Itona TC1430
The new, highly compact Itona TC 1430 desktop is a major breakthrough
in the provision of low cost, virtualisation-capable, thin client computing.
Measuring only 19cm (7.5” ) high, this entry level desktop offers an
affordable solution combined with advanced features and specication
well beyond its rivals. For example, the TC1430 incorporates the VMware
View client as standard making it “virtualisation ready”.
Built to VXL’s exacting specications, the fan-less design ensures the
TC1430 is extremely reliable and together with the energy efcient
power supply, achieves a very low average power consumption.
Backed by VXL’s comprehensive worldwide support network and an
impressive three year warranty, the new Itona represents an unbeatable
combination of affordability, performance, quality and service.
VMware Virtualisation ready•
Sylph-OS operating system•
AMD• ®Geode LX600, 366MHz
processor
Very small footprint - 19cm•
high x 14.2cm deep
Highly reliable fanless design•
- very low power consumption
256Mb RAM & 128Mb Flash•
Memory
4 USB ports•
In-built 10/100/1000•
Networking
32 Bit graphics•
Fully featured
About VXL
VXL is one of the world’s largest
suppliers of thin clients. Established
in 1976, VXL has grown steadily
and now has over three hundred
people worldwide – with ofces in
Germany, France, India, the United
States and the United Kingdom.
The company’s headquarters are in
Bangalore, India.
Itona TC1430 Entry-Level Desktop Thin Client
Networking ideas thin solutions
Green Credentials
With very low average power consump-
tion of 6 watts, the Energy Star 5.0 rated
Itona is far more efcient than a PC. It is
also substantially lower than the majority
of its competitors.
Remote management included
Every Itona comes with the powerful
XLmanage remote management soft-
ware, Workgroup Edition, making central
management a breeze.

Model
TC1430 Sylph-OS operating
system, Citrix ICA Client,
Citrix PN Agent, VMware
View Client and RDP Client.
Processor
AMD Geode LX600 366MHz•
Processor
System Memory
Ram: 256Mb•
Flash: 128Mb•
Display Support
Display Data Control (DDC)•
for automatic setting of
resolution and refresh rate
Video RAM: 8/16/32/64 MB.•
Selectable from BIOS (default
16MB). Display res. 4:3 up
to 1600 x 1200 32bit colour.
Widescreen up to 1680 x
1050 32bit colour.
Interfaces
4 x USB 2.0•
One VGA type video output•
Built-in Kensington Security•
Slot
Networking
Autosensing, 10/100/1000•
Ethernet, RJ-45
Wake On Lan•
PXE boot •
Audio
Line Out•
Mic•
Environmental
Temperature Range :•
Powered on: 5 to 35 ˚C
Powered off: –20 to 60 ˚C
Convectional cooling, fanless•
design
Humidity : 20% to 80%•
maximum, non-condensing
Physical Characteristics
External power adapter with•
full range
autosensing AC adapter•
(100/240 V) for worldwide
usage
Height: 190 mm•
Depth: 142 mm•
Width: 36.5 mm•
Weight: Approx 0.7Kg•
Software
VMware View Client•
Citrix ICA client for Linux•
10.xx
RDP 6x compatible client•
Ericom Blaze RDP Client•
Local Operating System
Features
Updated kernel version 2.6.x•
Password-protected support•
Server OS Compatibility/
Support :
Microsoft Windows Terminal•
Server Edition,Windows 2003
/2008
Citrix XenApp / Citrix•
Presentation Server/ Citrix
XenDesktop
Protocol Support :TCP/IP, NTP, •
DHCP, FTP, HTTP
Management:
Remote management,•
conguration, and upgrades
through XLmanage client
management software
(included)
Wake terminal remotely•
(Wake-on-LAN)
Terminal conguration (IP •
information, name, etc.)
Send messages•
Remote Shadowing•
Complete image upgrade•
Pull/Push Updates •
Regulatory Compliance
Europe: CE, TUV-GS•
US/Canada: cULus, FCC B•
Environmental: CE, RoHS,•
WEEE, Energy Star 5.0
Warranty
Three years limited warranty•
E & OE: Specications subject to change without notice. All trademarks are acknowledged and remain the property of their respective owners.
Head Ofce: ‘House of Excellence’, No 17 Electronics City, Hosur Road, Bangalore 560 100, India
Tel: [phone] (5 lines) Fax: [phone] E-mail: [email protected] Web: www.vxl.net
European Headquarters: Carrington Business Park, Carrington, Manchester, UK M31 4DD
Tel: [phone] Fax: [phone] E-mail: [email protected]
Regional Ofces France Germany United States
Tel: [phone] Tel: [phone] Tel: [phone]
E-mail: [email protected] E-mail: [email protected] E-mail: [email protected]
Itona TC1430
Networking ideas thin solutions
Part No
TC1430 - F3R4 128 MB Flash / 256 MB RAM
