Wallenstein 720123 User manual

OPERATOR'S MANUAL
Trailer Wood Splitter
WXR
720/L, WXR 740/L
Part Number: Z97105_EnRev Feb-2020
WXR720 up to S/N 720123
WXR720L up to S/N 720123
WXR740 up to S/N 740377
WXR740L up to S/N 740383

Introduction WXR720/L, WXR740/L
Trailer Wood Splitter
2
1. Introduction
1.1 Foreword
Congratulations on choosing a Wallenstein Trailer
Wood Splitter!
This high-quality machine is designed and
manufactured to meet the needs of an e󰀩cient wood
splitting operation.
The 27-ton WXR Series wood splitters feature
Wallenstein 2x2-Speed Firebolt Technology. Splitting
cycle time is reduced using a high-volume, two-stage
hydraulic pump and a regenerative control valve. The
valve provides two cylinder extend speeds that provide
either high speed or high power.
This manual covers both the Wallenstein WXR720 and
WXR740 Series of trailer wood splitters.
• The WXR720 is horizontal splitting only.
• The WXR740 features horizontal and vertical
splitting.
This manual covers the following models:
• WXR720
WXR720L (stop, turn signal, tail lights)
• WXR740
WXR740L (stop, turn signal, tail lights)
Keep this manual handy for reference and to pass
on to new operators or owners. Call your Wallenstein
dealer, distributor or the factory if you need assistance,
information or additional copies of the manuals.
Review all safety, operation and maintenance
information contained in this manual.
WARNING!
Do not attempt to start or operate the machine
without thoroughly reviewing this manual for
safe and proper operation.
Always keep this manual with the machine.
W034
www.wallensteinequipment.com

WXR720/L, WXR740/L
Trailer Wood Splitter Introduction
3
Table of Contents
1. Introduction............................................................2
1.1 Foreword .........................................................2
1.2 Delivery Inspection Report ..............................4
1.3 Serial Number Location ...................................5
1.4 Warranty ..........................................................6
1.5 Decal Information ............................................7
2. Safety......................................................................8
2.1 Safety Alert Symbol .........................................8
2.2 Signal Words ...................................................8
2.3 Why is SAFETY important?.............................9
2.4 Safety Rules ....................................................9
2.5 Equipment Safety Guidelines ........................10
2.6 Safety Training ..............................................10
2.7 Transport Safety ............................................10
2.8 Refueling Safety ............................................11
2.9 Tire Safety .....................................................11
2.10 Hydraulic System Safety ...............................11
2.11 Gas Engine Safety.........................................11
2.12 Be Prepared ..................................................12
3. Safety Signs .........................................................14
3.1 Safety Sign Locations....................................14
3.2 Safety Sign Explanations...............................15
3.3 Replacing Damaged Safety Signs.................16
4. Familiarization......................................................17
4.1 To the New Operator .....................................17
4.2 Machine Components....................................18
5. Controls ...............................................................20
5.1 Engine Controls .............................................20
5.2 Hydraulic Controls .........................................21
6. Operating Instructions ........................................22
6.1 Operating Safety............................................22
6.2 Before Starting the Engine ............................23
6.3 Pre-operation Checklist .................................23
6.4 Machine Break-In ..........................................24
6.5 Engine Oil Level Check .................................24
6.6 Hydraulic Oil Level Check .............................24
6.7 Fuel Level Check...........................................25
6.8 Engine Air Cleaner ........................................26
6.9 Machine Set-up .............................................26
6.10 Starting the Engine ........................................27
6.11 Stopping the Engine ......................................28
6.12 Stopping in an Emergency ............................28
6.13 Log Placement...............................................29
6.14 Splitting Logs .................................................29
6.15 Transporting ..................................................31
7. Storing the Wood Splitter ...................................32
7.1 Removing from Storage.................................32
8. Service and Maintenance....................................32
8.1 Maintenance Safety.......................................32
8.2 Fluids and Lubricants ....................................33
8.3 Maintenance Schedule ..................................33
8.4 Grease Points................................................34
8.5 Hydraulic Oil – Changing...............................35
8.6 Hydraulic Oil Filter – Changing......................35
8.7 Engine Air Cleaner ........................................36
8.8 Electrical System – General ..........................36
9. Troubleshooting...................................................37
10. Specications ....................................................38
10.1 Machine Specications..................................38
10.2 Common Bolt Torque Values ........................39
10.3 Hydraulic Fitting Torque ................................40
10.4 Wheel Lug Torque .........................................40
11. Alphabetical Index .............................................41

Introduction WXR720/L, WXR740/L
Trailer Wood Splitter
4
WALLENSTEIN
WXR720 / WXR740 Series Trailer Wood Splitters
Pre-delivery Inspection
Inspect for damage from shipping. Immediately contact the
shipping company if damage is found.
Trailer Wood Splitter
Hydraulic Valve Control Function
Hydraulic Cylinder Function
Hydraulic Reservoir level
Engine Oil Level
Horizontal / Vertical Pivot Moves Freely (as equipped)
Front and Rear Support Stands Move freely
All fasteners are Tight
Lubricate all Pivot Points (as equipped)
Check that all Hydraulic Connections are tight
Review Operating and Safety Instructions
Safety Checks
All Safety Decals Installed
Guards and Shields Installed and Secured
Check Function of Brake and Signal Lighting
Supports Function Correctly
Safety Chain on Hitch
Retainer Installed Through Ball Hitch
Review Operating and Safety Instructions
_________________________________________
Customer’s Name
_________________________________________
Contact Name
_________________________________________
Dealer Name
(_________)_______________________________
Phone Number
_________________________________________
Serial Number
__________ /__________ /__________
Delivery Date
I have thoroughly instructed the buyer on the equip-
ment care, adjustments, safe operation and applicable
warranty policy and reviewed the manual.
_________________________________________
Dealer’s Rep. Signature
__________ /__________ /__________
Date
The product manuals have been received by me and
I have been thoroughly instructed as to care, adjust-
ments, safe operation and applicable warranty policy.
_________________________________________
Owner's Signature
__________ /__________ /__________
Date
1.2 Delivery Inspection Report
To activate warranty, register your product online at
http://www.wallensteinequipment.com

WXR720/L, WXR740/L
Trailer Wood Splitter Introduction
5
1.3 Serial Number Location
Always provide the model and serial number of your
Wallenstein product when ordering parts, or requesting
service or other information. The product information
plate location is shown in the illustration.
For future convenience, record your product Model
and Serial Number in the spaces provided below.
Record Product Information Here
Model:
Serial Number:
00615
Model and Serial
Number Location
Fig. 1 – Product Information Plate Location (typical for all models)

Introduction WXR720/L, WXR740/L
Trailer Wood Splitter
6
1.4 Warranty
rev. Nov-2018
LIMITED WARRANTY
Wallenstein products are warranted to be free of defects in materials and
workmanship under normal use and service, for a period of
Five Years for Consumer Use
Two Years for Commercial/Rental Use
from the date of purchase, when operated and maintained in accordance with the operating
and maintenance instructions supplied with the unit. Warranty is limited to the repair of the
product and/or replacement of parts.
This warranty is extended only to the original purchaser and is not transferable.
Repairs must be done by an authorized dealer. Products will be returned to the dealer at the
customer’s expense. Include the original purchase receipt with any claim.
This warranty does not cover the following:
1) Normal maintenance or adjustments
2) Normal replacement of wearable and service parts
3) Consequential damage, indirect damage, or loss of profits
4) Damages resulting from:
•Misuse, negligence, accident, theft or fire
•Use of improper or insufficient fuel, fluids or lubricants
•Use of parts or aftermarket accessories other than genuine Wallenstein parts
•Modifications, alteration, tampering or improper repair performed by parties other
than an authorized dealer
•Any device or accessories installed by parties other than an authorized dealer
5) Engines. Engines are covered by the manufacturer of the engine for the warranty period
they specify. For the details of your engine warranty, see your engine owner’s manual.
Information about engine warranty and service is also available in the FAQ section at
www.wallensteinequipment.com

WXR720/L, WXR740/L
Trailer Wood Splitter Introduction
7
1.5 Decal Information
When getting familiar with the Wallenstein product,
notice that there are numerous decals located on the
machine. There are di󰀨erent types of decals for safety,
information, and product identication. The following
section explains what they are for and how to read
them.
Safety Decals are pictorial with a yellow background
and generally two panel. The top panel shows the
safety alert (the potential hazard) and the bottom panel
shows the message (how to avoid the hazard).
Safety alert
Message
Safety Notice Decals are pictorial with a blue
background and generally rectangular with single or
multiple symbols. This decal informs what Personal
Protective Equipment is required for safe operation.
Informative Decals are generally pictorial with a white
background and can vary in the number of panels. This
type of decal explains the operation of a control.
Product Decals indicate machine model and serial
number, and other important information.
VIN/
NLV:
MODEL: ##########
#########
Manufactured by:
Wallenstein Equipment Inc., 7201 Line 86, Wallenstein ON N0B2S0, Canada
TYPE OF VEHICLE/TYPE DE VEHICLE:
TRA / REM
GAWR/PNBE (KG): GVWR/PNBV (KG):
###
DIMENSION- RIM/JANTE /ERIT: PNEU:
COLD INFL. PRESS/PRESS DE
CONFLA A FROID (PSI/LPC):
THIS VEHICLE CONFORMS TO ALL APPLICABLE STANDARDS
PRESCRIBED UNDER THE CANADIAN MOTOR SAFTEY REGULATIONS
IN EFFECT ON THE DATE OF MANUFACTURE / CE VEHICLE EST
CONFORME A TOUTES LES NORMES QUI LUI SONT APPLICABLES EN
VERTU DU REGLEMENT SUR LA SECURITE DES VEHICLES
AUTOMOBILES DU CANADA EN VIGUEUR A LA DATE DE SA FABRICATION.
###
### ###
###
Maintenance Decals have a green background and
can vary to the number of panels. This decal shows a
type maintenance required and frequency interval.
See the section on safety signs for safety decal
denitions. For a complete illustration of decals and
decal locations, download the parts manual for your
model product at www.wallensteinequipment.com.

Safety WXR720/L, WXR740/L
Trailer Wood Splitter
Safety
8
2. Safety
2.1 Safety Alert Symbol
This Safety Alert Symbol means:
ATTENTION! BE ALERT!
YOUR SAFETY IS INVOLVED!
The Safety Alert Symbol identies important safety
messages on the Wallenstein wood splitter and in
the manual. When you see this symbol, be alert to
the possibility of personal injury or death. Follow the
instructions in the safety message.
2.2 Signal Words
The signal words DANGER, WARNING and CAUTION
determine the seriousness level of the warning
messages in this manual. The appropriate signal word
for each message in this manual has been selected
using the following guidelines:
DANGER –
Indicates an imminently hazardous situation that,
if not avoided, will result in death or serious injury.
This signal word is to be limited to the most extreme
situations typically for machine components which, for
functional purposes, cannot be guarded.
WARNING –
Indicates a potentially hazardous situation that, if not
avoided, could result in death or serious injury, and
includes hazards that are exposed when guards are
removed. It may also be used to alert against unsafe
practices.
CAUTION –
Indicates a potentially hazardous situation that, if not
avoided, may result in minor or moderate injury. It may
also be used to alert against unsafe practices.
IMPORTANT – To avoid confusing equipment
protection with personal safety messages, a signal
word IMPORTANT indicates a situation that if not
avoided, could result in damage to the machine.
NOTE: (plus text) – indicates an additional
explanation for an element of information.

WXR720/L, WXR740/L
Trailer Wood Splitter Safety
Safety
9
2.3 Why is SAFETY important?
Three Big Reasons:
• Accidents Disable and Kill
• Accidents Cost
• Accidents Can Be Avoided
The policy of Wallenstein Equipment Inc. is to produce
products that are safe and reliable. However, even
when using well-engineered equipment, there is always
an element of risk. To minimize the risks and promote
safety at all times, this section of the operator’s manual
details a number of safety rules that must always be
followed and obeyed.
YOU are responsible for the SAFE operation and
maintenance of your Wallenstein Trailer Wood Splitter.
YOU must ensure that you and anyone else who
is going to use, maintain or work around the wood
splitter be familiar with the operating and maintenance
procedures and related safety information contained
in this manual. This manual provides good safety
practices that should be followed while using the wood
splitter.
Remember, YOU are the key to safety. Good safety
practices not only protect you but also the people
around you. Make these practices a working part of
your safety program. Be certain that EVERYONE using
this equipment is familiar with the recommended use
and maintenance procedures and follows all the safety
precautions.
2.4 Safety Rules
• DO give operating instructions to operators or
employees before allowing them to operate the
machine, and REVIEW annually thereafter.
• DO read and understand ALL
Safety and Operating instructions
in the manual and follow them.
The most important safety device
on this equipment is a SAFE
operator.
• DO review safety related items annually with
all personnel who are operating the machine or
performing maintenance.
• DO wear appropriate Personal Protective
Equipment (PPE). The suggested equipment
includes but is not limited to the following:
- Hearing Protection
- Protective glasses, goggles or face shield
-Heavy work gloves
-Protective shoes with slip resistant soles
• DO have a rst-aid kit available
for use should the need arise and
know how to use it.
• DO read and understand all safety signs located
on the machine before operating, servicing,
adjusting, or cleaning. Safety signs are explained
on page 15.
• DO inspect and secure all guards before starting.
• DO check engine intake and exhaust. Make
sure they are clear of debris prior to starting the
machine.
• DO have a re extinguisher available for
use should the need arise. Know how to
use it.
• DO think SAFETY! Work SAFELY!
• DO NOT touch hot engine parts, mu󰀪er cover,
hydraulic hoses, engine body, engine oil, and so on
during operation or if the engine was recently shut
o󰀨. Contact may cause burns.
• DO NOT expect a person who has not read and
understood all operation and safety instructions
to use the machine. An untrained operator is
not qualied and is exposed to possible serious
injury or death. It is the owner's responsibility
to make sure to the operator has familiarity and
understanding of the machine.
• DO NOT allow riders during transport.
• DO NOT risk injury or death by ignoring good
safety practices.

Safety WXR720/L, WXR740/L
Trailer Wood Splitter
Safety
10
2.5 Equipment Safety Guidelines
Always place the machine in a Safe Condition before
performing any service work, maintenance procedures,
or storage preparation.
SAFE CONDITION
• Shut o󰀨 engine.
• Make sure all moving parts have stopped.
• Disconnect battery ground (-) cable.
• Block or chock wheels.
1. When two or more workers are present, only one
worker should be designated as the machine
operator and loader. A potentially dangerous
condition arises when the worker loading the
machine does not control the hydraulic ram.
A worker's hand may be pinched or crushed if the
ram has been activated during loading.
2. Never use equipment with safety shields removed.
Keep all shields in place. If shield removal
becomes necessary for repairs, reinstall the shield
prior to use.
3. Replace any safety sign or instruction sign that is
not readable or is missing. Location of safety signs
is indicated in this manual.
4. Do not allow anyone other than a responsible,
properly trained and physically able person to
operate this machine. This equipment is dangerous
to children and persons unfamiliar with its
operation.
5. Do not modify the equipment in any way.
Unauthorized modication may result in serious
injury or death and may impair the function and life
of the equipment.
6. Never exceed the limits of the machine. If its ability
to do the job or to do it safely is in question—
STOP IMMEDIATELY!
2.6 Safety Training
1. The best safety feature is an
informed, careful operator—we
ask you be that kind of operator.
It is the operator's responsibility
to read, understand and follow
ALL safety and operation
instructions in the manual.
2. Train all new personnel and review instruc tions
frequently with existing workers. Only properly
trained and physically able operators should
use this equipment. A person who has not
read and understood all operation and safety
instructions is not qualied to use the machine.
Untrained operators expose themselves and
bystanders to possible serious injury or death. If
elderly people are assisting with the work, their
physical limitations need to be recognized and
accommodated.
3. Learn the controls and how to stop the machine
quickly in an emergency.
4. If this machine is loaned or rented, it is the
machine owner's responsibility to make certain that
every operator:
• Reads and understands the owner's manual
• Is instructed in safe and proper use of the
equipment
• Understands and knows how to perform the
Safe Condition procedure
2.7 Transport Safety
1. Comply with local laws governing safety and
transporting of machinery on public roads.
2. Do not exceed 50 mph (80 km/h) when towing
this machine. Slow down for rough terrain and
cornering.
3. Do not transport or move the wood splitter with the
engine running.
4. Be sure the trailer is hitched correctly to the towing
vehicle and a retainer is used through the hitch
mechanism.
5. Always attach safety chains between the hitch and
the towing vehicle. Cross the chains underneath
the trailer tongue.
6. Check wheel lugs and tighten if required. Inspect
rims for damage.
7. Inspect tires for cuts or damage. Check tire
pressure and adjust if required.
8. Ensure the stability jacks are raised and secured
with the latch pin.
9. Make sure tow vehicle is tted with the correct size
(2 in) towing ball.
10. Make sure fuel and hydraulic tank caps are on tight
to prevent spills while transporting.
11. Clean all debris o󰀨 the splitter. Remove any tools
or other loose items.

WXR720/L, WXR740/L
Trailer Wood Splitter Safety
Safety
11
12. Check that all the lights, reectors and other
lighting requirements are installed and in good
working condition.
13. Never allow riders on the machine.
14. Be a safe and courteous driver. Always yield to
oncoming tra󰀩c in all situations, including narrow
bridges, intersections, and so on.
15. Watch for other tra󰀩c when near or crossing
roadways.
16. Do not drink and drive.
17. Before transporting, perform a walk-around
inspection to ensure everything is safe.
2.8 Refueling Safety
1. Engine fuel is highly ammable. Handle with care.
2. Fill fuel tank outdoors.
3. Stop the engine before refueling. Allow engine to
cool for ve minutes. Clean up spilled fuel before
restarting engine.
4. Do not overll the fuel tank.
5. If fuel is spilled, wipe it away carefully and wait until
the fuel has dried before starting the engine.
6. Do not refuel the machine while
smoking or when near open ame
or sparks.
7. After refueling, make sure that the fuel cap is
secured to prevent spillage.
8. Prevent res by keeping machine clean of
accumulated trash, grease, and debris.
2.9 Tire Safety
1. Failure to follow proper procedures when mounting
a tire on a wheel or rim can produce an explosion
which may result in serious injury or death.
2. Do not attempt to mount a tire unless you have the
proper equipment and experience to do the job.
3. Have a qualied tire dealer or repair service
perform required tire maintenance.
4. When replacing worn tires, make sure they
meet the original tire specications. Never install
undersized tires.
2.10 Hydraulic System Safety
1. Make sure that all the components in the hydraulic
system are kept in good condition and are clean.
2. Before applying pressure to the
system, make sure all components
are tight, and that lines, hoses and
couplings are not damaged.
3. Do not attempt any makeshift repairs to the
hydraulic lines, ttings or hoses by using tapes,
clamps or cements. The hydraulic system operates
under extremely high pressure. Such repairs can
fail suddenly and create a hazardous and unsafe
condition.
4. Wear proper hand and eye
protection when searching for a
high-pressure hydraulic leak. Use
a piece of wood or cardboard as
a backstop instead of hands to
isolate and identify a leak.
5. If injured by a concentrated high-pressure
stream of hydraulic uid, seek medical attention
immediately. Serious infection or toxic reaction
can develop from hydraulic uid piercing the skin
surface.
6. Relieve pressure in the hydraulic system before
working on it.
2.11 Gas Engine Safety
CAUTION!
Before starting engine, review the operating and
maintenance instructions in the engine manual.
W019
1. DO NOT operate engine in an enclosed area.
Exhaust gases contain odorless and deadly carbon
monoxide that can cause death by asphyxiation.
2. DO NOT place hands or feet near moving or
rotating parts.
3. DO NOT store, spill, or use gasoline near an
open ame, or devices such as a stove, furnace,
or water heater which use a pilot light or devices
which can create a spark.
4. DO NOT refuel indoors where area is not well
ventilated.
5. DO NOT refuel while engine is running. Allow
engine to cool for ve minutes before refueling.
Store fuel in approved safety containers.

Safety WXR720/L, WXR740/L
Trailer Wood Splitter
Safety
12
6. DO NOT remove fuel tank cap while engine is
running.
7. DO NOT operate engine if gasoline is spilled.
Move machine away from the spill and avoid
engine ignition until gasoline has evaporated.
8. DO NOT smoke while lling fuel tank.
9. DO NOT choke carburetor to stop engine.
Whenever possible, gradually reduce engine
speed before stopping.
10. DO NOT run engine above rated speeds. This may
result in injury.
11. DO NOT tamper with governor springs, governor
links or other parts which may increase the
governed speed.
12. DO NOT tamper with the engine as set by the
original equipment manufacturer.
13. DO NOT check for spark with spark plug or spark
plug wire removed.
14. DO NOT crank engine with spark plug removed. If
engine is ooded, crank until engine starts.
15. DO NOT strike ywheel with a hard object or
metal tool as this may cause ywheel to shatter in
operation. Use proper tools to service engine.
16. DO NOT operate engine without a mu󰀪er. Inspect
periodically and replace, if necessary.
17. DO NOT operate engine with an accumulation of
grass, leaves, dirt or other combustible materials in
the mu󰀪er area.
18. DO NOT use this engine on any forest covered,
brush covered, or grass covered unimproved land
unless a spark arrester is installed on the mu󰀪er.
The arrester must be maintained in e󰀨ective
working order by the operator. In the state of
California, the above is required by law (Section
4442 of the California Public Resources Code).
Other states may have similar laws. Federal laws
apply on federal land.
19. DO NOT touch hot mu󰀪er, engine body or cooling
ns. Contact may cause burns.
20. DO NOT run engine with air cleaner or air cleaner
cover removed.
Be sure to:
1. Remove the wire from the spark plug when
servicing the engine or equipment to prevent
accidental starting. Disconnect the (-) ground wire
from the battery terminal.
2. Keep engine cooling ns and governor parts free
of grass and other debris that can a󰀨ect engine
speed.
3. Examine mu󰀪er periodically to be sure it is
functioning e󰀨ectively. A worn or leaking mu󰀪er
should be repaired or replaced as necessary.
4. Use fresh gasoline. Old fuel can clog carburetor
and cause leakage.
5. Check fuel lines and ttings frequently for cracks or
leaks. Replace if necessary.
2.12 Be Prepared
1. Determine where the split wood is going to be piled
ahead of time. Make sure it does not interfere with
safe loading of wood into the splitter.
2. Precut logs so wood is ready to load into the
splitter. Do not run a chain saw and the splitter at
the same time.
3. Determine a safe work area location:
• Area must be clear of stones, branches or
hidden obstacles that might cause a tripping,
hooking or snagging hazard.
• Ground should be rm and level.
4. Operate only in daylight or good articial light.
5. Make sure machine is properly adjusted and in
good operating condition.
6. Store fuel well away from the wood pile.
7. Perform the Pre-operation Checklist procedure
before starting work (see Pre-operation Checklist
on page 35).
8. Do not operate on hillsides or when working area is
cluttered, wet, muddy or icy to prevent slipping and
tripping. Operate only on level ground.
9. Position machine so prevailing winds blow engine
exhaust fumes away from operator's station.
10. Stop engine when leaving the machine
unattended.

WXR720/L, WXR740/L
Trailer Wood Splitter Safety
Safety
13
Sign-off Form
Date Owner Employee
2.12.1 Sign-O󰀨 Form
Anyone using this machine must read and thoroughly
understand all Safety, Operation and Maintenance
information in this manual. An untrained operator
should never use this machine.
To help document this training, the sign-o󰀨 sheet
provided below can be used.
Make periodic reviews of Safety and Operation a
standard practice for all operators. Review again at the
startup of every season.
The design and manufacture of this product conforms
to relative provisions in the following standards:
ISO 4254-1 Agricultural machinery – Safety
ASABE S318 Safety for Agricultural Field Equipment
ISO 3600 Operator’s Manual – Machinery for
Agriculture, Forestry & Lawn Equipment

Safety Signs WXR720/L, WXR740/L
Trailer Wood Splitter
Safety
14
3. Safety Signs
3.1 Safety Sign Locations
The types of safety signs and locations on the
equipment are shown in the illustrations that follow.
Good safety requires that you familiarize yourself with
the various safety signs, the type of warning and the
area, or particular function related to that area, that
requires your SAFETY AWARENESS.
Think SAFETY! Work SAFELY!
Fig. 2 – Safety Decal Locations (typical for all WXR models)
00620
41 2 3

WXR720/L, WXR740/L
Trailer Wood Splitter Safety Signs
Safety
15
3.2 Safety Sign Explanations
1. Warning!
Always wear appropriate Personal Protective
Equipment when using this machine. For example:
• A hard hat
• Heavy gloves
• Hearing protection
• Protective shoes with slip resistant soles
• Protective glasses, goggles or face shield
2. Caution!
Refer to the operator's manual. Read ALL operating
instructions in the manual and learn the meaning of
ALL safety signs on the machine.
The best safety feature is an informed operator.
3. Warning!
Pinch point / crushing danger! Keep your hands away
from all moving parts during and after split operation!
Never try to clear a jammed log with your hands! Wait
for all moving parts to come to a complete stop before
loading or clearing obstructions.

Safety Signs WXR720/L, WXR740/L
Trailer Wood Splitter
Safety
16
4. Warning!
Keep feet away from falling split wood. Always wear
steel toed foot wear while machine is operating to
avoid serious personal injury.
3.3 Replacing Damaged Safety
Signs
1. Keep safety signs clean and legible at all times.
2. Replace safety signs that are missing or have
become illegible.
3. Parts that were replaced with a safety decal on
them must also have the safety sign replaced.
4. Replacement safety signs are available from your
authorized Distributor or Dealer Parts Department
or the factory.
3.3.1 How to Install Safety Signs
Ambient temperature must be above 50 °F (10 °C) to
install decals.
1. Clean and dry the installation area.
2. Determine exact position before removing the
backing paper.
3. Peel back the corner of the backing paper.
4. Align the sign over the specied area and carefully
press the small portion with the exposed sticky
backing in place.
5. Slowly peel back the remaining paper and carefully
smooth the remaining portion of the sign in place.
6. Small air pockets can be pierced with a pin and
smoothed out using the piece of sign backing
paper.

WXR720/L, WXR740/L
Trailer Wood Splitter Familiarization
17
4. Familiarization
4.1 To the New Operator
It is the responsibility of the owner or operator to
read this manual and to train all other operators
before they start working with the machine. Follow
all safety instructions exactly.
By following recommended procedures, a safe
working environment is provided for the operator,
bystanders and the area around the work site.
Untrained operators are not qualied to use the
machine.
Many features incorporated into this machine are
the result of suggestions made by customers like
you. Read this manual carefully to learn how to use
the machine safely and provide maximum operating
e󰀩ciency. By following the instructions in conjunction
with a good maintenance program, your wood splitter
can provide many years of trouble-free service.
IMPORTANT! Make sure all operators
understand how to put the wood splitter in a Safe
Condition before working with this machine. See
Safe Condition page 10.
4.1.1 Training
Each operator must be trained in the proper set-up and
operating procedures before using the machine.
1. Move the unit to a large open area to allow the
operator to become familiar with control functions
and machine response.
2. Do not allow untrained operators to use the
machine. They can endanger themselves and
others, or damage property and the machine.
4.1.2 Job Site Familiarization
It is the responsibility of the operator to be thoroughly
familiar with the work site prior to starting.
1. Check for close or cramped work space. Be sure
there is su󰀩cient space and clearance for the
machine to operate.
2. Organize the working area to minimize movement.
3. Position the machine so prevailing winds blow
engine exhaust fumes away from operator's
station.

Familiarization WXR720/L, WXR740/L
Trailer Wood Splitter
18
4.2 Machine Components
WXR720, WXR720L
Fig. 3 – WXR720, WXR720L Wood Splitter Components
1. Hydraulic Cylinder
2. Splitter Control Handle
3. Sliding Push Block
4. Non-tilting Splitter Bed
5. Splitter Wedge
6. Trailer Tongue
7. Safety Chains
8. Front Jack Stand
9. Product Manual Storage Tube
10. Hydraulic Oil Reservoir
11. 4.80-8 LRB SportTrail Tire
12. Stop, Tail, Turn Signal Lights (WXR720L only)
13. Honda GX200 Engine
12
3
4
5
6
7
8
9
1011
12
13
00618

WXR720/L, WXR740/L
Trailer Wood Splitter Familiarization
19
1 2
3
4
5
6
7
8
9
10
11
12
13
14
00619
Fig. 4 – WXR740, WXR740L Wood Splitter Components
1. Tilting Splitter Bed
2. Sliding Wedge
3. Splitter Control Handle
4. Splitter Bed Spring Latch
5. Hydraulic Cylinder
6. Honda GX200 Engine
7. Product Manual Storage Tube
8. Trailer Tongue
9. Safety Chains
10. Front Jack Stand
11. Hydraulic Oil Reservoir
12. 4.80-8 LRB SportTrail Tire
13. Stop, Tail, Turn Signal Lights (WXR740L only)
14. Rear Jack Stand
WXR740, WXR740L

Controls WXR720/L, WXR740/L
Trailer Wood Splitter
20
5. Controls
IMPORTANT! Before starting work with the wood
splitter, become familiar with the location and
function of all controls.
5.1 Engine Controls
Refer to the engine manual that came with this product
for further explanation on engine controls.
00189
2
3
1
5
4
Fig. 5 – Engine Controls
1. Throttle Lever
2. Ignition Switch
3. Oil Level Check
4. Oil Drain Plug
5. Starting Rope
6. Fuel Valve Lever
7. Choke Lever
5.1.1 Ignition Switch
This rotary switch controls the ignition system.
• The engine operates in the ON position. Before
starting the engine, turn the switch to ON.
• Turn it counter-clockwise to OFF to stop the
engine.
00187
Fig. 6 – Ignition Switch
5.1.2 Choke Lever
The choke lever opens and closes the choke valve in
the carburetor.
• Place the choke lever in the CLOSED position (3)
when starting a cold engine.
• Move the choke lever to the OPEN position (2)
after the engine starts. When restarting a warm
engine, leave the lever in the OPEN position.
00188
1
2
3
Fig. 7 – Choke Lever
1. Choke Lever
2. Choke Open Position
3. Choke Closed Position
5.1.3 Fuel Shut-o󰀨 Valve
The engine is equipped with a valve between the fuel
tank and the carburetor.
• Slide the fuel valve lever toward the block (2) to
turn fuel ON, and away (3) to turn OFF.
• Turn the fuel OFF when not in use or when
transporting.
00190
2
1
3
Fig. 8 – Fuel Valve Lever
1. Fuel Shut-o󰀨 Valve Lever
2. ON Position
3. OFF Position
