Input Video Signal 0.5-1.0 Volts P-P
Input DDC signal 5 Volts P-P(TTL)
Deep Color 12bit
Single Link Range 1920*1200@60Hz, 1080p
HDMI Version HDMI1.3b
Bandwidth Up to 225MHz Up to 340MHz
Signal Speed Up to 2.5Gbps Up to 10.2Gbps
The length of input cable ≤20M ≤10M
The length of output cable ≤25M
The cable standard 28AWG HDMI1.3
Vertical Frequency Range 60Hz
Power Consumption(max) 1 Watt 3 Watt
Operation Temperature 0℃TO 70℃
Working Voltage DC 5V
Power Adaptor 5V 1A
Net Weight(Kg) 0.279 .456
Dimension: L×W×H（mm）81×58×19 150×65×26
7.0 Installation and Precautions
To avoid electric shock , product damage and to protect your safety , please
notice the following:
1.Please slowly plug or unplug signal cables and do not frequently plug,
unplug, or shake them.
2.The equipment should not be placed in the sun, rain, a damp or unventilated
environment.
3.Items containing liquid should not be placed on the equipment.
4.Do not install the equipment near heat sources such as fire, power, or other
sources of heat.
MAN299 REV 7/23/18
