VULU STROLLER
Instruction Manual
VULU 01
PLEASE KEEP INSTRUCTIONS FOR FUTURE REFERENCE

POSITIONS

FOLLOW THE MANUFACTURER’S INSTRUCTIONS.
PUT ON ALL THE BRAKES WHENEVER YOU PARK THE STROLLER.
ALWAYS APPLY THE BRAKES WHENEVER THE STROLLER IS STATIONARY.
DO NOT LEAVE CHILDREN UNATTENDED.
SECURE THE CHILD IN THE HARNESS AT ALLTIMES.
DO NOT CARRY EXTRA CHILDREN OR BAGS ON THIS STROLLER.
DO NOT USE THIS SEAT WITH ANY OTHER MODELS OF STROLLER.
DO NOT USE THIS BASSINET ONCE THE CHILD CAN SIT UP UNAIDED.
USE THE SEAT IN THE UPRIGHT ONCE THIS OCCURS.
ALWAYS LOAD THE HEAVIER CHILD IN THE FRONT SEAT THEN PLACE THE
LIGHTER CHILD IN THE REAR SEAT. ALWAYS UNLOAD THE REAR CHILD FIRST.
MAKE SURE CHILDREN ARE CLEAR OFANY MOVING PARTS IF YOUADJUST THE
STROLLER, OTHERWISE THEY MAY BE INJURED.
USE THE HARNESS AT ALL TIMES.
WHEN NOT IN USE DISCONNECT SHOULDER STRAPS FROM THE WAIST STRAP
AND/OR BUCKLE.
THE HARNESS CAN FORM LOOPS WHICH MAY BE A STRANGULATION HAZARD.
NEVER LEAVE A HARNESS CONNECTED WHEN NOT FITTED TO A CHILD IN THE
STROLLER.
TO AVOID SERIOUS INJURY ALWAYS USE THE HARNESS PROVIDED TO SECURE THE
CHILD. (ADJUST THE STRAPS TO SUIT THE SIZE OF YOUR CHILDS BODY)
IT IS UNSAFE TO USE ACCESSORIES OTHER THAN THOSE SUPPLIED BY LOVE N CARE.
CARE SHOULD BE TAKEN IF THE STROLLER IS TO BE USED ON STAIRS OR ESCALATORS.
THIS STROLLER SHOULD NOT BE USED NEAR AN OPEN FIRE OR AN EXPOSED FLAME.
CARE SHOULD BE TAKEN WHILST FOLDING AND UNFOLDING THE STROLLER TO
PREVENT FINGERS BEING TRAPPED.
ENSURE YOUR CHILDS FINGERS, HANDS AND ALL OTHER BODY PARTS ARE CLEAR
FROM ANY MOVING PARTS WHEN ADJUSTING THE SEAT OR HANDLE ON YOUR
STROLLER.
WHEN USED IN THE UPPER POSITION MAX WEIGHT OF SEAT: 15KG
WHEN USED IN LOWER POSITION MAX WEIGHT OF SEAT : 9KG
MAXIMUM WEIGHT FOR BASKET: 3KGS
MAXIMUM WEIGHT FOR THE CUP HOLDER: 1KG
MAXIMUM WEIGHT CAPACITY IS: 28KG
WARNING
SAFETY GUIDELINES AND INSTRUCTIONS MUST ALWAYS BE FOLLOWED BEFORE
MAKING USE OF THIS PRODUCT. PLEASE RETAIN THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
THIS PRODUCT COMPLIES WITH PRODUCT SAFETY STANDARD AS/NZS 2088:2009
*PICTURES USED IN THIS MANUAL ARE FOR ILLUSTRATIVE PURPOSES ONLY. THE ACTUAL STROLLER MAY
VARY IN DISPLAY.

1. 2. 3.
4. 5.
6. 7.
8.
PARTS LIST:
MAKE SURE YOU HAVE THE FOLLOWING
1. 2X REAR WHEELS
2. 2X FRONT WHEELS
3. 2X REAR MUDGUARD
4. 2X REAR SEAT ADAPTER (SOLD SEPARATELY)
5. HANDLE BAR (MAIN SEAT)
6. CANOPY (MAIN SEAT)
7. CANOPY SECOND SEAT (SOLD SEPARATELY)
8. PRIMARY SEAT UNIT (LARGE)
9. SECOND SEAT UNIT (SMALL)(SOLD SEPARATELY)
10. HANDLE BAR (SECOND SEAT)(SOLD SEPARATELY)
11. MAIN FRAME
12. TETHER STRAP
WHATS INSIDE
9.
10.
11.
12.

HOW TO ASSEMBLE
UNFOLD THE FRAME
Unclip the latch from the
frame. Pull the frame away from the
handle.
When pulling the stroller away
from the handle make sure you
keep you ngers away from the
joints.
Pull the handle upwards. You should hear
the handle bar locking into place
the sould of a click.

ATTACHING THE FRONT WHEELS
Slide front wheel (2) into the front axel
hole. he wheel should click into place.
Repeat on both sides.
To remove the front wheel: Press the button
on the top of the front axel to release the front
wheel.
To use the stroller in swivel
mode the front lock on the
axel should be upwards.
To lock the front wheels,
press downwards on the
front axel switch.
HOW TO ASSEMBLE

ATTACHING THE REAR WHEELS
Slide the mudguard (3) onto the rail on the
rear axel.
Slide the Mudguard until it clips into position.
You will hear it click.
To remove the mudguard just slide it the
opposite direction.
Place the wheel into the hole located on the
rear axel. Push the wheel inside until it is locked
inside. Pull on it slightly to ensure that it is not
loose.
To remove the wheel press on the middle
release button and pull the wheel out
HOW TO ASSEMBLE

ATTACHING THE SECOND SEAT UNIT TO THE FRAME
(SOLD SEPARATELY)
ATTACHING THE ADAPTERS FOR THE SECOND SEAT
(SOLD SEPARATELY)
To remove the seat from the frame press
the release buttons located on each side
of the seat unit (8) then lift.
Place the seat unit (8) over the openings
on the frame. It should click into place.
Slide the rear seat adapters (5) in the
slots located next to the rear wheels.
once they are locked in you will hear
a click.
To remove the adapters press the
button located on the frame then lift
the adapter out.
Place the seat unit (8) over the openings
on the frame. It should click into place.
HOW TO ASSEMBLE

ATTACHING THE BASKET
To assemble the basket place the
3 velcro straps through the 3
openings located on the front
footrest.
Once they are through the openings
attach them to the velcro slots on the
bottom of the seat unit.
Then you can strap the middle velcro
strap on the assist tube.
Then you can attach the rear velcro
strap around the rear axel.
MAXIMUM WEIGHT LIMIT IS 3KG
HOW TO ASSEMBLE

ATTACHING THE HOOD AND BUMPER BAR
Insert the ends of the Canopy (7)
into the slots located on the
sides of the seat unit (8)
Match the zipper ends together
and then pull it upwards.
The assembled canopy should look
like this.
To use the canopy pull it
forwards.
To close the canopy push it
inwards.
To Attach the bumper bar (6) slide it into the
slots located on each side of the seat units (8)
To remove the bumper bar (6) press the buttons on
the front of the bar then lift it out of the slots.
HOW TO ASSEMBLE

CONVERTING THE SEAT UNIT TO A BASSINET
Press the button located on the top
of the stroller seat. Recline the seat
unit until it lays at.
Unclip the straps located on the
bottom of the seat unit.
Strap the velcro around the bar
on the side of the seat unit.
Curl the material on the base
of the stroller around the bar
on the bottom and zip the
stroller.
The Assembled bassinet should look
like this.
HOW TO ASSEMBLE

ADJUSTING THE POSITION
To adjust the angle of the seat press the
button located at the top of the seat unit
and push the seat in the direction you need.
The back rest can adjust to three sections.
ADJUSTING THE BACKREST
To adjust the backrest, lift the backrest
adjustment key.
Then Pull the belt to the desired
position.
HOW TO ASSEMBLE

ADJUSTING THE HANDLE
To adjust the handle press the middle
handle button and pull to the desired
position
USING THE BRAKES
To Apply the brakes push the red brake lever
downwards.
To remove the brakes kick the red brake lever
upwards.
WARNING: TO AVOID INJURY OR DEATH:
ALWAYS APPLY THE BRAKES WHENEVER
THE STROLLER IS STATIONARY.
HOW TO ASSEMBLE

FOLD THE FRAME
Remove all seats and children before you
commence unfolding. Press the release button on
the side of the stroller (1) and (2) then push the
button the handle (3) and push the handle
inwards (4).
Once the handle has been loosened
push the handle downwards.
Push the handle all the way down. Attach the latch to keep the
stroller locked.
HOW TO ASSEMBLE
Then push the front wheels to
the back.
1.
2.
3.
4.

USE THIS HARNESS AT ALL TIMES
WARNING
HOW TO USE THE 5-POINT HARNESS:
THIS STROLLER HAS BEEN DESIGNED WITH
A 5-POINT HARNESS FOR THE SAFETY OF
YOUR CHILD.
CAREFULLY PLACE YOUR CHILD INTO THE
SEAT AND BRING THE WAIST STRAPS
AROUND THE CHILDS WAIST AND OVER
THE CHILDS SHOULDERS.
PLACE THE CROTCH STRAP BETWEEN YOUR
CHILDS LEGS.
TIGHTEN THE HARNESS TO BE SNUG AROUND
THE CHILDS WAIST AND OVER ITS SHOULDERS.
FIG.1
ATTACH EACH OF THE SHOULDER STRAPS TO
THE WAIST STRAP BUCKLE WITH EACH END.
FIG.2 REPEAT THIS FOR BOTH SHOULDER
STRAPS.
ONCE EACH SHOULDER STRAP IS ATTACHED ON
THE WAIST BUCKLE INSERT THE WAIST STRAP
END TO THE CROTCH STRAP BUCKLE. FIG 3.
REPEAT FOR BOTH SIDES.
THEY SHOULD SNAP IN. (PULL ON THEM TO TEST)
TO RELEASE THE HARNESS SQUEEZE THE CENTRE
OF THE BUCKLES FOR BOTH WAIST STRAP ENDS.
FIG. 4
YOUR CHILD SHOULD BE SECURELY HARNESSED AT
ALL TIMES AND SHOULD NEVER BE LEFT UNATTENDED
FIG. 1 FIG. 2
FIG. 3 FIG. 4
HOW TO ASSEMBLE
SHOULDER STRAPS
WAIST STRAPS
WAIST STRAPS
CROTCH STRAP
ASSEMBLED HARNESS

WARRANTY AGAINST DEFECTS
ALL LOVE N CARE/VULU PRODUCTS ARE GUARANTEED FOR TWELVE MONTHS FROM THE
DATE OF PURCHASE.
OUR GOODS COME WITH GUARANTEES THAT CANNOT BE EXCLUDED UNDER THE
AUSTRALIAN CONSUMER LAW. YOU ARE ENTITLED TO A REPLACEMENT OR REFUND FOR
A MAJOR FAILURE AND FOR COMPENSATION FOR ANY OTHER REASONABLY FORSEEABLE
LOSS OR DAMAGE. YOU ARE ALSO ENTITLED TO HAVE THE GOODS REPAIRED OR REPLACED
IF THE GOODS FAIL TO BE OF ACCEPTABLE QUALITY AND THE FAILURE DOES NOT AMOUNT
TO A MAJOR FAILURE.
THIS COVERS AGAINST FAULTS WHICH DEVELOP THROUGH FAULTY MATERIALS AND
WORKMANSHIP. MISUSE, ACCIDENTAL DAMAGES, NORMAL WEAR AND TEAR OR NEGLECT
ARE NOT COVERED.
IF A FAULT BECOMES APPARENT, PLEASE RETURN THE ITEM TO THE STORE OF PURCHASE
WITH YOUR RECEIPT. YOU MUST INFORM THE STORE WHAT THE DEFECT IS. WE WILL THEN
ARRANGE FOR ITS REPAIR OR IT WILL BE ASSESSED FOR REPLACEMENT AS EXPEDIENTLY
AS POSSIBLE. THE BENEFITS OF THIS WARRANTY ARE IN ADDITION TO OTHER RIGHTS AND
REMEDIES UNDER THE LAW IN RELATION TO THE GOODS ABD SERVICES TO WHICH THIS
WARRANTY RELATES.
IF YOU ARE UNABLE TO RETURN THE ITEM TO THE STORE OF PURCHASE, YOU CAN
CONTACT LOVE N CARE ON FREECALL 1300732599. WE WILL THEN ORGANISE FOR EITHER
SOMEBODY TO INSPECT THE ITEM OR ARRANGE FOR A COURIER TO PICK IT UP AND
RETURN IT BACK TO YOU.
FOR MORE INFORMATION PLEASE CONTACT:
LOVE N CARE PTY LTD
EMAIL: [e-mail]
WEB: www.lovencare.com.au
PHONE: [phone]
FAX: [phone]

CLEANING AND MAINTENANCE
ALL LOVE N CARE PRODUCTS HAVE ONE YEAR WARRANTY FROM THE DATE OF PURCHASE.
IT IS RECOMMENDED TO REGULARLY INSPECT AND MAINTAIN MOVEMENT OF LOCKING DEVICES AND SECURITY
OF ESSENTIAL COMPONENTS.
REGULARLY CHECK ALL PARTS FOR WEAR AND TEAR. LUBRICATE IF TIGHT.
DO NOT USE SPRAY LUBRICANTS, SIMPLY WIPE CLEAN AFTER USE.
THE SEAT LINER CAN BE CLEANED BY SPONGING WITH WARM SOAPY WATER AND A MILD DETERGENT. A MILD
DISINFECTANT MAY BE USED IF DESIRED.
STUBBORN MARKS MAY BE REMOVED WITH A NON ABRASICE CREAM CLEANER.
NEVER CLEAN WITH ABRASIVE, AMMONIA BASED, BLEACH BASED OR SPIRIT TYPE CLEANERS.
IF THE WHEELS BECOME DAMAGED OR WORN DISCONTINUE USE AND REPLACE.
FABRIC CARE
- HAND WASH ONLY
- DO NOT BLEACH
- DO NOT TUMBLE DRY
- DO NOT IRON
- DO NOT WRING
- DO NOT DRY CLEAN
