VR46 Kiddy User manual
User manual
English | Italiano | Español | Français | Deutsch | Polskie | Čeština | Slovenský | Português | Ελληνικά
electric scooter
English
Italiano
Español
Français
Deutsch
Polskie
Čeština
Slovenský
Português
Ελληνικά
01
28
55
82
109
136
163
190
217
244
Index
01
Electric scooter
User manual
Thank you for choosing this product.
For information, technical support and assistance, contact your reseller
or visit www.vr46e-mobility.com
For spare parts visit www.urbanemobility.com
English
02
Index
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
Safety instructions
Quick guide
Contents of the package
Product overview
Assembly and setup
Battery charging and activation
Brake adjustment
Autonomy
Storage and cleaning
General warnings
Learning to ride the scooter
Battery (Warnings)
Responsibility
Daily maintenance and care
Technical data sheet
Troubleshooting
03
1. Safety instructions
Please read the following instructions carefully before using the scooter. Keep this manual for future
reference or new users.
• The company shall not accept liabilities resulting from product misuse or from non-compliance with
trafcregulationsortheinstructionsprovidedinthismanual.
• This electric scooter is not a toy. Use it responsibly, with care and respect for others.
• Check local current regulations on the use of these products before riding it, and comply with local
trafcregulations.Rideresponsiblyandpayattentiontopeopleandobstaclestoavoidaccidents.
• Always use the recommended clothing: non-slip gloves, knee and elbow pads and wear a helmet.
• When holding the handlebars at the correct height, the person riding this scooter must be able to place
both feet on the ground easily.
•Whenstoppingorparkingyourvehicle,besuretodosoonaatandsafesurface
• The maximum load capacity for the scooter is 80 kg.
• This scooter may not be used by more than one person at a time.
• Misuse of the scooter or non-compliance with the instructions provided in this manual may cause
serious injury.
• Should technical problems occur, contact the Technical Support Service at your dealer.
• Do not attempt to disassemble or repair the scooter yourself.
•Donotleavethebatterynearreorheatsources.
• Avoid using used, defective and/or non-original batteries.
• Do not sit on the scooter both while riding it or when it is parked.
• If the user who is going to use the scooter is not familiar with this type of vehicle, they should be
instructedonthebasicsofdrivingbyanadultbeforeusingitforthersttime.Trainingshould
cover the following topics:
1. Acceleration
2. Deceleration
3. Braking
4. Basic riding principles
04
2. Quick guide
• Fully charge the scooter before using it for the first time.
• Press the power switch located on the right side of the footrest.
• If the battery is low, recharge it before use. The electric scooter is a device that requires
periodic charging.
• Place the electric scooter on a flat surface.
• Place your hands on the handlebars. Step onto the footrest with one foot and use the other
to give yourself a gentle push and accelerate.
• When the electric scooter begins to move, place both feet on the footrest and press
the accelerator.
• To steer the electric scooter, tilt your body in the direction of travel when turning and slowly
turn the handlebar.
• To stop the electric scooter, release the accelerator and press the electronic brake or lever
on the left side of the handlebar.
• Stop the electric scooter completely before getting off. Trying to get off the electric scooter
while it is moving may result in injury.
• Once the power switch is set to “ON”, the electric scooter will move when the throttle is rotated.
Before the throttle is rotated, make sure you are in an open area where it is safe to ride;
make sure you are balanced on the electric scooter, and have both hands on the
handlebar controls.
• Always make sure the power switch is set to “OFF” when the electric scooter is not in use.
Never store the product at a temperature that is near or below zero. Low temperatures will cause
permanent damage to the battery.
For your own safety, wear a helmet and knee pads to protect yourself against falls and injuries
while learning to ride the electric scooter.
The rider assumes all responsibility for any injury suffered when not wearing a helmet or other
protective gear.
05
3. Contents of the package
1x Charger
1x 2.5 mm hex wrench
1x 5 mm hex wrench
1x 10 / 8 mm wrench
1x 15 / 13 mm wrench
1x Screwdriver
Assembledelectricscooter;thehandlebarmustbettedusingthescrewsprovided.
06
4. Product overview
handlebar stem
drive wheel
rear wheel
charging port reset switchfront wheel
footrest
ON/OFF switch
accelerator
brake lever
07
5. Assembly and setup
Tools required: 5 mm hex wrench, 10 mm wrench
1. Press the switch located on the back of the fork and
insert the stem of the handlebar steering into the fork.
The switch should align with the positioning hole in the
handlebar stem and securely lock the stem in place.
2. Tighten the bolts using the 5 mm hex wrench and the 10
mm wrench. Tighten the bolts evenly and securely.
3. Align the handlebars both vertically and horizontally
(a) on the handlebar steering stem clamp (b), install the
handlebar clamp and components (c and d) and tighten
evenly and securely using the 5 mm hex wrench and the
10 mm wrench
08
The charging port is located on the left side of the footrest (see photo)
The device is usually delivered partially charged. However, we recommend
chargingitfor6to8hoursbeforeusingitforthersttime.
We also recommend charging it after each use and before storing it.
Do not allow the electrical scooter to fully discharge to avoid damaging the
battery.
6. Battery charging and activation
IMPORTANT
1. Make sure that the power switch, on the right side of the platform, is set to “0” before connecting the
charger. Connect the charger to the charging port, which is located on the left side of the footrest. Set the
switch on the right side of the footrest to “I”
2. Plug the charger into a wall power outlet. The light on the
charger housing should come on. A red LED light indicates
that the battery is charging whereas a green LED light
indicates that the battery is fully charged.
09
Checkthebrakestomakesuretheyareefcient.Makesurethatthebrakesdonotdragwhentheleveris
not being pressed. Do not ride the electric scooter if the brakes are not working properly.
Tools required: 10 mm wrench
7. Brake adjustment
Before using this product under any circumstances, check that the
brake is working properly
IMPORTANT
1. To adjust the brake cable, turn the adjuster barrel on
the brake lever clockwise (to loosen) or counterclockwise
(to tighten). Rotate the cylinder only a little at a time,
until the desired adjustment is reached. If the brake still
needs further adjustment, proceed to the next step.
2. If the brake cable is still too tight or too loose, use a 10
mm wrench to loosen the brake cable clamp bolt to carry out
further adjustments on the cable. Ensure that the 10 mm nut
is securely tightened after the adjustment has been made.
Tighten
Loosen
10
The maximum autonomy depends on several variables:
Terrain: riding on a smooth surface promotes a longer autonomy than riding on rough roads and slopes.
User weight: the heavier the user, the shorter the autonomy.
Temperature: riding the scooter in a very cold or hot environment affects the autonomy.
Speed and riding style: riding smoothly and at constant speed extends the autonomy. Acceleration and
manoeuvring drastically reduce
the autonomy. A lower speed extends the autonomy. Maintenance: timely recharging and correct
maintenance increase the autonomy.
Charge the scooter to 80% - 90% before storing it for extended periods of time. Recharge it to 80% -
90% every 2-3 months. If not used daily, the electric scooter should be stored at a temperature of
15-25 *C. Do not expose the electric scooter to extreme temperatures (below 0 °C or above 45 °C).
Avoid leaving it outdoors, as it is not water-resistant.
When the electric scooter gets dirty, clean it with a damp cloth. Before cleaning it, make sure that it is
turned off and cover the charging port to prevent damage to the electronic components. Do not use
alcohol, petrol, kerosene or other corrosive and volatile chemical solvents. This may damage both the
appearance and the internal structure of the electric scooter. Do not use pressurized water jets or
running water to clean the scooter. The electric scooter is not waterproof.
Do not expose it to rain or water or immerse it in water to wash it.
8. Autonomy
9. Storage and cleaning
11
10. General warnings
• Check the brakes, the condition of the wheels and the throttle before each use. If you notice any
unusual noises or anomalies, do not use the scooter, and contact your dealer’s Technical Support Service.
•Itisforbiddentomodifytheelectricscooterinanywayasthismayimpairitsefciencyordamage
its structure and cause damage.
• Make sure the scooter is off before parking it.
• Do not ride the vehicle in the rain, snow, or fog.
• Make sure the electrical components of the vehicle do not come into contact with water or other liquids.
• Avoid riding near rivers or lakes.
• Supervise children to ensure that they play properly with the product. Close supervision is necessary if
the scooter is being used near other children.
• For information, technical support and help, contact your dealer.
Instructions on riding behaviour
• Do not use the phone or listen to music while riding the electric scooter.
• Only ride if there is enough light to ride safely.
• Always hold the handlebar with both hands when riding.
• Always ride with both feet on the footrest in a safe and comfortable position.
• Do not get distracted while riding and always look straight ahead.
• Always ride at a speed that allows braking safely.
• Start braking early enough so as to avoid obstacles, handle bends on the road, and areas with
uneven surfaces. Remember to release the accelerator before braking.
• Do not race with other riders.
• Keep a minimum safety distance of 5 m from other vehicles.
12
Read the safety instructions before riding the
electric scooter.
Use approved equipment such as helmets and
knee pads.
Do not use the electric scooter in the rain.
The electric scooter may not be used by more than
one person at a time.
Children under the age of 6* and pregnant
women should not use this electric scooter.
* For use on public roads, consult local laws
and regulations
11. Learning to ride the scooter
6
13
Minimum weight allowed on the Electric scooter:
20 kg.
Maximum weight allowed on the Electric scooter:
80 kg.
Do not ride the electric scooter if you have been
drinking alcohol or if you are on medication.
Do not use the phone or listen to music while
riding the electric scooter.
Take extra care if you are riding where there are
bumps, sand, puddles, frost, snow, or steps, or in
dark places, at night, or in wet conditions.
14
Do not use the electric scooter in dangerous areas,
nearammableand/orexplosivesubstances,
liquids and/or dirt.
This electric scooter is not designed to be ridden
on roads and motorways.
Consult the laws in force in your municipality on
where the use of electric scooters is permitted.
Do not hang heavy objects on the handlebar.
Do not use the electric scooter to go up or
down steps or stairs.
15
Always hold the handlebar with both hands.
Do not ride the electric scooter with just one
foot on the footrest.
Do not press the accelerator when walking with
the electric scooter.
Do not ride the electric scooter over puddles
and wet surfaces.
16
Mind your head when passing under canopies,
through doorways or similar places.
When riding at the highest permitted speed,
do not turn the handlebar abruptly.
Start braking early enough so as to avoid
obstacles, handle bends on the road, and areas
with uneven surfaces. Remember to release the
accelerator before braking
Do not travel at speed over obstacles such as
steps, curbs, or bumps.
17
5m
Do not hit obstacles with the wheels.
Do not touch the motor immediately after
riding as it may be extremely hot.
Keep a minimum safety distance of 5 m from
other vehicles.
18
12. Battery (Warnings)
Make sure the electric scooter, charger, and charging port are dry.
When the electric scooter is fully charged, the LED light on the charger changes from red (charging) to
green (charging completed).
Use only the original charger. Other chargers may damage your device and expose users to other
potential risks.
The electric scooter should not be charged for extended periods. Overcharging reduces battery life and
may cause other damages.
Chargetheelectricscooterinadryenvironmentawayfromammablematerials(e.g.materialsthatmay
burstintoames),preferablyataninternaltemperatureof15-25°C,butneverlowerthan0°Corhigher
than+45°C.Donotchargeindirectsunlightornearare.
Do not charge the electric scooter immediately after use. Let the electric scooter cool down for one hour
before recharging.
Never leave the electric scooter unattended while charging. Fire hazard! Never touch the charging socket
with metal objects.
Read the charging and storage sections above to ensure that the battery is maintained and handled
properly.Keeptheelectricscooterawayfromopenamesorotherheatsourcestopreventthebattery
from overheating. Do not leave the electric scooter exposed to freezing temperatures. Both excessive
heat and cold temperatures may cause the battery to lose their charge.
Avoid completely discharging the battery.
It is best to recharge the battery while there is still some charge left. This prolongs the life of the battery.
When the charge is too low, it is not possible to ride normally. This may lead to the rider losing control or
falling off.
Make sure the battery is charged at regular intervals, even if you do not use the electric scooter for an
extended period of time. This prevents damage to the battery caused by low voltage over an extended
period.
Battery precautions:
The battery is made up of chemical elements that are hazardous to the health and the environment. Do
not use the electric scooter if it begins to smell or leak, or becomes excessively hot. Do not dispose of the
electric scooter or battery with household waste. The end user is responsible for the disposal of electrical
and electronic equipment and batteries in compliance with all applicable regulations.
Table of contents
Languages:
Other VR46 Scooter manuals
