Welcome to the WatchGuard Video 4RE Vehicle Installation Instructions. This guide is designed
to provide basic information and instructions for installing the WatchGuard Video 4RE DVR and
its related components in a vehicle.
About this document
The 4RE Vehicle Installation Instructions covers the following topics:
lPreparing for a vehicle installation, including:
oPre-install checklist
oStandard installation parts lists and recommended tools
oInstallation best practices
lInstalling WatchGuard Video equipment in a vehicle, including:
oRecommended installation workflow
oCameras
o4RE DVR
oVISTA WiFi
oWireless radio
oMicrophones
oRelated components and cables
lTesting the installation
The images in this document are representative of what you could experience while installing.
They are meant to serve as a guide.
This guide contains general recommended instructions for installing a WatchGuard Video 4RE
system in a vehicle. This document is not an exclusive or comprehensive blueprint for any
particular vehicle installation. If you have a question about installing the system in a particular
vehicle, contact WatchGuard Video Customer Service.
Important! This document assumes knowledge of standard 12-volt vehicle
installation best practices. It is meant to guide a technician through the specifics
of installing WatchGuard Video equipment.
4RE Vehicle Installation
WGD00085 Revision C 5

Introduction
Related documents and information
For further information related to installing WatchGuard Video equipment in a vehicle that is
not covered by the 4RE Vehicle Installation Instructions, see the following documents:
l4RE Installation Poster
lWatchGuard Video Bracket Guides
lHiFi Microphone User Guide
l4RE In-Car DVR User Guide
lVISTA Wearable Camera User Guide
lEvidence Library 4 Web User Guide
lEvidence Library Express 3.5 User Guide
Installation training
WatchGuard Video holds factory training courses several times per year for installers to become
certified in WatchGuard Video equipment installation. For more information and to register, go
to http://watchguardvideo.com/training.
64RE Vehicle Installation
WGD00085 Revision C

Preparing for the Installation
Overview
This section includes information to help you prepare for the in-vehicle installation of the 4RE
DVR and its related components. The section includes:
lPre-installation checklist: Complete the items on this checklist before starting the
installation (page 9)
lStandard installation parts lists: Contains an example of a parts list for a standard 4RE
vehicle installation (page 10)
lRecommended tools list: Shows a list of tools, including some specialized items, you should
have at hand before beginning the installation (page 12)
lInstallation required practices: Lists a number of best practices that WatchGuard Video
requires you to follow as you perform the vehicle installation (page 13)
84RE Vehicle Installation
WGD00085 Revision C

Before Installing the 4RE System in a Vehicle
Before Installing the 4RE System in a Vehicle
You can use the following checklist to help you prepare for a successful 4RE system installation
in a vehicle:
Prepare to document the installation for a first-time vehicle (year and/or model), as applicable
Gather all necessary tools for the installation (page 12)
Remove any old video equipment, as applicable
Verify that you have received all the components for the 4RE system that you are installing
(page 10)
Note: If you have any missing or damaged parts, contact WatchGuard
Video Customer Service.
Make sure the mounting brackets are the correct type for the specific vehicle
Note: When installing brackets, follow the instructions included with the
bracket. If you need a copy of the bracket instructions, contact
WatchGuard Video Customer Service.
Determine the installation locations for all components (including brackets and cables)
Determine the wire connection points, for example, vehicle battery location, emergency
light input, brake input, auxiliary input
Roughly lay out the main components in their installation locations to test positioning
Read through the Installation Required Practices (page 13) and add them to your installation
plan
Tip: Use the 4RE installation overview poster as a reference for the installation.
You can download a copy of the installation poster from the WatchGuard Video
website: http://cs.watchguardvideo.com/downloads/
4RE Vehicle Installation
WGD00085 Revision C 9

Preparing for the Installation
Standard Parts Lists
Note: The following parts lists are included as examples. Your installation
equipment order includes the actual parts list for your installation. If you need
additional parts, contact WatchGuard Video Customer Service.
The following table lists the standard parts included for a 4RE system installation (with wireless
upload) in a vehicle:
Qty Part Number Description
1 WGA00428-101 MikroTik Configured Wireless Kit, 4RE In-Car 802.11n (Radio,
Antenna, PoE, 2-10' Ethernet Cables)
1 WGP01394-001 Cable, WiFi Vehicle Antenna Mount, NMO, Drill 3/4" Hole, 17' long
1 WGA00480-101 4RE, HD DVR, Gen 2, 200GB HDD
1 WGA00370-200 4RE, Remote Display Control Panel, Gen 3
1 WGA00496 Front Camera, 4RE, HD Zero Sightline (ZSL)
Or 1 WGA00543 Front Camera, 4RE, HD Panoramic
Or 1 WGA00500 Front Camera, 4RE, HD Mini Zoom
1 WGP01760-200 Camera, Infrared Analog, WMv.2, 114 Degree, 2-Pin Connector
1 WGP01903-001 Cable, 4RE, HDMI, (HD Mini Zoom, Panoramic, ZSL) Straight, 15'
1 WGP01832 Cable, 4RE, HDMI, Port 2 IR Camera, 2-Pin Connect, Straight, 16'
(5000mm)
1 WGP02055-KIT R/A Adapter KIT, HDMI Cables, Dual Mount Bracket, 4RE DVR
1 WGA00382-100 Cable, 4RE, HDMI/Mini, Display ONLY, Straight, 15'
1 WGA00420 Bracket Kit, 4RE, Display, w/ Diamond 1" Ball Mounts & 2" RAM
1 WGP01459-
008-KIT
Bracket Kit, 4RE, Display, Universal Visor Post (Ford PI SUV & Sedan)
1 WGP01443-
001-KIT
Bracket Kit, 4RE, DVR, Universal
1 WGP01487-KIT Bracket Kit, 4RE, DVR, Console Faceplate, 2"
1 WGP362 GPS Antenna, Magnetic Mount
1 WGP02073-
300-KIT
Cable Assembly, DV-1C/4RE, Power/Input, R/A 24'
1 WGA00475-
KIT1-V2
Hi-Fi Microphone Kit 1v.2 (Transmitter, Cradle, Belt clip, Pivot clip, 3'
+ 12' antenna)
1 WGP01475 Bracket, Hi-Fi Microphone, Universal
1 WGA00510-005 Cable Assembly, DVR to Hi-Fi MIC, 180"
10 4RE Vehicle Installation
WGD00085 Revision C

VISTA WiFi standard parts list
Qty Part Number Description
1 WGP412 Cabin Microphone - 7'
1 WGP412-300 Cabin Microphone Extension Cable - 12'
1 WGD00085-KIT Kit, 4RE DVR Installation Kit
1 WGD00089-KIT Kit, 4RE In-Car Video System User Guide
1 WGD00122 Document, Groove Setup Instructions
VISTA WiFi standard parts list
The following table lists the standard parts included when adding integrated VISTA WiFi to the
4RE system installation in a vehicle:
Qty Part Number Description
1 WGA00600 VISTA HD, WiFi Extended Wearable Camera
1 WGA00586-KIT VISTA HD, WiFi Charging Radio Base Kit, incl. Power and Cables
1 WGA00574 4RE, VISTA HD WiFi, Smart PoE Switch
1 WGP02225-203-KIT Bracket, VISTA WiFi base Universal, All-In-One, with Screws
1 WGP02225-202-KIT Bracket Kit, Wi-Fi Base, Universal w/ screws
4RE Vehicle Installation
WGD00085 Revision C 11

Preparing for the Installation
Recommended Tools
The following tools are recommended for installing the 4RE DVR and its related components in a
vehicle:
lDrill and bits, including 3/4-inch bit for antenna mounting
lCoarse sandpaper, 60 or 80 grain
l10-30 feet of 16-20 gauge primary wire for extending input cable connections if necessary
lWire strippers
lWire crimpers
lVarious wrenches and sockets, including 24mm or 15/16-inch open-ended wrench
lPliers
lUtility knife
lTorx® screwdrivers or bits, sizes T20, T15, and T10
l1/16-inch hex screwdriver or Allen® wrench
lElectrical tape and/or heat-shrink tubing
lZip ties
lHand-held butane torch or lighter (Optional)
lLoctite® 312 adhesive and primer
l3M™ Scotch® Super 33+™ tape
12 4RE Vehicle Installation
WGD00085 Revision C

Installation Required Practices
Installation Required Practices
Important! These practices are required by WatchGuard Video. Using them
helps you have a more successful installation experience.
Cables
HDMI cables
Important! The HDMI cables included with the WatchGuard Video installation
kits are customized to be as rugged as possible; however, HDMIcables are very
susceptible to damage. They do not work if kinked or pinched.
Keep the following required practices in mind when working with the system HDMI cables:
lBe careful of cable bends—use no more than a soft S-bend
lLeave the plastic caps on the cable ends until you are ready to connect them to a component
lUse the 10 VELCRO® strips included with each system when you install the HDMIcables
lIf you use zip ties on HDMI cables, make the loops loose enough to allow the cable or cable
bundle to barely spin in the loop
Zip ties that are pulled too tight damage HDMIcables. Be careful not to damage the HDMI
cables if you use a zip tie gun.
Tip: If you are mounting the 4RE DVR in the console, you may need to use the
HDMI right-angle adapter kit to avoid making sharp bends in the HDMI cables
where they connect to the 4RE DVR. For more information and to order the kit,
contact WatchGuard Video Customer Service.
Pulling cables
Pulling cables in the vehicle can be difficult and can damage the cables. If you move a system
from one vehicle to another, consider ordering and installing new cables.
Cameras
Front camera installation
If you are mounting the front camera on a puck:
nInstall the puck on the windshield FIRST to allow the glue to dry.
4RE Vehicle Installation
WGD00085 Revision C 13

Preparing for the Installation
Tip: You can use a hand-held butane torch or lighter to heat the puck. This can
help speed up the installation process (page 21).
Connections
nALWAYS butt-splice and crimp wire connections.
Important! DO NOT use 3M™ ScotchLok™ or similar types of
connectors.
nUse 3M Scotch® Super 33+™ tape to cover any soldered electrical connections.
HiFi Microphone antenna
nALWAYS position and install the HiFi Microphone (HiFi Mic) antenna horizontally.
The antenna inside the HiFi Mic transmitter is horizontal. For good performance, the HiFi Mic
antenna needs to be mounted horizontally to match.
Warning! DO NOT follow the manufacturer's online specifications for installing
the antenna vertically. If you mount the antenna vertically, the HiFi Mic loses 90
percent of its operational range.
Power
nWire power to the battery.
The battery is the cleanest source of power in the vehicle.
Wireless radio
nALWAYS mount the wireless radio in a position where you can easily see its LEDs.
Access to the LEDs is needed for diagnostic purposes.
Important! Do not mount the wireless radio in a location that is difficult to
access, for example, in the console.
14 4RE Vehicle Installation
WGD00085 Revision C

Installing the 4RE System
Installing the 4RE System
In this section...
lRecommended installation workflow (page 17)
lInstallation information and procedures for:
oFront and secondary cameras (page 21)
o4RE DVR (page 27) and its display (page 26)
oPoE (power over Ethernet) adapter (page 35) and switch (page 37)
oSmart Power Switch (page 40)
oWireless radio and its antenna (page 29)
oWireless and cabin microphones (page 44)
oVISTA WiFi Base (page 43)
oGPS antenna (page 46)
oConnecting the system to external inputs (page 47)
oConnecting power to the 4RE DVR (page 49)
oConnecting power to the Smart Power Switch (page 41)
lTesting the 4RE DVR installation (page 51)
4RE Vehicle Installation
WGD00085 Revision C 15

Installing the 4RE System
Overview
This section includes a full system installation workflow (page 17). WatchGuard Video
recommends that you follow this workflow for best results.
It also includes individual sections for installing the following components:
lFront and secondary cameras (page 21)
l4RE DVR (page 27) and its display (page 26)
lPoE (power over Ethernet) adapter (page 35) and switch (page 37)
lSmart Power Switch (page 40)
lWireless radio and its antenna (page 29)
lWireless and cabin microphones (page 44)
lVISTA WiFi Base (page 43)
lGPS antenna (page 46)
lConnecting the system to external inputs (page 47)
lConnecting power to the 4RE DVR (page 49)
lConnecting power to the Smart Power Switch (page 41)
The final section provides instructions for testing the 4RE DVR installation (page 51).
16 4RE Vehicle Installation
WGD00085 Revision C

Recommended Installation Workflow
Recommended Installation Workflow
The following steps make up a recommended workflow for installing the 4RE DVRand its related
components:
Warning! Only connect cables when this workflow instructs you to. Connecting
cables out of sequence can damage components.
1. Complete all items in the Before Installing the 4RE System in a Vehicle checklist (page 9).
2. Remove vehicle panels, as needed.
3. Remove cables from their packaging, and roughly lay them throughout the vehicle to verify
routing and length.
Note: If a cable is too short, contact WatchGuard Video customer service
for a longer cable.
4. Install the front camera (page 21):
a. If you are using a puck (rearview mirror button), glue the puck to the windshield.
(page 21)
If you are using a front camera bracket, install the bracket then attach the camera
to it.
b. Connect the HDMIcable to the front camera then run it to the location where you will
install the 4RE DVR, but DONOT connect the cable to the 4RE.
5. Install the 4RE Display (page 26):
a. Position and install the display bracket.
b. Install the bracket-side RAM® ball on the display bracket.
c. On the back of the display, connect the HDMI cable.
d. Install the display-side RAM bracket and ball on the back of the display.
e. Attach the display to the display bracket using the RAMball mount.
f. Run the HDMI cable to the DVR location, but DO NOT connect it to the 4RE.
6. Mount the 4RE DVR (page 27):
a. Install the DVR bracket.
b. Position and loosely install the DVR, but DO NOTconnect cables to it.
4RE Vehicle Installation
WGD00085 Revision C 17

Installing the 4RE System
7. If you have a wireless radio kit, position and install (but DO NOT connect cables):
a. PoE (power over Ethernet) adapter (page 35) or PoE switch (page 37)
Note: If you have a switch in your set of components to be installed,
you should install the switch, not the adapter.
b. Wireless radio (page 29)
If you have a wireless radio kit AND a VISTAWiFi kit, position and install (but DONOT
connect cables):
a. Smart Power Switch (page 40)
b. Wireless radio (page 29)
If you have a VISTA WiFi kit but NO wireless radio kit, position and install (but DO NOT
connect cables):
oSmart Power Switch (page 40)
If you have a mobile data computer (MDC) kit, and/or a modem, AND a
VISTAWiFi kit, position and install (but DO NOT connect cables):
oSmart Power Switch (page 40)
If you have an MDC kit, and/or a modem, but NO VISTA WiFi kit, position and install
(but DO NOT connect cables):
oPoE switch (page 37)
8. If you have a wireless radio kit, install the wireless radio antenna and the radio-to-4RE
Ethernet cables:
a. Mount (drilled, magnetic, or trunk mount) the wireless radio antenna cable then run it to
the wireless radio. (page 30)
b. Connect the antenna cable to the wireless radio.
c. Connect an Ethernet cable from the wireless radio to the Radio connector port on the PoE
adapter/switch or the Smart Power Switch.
d. Connect an Ethernet cable from the DVR connector port on the PoE adapter/switch or the
Smart Power Switch to the Ethernet port on the 4RE DVR.
9. If you have a VISTA WiFi kit but NO wireless radio kit, connect an Ethernet cable from
the DVR connector port on the Smart Power Switch to the Ethernet port on the 4RE DVR.
10. If you have an MDC kit, connect an Ethernet cable from one of the following switch
connector ports to the MDC/laptop:
oPoE switch: One of the numbered connector ports (for example, Port 1)
oSmart Power Switch:Ethernet connector port
11. If you have a modem, connect an Ethernet cable from one of the following switch
connector ports to the modem:
oPoE switch: One of the numbered connector ports (for example, Port 2)
oSmart Power Switch:Base 2 or Ethernet connector port (whichever is available)
18 4RE Vehicle Installation
WGD00085 Revision C

Recommended Installation Workflow
12. If you have a HiFi Microphone kit, install the HiFi Mic and its related components (page
44):
a. Position and install the HiFi Mic antenna on the windshield.
Note: You may need to install two HiFi Mics in some vehicles. For
information on antenna placement in this case, see the HiFi
Microphone User Guide.
b. Install the HiFi Mic bracket and attach the HiFi Mic base to it.
c. Connect the HiFi Mic antenna cable to the HiFi Mic base.
d. Connect the HiFi Mic cable to the HiFi Mic base then run it to the 4RE DVR location (but DO
NOT connect the cable).
13. If you have a VISTA WiFi kit, install the VISTA WiFi Base and its related components
(page 43):
a. Position and install the VISTA WiFi antenna on the windshield.
b. Install the VISTA WiFi bracket and attach the VISTA WiFi Base to it.
c. Connect the VISTA WiFi antenna cable to the VISTA WiFi Base.
d. Connect the VISTA WiFi cable to the VISTA WiFi Base, run it to the Smart Power Switch,
then connect it to the Base 1 connector port on the switch.
14. Install the cabin microphone and run its cable to the 4RE DVR location (but DO NOT connect
the cable). (page 45)
15. Install the GPS antenna and run its cable to the 4RE DVR location (but DO NOT connect the
cable). (page 46)
16. Install the cabin camera and any other secondary cameras, then run their cables to the 4RE
DVR location (but DONOT connect the cables). (page 24)
17. Position the external inputs cable part of the power and external inputs harness (page 47):
a. Run the DVR connector end of the power and external inputs harness to the 4RE DVR
location, but DONOT connect the harness to the 4RE.
b. Run the external inputs cable to the best location for the vehicle, according to your
installation plan.
c. If you installed a PoE adapter (page 35) or a PoE switch (page 37), connect the
orange and brown wires from the external inputs cable to the appropriate component.
d. Connect each remaining sense wire in the external inputs cable to the corresponding
external device input wire, as needed. (page 47)
18. Install the system power cable part of the power and external inputs harness (but DONOT
insert the 7.5 amp fuse in the fuse holder) (page 49):
a. Run the power cable to the vehicle battery location.
b. Connect the red and black wire extensions to the red and black (and drain) wires in the
power cable.
c. Connect the red and black ring terminals to the appropriate vehicle battery posts, but
DONOTinsert the 7.5 amp fuse in the fuse holder.
4RE Vehicle Installation
WGD00085 Revision C 19

Installing the 4RE System
19. If you installed a Smart Power Switch, install the Smart Power Switch power cable (but
DONOT insert the 7.5 amp fuse in the fuse holder) (page 41).
a. Position the Smart Power Switch end of the power cable near the Smart Power Switch
location, but DO NOT connect it to the switch.
b. Run the power cable to the shut-off timer location.
c. Connect the red and black wire extensions to the red and black (and drain) wires in the
power cable, as needed.
d. Connect the red and black ring terminals to the appropriate shut-off timer connections, as
needed, but DO NOT insert the 7.5 amp fuse in the fuse holder.
20. Connect the following cables to the 4RE DVR, as applicable:
a. Cabin microphone cable to the Cab Mic connector port
b. Display HDMI cable to the Display connector port
c. All camera cables to their appropriate connector ports
d. HiFi Microphone cable to the Wireless Mic connector port
e. GPS cable to the GPS connector port
Note: If you are mounting the 4RE DVR in the console, you may need to
use the HDMI right-angle adapter kit to avoid making sharp bends in the
HDMI cables where they connect to the 4RE DVR. For more information
and to order the kit, contact WatchGuard Video Customer Service.
21. If you installed a Smart Power Switch, connect the Smart Power Switch power cable to
the +12 VDC connector port on the switch.
22. Connect the system power and external inputs harness to the External Inputs/Power
connector port on the 4RE DVR.
23. Insert the 7.5 amp fuse into the Smart Power Switch power cable fuse holder.
24. Insert the 7.5 amp fuse into the system power cable fuse holder.
25. Test the installation (page 51).
20 4RE Vehicle Installation
WGD00085 Revision C
Other manuals for 4RE
2
Table of contents
Other Watchguard DVR manuals
