Wampat W18N4062W User manual

W18N4062W
Assembly Instructions
Please read this manual carefully before beginning assembly of this product.Keep this manual for future reference.

1-1

1
3
4
1
2
5
6
7
8
9
10
11
12

２
CD E F
GH I JL
M N OPQ
Wooden dowel
Ø6x30mm
Screw
Ø3x12mm
Screw
Ø3x14mm
Shelf support pin
Ø5x25mm
Hinge Magnetic catch Plastic wedge Handle
Ø4x18mm
Bolt Anchor Screw
Ø4x35mm
Philips screwdriverr
Slotted screwdriver Wood Drill Drill Pencil
Tools Required
(Not included)
Screw
Ø4x12mm
L-iron
Hammer
Mat
Ø6x30mm
Cam lock
Ø15x10mm
B
x 21
Cam bolt
Ø6x35mm
A
x 21 x 16 x 18 x 10 x 4
x 1 x 4 x 1 x 8
Magnetic plate
K
x 2x 2
x 4 x 1 x 1 x 1 x 4

３
1
· Gently screw cam bolts (A) into panels(1,2).
· Stick parts(Q) on panels(1,2) as shown.
AQ
A
Q
1
2
x 8 x 4

4
2
Finished edge
· Attach panels(5,7) to panel(2).
· Insert and secure cam locks(B) to panels(5,7) to lock it.
· Insert dowel(C) into panels(5,7). BC
B
C
2
5
7
x 4 x 4
1 2 3

5
3
· Attach panel(1) to panels(5,7).
· Insert and secure cam locks(B) to panels(5,7) to lock it.
· Insert dowels(C) into panels(5,7). BC
B
C
5
7
1
x 4 x 4
1 2 3

6
4
· Attach parts(H) to panels(9,10) with screws(D).
· Gently screw cam bolts(A) into panels(8,9,10).
ADH
A
9
10
8
D
H
x 9 x 8 x 4

7
5
· Attach panels(8,9,10) to panels(1,2,7).
· Insert and secure cam locks(B) to panels(1,2,7) to lock it.
· Insert dowels(C) into panels(9,10), then attach panels(9,10) to panel(8). BC
B
C
9
10
10
8
8
17
2
9
x 9 x 2
1 2 3

8
6
·Carefully insert panel(4) into the slot of panels(1,2,7).
4
4
1
2
7

9
7
· Gently screw cam bolts(A) into panel(3).
· Attach magnetic catch(I) to panel(3) with screws(E).
· Attach L-iron(N) to panel(3) with screws(G).
AEGIN
AE
I
N
G
3
x 4 x 2 x 1 x 1 x 1

10
8
· Attach panel(3) to panels(1,2,9,10).
· Insert and secure cam locks(B) to panels(1,2) to lock it.
· Insert dowels(C) into panels(1,2,9,10). BC
C
3
1
2
9
10
x 4 x 6
1 2 3

11
9
· Secure parts(J) with screws(E).
EJ
3
4
1
2
7
E
J
x 8 x 8

12
10
Finished edge
· Insert the shelf supports(F) at the desired level and place
the adjustable shelf(6) onto the shelf supports.
6
F
1
2F
x 4

13
11
· Attach parts(K) to panels(11,12) with screws(D).
· Attach parts(L) to panels(11,12) with bolts(M).
DKLM
11
12
D
K
L
M
x 2 x 2 x 2 x 4

14
12
· Attach panels(11,12) to panels(9,10) with screws(D). D
11
12
9
10
D
x 8

15
13
OP
3
N
O
P
Note:
We recommend it to be fixed to
the wall to prevent the furniture
from tipping over. Wall anchor
and hardware are included in
the package.
Please make sure hardware is
suitable for your walls before
installation, as different wall
materials may require different
types of anchors.
x 1 x 1
1 2 3
