W Box Technologies 0E-HDMISW5X1 User manual

4K@60Hz (4:2:0)
HDMI SWITCHER
0E-HDMISW5X1

1
Content
Introduction ......................................................................................................................2
Features ............................................................................................................................3
Package Contents ............................................................................................................3
Panel..................................................................................................................................4
Front Panel...........................................................................................................4
Rear Panel...........................................................................................................5
IR Remote Handset ..........................................................................................................6
Installation Instructions...................................................................................................7
Auto-switch Function.......................................................................................................8
Troubleshooting...............................................................................................................8
Specification................................................................................................................... 11
Limited Warranty............................................................................................................13
Introduction ....................................................................................................................19
Caractéristiques.............................................................................................................20
Contenu...........................................................................................................................20
Panneau ..........................................................................................................................21
Panneau avant...................................................................................................21
Panneau arrière .................................................................................................22
Télécommande IR...........................................................................................................23
Procédure d’installation.................................................................................................24
Fonction de basculement automatique........................................................................25
Dépannage......................................................................................................................26
Spécifications.................................................................................................................28
Garantie limitée ..............................................................................................................30

2
Introduction
Congratulations and thank you for purchasing W Box Technologies
0E-HDMISW5X1.
0E-HDMISW5X1 is a 5 to 1 HDMI switcher. It is HDCP 2.2
compliant and supports resolutions up to 4K@60Hz 4:2:0 8 bit. It
includes five inputs for direct connection of HDMI source devices,
which gives you a high performance connection between five
sources and a display without signal loss. This switcher also
provides IR remote, auto and manual button control, enabling users
to switch among multiple sources with ease.
Please follow the instructions in this manual to assure proper
installation and to achieve the full performance and satisfaction you
would expect from W Box Technologies.

3
Features
Cost effective 4K 5 to 1 HDMI switcher
Supports resolutions up to 4K@60Hz 4:2:0 8bit
HDCP 2.2 compliant
HDMI signal transmission distance up to 10ft/3m at 4K, and up
to 16ft/5m at 1080P
Able to receive power from the HDMI source devices
Supports IR remote, auto and manual switch control to switch
among multiple sources
Compact size for hidden installation
Note: In order to ensure proper functionality, make sure the resolution of the HDMI
sources is set to 4K@60Hz 4:2:0 or lower when both the connected sources and sink
support 4K@60Hz 4:4:4 8 bit.
Package Contents
Before you start the installation, please check the package contents:
1 x 0E-HDMISW5X1
1 x IR Remote
1 x IR Receiver Cable
2 x Mounting Bracket
1 x User Manual
1 x Datasheet

4
Panel
Front Panel
ID.
Name
Description
1
IR IN Window
Point the remote directly at IR In
window to switch among connected
sources.
Note: IR In window will be disabled
when using the IR extend function on
rear panel.
2
SWITCH
Button
Press to cycle through different sources.
3
POWER LED
On: The device is powered on.
Off: The device is powered off.
4
HDMI IN 1-5
LEDs
On: The source is selected.
Off: The source is not selected.
5
HDMI OUT
LED
On: The device is connected to a sink.
Off: The device is not connected to a
sink.

5
Rear Panel
ID.
Name
Description
1
HDMI IN
1-5
Connect to HDMI sources.
2
HDMI OUT
Connect to an HDMI sink.
3
IR EXT.
Connect to the supplied IR receiver cable.
Note: IR receiver window on front panel
will be disabled when using the IR extend
function.
4
DC 5V
DC 5V power supply input
Note: When the switcher cannot be
powered by HDMI source(s), to connect to
an external 5V DC power supply is
required (power adapter is not included in
the package).

6
IR Remote Handset
Button
IR Code
Description
0x02 0x0a
Switch to next active source input
(Cycle 15)
0x02 0x08
Switch to previous active source input
(Cycle 51)
0x02 0x04
Switch to source 1
0x02 0x05
Switch to source 2
0x02 0x06
Switch to source 3
0x02 0x0c
Switch to source 4
0x02 0x0e
Switch to source 5
Note:
Since the encoding format for IR codes above is NEC (38KHz),
please ensure your own third party device to remote control the
switcher is with the same format NEC (38KHz).
Please ensure the remote is pointed directly at the IR receiver
window/cable.
1
2
3
4
5

7
Installation Instructions
1. Connect the HDMI sources (such as the DVD player, computer,
Apple TV, STB, Xbox, etc.) to the HDMI input ports of the
switcher via quality HDMI cables as number 1 shown below.
2. Connect the HDMI display (such as a TV, projector, LED/LCD
display, etc.) to the HDMI output port of the switcher via an
HDMI cable as number 2 shown below.
3. Connect the included IR receiver cable to the IR EXT port if you
need to extend the remote control distance as number 3 shown
below.
4. Power on the HDMI sources and display.
Note: When the switcher cannot be powered by HDMI
source(s), it’s required to connect to an external power supply.
5. Switch among the HDMI sources by the IR remote or Switch
button on front panel.
Note: When you use the IR extend function for remote control,
the IR receiver window on front panel will be disabled.

8
Auto-switch Function
With auto-switch function, the switcher can switch input to the last
connected source automatically without additional operations.
1. When a new HDMI source is inserted, the switcher will switch
input to it automatically.
2. When the selected HDMI source is removed, the switcher will
switch input to the active source with top priority automatically
(Priority: 1>2>3>4>5).
Troubleshooting
W Box Technologies products are designed to function trouble-free.
Most problems that occur are due to simple issues. If you have
trouble, please check the list of simple fixes below.

9
Steps of Regular Troubleshooting Routine
1. Power: Make sure all devices are powered on (source, switcher,
and display devices).
2. Indicator: Make sure LED indicators of the switcher are normal
according to user manual.
3. Devices: Please make sure picture can be shown normally
when connecting source to display devices directly.
4. Cable: Plug in and out HDMI cable or try another HDMI cable.
For1080P, the input/output HDMI cable’s length should be
within 16ft/5m.
For 4K@60Hz, the input/output HDMI cable’s length should
be within 10ft/3m.
5. Compatibility: Please test other source and display devices to
determine if it is a compatibility issue.
Typical Questions
1. How to deal with video flash or cut off during the
installation?
Verify that all the indicators are solid on. If not, please check
if the HDMI cables are well connected.
Verify that the display device works properly and that the
source devices have normal signal output. Also, make sure
HDMI sources are under 4K@60Hz 4:2:0 8bit.
2. How to deal with a weak or not working IR signal?
Make sure the IR receiver cable is correctly installed
according to the diagram above.
Pay attention to the control angle and distance as below.
The control signal will be better when your controller is
pointed at the IR receiver head directly.

10
Enabled Angle
0°
30°(Horizontal)
15°(Vertical)
Distance
26ft (Max)
16ft (Max)
10ft (Max)

11
Specification
Technical
Input/Output Signal Type
HDMI 1.4 with HDCP 2.2
Audio Format
PCM2.0/5.1/7.1, Dolby TrueHD and
DTS HD Master Audio
Input/Output Resolution
Supported
SMPTE:
1280x720P1,2,3,4,5,6,7,8,
1920x1080I6,8,
1920x1080P1,2,3,4,5,6,7,8,
3840x21602,3,5,6,8, 4096x21602,3,5,6,8
VESA:
800x6008, 1024x7688, 1280x7688,
1280x8008, 1280x9608,
1280x10248, 1360x7688,
1366x7688, 1400x10508,
1440x9008, 1600x9008,
1600x12008, 1680x10508,
1920x12008
1 = at 23.98 Hz, 2 = at 24 Hz, 3 = at 25 Hz, 4 =
at 29.97 Hz, 5 = at 30 Hz, 6 = at 50 Hz, 7 = at
59.94 Hz, 8 = at 60 Hz
Note: 4096x2160/3840x2160@50Hz/60Hz is
based on chroma sub-sampling 4:2:0 8-bit only.
Control Method
IR remote control
Switch button control

12
General
Operating Temperature
+32°F to +113°F (0°C to +45°C)
10% to 90%, non-condensing
Storage Temperature
-4°F to +158°F (-20°C to +70°C)
10% to 90%, non-condensing
ESD Protection
Human Body Model:
±8kV (air-gap discharge)/
±4kV (contact discharge)
Power Consumption (Max)
0.25W
Dimensions
7.09'' ×2.76'' ×0.83''
(180mm ×70.2mm ×21mm)
Weight
0.75lb/0.34kg
Certification
CE, FCC, RoHS
Cable Specifications:
Cable Type
Range
Supported Video
HDMI
Input/Output: 10ft/3m
4K@60 Hz 4:2:0 8bit,
4K@30 Hz
Input/Output:16ft/5m
1080P@60Hz

13
Limited Warranty
1. Limited Warranty
a. General
Subject to the terms and conditions of this Limited Warranty, from
the date of sale through the period of time for product categories
specified in Section 1(b), ADI warrants its W Box Technologies
products to be free from defects in materials and workmanship
under normal use and service, normal wear and tear excepted.
Except as required by law, this Limited Warranty is only made to
Buyer and may not be transferred to any third party.
ADI shall have no obligation under this Limited Warranty or
otherwise if:
(i) The product is improperly installed, applied or maintained;
(ii) The product is installed outside of stated operating parameters,
altered, or improperly services or repaired;
(iii) Damage is caused by outside natural occurrences, such as
lightning, power surges, fire, floods, acts of nature, or the like.
(iv) Defects resulting from unauthorized modification, misuse,
vandalism, or other causes
(v) Unrelated to defective materials or workmanship, or failures
related to batteries of any type used in connection with the
products sold hereunder.
ADI only warrants those products branded as W Box Technologies
products and sold by ADI. Any other products branded by third
parties are warranted by the third party manufacturer for a period as
defined by the third party manufacturer, and ADI assigns to Buyer
those warranties and only those warranties extended by such third
party manufacturers or vendors for non-ADI branded products. ADI

14
does not itself warrant any non-ADI branded product and sells only
on an as is basis in accordance with ADI’s terms and conditions of
sale.
b. Specific Warranties for product categories are as follows:
Product Categories
Warranty Period
Soundbars
12 months
Walk Through Metal Detectors
12 months
Intrusion Wireless Communication
Accessories
12 months
Analog Cameras
24 months
HD TVI Cameras and HD TVI DVR’s
24 months
Televisions
24 months
CCTV Power Supplies
24 months
In Ceiling Speakers
24 months
Amplifiers
24 months
Magnetic Locks
24 months
Request to Exit Devices
24 months
Surge Protection
24 months
UPS (uninterruptible power supplies)
24 months
Volume Controls
24 months
HDMI Distribution
24 months
Intrusion Audio Devices
30 months
Monitors
30 months
Power and Relays
30 months
Hold-up Buttons
30 months
Video Baluns
30 months
DVR's, NVR's
60 months
IP Cameras
60 months
Racks
60 months
TV Mounts
60 months

15
Product Categories
Warranty Period
PIR’s
60 months
Analog Cables
Limited Lifetime
B Connectors
Limited Lifetime
Bus Terminals
Limited Lifetime
Extension Cords
Limited Lifetime
HDMI Cables
Limited Lifetime
Jacks, Cords and Intrusion
Communication Accessories
Limited Lifetime
Patch Cables
Limited Lifetime
Patch Panels
Limited Lifetime
Raceway Conduit
Limited Lifetime
Wire Ties
Limited Lifetime
Magnetic Contacts
Limited Lifetime

16
2. EXCLUSION OF WARRANTIES, LIMITATION OF LIABILITY
THERE ARE NO WARRANTIES OR CONDITIONS, EXPRESS OR
IMPLIED, OF MERCHANTABILITY, OR FITNESS FOR A
PARTICULAR PURPOSE OR OTHERWISE, WHICH EXTEND
BEYOND THE DESCRIPTION ON THE FACE HEREOF. TO THE
FULLEST EXTENT PERMITTED BY LAW, IN NO CASE SHALL
ADI BE LIABLE TO ANYONE FOR ANY (I) CONSEQUENTIAL,
INCIDENTAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES
ARISING OUT OF OR RELATING IN ANY WAY TO THE
PRODUCT AND.OR FOR BREACH OF THIS OR ANY OTHER
WARRANTY OR CONDITION, EXPRESS OR IMPLIED, OR UPON
ANY OTHER BASIS OF LIABILITY WHATSOEVER, EVEN IF THE
LOSS OR DAMAGE IS CAUSED BY ADI’S OWN NEGLIGENCE
OR FAULT AND EVEN IF ADI HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH LOSSES OR DAMAGES. Any product
description (whether in writing or made orally by ADI or ADI’s
agents), specifications, samples, models, bulletin, drawings,
diagrams, engineering sheets, or similar materials used in
connection with the Buyer’s order are for the sole purpose of
identifying ADI’s products and shall not be construed as an express
warranty or condition. Any suggestions by ADI or ADI’s agents
regarding use, applications or suitability of the products shall not be
construed as an express warranty or condition unless confirmed to
be such in writing by ADI. ADI does not represent that the products
it sells may not be compromised or circumvented; that the products
will prevent any personal injury or property loss by burglary, robbery,
fire or otherwise, or that the products will in all cases provide
adequate warning or protection. Buyer understands and will cause
its customer to understand that a properly installed and maintained
product is not insurance or guarantee that such will not cause or
lead to personal injury or property loss. CONSEQUENTLY ADI
SHALL HAVE NO LIABILITY FOR ANY PERSONAL INJURY,

17
PROPERTY DAMAGE OR OTHER LOSS BASED ON ANY CLAIM
AT ALL INCLUDING A CLAIM THAT THE PRODUCT FAILED TO
GIVE WARNING. However, if ADI is held liable whether directly or
indirectly for any loss or damage with respect to the products it sells,
regardless of cause or origin, its maximum liability shall not in any
case exceed the purchase price of the product, which shall be fixed
as liquidated damages and not as a penalty and shall be the
complete and exclusive remedy against ADI.
3. Limitation on Liability to Buyer’s Customers.
Buyer agrees to limit liability to its customers to the fullest extent
permitted by law. Buyer acknowledges that ADI shall only be
deemed to give consumers of its products such statutory warranties
as may be required by law and at no time shall Buyer represent to
its customers and/or users of ADI products that ADI provides any
additional warranties. By accepting the products, to the fullest
extent permitted by law, Buyer assumes all liability for, and agrees
to indemnity and hold ADI harmless against and defend ADI from,
any and all suits, claims, demands, causes of action and judgments
relating to damages, whether for personal injury or to personal
property, suffered by any person, firm, corporation or business
association, including but not limited to, Buyer’s customers and/or
users of the products because of any failure of the products to
detect and/or warn of the danger for which the goods were
designed or any other failure of the products whether or not such
damages are caused or contributed to by the sold or joint concurring
negligence or fault of ADI.

18
4. Returns
Subject to the terms and conditions listed below, during the
applicable warranty period, ADI will replace Product or provide a
credit at purchase at its sole option free of charge any defective
products returned prepaid. Any obligations of ADI to replace Limited
Lifetime warranty products pursuant to this warranty which result
from defect are limited to the availability of replacement product.
ADI reserves the right to replace any such products with the then
currently available products, or provide a credit in its sole discretion.
In the event Buyer has a problem with any ADI product, please call
your local ADI branch for return instructions:
For US call 1-800-233-6261
For Canada call 877-234-7378
For Puerto Rico call 787-793-8830
Be sure to have the model number and the nature of the problem
available. In the event of replacement, the return product will be
credited to Buyer’s account and a new invoice issued for the
replacement item. ADI reserves the right to issue a credit only in lieu
of replacement.
If any W Box Technologies product is found to be in good working
order or such product’s inability to function properly is a result of
user damage or abuse, the product will be returned to Buyer in the
same condition as received and Buyer shall be responsible for any
return freight changes.
