VULCAN-HART COmpANy, p.O. BOX 696, LOUISVILLE, Ky 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
A2780 ISO9001 Vulcan-Hart Co.
Item # __________________________
C.S.I. Section 11420
F-32635 (6-07)
MODEL: 2GPC12S GAS PASTA COOKER WITH RINSE SINK
STANDARDFEATURES
Stainless steel front and sides.
16 gauge 316 stainless steel tank with rear water fill, 12
gallon capacity.
Set of Four 6" adjustable casters (2 locking).
Overflow dam with skim port for starch removal and overflow
protection.
1" full port drain valve.
90,000 BTU/hr. input.
Temperature control adjusts from 190 to 212F. Power "ON",
"HEATING" and "HI-LIMIT" indicators.
Hi-limit shut-off.
Electronic pilot ignition system.
1/2" rear gas connection.
Hot and cold water mixing valve with swivel head (mounts on
rinse station only).
Tank cleaning brush.
One year limited parts and labor warranty. Twelve year limited
tank warranty.
ACCESSORIES
Fine mesh stainless steel bulk cook basket.
Twelve section retherm basket with a set of twelve plastic
retherm portion cups. NSF approved.
Set of six individual 51/4" round fine mesh stainless steel cook
and retherm baskets with base screen.
3/4" x 4 ft. flexible gas hose with quick disconnect and restrain-
ing device.
MODEL 2GPC12S
GAS PASTA COOKER WITH RINSE SINK
SPECIFICATIONS:
Gas pasta cooker with rinse sink, Vulcan-Hart Model No.
2GPC12S. 12 gallon capacity cook tank and rinse sink. Hot and
cold water valves at the rear. Stainless steel front and sides. Set
of four 6" adjustable casters (2 locking). 16 gauge 316 stainless
steel tank with rear water fill. Overflow dam with skim port. 1" full
port ball type drain valve. 90,000 BTU/hr. input. Temperature
control adjusts from 190 to 212F. Power "ON", "HEATING" and
"HI-LIMIT" indicators. Hi-limit shut-off. Electronic pilot ignition
system. 1/2" rear gas connection. Hot and cold water mixing valve
with swivel head (mounts on rinse station only). Tank cleaning
brush.
Overall dimensions: 31"w x 343/4"d x 563/4"h. Working height
361/4".
CSA design certified. NSF listed.
SPECIFY TYPE OF GAS WHEN ORDERING.
SPECIFYALTITUDEWHENABOVE 2,500FT.
2GPC12S shown
OPTIONS
Second year extended limited parts and labor warranty.
CERTIFIED

VULCAN-HART COmpANy, p.O. BOX 696, LOUISVILLE, Ky 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.
F-32635 (6-07)
MODEL 2GPC12S
GAS PASTA COOKER WITH RINSE SINK
IMPORTANT
1. A combination valve with pressure regulator is provided with this unit.
Natural Gas 4.0" (102 mm) W.C.
Propane Gas 10.0" (254 mm) W.C.
2. An adequate ventilation system is required for Commercial Cooking
Equipment. Information may be obtained by writing to the National
Fire Protection Association, Batterymarch Park, Quincy, MA 02269.
When writing refer to NFPA No. 96.
3. All models require a 6" (152 mm) clearance at both sides and rear
adjacent to combustible construction.
4. All models require a 6" (152 mm) minimum clearance to adjacent
open top burner units.
5. This appliance is manufactured for commercial installation only and
is not intended for home use.
OVERALL WORKING TANK TANK APPROX.
MODEL WIDTH DEPTH HEIGHT HEIGHT SIZE BTU/HR. CAPACITY SHP.WT.
Pasta Cooker 15
1
/ 2 " 34
3
/ 4 " 46
1
/ 4 " 36
1
/ 4 " 14" x 18
1
/ 4 " 90,000 12 gallons 250 lbs.
Rinse Sink 15
1
/ 2 " 34
3
/ 4 " 56
3
/ 4 " 36
1
/ 4 " 14" x 18
1
/ 4 "  12 gallons 190 lbs.
SERVICE CONNECTIONS:
P1 1/2" NPT pipe gas connection, 14" above floor.
P2 3/4" garden hose water connection, 16" above floor.
P3 11/4" NPT drain connection, 33/8" above floor.
E1 Electrical connection, 120/60/1, 121/2" above floor.
