WaterRower M1 SERIES User manual

Place handle into the most forward position near the Forward
Riser Pulley.
Remove the handle rest bolts.
Pivot back the footboard. Remove the cover from the rower to expose the top deck.
Remove the handle. To do this;
a. Unclip the bungee cord from the recoil strap. Gently pull the handle keeping tension on the recoil belt.
The recoil belt will wind around the paddle shaft underneath the clutch.
REPLACING THE FORWARD RISER
STEP 1 STEP 2
STEP 3 STEP 4
STEP 5
WRM7075

Remove the handle, (Continued);
b. Using a 1/8 allen key, remove the bolt joining the handle to the clutch.
c. Pull the handle free from the clutch.
Using the 5mm ratchet supplied with the machine, remove the bolts and washers (2 on either side) joining the Font End Pad to each
rail.
Using the 5mm ratchet supplied with the machine, remove the 4 tie rods bolts. Be sure to keep an eye on the barrel nuts that will fall
out from underneath the Top Deck when removing the top tie rod bolts. The bottom tie rod barrel nuts will stay in place.
REPLACING THE FORWARD RISER
STEP 5 CONT.
STEP 6
STEP 7
WRM7075

Remove the Forward Riser Assembly Replace with the new Forward Riser Assembly
To secure the replacement Forward Riser in place, screw back in the 4 bolts and washers securing the Front End pad to each rail.
We recommend leaving these slightly loose in case any adjustment is needed when securing the tie rods.
Replace all 4 tie rods, the lower tie rods should screw straight in
to the housed barrel nuts.
The upper tie rods require holding the barrel nut in place to screw
in the tie rod.
REPLACING THE FORWARD RISER
STEP 8 STEP 9
STEP 10
STEP 11
WRM7075

Replace the handle, to do this (please see this link to a video on replacing the handle);
a. Ensure the handle is the correct way around before threading the strap through the end cap and over the Forward
Riser Pulley.
b. Guide the handle strap over the Forward Riser pulley, underneath the top deck and on the inside of the top guide pulley.
c. Thread it through the openings in the clutch and secure the handle by tightening the small bolt with the 1/8 allen key.
d. Once the handle is secure, gently pull on the recoil belt to wind the handle around the clutch. The handle must reach its
most forward position, up against the Forward Riser.
REPLACING THE FORWARD RISER
STEP 12a
STEP 12b STEP 12c
STEP 12d
WRM7075

Swing the footboard back into position towards the tank and replace the handle rests and bolts.
Be sure to tighten the all bolts on the rower, especially the bolts joining the front end pad to each rail which were left loose from
Step 10.
Replace the tank cover plate.
REPLACING THE FORWARD RISER
STEP 14
STEP 15
Ensure the recoil belt is straight and aligned over the 2 guide pulleys on the Forward Riser.
Reconnect the bungee cord to the recoil belt.
