Wallenstein WP240 Manual

WP240 / WP270
Firewood Processor
SET-UP INSTRUCTIONS
PRINTED IN CANADA
Rev Aug-2018
Part Number: Z97115_SI-WP240-270_July-2018
EMB Manufacturing Inc.
4144 Boomer Line · St. Clements, ON · N0B 2M0 · Canada
www.wallensteinequipment.com

Always Put Safety First!
Read these assembly instructions thoroughly
before beginning. Make sure each step is
understood before attempting. Be familiar
with all safety signs on the machine and their
meaning.
Tighten all fasteners to the torque value
specied on Bolt Torque Specications page.
Recheck before using the machine.
WARNING!
Avoid the risk of personal injury or machine
damage! Read the operator’s manual before
using this equipment. Carefully read all safety
messages in the manual and follow all safety
signs on the machine.
WARNING!
Position the crate in a large open area to allow
access from all sides during assembly.
Stay clear of overhead power lines and
obstructions when lifting the machine during
assembly. Contact with power lines can cause
electrocution. Contact with obstructions can
damage components or cause them to fail.
Keep the assembly area clean to prevent slipping
or tripping.
Use a hoist when lifting components that weigh
50 lb (23 kg) or more to avoid back injury.
All lifting devices (straps, slings, chains, ratchet
blocks) must comply with applicable local
regulations and certications. EMB cannot
accept responsibility for the use of sub-standard
equipment and work practices.
Use lifting equipment with a capacity greater than
the weight of the component. Place jack stands
under the machine to securely stabilize it before
working on, beside or under it during assembly.
Use the correct tool for the job. Repair or
replace broken or defective equipment or tools.
Makeshift tools, parts, and procedures can
create safety hazards. Select a functional and
adequately sized tool. An increased risk of
personal injury occurs if a tool breaks or slips
during use.
WP240-270 Set-up Instructions

NOTE: Crate top and some parts are attached to
skid with screws.
IMPORTANT! Inspect for damage from
shipping. Immediately contact the
shipping company if damage is found.
WP240 / WP270 Set-up InstructionsWP240 / WP270 Set-up Instructions
1

NOTE: Shipping brackets and hardware not
reused.
A. Bottom Chute
B. Lead In Chute
C. Log Chute
D. Splitter Chute
E. Winch Strap
Hardware is located inside Operators Manual Tube.
D
B
A
C
E
NOTE: WP270 is shown. WP270 and WP240 are
similiar.
WP240 / WP270 Set-up Instructions
2

WP240 / WP270 Set-up Instructions
3
44
3

5
WP240 / WP270 Set-up Instructions
2X
2X
2X
2X
C
A

WP240 / WP270 Set-up Instructions
6
2X
B
7
E
WP240 / WP270 Set-up Instructions

WP240 / WP270 Set-up Instructions
8
D
D
B
B
A
WP240 / WP270 Set-up Instructions

Pre-delivery Inspection
Inspect for damage from shipping. Immediately contact the
shipping company if damage is found.
Wood Processor
Hydraulic Splitter Controls Function
Hydraulic Cylinder Functions
Splitter Chute Folds Up
Wedge Height Adjuster Functions
Loader and Lead-in Chutes Fold Up and Latch Securely
Log Stabilizer Moves Freely
Fasteners Tight
Grease Zerks / Lubricate Pivot Points
Pivot Tongue Moves Freely
Hydraulic Connections
Review Operating and Safety Instructions
Safety Checks
All Safety Decals Installed
Guards and Shields Installed and Secured
All Jacks Function
Retainer Installed Through Hitch Points
Review Operating and Safety Instructions
Hydraulic Winch
Check Winch Clutch Handle Control
Check Winch Rope / Hook / Fairlead
Check Hydraulic Function
Review Operating and Safety Instructions
Optional Equipment
Chain Saw Holster: Installed securely
6 Way Wedge: Check Height Adjuster
Chainsaw Pivot: Check Pivot Function
WP240 / WP270 Set-up Instructions
9

Bolt Torque Specications
Checking Bolt Torque
The tables shown give correct torque
values for various bolts and capscrews.
Tighten all bolts to the torque values
specied in the table, unless indicated
otherwise. Check tightness of bolts
periodically.
IMPORTANT! If replacing hardware,
use fasteners of the same grade.
IMPORTANT! Torque gures indicated
in the table are for non-greased or
non-oiled threads. Do not grease or oil
threads unless indicated otherwise.
When using a thread locker, increase
torque values by 5%.
NOTE: Bolt grades are identied by their
head markings.
Imperial Bolt Torque Speci cations
Bolt
Diameter
Torque Value
SAE Gr. 2 SAE Gr. 5 SAE Gr. 8
lbf•ft N•m lbf•ft N•m lbf•ft N•m
1/4" 6 8 9 12 12 17
5/16" 10 13 19 25 27 36
3/8" 20 27 33 45 45 63
7/16" 30 41 53 72 75 100
1/2" 45 61 80 110 115 155
9/16" 60 95 115 155 165 220
5/8" 95 128 160 215 220 305
3/4" 165 225 290 390 400 540
7/8" 170 230 420 570 650 880
1" 225 345 630 850 970 1320
Metric Bolt Torque Speci cations
Bolt
Diameter
Torque Value
Gr. 8.8 Gr. 10.9
lbf•ft N•m lbf•ft N•m
M3 0.4 0.5 1.3 1.8
M4 2.2 3 3.3 4.5
M6 7 10 11 15
M8 18 25 26 35
M10 37 50 52 70
M12 66 90 92 125
M16 166 225 229 310
M20 321 435 450 610
M30 1,103 1 495 1,550 2 100
M36 1,917 2 600 2,700 3 675
WP240-270 Set-up Instructions

Hydraulic Fitting
Torque
Tightening Flare Type Tube Fittings
1. Check are and are seat for defects that
might cause leakage.
2. Align tube with tting before tightening.
3. Hand-tighten swivel nut until snug.
4. To prevent twisting the tube, use two
wrenches. Place one wrench on the
connector body and tighten the swivel nut
with the second. Torque to values shown.
If a torque wrench is not available, use
the FFFT (Flats From Finger Tight)
method.
Hydraulic Fitting Torque
Tube
Size
OD
Hex
Size
Across
Flats
Torque value Flats From
Finger Tight
Inches Inches lbf•ft N•m Flats Turns
3/16 7/16 6 8 2 1/6
1/4 9/16 11–12 15–17 2 1/6
5/16 5/8 14–16 19–22 2 1/6
3/8 11/16 20–22 27–30 1-1/4 1/6
1/2 7/8 44–48 59–65 1 1/6
5/8 1 50–58 68–79 1 1/6
3/4 1-1/4 79–88 107–119 1 1/8
1 1-5/8 117–125 158–170 1 1/8
Values shown are for non-lubricated connections.
WP240-270 Set-up Instructions
