Warwick Amplification Gnome Series Bass Amplifier Heads
Gnome · Gnome i · Gnome i Pro V2 · Gnome i Pro 600

Warwick Amplification Gnome Series - Bass Amplifier Heads
Gnome ·Gnome i ·Gnome i Pro V2 ·Gnome i Pro 600
Risk of Electric Shock
To reduce the risk of re or electric shock, do not remove the screws or open the unit. The Warwick Gnome has no user-serviceable parts inside.
Only allow qualied service personnel to service. Do not expose the units to rain or moisture.
FCC Certication
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that may cause undesired operation.
Volume Warning
This amplier is capable of producing high sound pressure levels. Continued exposure to these high sound pressure levels can cause permanent
and irreversible hearing damage. Ear protection is recommended if the unit is operated at high volume for long period of time. If you experience
any hearing loss or ringing in the ears you should consult a doctor.
Main Features
• Ultra-portable, lightweight bass amplier head
• Solid-state design, class D amplier circuitry
• Power:
200 W at 4 ohms / 130 W at 8 ohms (Gnome and Gnome i)
280 W at 4 ohms / 180 W at 8 ohms (Gnome i Pro V2)
600 W at 4 ohms / 350 W at 8 ohms (Gnome i Pro 600)
• 3-band EQ with +/- 15 dB cut/boost
• 6.35 mm (1/4") headphone output for silent practice
• 3.5 mm (1/8") AUX input to connect external sound sources (Gnome i Pro V2)
• Post-EQ balanced XLR DI output with switchable ground lift
• More than 10 MOhms input impedance provide maximum sensitivity for passive pickups
• USB audio interface on the Gnome i and Gnome i Pro V2 models:
· For PC, MAC or compatible mobile devices
· Direct recording via DAW plug-ins
· No drivers or special software required
• Dimensions (L x W x H):
170 x 118 x 45.5 mm / 6 11/16" x 4 41/64" x 1 51/64" (Gnome and Gnome i)
200 x 137 x 49 mm / 7 7/8" x 5 25/64" x 1 59/64" (Gnome i Pro V2)
340 x 250 x 100 mm / 13 25/64" x 9 27/32" x 3 15/16" (Gnome i Pro 600)
• Weight:
0.96 kg / 2.12 lbs (Gnome) / 0.98 kg / 2.16 lbs (Gnome i) / 1.35 kg / 2.98 lbs (Gnome i Pro V2) / 3.01 kg / 6.62 lbs (Gnome i Pro 600)
Introduction
Thank you for purchasing a Warwick Gnome amplier - clear, dened bass sound, true power and a built-in USB audio interface on the Gnome i
and Gnome i Pro V2 models - all packed in a super compact, lightweight design that will easily t in your pocket! The Gnome amp heads were de-
veloped to oer transparent, crisp and noise-free performance combined with an ultra-portable, lightweight design in an aordable and reliable
amp for discerning musicians and for the seasoned professionals.
The Warwick Gnome i and Gnome i Pro V2 oer an easy-to-use audio interface without any special driver or software requirements. The USB
audio interface allows you to connect your Gnome amp to a PC, MAC or compatible mobile device to record your playing or to process your signal
using digital audio software plug-ins.
Precautions / Safety Instructions
Power Supply
The Warwick Gnome is powered by an IEC power cable, which provides AC power to the unit. Connect the IEC power cable to provide power.
Improper line voltage can cause serious damage to the unit, always check the line voltage marking on the amplier before you connect the IEC
power cable. Unplug the unit when not in use or during electrical storms.
Connections
Always turn o power to all other equipment before connecting or disconnecting. This will help to prevent malfunction and damage to any of the
devices used.
Cleaning
Clean only with a soft, dry cloth.
Handling
Do not apply excessive force to the switches or controls. Do not block any ventilation openings. Install in accordance to the instructions. Do not let
paper, metal, dirt or other objects come into contact with the device or its connections. Take care not to drop the device and do not subject it to
shock or excessive pressure. The unit should be connected to a mains socket outlet with a protective earthing connection. Replace fuse with rated
value, never bridge defective fuses. Before changing fuse disconnect power cable from unit! To avoid deformation, discoloration, or other serious
damage, do not expose this unit to any of the following conditions:
• Direct sunlight
• Strong magnetic elds
• Excessively dusty or dirty environments
• Strong vibration or shock
• Heat sources
• Extreme temperature
• High humidity or moisture

Warwick Amplification Gnome Series - Bass Amplifier Heads
Gnome ·Gnome i ·Gnome i Pro V2 ·Gnome i Pro 600
Front Panel Description
1. Input Jack: Accepts 6.35 mm (1/4") audio jacks for connecting active or passive basses. If you use eects pedals, connect the output from
the last unit in the signal chain here. We recommend using high quality instrument cables for best sonic performance and reliable con-
nection.
2. Signal LED: The LED will light up green when the instrument signal passes the preamp without any compression. Higher input levels and
gain settings will activate the built-in compressor / limiter to prevent clipping in the pre-amp stage. The LED will light up red to indicate
active compression. The compressor also tracks changes made to the EQ settings, therefore an increase in an EQ setting might require
a decrease in the Gain setting to maintain the same amount of compression.
3. Gain: Adjusts the input gain of the pre-amp stage.
4. 3-Band EQ: The active tone control EQ section provides up to +/- 15 dB cut or boost for each band. All controls set to center position
(12 o‘clock) will provide a at EQ, turning the knobs clockwise will boost the frequency band, turning the controls counterclockwise will
cut the frequency band.
5. Master: The master volume control sets the signal level for the power output stage and the speaker output on the back of the Gnome
amplier. Set Master completely counterclockwise before you turn on the amplier and increase the control slowly until you reach the
desired volume level. A built-in limiter will prevent power amplier clipping when maximum power is detected.
6. Power LED: The LED will light up green when the Gnome is powered and turned on.
7. AUX Input: Input to connect external sound sources, accepts 3.5 mm (1/8") stereo jack for connecting (Gnome I Pro V2).
8. Headphone Jack: Accepts headphones with 6.35 mm (1/4") audio jacks. Silent practicing is possible if you disconnect the speaker output
and input your headphones. Silent practicing without connected load will not cause any damage to the amplier.
Back Panel Description
1. Power Switch: This switch turns the Gnome amplier on and o. Connect the power cord from the mains outlet to the amplier before
you turn this switch on. To disconnect the amplier, turn the switch o rst, then disconnect the power cord from the outlet and nally
disconnect the power cord from the amp.
2. AC Mains In: This is the power socket for an IEC line cord, which provides AC power to the unit. Always make sure to check the line voltage
marking on the unit before you connect the power cord. Improper line voltage may cause serious damage to the unit.
3. Speaker Out: Accepts 6.35 mm (1/4") mono jacks to connect an external speaker cabinet. The minimum load for the amplier is 4 ohms.
4. XLR DI Out: Low impedance balanced XLR output for connecting the amplier to a stage box, mixing desk or the PA for live and studio
use. The XLR DI out is congured post-EQ with standard wiring (Pin 1: Ground, Pin 2: Signal +, Pin 3: Signal -).
5. Ground Lift: The switch will disconnect the ground connection from pin 1 on the DI output XLR socket. Use this function only when you
face excessive hum, possibly caused by a ground loop. Usually this switch should be left in the out position.
6. USB Out Port (on Gnome i, Gnome i Pro V2 and Gnome i Pro 600): Connect the USB type B port to PC, MAC or compatible mobile de-
vices to use the audio interface.
1 2 3456
1 2 345
11 8 22 3
34 5 6
67 84 5

Setup & Operation
To use your new Warwick Gnome amplier, follow the quick start instructions:
1. Unpacking: Unpack the amplier carefully from the box.
2. Powering up: Ensure the Power Switch is in ‘o’ position, then connect the supplied power cord from the AC Mains In of the amplier to
the mains power outlet. Now ip the power switch on the amplier to the ‘on’position.
3. Connecting speaker cabinets: Connect speaker cabinet(s) to the Speaker Out using a compatible speaker cable. The recommended
minimum load for the amplier is 4 ohms.
4. Connecting an instrument: Turn the Gain and Master controls to minimum, then connect your bass to the Input Jack on the front pan
5. Adjust Gain for a good input level, set the EQ controls as you like, adjust the Master volume to a reasonable level.
6. Start playing!
USB Interface (Gnome i, Gnome i Pro V2 and Gnome i Pro 600)
The Warwick Gnome i, Gnome i Pro V2 and Gnome i Pro 600 ampliers feature an USB audio interface that can be used as universal connection
device for PC, MAC or compatible mobile devices without any specic drivers or software requirements. The interface uses high quality ADC/
DAC converters to convert your audio signal to be processed with the many applications available or for direct recording in your DAW. Gnome i,
Gnome i Pro V2 and Gnome i Pro 600 are functioning as external soundcards for your mobile device or PC/Mac, converting your instrument's
signal into a digital audio signal. The interface section is compatible with any USB device that can manage digital audio signals, via a standard
USB-B to USB-A cable.
Setup a Windows 7 / 8 / 8.1 / 10 Device
1. Use an USB-B to USB-A cable to connect the amplier to your computer.
2. Your computer will recognize the interface automatically and set all parameters accordingly. If you have problems with the automatic
setup, open the sound settings (right-click on the Windows Start button > Control Panel > Sound).
3. Click the Playback tab and select USB AUDIO CODEC as the default device.
4. Click the Recording tab and select USB AUDIO CODEC as the default device.
5. Open Input Properties > Additional Properties.
6. In the new window, click the Advanced tab and select 2-channel, 16-bit, 44100 Hz (CD Quality) as the default format.
7. Uncheck both boxes under Exclusive Mode.
8. Click OK to close the Sound control panel.
Setup a Mac OS X Device
1. Use an USB-B to USB-A cable to connect the amplier to your computer.
2. Your computer will recognize the interface automatically and set all parameters accordingly. If you have problems with the automatic
setup, go to System Preferences > Sound.
3. Under the Output tab, select USB AUDIO CODEC as your default device.
4. Under the Input tab, select USB AUDIO CODEC as your default device.
5. Close the window.
Protective Circuits
Your new Warwick Gnome amplier comes with multiple protective circuits to prevent malfunctions under unsuitable operating conditions.
Over-Current / Short-Circuit Protection
The amplier features an over-current / short-circuit protected output. A current drop occurs when the amplier exceeds the specied peak current
output. This goes along with the drop in the voltage of the amplier. If the current output of the amplier exceeds its specied peak current output for
a longer period of time e.g. in case of a short circuit of the output, the amplier will be disabled (muted) for 1000 ms and automatically restart.
DC Output Protection
A built-in DC protection circuit will attenuate any DC signals on the power amplier input, produced by a signal containing a DC signal. In case of
a permanent DC on the output of the amplier, the amplier will latch and power must be removed for the product to restart.
Excessive Temperature
This circuit protects the power stage from malfunction by switching the device o if the temperature-regulated fan cooling proves to be insucient
and temperature of the unit is too high.
Warwick Amplification Gnome Series - Bass Amplifier Heads
Gnome ·Gnome i ·Gnome i Pro V2 ·Gnome i Pro 600

Warwick Amplification Gnome Series - Bass Amplifier Heads
Gnome ·Gnome i ·Gnome i Pro V2 ·Gnome i Pro 600
Specications
Gnome Gnome i Gnome i Pro V2 Gnome i Pro 600
Mains Voltage
USA/Canda/Japan:
100-120V AC, 50/60 Hz, T3.15AL/250V
Euro/UK/Australia/China/Korea:
220-240V AC, 50/60Hz, T1.6AL/250V
USA/Canda/Japan:
100-120V AC, 50/60 Hz, T3.15AL/250V
Euro/UK/Australia/China/Korea:
220-240V AC, 50/60Hz, T1.6AL/250V
USA/Canda/Japan:
100-120V AC, 50/60 Hz, T3.15AL/250V
Euro/UK/Australia/China/Korea:
220-240V AC, 50/60Hz, T1.6AL/250V
USA/Canda/Japan:
100-120V AC, 50/60 Hz, T6.3AL/250V
Euro/UK/Australia/China/Korea:
220-240V AC, 50/60Hz, T3.15AL/250V
Power Consumption Typical: 30 W, Maximum: 240 W Typical: 30 W, Maximum: 240 W Typical: 30 W, Maximum: 400 W Typical: 160 W, Maximum: 720 W
SMPS Thermal protection, over-current protection Thermal protection, over-current protection Thermal protection, over-current protection Thermal protection, over-current protection
Power Amp Protection
Clip limiting, thermal protection,
DC output protection,
over-current / short-circuit protection
Clip limiting, thermal protection,
DC output protection,
over-current / short-circuit protection
Clip limiting, thermal protection,
DC output protection,
over-current / short-circuit protection
Clip limiting, thermal protection,
DC output protection,
over-current / short-circuit protection
Power Amp
Class D Class D Class D Class D
Min. Load
4 ohms 4 ohms 4 ohms 4 ohms
Power Output (1% THD) 200 W at 4 ohms / 130 W at 8 ohms 200 W at 4 ohms / 130 W at 8 ohms 280 W at 4 ohms / 180 W at 8 ohms 600 W at 4 ohms / 350 W at 8 ohms
Noise
-75 dBu -75 dBu -75 dBu -75 dBu
AUX Input
- - 3.5 mm (
1
/
8
") stereo jack 3.5 mm (
1
/
8
") stereo jack
EQ
Bass: +/- 15 dB at 80 Hz, shelving
Middle: +/- 15 dB at 400 Hz
Treble: +/- 15 dB at 4.2 kHz, shelving
Bass: +/- 15 dB at 80 Hz, shelving
Middle: +/- 15 dB at 400 Hz
Treble: +/- 15 dB at 4.2 kHz, shelving
Bass: +/- 15 dB at 80 Hz, shelving
Middle: +/- 15 dB at 400 Hz
Treble: +/- 15 dB at 4.2 kHz, shelving
Bass: +/- 15 dB at 80 Hz, shelving
Mid low : +/- 15 dB at 600 Hz
Mid high : +/- 15 dB at 2.5 kHz
Treble: +/- 15 dB at 5 kHz, shelving
Input Impedance
> 10 Mohms > 10 Mohms > 10 Mohms > 10 Mohms
XLR DI Out
Pin 1: Ground, Pin 2: Signal +, Pin 3: Signal -
1 kohms output impedance
Noise oor: -104.3 dBu
Noise oor w/sig (nom.): -88 dBu
Pin 1: Ground, Pin 2: Signal +, Pin 3: Signal -
1 kohms output impedance
Noise oor: -104.3 dBu
Noise oor w/sig (nom.): -88 dBu
Pin 1: Ground, Pin 2: Signal +, Pin 3: Signal -
1 kohms output impedance
Noise oor: -104.3 dBu
Noise oor w/sig (nom.): -88 dBu
Pin 1: Ground, Pin 2: Signal +, Pin 3: Signal -
1 kohms output impedance
Noise oor: -104.3 dBu
Noise oor w/sig (nom.): -88 dBu
System Requirements
-
• Windows 7, Windows 8 / 8.1, Windows 10
• Mac OS X 10.6 or later
• iOS 6 or later (adapter not included)
• Android 4.2 or later that supports USB/
OTG mode (adapter not included)
• Windows 7, Windows 8 / 8.1, Windows 10
• Mac OS X 10.6 or later
• iOS 6 or later (adapter not included)
• Android 4.2 or later that supports USB/
OTG mode (adapter not included)
• Windows 7, Windows 8 / 8.1, Windows 10
• Mac OS X 10.6 or later
• iOS 6 or later (adapter not included)
• Android 4.2 or later that supports USB/
OTG mode (adapter not included)
Bit Rate
- 16 Bit 16 Bit 16 Bit
Sampling Rate
- 44.1 kHz / 48 kHz 44.1 kHz / 48 kHz 44.1 kHz / 48 kHz
A/D converter dynamic range
- 88.5 dB 88.5 dB 88.5 dB
D/A converter dynamic range
- 92 dB 92 dB 92 dB
A/D SNR
- 90 dB 90 dB 90 dB
D/A SNR
- 93 dB 93 dB 93 dB
Silent SNR
- 98 dB 98 dB 98 dB
USB Version
- USB 2.0 USB 2.0 USB 2.0
Dimensions (L x W x H)
170 x 118 x 45.5 mm
6
11
/
16
" x 4
41
/
64
" x 1
51
/
64
"
170 x 118 x 45.5 mm
6
11
/
16
" x 4
41
/
64
" x 1
51
/
64
"
200 x 137 x 49 mm
7
7
/
8
" x 5
25
/
64
" x 1
59
/
64
"
340 x 250 x 100 mm
13
25
/
64
" x 9
27
/
32
" x 3
15
/
16
"
Weight
0.96 kg / 2.12 lbs 0.98 kg / 2.16 lbs 1.35 kg / 2.98 lbs 3.01 kg / 6.62 lbs
Note: The manufacturer reserves the right to change these specications without notice.
USA DISTRIBUTION: W-Music Distribution USA | [email protected] | 629.202.6790
CHINESE DISTRIBUTION: Warwick Music Equipment Trading (Shanghai) Co. Ltd. | [email protected] | [phone]
NORTH EUROPEAN DISTRIBUTION: W-Music Distribution | www.w-distribution.de | [email protected]
Headquarters: Warwick GmbH & Co. Music Equipment KG | 08258 Markneukirchen / Germany | [phone] / 555 - 0
Family Owned • Solar Powered • Sustainably Manufactured in a Green Environment
