W Box Technologies 0E-32LEDMON2 User manual
1
Contents
Contents ................................................................................................................................
1
Safety.....................................................................................................................................
1
Cautions................................................................................................................................
3
FCC RF Interference Statement .................................................................................. 4
Connections...........................................................................................................................
5
Controls & Menu Operation......................................................................................... 6
Mounting Guide ............................................................................................................ 12
Accessories...........................................................................................................................
13
Power Indicator / Modes of Operation........................................................................ 13
Dimensions ...........................................................................................................................
14
Specifications............................................................................................................
15
Limited Warranty.......................................................................................................
16
Safety
1. Read these instructions completely and comply with all requirements.
2. Retain these instructions for reference.
3. Comply with all instructions and warnings, both in this manual and on the product.
4. Disconnect the monitor from all power before cleaning. Use a damp cloth for
cleaning; and do not use liquid or aerosol cleaners.
5. Never use the monitor in damp areas or near water.
6. Never place the monitor on an unstable surface; if the monitor falls it may cause
serious damage to people or property.
7. When selecting a location for placement/installation please ensure:
A. To allow for sufficient ventilation leave a minimum distance of 4” around the monitor.
B. Never allow anything (e.g. paper, cloth, etc.) to obstruct the monitor ventilation
openings.
C. Never allow an open flame source (e.g. lighted candles) near the monitor.
2
D. If batteries are used, please dispose of all batteries as per local regulations.
E. Use the monitor in indoor environments as per the temperature and humidity specs.
8. The monitor should be operated from a power source indicated on the rear of the monitor.
9. The 3 wire grounding type plug [having a third (grounding) pin] used on this monitor is a
safety feature. Do not power the monitor without a grounding-type plug.
10. Do not place the monitor where people will walk on the cord or allow anything to rest on
or rub against the power cord.
11. If an extension cord is used to power the monitor, make surethat the total ampere
usage of all the products plugged into the extension cord does not exceed the ampere
rating of the extension cord nor the power rating of the outlet.
12. To avoid the risk of fire or an electric shock resulting from contact with dangerous
voltage points or damage to parts, never insert objects of any kind into the monitor
cabinet slots. Never spill any kind of liquid on the monitor.
13. Do not attempt to service this monitor yourself, as opening or removing the cover may
expose you to dangerous voltage points or other risks.
14. If any of the following occur, disconnect the power to the monitor and refer
servicing to qualified service personnel:
A. The power cord or plug is damaged or frayed.
B. If liquid has been spilled into the monitor.
C. If the monitor has been exposed to rain, water or other liquids.
D.If the monitor does not operate as expected as per the operating instructions.
Adjust only those controls as described in the operating instructions; improper
adjustment of other controls may cause the monitor to become inoperative and
may void the warranty.
E. If the monitor has been dropped or the cabinet has been damaged.
F. If the monitor exhibits a distinct change in performance, indicating a need for service.
Please note:
The power supply cord is used as the main disconnect device. Ensure that the power
outlet is located/installed near the monitor and is easily accessible.
3
Cautions
Only specially qualified personnel should open the case. No user serviceable parts inside.
To prevent electrical shock or a fire hazard, do not expose the monitor to rain or
moisture. This monitor is designed to be used in a residential or commercial
environment. Do not subject the monitor to excessive vibration or dust, or to corrosive
gases.
Ventilation slots are provided on the cabinet to control the internal temperature of the
monitor. Do not cover these ventilation holes or place anything on the unit which
might block those slots.
Avoid placing the monitor in direct sunshine or near a heating appliance.
Do not use the monitor against a bright background or where sunlight and other light
sources will shine directly on the monitor.
Neither the monitor itself nor any other heavy object should rest on the power cord.
Damage to a power cord can cause fire or electrical shock.
POWER SUPPLY CORD IS USED AS MAIN POWER
DISCONNECT DEVICE IN THIS PRODUCT. UNPLUG THIS
PRODUCT FROM THE WALL OUTLET BEFORE REMOVING
THE BACK COVER AND SERVICING.
CAUTION TO SERVICE PERSONNEL
1. Never open the monitor case
2. Do not use in environments that may cause hazards.
3. Keep in a well-ventilated location.
4. Avoid excessive heat.
5. To eliminate eye fatigue.
6. Be careful of heavy objects.
4
FCC RF Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment causes harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures.
oReorient or relocate the receiving antenna.
oIncrease the space between the equipment and receiver.
oConnect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
oOnly a shielded interface cable should be used.
Finally, any changes or modifications to the equipment by the user not expressly approved
by the grantee or manufacturer could void the user's authority to operate such equipment.
DOC Compliance Notice
This digital apparatus does not exceed the Class A limit for radio noise emissions from
digital apparatus set out in the radio interference regulation of Canadian Department of
Communications.
CE Compliance
This monitor complies with the basic protection requirements of the
Electromagnetic Compatibility (EMC) Directive 2004/108/EC for electrical
and electronic equipment imported into the European Union (EU):
The electromagnetic disturbance generated by the apparatus does not exceed the
level specified in the harmonized EMC Standards for this type of apparatus. It has a
level of immunity to the electromagnetic disturbance to be expected in its intended
use, and should operate without unacceptable degradation of its specified
performance.
Connections
Back View of Monitor
Connector panel is located on
the underside of the case rear
projection, just above the
stand.
Detailed View of the Connector
Panel
Only use a properly,
grounded, three wire cord
appropriate for the local
power system.
Remote control
The remote control offers various shortcuts and
added convenience
5
Controls & Menu Operation
Control Keys / Buttons
Buttons are located on the right side of the
Bezel on 0E-32LEDMON2 model.
Source Auto detection function
when there is/are source(s) connect to the
monitor, monitor will auto detect the source(s) and
auto select the desired source. The source should
be selected manually when there is more than
one source connected to the monitor.
A. “SOURCE” button
To change the input selection, press
SOURCE to display the pop-up menu,
use up/down to highlight the desired
source, then press left/right to
complete the selection.
To verify the current input selection,
press SOURCE to display the pop-up,
then press MENU again to dismiss the
pop-up.
●Press the button to display
all the signal channel menus.
When Main MENU display as
confirmation key during the
OSD operation
B. “MENU” button
●Press the button to show the OSD
main menu.
●Press the button to exit OSD
menu.
C. “LEFT” button
●Press LEFT button, volume
decrease
Press the LEFT button to scroll
the cursor to desired function.
6
MOVE SEL
16:9/4:3 POWER
D. “RIGHT” button
●Press RIGHT button,
volume increase
E. “DOWN” button
●Press the button to scroll the
cursor to desired function.
Press the DOWN to decrease
the value of selected function in
sub OSD menu.
F. “UP” button
●Press the button to scroll the
cursor to desired function.
●Press the button to increase
the value of selected function in
sub OSD menu.
G. “POWER” button
●Press the button to turn ON or
turn OFF the monitor.
Volume
Press buttons to adjust volume on monitor.
Press buttons to adjust volume on remote controller.
Press
One-Touch Button 4:3/16:9 Scale Toggle
▼button to adjust the aspect ratio of the picture 4:3/16:9 scale toggle.
7
8
Picture Menu
The “PICTURE” menu is for adjusting the image appearance and parameters. The Picture
menu is the same for BNC/CVBS and HDMI; the Picture menu options differ for VGA.
Picture Menu (BNC/CVBS & HDMI)
Press the MENU button to bring the menu on
screen, and then the right/left buttons to move
up along the main menu selections to choose the
PICTURE menu. Press up/down to move
between the left side main menu selector into the
window of menu choices and parameters.
Use the left & right buttons to move the yellow
highlight
sub-menu selection
within
the sub-
menu. Pressing the right & left buttons will
adjust the value of the highlighted item. Press
the MENU button to exit the sub-menu and
return to the main menu selector.
To exit the menu system, press the MENU. Settings will remain as they appear on screen.
Adjustments
Picture mode:Choose for User/Dynamic/Standard /Mild for most pleasing image
based on ambient light.
Contrast: Adjusts the range of difference between light and dark areas of the picture.
Brightness: Adjusts the overall picture intensity
Color: Adjust the color saturation 0-100.
Tint: Increase or decrease the intensity of colors in the image.
Sharpness: Change the balance between image detail (Resolution) and degree of
transition between areas of differing brightness.
Aspect Ratio: Choose between SD 4:3 and HD 16:9 aspect ratio. If analog images
appear
stretched use 4:3 scaling.
Picture ModeStandard 50
70
50
50
50
16:9
Contrast
Brightness
Color
Tint
Sharpness
Aspect Ratio
Select Move MENU TO Exit
<
<
<
<
9
Adjustments
Noise Reduction: Reduce noise of the display
image (LOW/MID/HIGH/OFF)
Color Temp: Adjust color reproduction: choose
between Normal/Warm/User/Cool.
To set custom color temperature (R.G.B values),
select “USER” to set color temperature.
Keep pushing ‘DOWN” button on the monitor or
the remote controller, then you will see
Red, Green and Blue option.
Audio Menu
Press the MENU button to bring the menu on
screen, and then left/right buttons to move
along the menu selections to highlight the
AUDIO menu. Press up/down to move
between the left side main menu selector into
the window of menu choices and parameters.
Use the left & right buttons to move the yellow highlighted sub-menu selection within the
sub-menu. Pressing the right & left buttons will adjust the value of the highlighted item.
Press the MENU button to exit the sub-menu and return to the main menu selector.
To exit the menu system, press the MENU.
Adjustments
SoundMode: Select one of the presets (User, Sport, Movie, Music, Standard)
Treble: Boost/limit high frequency tones (0-100)
Bass: Boost/limit low frequency tones (0-100)
Balance: Change relative volume between left and right speakers).
Noise ReductionMID
50
50
Color Temperature
Red
Green
Blue
Select Move Exit
<
<
<
<
Normal
MENU TO
50
Sound ModeStandard 50
50
Treble
Bass
Balance
Select Move Exit
<
<
MENU TO
0
10
OSD Menu
Press the MENU button to bring the menu on
screen, and then left/right buttons to move along
the menu selections to highlight the OSD menu.
Press up/down to move the left side main menu
selector into the window of menu choices and
parameters.
Use the left & right buttons to move the yellow
highlighted sub-menu selection within the
sub-menu. Pressing the left & right buttons
will adjust the value of the highlighted item.
Press the MENU button to exit the sub-menu
and return to the main menu selector.
To exit the menu system, press MENU.
OSD Language: Choose OSD displaylanguage from
Restore User Default: Reset the monitor settings to the factory default
No Signal Screen: Show the color when there is “No Signal” (Blue/Black)
No Signal Standby: Show the color when there is “No Signal” (On/Off)
PreventBurn-in: Set periodic image retention (On/Off)
Black
English
Off
On
Select Move Exit
<
<
<
<
<
<
<
<
<
OSD Language
Restore Factory Default
No Signal Screen
No Signal Standby
Prevent Burn-in
MENU TO
English/French/Spanish
Italian / Netherlands/ Polish/Czech/Danish
11
Computer Menu (VGA model Only)
Press the MENU button to bring the menu
on screen, and then left/right buttons to move
along the menu selections to highlight the
GEOMETRY menu. Press up/down to move
between the left side main menu selector into
the window of menu choices and parameters.
Use the left & right buttons to move the
yellow highlighted sub-menu selection within
the sub- menu. Pressing the left & right
buttons will adjust the value of the highlighted item.
Press the MENU button to exit the sub-menu
and return to the main menu selector.
To exit the menu system, press the SOURCE button
twice.
Adjustments
Auto Adjust: Press Vol Right button to automatically adjust settings to match input
signal parameters
H- Position: OSD horizontal position on the screen
V-Position: OSD vertical position on screen
Clock: Relative adjustment of horizontal scan rate
Phase: Reduce video distortion and instability components
Auto Adjust
H-Position
V-Position
Clock
Phase
Select Move Exit
<
MENU TO
50
50
50
65
12
CAUTION The wall mount must bear a minimum of five
times the monitor’s net weight. To mount your MONITOR
to the wall or another surface, you need to purchase a
VESA wall mount. Use four HMФ6.0x10mm screws (the base
attachment screws removed in step 1 below are HMФ6.0x
10mm) to attach the mount. The monitor mount VESA
hole pattern is ( 0E-32LEDMON2 (200mm x 200mm))
Mountin
g
Guide
Wall or Other Mounting with VESA Standard
Note: Metric (HMФ6.0x10mm) is the type screw that should be used (do not use longer
screws or the monitor may be damaged).
1. Before mounting the monitor, remove the base riser (vertical portion of the base) by
removing the four screws near the top with a screwdriver. Then the base and the
riser can be removed. In order to prevent losing these screws, we suggest replacing
the screws in their original holes.
2. Attach the VESA mount (0E-32LEDMON2 (200mm x 200mm)) plate to the rear of the
monitor and follow all of the instructions provided with the mount to complete the
mounting process.
13
Accessories
Power Cable HDMI Cable VGA Cable Audio Cable
Power Indicator / Modes of Operation
LED Indicator
LED is off when power is off, LED glows blue when power is on, LED glows red when
monitor is sleep/standby model. The power management feature of the monitor is
designed for security surveillance applications. When there is no video, the monitor
remains ON to be instantly ready to display video when the source is changed or if a PC
changes state from sleep/standby to active mode. A floating “No Signal” box moves
slowly across the screen until video is restored.
IR Remote
Qty: 1Qty: 1Qty: 1Qty: 1Qty: 1
Qty: 2 Qty: 2 Qty: 2
Stand Supports User Manuals
Base of Stands
Qty: 2
Screws Type: HMФ6.0x10mm Qty: 4 Screws Type: HMФ6.0×10mm Qty: 4Screws Type: KMФ4.0×10mm Qty: 6
Screws for Mounting Monitor Screws for Securing Base of Stand Screws for Installing Monitor Stand
Batteries
0E-32LEDMON2
TechSupport
#833-574-9124(Option2)
FULL HD PRO-GRADE
LED COLOR MONITOR
Qty: 1
Allen Wrench
14
Dimensions
Model 0E-32LEDMON2
Letter Dimension mm inch
A Width of monitor body 737 29
B Height of monitor body 441.9 17.4
C Depth of monitor body 54.4 2.1
D Height of monitor on base 515.9 20.3
E Width of base 434 17
F Depth of base 159.8 6.3
G Width of viewable area 700 27.5
H Height of viewable area 394.5 15.5
I Thickness of monitor 18.4 0.72
J Bottom bezel width 26.3 1
K Side bezel width 18.5 0.72
A
BH
G
D
E
F
C
I
J
K
Specifications
Model 0E-32LEDMON2
Screen Diagonal Dimension (inches) 31.5
Viewable Area W x H (inches) 27.5*15.47
Led Type LED
Pixel Pitch (mm) 0.36x0.36
Screen Maximum Resolution 1920 x 1080
Display Resolutions 720x400;640x480;800x600;1024x768;1280x1024;1920x1080
720x400;640x480;800x600;1024x768;1280x1024;1920x1080
Supported Input Resolutions
Refresh Rate (Hz) 60
Color Depth (M) 16.7
Brightness (cd/㎡)300
Auto Adjust Yes
Monitor Aspect Ratio 16:9
Display Aspect Ratio OSD selectable 16:9 or 4:3
Horizontal TV Lines 1080
Contrast Ratio 3000:1SCR
Response Time (ms) 5(GTG)
View Angle H/V (degrees) 178° x 178°/CR＞10
Digital Video Inputs HDMI up to1920 x 1080
Analog Video In/Out VGA up to 1920 x 1080, BNC CVBS looping
Audio Inputs (stereo) 1x3.5mm mini-jack
Speakers (W) 2 x 5
Stand-by (W) ＜0.5
Power Consumption 50W Typical
Monitor Body Dimensions (inches) 29 *17.4 *2.1
Dimension Monitor + Stand (inches) 29 *20.3 *6.3
Panel Surface Matte black
Case & Stand Material Metal + Aluminum (removable stand)
VESA Mounting Pattern (mm) 200 x 200
Base/Stand included Yes
Base/Tilt Angle -5°~15
Weight Cabinet Only (Ib.) 21.1
Weight Cabinet + Base Stand (Ib.) 22.9
Power Supply (internal) AC 100-240V~50/60Hz 1.1A
Operating Temperature 0°C~40°C / 32℉~104℉
-20°C~50°C / -4℉~122℉
Storage Temperature
Operating Humidity 10~90%
Accessories
Rack Mount Screw Size (mm)
Certifications
CE/FCC/ROHS/HDMI/UL/WEEE/REACH
Warranty 30 Months
15
Screws for Mounting Monitor, Screws Type: HMФ6.0x10mm/4pcs
Screws for Securing Base of Stand, Screws Type: KMФ4.0x10mm/6pcs
Screws for Installing Monitor Stand, Screws Type: HMФ6.0x10mm/4pcs
Power cable/HDMI cable/VGA cable/Audio cable/IR Remote/Batteries
Allen wrench/Screws/Base of stand/Stand support/User manuals
16
Limited Warranty
1. Limited Warranty
A. General
Subject to the terms and conditions of this Limited Warranty, from the date of sale
through the period of time for product categories specified in Section 1(b), ADI warrants
its W Box Technologies products to be free from defects in materials and workmanship
under normal use and service, normal wear and tear excepted. Except as required by
law, this Limited Warranty is only made to Buyer and may not be transferred to any third
party.
ADI shall have no obligation under this Limited Warranty or otherwise if:
(I) The product is improperly installed, applied or maintained;
(II) The product is installed outside of stated operating parameters, altered, or
improperly services or repaired;
(III) Damage is caused by outside natural occurrences, such as lightning, power
surges, fire, floods, acts of nature, or the like.
(IV) Defects resulting from unauthorized modification, misuse, vandalism, or other
causes unrelated to defective materials or workmanship, or failures related to
batteries of any type used in connection with the products sold here under.
ADI only warrants those products branded as W Box Technologies products and sold by
ADI. Any other products branded by third parties are warranted by the third party
manufacturer for a period as defined by the third party manufacturer, and ADI assigns to
Buyer those warranties and only those warranties extended by such third party
manufacturers or vendors for non-ADI branded products. ADI does not itself warrant any
non-ADI branded product and sells only on an as is basis in accordance with ADI’s
terms and conditions of sale.
17
B. Specific Warranties for Product Categories
Product Categories Warranty
CCTV Power Supplies 24 months
Monitors
30 months
Video Baluns
30 months
Analog Cameras
36 months
DVRs, NVRs (excluding HDD) 60 months
IP Cameras 60 months
Racks 60 months
TV Mounts 60 months
Analog Cables
Limited Lifetime
B Connectors
Limited Lifetime
Extension Cords
Limited Lifetime
HDMI Cables Limited Lifetime
Jacks, Cords and Intrusion Limited Lifetime
Patch Cables Limited Lifetime
Wire Ties Limited Lifetime
2. Exclusion of Warranties, Limitation of Liability
THERE ARE NO WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED, OF
MERCHANTABILITY, OR FITNESS FOR A PARTICULAR PURPOSE OR OTHERWISE,
WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. TO THE
FULLEST EXTENT PERMITTED BY LAW, IN NO CASE SHALL ADI BE LIABLE TO
ANYONE FOR ANY (I) CONSEQUENTIAL, INCIDENTAL, INDIRECT, SPECIAL, OR
PUNITIVE DAMAGES ARISING OUT OF OR RELATING IN ANY WAY TO THE PRODUCT
AND.OR FOR BREACH OF THIS OR ANY OTHER WARRANTY OR CONDITION,
EXPRESS OR IMPLIED, OR UPON ANY OTHER BASIS OF LIABILITY WHATSOEVER,
EVEN IF THE LOSS OR DAMAGE IS CAUSED BY ADI’S OWN NEGLIGENCE OR FAULT
AND EVEN IF ADI HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH LOSSES OR
DAMAGES.
18
Any product description (whether in writing or made orally by ADI or ADI’s agents),
specifications, samples, models, bulletin, drawings, diagrams, engineering sheets, or
similar materials used in connection with the Buyer's order are for the sole purpose of
identifying ADI's products and shall not be construed as an express warranty or condition.
Any suggestions by ADI or ADI's agents regarding use, applications or suitability of the
products shall not be construed as an express warranty or condition unless confirmed to
be such in writing by ADI. ADI does not represent that the products it sells may not be
compromised or circumvented; that the products will prevent any personal injury
or property loss by burglary, robbery, fire or otherwise, or that the products will in all cases
provide adequate warning or protection. Buyer understands and will cause its customer to
understand that a properly installed and maintained product is not insurance or guarantee
that such will not cause or lead to personal injury or property loss. CONSEQUENTLY ADI
SHALL HAVE NO LIABILITY FOR ANY PERSONAL INJURY, PROPERTY DAMAGE OR
OTHER LOSS BASED ON ANY CLAIM AT ALL INCLUDING A CLAIM THAT THE
PRODUCT FAILED TO GIVE WARNING. However, if ADI is held liable whether directly or
indirectly for any loss or damage with respect to the products it sells, regardless of cause or
origin, its maximum liability shall not in any case exceed the purchase price of the product,
which shall be fixed as liquidated damages and not as a penalty and shall be the complete
and exclusive remedy against ADI.
FOR THE AVOIDANCE OF DOUBT, ADI DOES NOT SEEK HEREUNDER TO EXCLUDE
OR RESTRICT ITS LIABILITY IN RELATION TO (I) FRAUD, (II) DEATH OR PERSONAL
INJURY DIRECTLY RESULTING FROM ITS NEGLIGENCE OR (III) ANY MATTER IN
RESPECT OF WHICH, BY LAW, IT IS NOT PERMITTED TO RESTRICT ITS LIABILITY.
3. Limitation on Liability to Buyer’s Customers
Buyer agrees to limit liability to its customers to the fullest extent permitted by law. Buyer
acknowledges that ADI shall only be deemed to give consumers of its products such
statutory warranties as may be required by law and at no time shall Buyer represent to its
customers and/or users of ADI products that ADI provides any additional warranties. By
accepting the products, to the fullest extent permitted by law, Buyer assumes all liability for,
and agrees to indemnity and hold ADI harmless against and defend ADI from, any and all
suits, claims, demands, causes of action and judgments relating to damages, whether for
personal injury or to personal property, suffered by
any person, firm, corporation or business association, including but not limited to, Buyer's
customers and/or users of the products because of any failure of the products to detect
and/or warn of the danger for which the goods were designed or any other failure of the
products whether or not such damages are caused or contributed to by the sold or joint
concurring negligence or fault of ADI.
19
4. Returns
Subject to the terms and conditions listed below, during the applicable warranty period,
ADI will replace Product or provide a credit at purchase at its sole option free of charge
any defective products returned prepaid. Any obligations of ADI to replace Limited
Lifetime warranty products pursuant to this warranty which result from defect are limited
to the availability of replacement product. ADI reserves the right to replace any such
products with the then currently available products, or provide a credit in its sole
discretion. In the event Buyer has a problem with any ADI product, please call your local
ADI branch for return instructions:
WWW.WBOXTECH.COM
Be sure to have the model number and the nature of the problem available. In the event of
replacement, the return product will be credited to Buyer's account and a new invoice
issued for the replacement item. ADI reserves the right to issue a credit only in lieu of
replacement.
If any WBox Technologies product is found to be in good working order or such
product's inability to function properly is a result of user damage or abuse, the
product will be returned to Buyer in the same condition as received and Buyer shall
be responsible for any return freight changes.
5. Governing Law
This Limited Warranty shall be governed by the laws of England and Wales.
6. Miscellaneous
Where any term of this Limited Warranty is prohibited by such laws, it shall be null and void,
but the remainder of the Limited Warranty shall remain in full force and effect.
Table of contents
Other W Box Technologies Monitor manuals
