User Manual
Digicom Ark 3100SP
Multi-screen Processor
V2.1
VTRON
http://www.vtron.com
E-Mail: [email protected]
All rights reserved

User Manual Digicom3100SP Multi-screen Processor
The copyright of this manual belongs to VTRON. Without written permission, the copy or
promulgation of any part of this manual in any means is prohibited.
The manual is subject to change without prior notice.
This product may allow you to use the third party’s software or upload, download the third party’s
works, including articles, images, video or software, but VTRON does not own or provide such
third party’s works. By using the above-mentioned third party’s works, you agree that you will use
such works without infringing or breaching the rights of the third party and VTRON will not
assume any liability for your use.
VTRON and Digicom are registered trademarks of VTRON. Windows, Windows NT, Windows
2000 and Windows XP are trademarks or registered trademarks of Microsoft Cooperation in USA
and/or other countries (regions). Other product names or company names in this manual may be
the trademarks of the owners respectively.
Notice
This manual is designed for Digicom Ark 3100SP Multi-screen Processor of VTRON. The specific
configuration and function depend on the order contract. If you find that certain functions and
interfaces of ordered products are different from the content of this manual, the ordered product may
be different from those described in this manual.
Statement
This is a Class A product, which may cause radio interference in living environment. In this case, the
user needs to take practical measures.

User Manual Digicom3100SP Multi-screen Processor
Before operating VTRON DigicomArk 3100SPMulti-screen Processor please read the
following carefully:
Perfect grounding measures (as in the left figure)
The product should be grounded properly. Otherwise, a series
of problems will occur: serious system fault, system
instability and unreliability, and even the paralysis to the
whole system. Even worse, the safety of users cannot be
ensured.
Do not change the original design
Do not add or delete any mechanical parts or electrical loop of
the product, or else VTRON isn’t responsible for any result
thereby.
Do not install illegal software
The Multi-screen signal processor described in this manual is
dedicated image processing and controlling device, and
shouldn’t be used for other purposes. If it is necessary to
install other software, please consult VTRON or designated
agent, or else VTRON isn’t responsible for any result thereby.
Safety Warning
!
Earth wire (connect
to earth)
●

User Manual Digicom3100SP Multi-screen Processor
Away from corrosive chemicals, pharmaceuticals
The corrosive chemicals and pharmaceuticals will damage the
mechanical parts and electrical loop of the product and affect
the service life directly. Do not use highly volatile solvents or
detergents, such as gasoline, thinner and acetone, to clean the
interior and exterior of the product.
Away from flammable, explosive objects
The flammable and explosive objects are not only the threat to
the product, but also to the users’ safety.
Away from strong electromagnetic interference equipment
In the environment with strong electromagnetic interference,
the performance of the product can’t be exerted, and the
stability is also affected.
Be sure to cut off power supply
Please cut off the power supply before the following
operations:
A. Remove or reinstall any part (unless HOT SWAP
parts).
B. Disconnect or reconnect the electrical plug of any part
or any other connections.

User Manual Digicom3100SP Multi-screen Processor
Disconnecting device of the power supply
This device uses appliance coupler or power plug as the
disconnecting device. Please make sure that the plug or
coupler is reachable, so as to disconnect the power supply
through the coupler or plug upon emergency.
Note
A. The device integrates replaceable batteries. It may cause
explosion if the battery model isn’t proper. Please
replace with the batteries provided by VTRON.
B. Follow the instructions to dispose the used batteries.
Please consult local environment protection department
for the treatment of used batteries.

User Manual Digicom3100SP Multi-screen Processor
Contents
1. Introduction ........................................................................................................................................1
1.1 About Digicom Ark 3100SP Multi-screen Processor .....................................................................1
1.2 Functions and Features...................................................................................................................2
1.2.1 Digicom Ark 3100SP Multi-screen Processor.........................................................................2
1.2.2 Functions and Features of SPV3000 Signal Preview Processor (Optional) ............................6
1.2.3 Functions and Features of SMA3000 Streaming Media Processor (Optional)........................7
1.3 Appearance.....................................................................................................................................9
1.3.1 Digicom Ark 3100SP Multi-screen Processor.........................................................................9
1.3.2 SPV3000 Signal Preview Processor（Optional）................................................................15
1.3.3 SMA3000 Streaming Media Processor .................................................................................16
1.4 Technical Specifications...............................................................................................................18
1.5 Classical Application Diagram.....................................................................................................22
2. Introduction to Boards.....................................................................................................................23
2.1 System Main Control Board.........................................................................................................23
2.2 Signal Processing Board...............................................................................................................24
2.3 Audio Signal Expansion Processing Board ..................................................................................25
2.4 RGB Signal Acquisition Board (Optional)...................................................................................26
2.5 Video Signal Acquisition Board (Optional)..................................................................................28
2.6 Dual-Link Signal Acquisition Board (Optional)...........................................................................29
2.7 HDMI Signal Acquisition Board (Optional) ................................................................................30
2.8 DisplayPort Signal Acquisition Board (Optional)........................................................................31
2.9 SDI Signal Acquisition Board（Optional）................................................................................32
2.10 Optical Signal Acquisition Board (Optional) .............................................................................33
2.11 Optical Signal Output Board (Optional).....................................................................................34
2.12 IP Streaming Signal Acquisition Board（Optional）................................................................35
2.13 Desktop Processing Board (Optional) ........................................................................................36
2.14 Live View Board (Optional).......................................................................................................38

User Manual Digicom3100SP Multi-screen Processor
3. Installation ........................................................................................................................................39
3.2 Installing the Cabinet....................................................................................................................42
3.2.1 Rack Mounting......................................................................................................................42
3.2.2 Cabling Bracket.....................................................................................................................42
3.3 Connecting Display Device..........................................................................................................43
3.4 Connecting Signal Source ............................................................................................................44
3.5 Connecting Network Cable ..........................................................................................................44
3.6 Connecting Power Cord ...............................................................................................................46
3.7 System Grounding........................................................................................................................46
4. VTRON Wall Administration System (VWAS) (Optional) ...........................................................48
5. Maintenance......................................................................................................................................49
5.1 Routine Inspection and Maintenance ...........................................................................................50
5.2 Routine Inspection........................................................................................................................50
5.3 Replacing Hot plug Module .........................................................................................................50
5.3.1 Hot Plug Module...................................................................................................................50
5.3.2 Replacing Boards ..................................................................................................................51
5.4 Troubleshooting............................................................................................................................53
6. Contact ..............................................................................................................................................57

User Manual Digicom3100SP Multi-screen Processor
1
1. Introduction
1.1 About Digicom Ark 3100SP Multi-screen Processor
Digicom Ark 3100SP is a new generation of Multi-screen signal processor developed by VTRON.
It features world leading technology such as fast system response, high safety, good signal
synchronization and perfect real-time display.
System input signal acquisition includes SD signal acquisition, HD signal acquisition, HDMI
signal acquisition, DUAL-LINK ultra-high resolution signal acquisition, DP signal acquisition,
SDI signal acquisition and optical signal acquisition. The processor also supports computer
graphical display signal (also called as desktop signal). After serials of processing (exchanging,
zooming in/out and overlapping) inside the processor, all of the collection signals can be displayed
with real-time on the display wall. It is suitable for control room, command center, operation and
maintenance center, data center, conference room, etc.
Fig. 1-1 Digicom Ark 3100SP
Appearance of SPV3000 Signal Preview Processor
Fig. 1-2-1 SPV3000 Signal Preview Processor

User Manual Digicom3100SP Multi-screen Processor
2
Appearance of SMA3000 Streaming Media Processor
Fig. 1-2-2 SMA3000 Streaming Media Processor
1.2 Functions and Features
1.2.1 DigicomArk 3100SP Multi-screen Processor
Functions and features of DigicomArk 3100SP Multi-screen Processor are as the followings:
Built-in background images
Provide gray scale, color stripe, checkerboard, black, red, green, blue, white, and testing
circles required for system debugging
Provide images with customized background
All-digital non-blocking cross-dispatch
All signals can be cross dispatched in the system without blocking, so that all signals can be
displayed at any position in the corresponding display cube in the system.
Support signal superposition
Each display Cube supports the superposition of one channel of desktop signal and 4 channels
of input signals, achievingAlpha transparency.
Support signal cutting
Support signal cutting and displaying for any part of the cutting signals. For signal acquisition end,
cutting is available for all signal-displaying windows.
Signal input
System HD signal acquisition board supports VESA standard and non-standard analog signal,
DRGB digital signal and HDMI signal input.

User Manual Digicom3100SP Multi-screen Processor
3
SD signal acquisition board supports CVBS and S_VIDEO signal input.
The input HDMI signal can meet HDMI1.3Astandard and HDCP protection protocol.
DP signal acquisition board supports DisplayPort（DP 1.1a）signal input.
SDI signal acquisition board supports SDI signal input.
IP signal acquisition board supports IP signal input.
System supports DVI optical signal input with the resolution of 1920×1080@60Hz (a DVI to
optical-fiber transmitter is required at the signal source end).
System ultra-HD signal acquisition board supports ultra-high resolution signal input with
maximum resolution up to 4K×2K.
The desktop signal processing board supports the desktop signal with adaptive ultra high
resolution.
System supports cascade signal inputs..
All of the input signals can be echoed via network.
Signal output
System supports DVI digital signal (the resolution is up to 1920×1200@60) outputs onto the
screen wall.
System supports DVI optical signal outputs with maximum resolution of 1920×1080@60Hz
(a DVI to optical-fiber receiver is required at the display output end).
Upgrade online
The software and logic can be upgraded online. There is no need to shut down the processor.
System clock synchronization
System main control board supports both inside and outside synchronization.
Signal acquisition board supports both inside and outside synchronization.
Signal processing board supports both inside and outside synchronization.
