WaterSoft CD24 User manual

Cabinet Softener Manual
Installation / Operation Manual

2
www.watersoftinc.com
Online at
Register Your Product
Softener Specications....................................................................... Page 3
Softener Installation........................................................................... Page 5
Start Up Procedure.............................................................................. Page 10
Master Programming.......................................................................... Page 13
Utilizing Bluetooth............................................................................... Page 14
Powerhead Assembly.......................................................................... Page 17
Valve Body Assembly........................................................................... Page 18
Cabinet Body Assembly....................................................................... Page 19
Bypass Assembly.................................................................................. Page 20
Additional Information........................................................................ Page 21
Troubleshooting................................................................................... Page 23
Error Codes............................................................................................ Page 25
Warranty................................................................................................ Page 27
FCC Compliance Statement:
http://www.chandlersystemsinc.com/files/FCC_Compliance_Statement.pdf
Industry Canada Compliance Statement:
http://www.chandlersystemsinc.com/files/Industry_Canada_Compliance_Statement.pdf
One or more features of this product are covered by U.S. patents, visit http://www.watersoftinc.com/patents.php
for more information.

3
WARNING
Lubricants
Do NOT use Vaseline, oils, hydrocarbon lubricants or spray silicone anywhere! Petroleum base lubricants
will cause swelling of o-rings and seals. The use of other lubricants may attack plastic Noryl®. It is recom-
mended that Dow Corning® silicone grease be used as a lubricant for all control valves. Dow Corning® 7
Release Compound is used in the manufacture of Chandler Systems control valves. (Part # LT-150)
Sealants
Pipe dope and liquid thread sealers may contain a carrier that attacks some plastic materials. It is recom-
mended that Teon® tape be used to seal plastic Noryl® threaded ttings.
Res-Up
The use of Res-Up or any other resin cleaners is prohibited. These cause deterioration of the control valve
and VOIDS warranty.
Softener Specications
General Specications CD24 CD32
Grains Capacity / Lbs Salt Used* per regeneration 20,000 / 7.5 27,000 / 9
Maximum Raw Water Hardness (grains) 50 75
Maximum Clear Iron / Manganese (ppm) 3 5
Exchange Resin (cu ft ) .75 1.0
Mineral Tank (polyglass) 9 x 35 9 x 35
Service Flow Rate** (gpm) 10.0 11.0
Backwash Flow Rate (gpm) 2.0 2.0
Gallons Used / Regeneration 86 88
Space Required 23x14x 45 23x14x45
Approximate Shipping Weight (lbs) 88 100

4
PLEASE NOTE THESE SPECIFICATIONS BEFORE PROCEEDING
OPERATING PRESSURE RANGE : 20 - 125 PSI
OPERATING TEMPERATURE RANGE : 33º F - 120º F
INLET / OUTLET PIPE SIZE : 3/4: FNPT
PLEASE COMPLY WITH ALL APPLICABLE PLUMBING CODES
PROTECT THE SOFTENER AND PIPING FROM FREEZING TEMPERATURES
Please read the entire Owner’s Manual and Instruction before installation.
This Owner’s Manual must stay with the unit.
-How A Water Softener Works-
Water hardness is derived from Calcium and Magnesium minerals that have been dissolved into the water
under the earth’s surface. These minerals are found in limestone deposits and are the source of hard water.
The amount of hardness in a given water supply is dependent upon the quantity of Calcium and Magne-
sium present and the length of time water has been in contact with them. This can vary dramatically from
well-to-well and, for this reason, a water analysis is imperative in order to determine the proper treatment
method. The degree of hardness increases as the concentration of Calcium and Magnesium “ions” increase
and is measured in Grains Per Gallon (gpg).
The problem of hard water in the home / business comes to light in many facets of daily use. Water spots
and scum left behind on bathtubs, xtures and showers; wear and tear on appliances; calcium build-up
in hot water heaters and piping; and, greater amounts of soap and detergents being used are just a few
examples.
The modern water softener is designed to reduce hardness ions and their unpleasant side eects. Special
resin beads in the softener mineral tank are used to change hard water into soft water. The surfaces of
these beads are covered with sodium ions. As hard water enters the mineral tank and comes into contact
with the resin, an exchange of ions takes place as dissolved Calcium and Magnesium ions cling to the resin
surface and sodium ions take their place, thus softening the water. This process is called Ion Exchange.
Over time, the sodium ions used for the exchange process become depleted and must be replenished.
The water softener provides a Regeneration process whereby brine solution enters the mineral tank, driv-
ing-o the collected hardness ions and replenishes the surface of the resin beads with more sodium ions.
This process is automatically initiated by the control valve on the mineral tank. The regeneration process
has ve basic cycles as follows:
1. Backwash - The control valve directs the water ow in a reverse direction through the mineral tank,
separating the resin beads and ushing any accumulated particles to a waste drain.
2. Brine & Rinse - In the rst part of this cycle, the control valve directs brine solution downward through
the mineral tank, driving-o collected hardness ions and replenishing the resin beads with sodium ions.
The second part of the cycle rinses hardness ions and excess brine from the mineral tank to the waste
drain.
3. Rapid Rinse - The control valve directs the water ow downward, settling and recompacting the resin
bed.
4. Brine Rell - The control valve directs fresh water into the salt compartment to create new brine solu-
tion for the next scheduled regeneration.
5. Service - This is the normal “operating” cycle where hard water enters the mineral tank, comes into con
tact with the resin beads and exchanges hardness ions for sodium ions - the water then becomes “soft”
and ready for use.
Softener Specications

5
-Pre-Installation Check List-
A water test should always be performed in order to determine total water hardness (in gpg) and total
dissolved iron (in parts per million - ppm). This is critical for proper equipment selection, sizing and for
determining the program for regeneration frequency. If heavy concentrations of iron (above 5 ppm), iron
coloration, iron bacteria or sediment are present, ltration prior to the softener will most generally be re-
quired. Certain states may require a licensed plumber for installation.
Note: Flexible water supply connectors and exible drain line tubing may not be allowed in you locale.
Please check with local plumbing code ocials prior to installation.
Installation Requirements
• A level oor position ahead of piping into water heater.
• Unit must be installed at least 10’ ahead of the inlet to a water heater to prevent damage due to back-up
of hot water.
• DO NOT install the unit in an area of direct sunlight or where freezing temperatures may occur!
(See Installation Diagrams for proper placement and plumbing connections.)
-Major System Components-
1. Cabinet Tank - This tank holds the salt that is added to the softener. This salt is dissolved with water to
form a brine solution used in the softener regeneration process.
2. Resin Tank - This tank contains the ion exchange resin media. Water ows through the resin tank under
pressure to come into contact with the resin for water softening.
3. Control Valve - The valve directs water through the resin tank for water softening and controls the ow
of water / brine for the regeneration process.
Installation
CITY WATER
INLET
WELL
INLET
RELIEF VALVE
MUST BE
INSTALLED
PRESSURE
TANK
WATER
METER
FILTER
(If req.)
WATER
HEATER
PRESSURE RELIEF VALVE
(To drain)
PUMP
HARD WATER
TO OUTSIDE FAUCETS
HOT SOFT WATER
COLD SOFT WATER
SERVICE
TWO TANK SETUP
(Incoming Water from Left-Side)
GROUNDED & UNSWITCHED
115- VOLT OUTLET
DRAIN LINES
REQUIRED
4" AIR GAP
CABINET
SOFTENER

6
Removal of Top Cabinet Lid
PUSH CLIPS
Installation

7
-Softener Location / Other Requirements-
• Locate the unit near an unswitched, 120 volt / 60 Hz grounded electrical outlet.
• Check for distance and proper drain installation (e.g. oor drain, washing machine standpipe).
• Determine type and size of piping required for softener connection (e.g. copper, galvanized, PVC plastic).
Note
• If household plumbing is galvanized and you intend to make the installation with copper (or vise versa),
obtain di-electric unions to prevent dissimilar metal corrosion.
• Where the drain line is elevated above the control valve or exceeds 20 feet in length to reach the drain,
use 3/4" I.D. drain line tubing instead of 1/2" I.D. Drain line tubing is not included.
• All plumbing lines not requiring “soft” water should be connected “upstream” of the softener.
• The cabinet brine tank drain line is gravity ow and must discharge below the overow tting.
• The cabinet brine overow is provided as a back-up in the event the safety oat shut-o should fail, allow-
ing the brine tank to overll. This drain connection would then carry the excess water to the drain and
prevent ooding of the oor. Therefore, no liability will or can be assumed by the manufacturer of the
softener should this occur.
Caution
• If sweat soldering copper pipe (remember to always use lead free solder and ux), cover bypass valve
with wet rags to prevent heat damage to connections and control valve! If using PVC or plastic pipe prim
ers and solvent cements specically recommended for use with potable water are required.
-Installation Procedure-
- Water Supply Connections and Bypass Valve -
To allow for softener servicing, swimming pool lling or lawn sprinkling, a manual bypass valve has been
installed at the factory. The bypass allows hard water to be manually routed around the softener.
1. Position softener at desired location for installation. (See Installation Diagrams.)
2. Turn OFF main water supply and OPEN nearest faucet to relieve pressure.
3. Cut main line and install appropriate elbows and extensions. Inlet and outlet connections on the control
valve are 3/4” FNPT.
Caution: Raised arrows located on the sides of control valve body and bypass valve indicate proper direc
tion of water ow. Install inlet and outlet piping in direction of arrows. It is recommended that a
vacuum breaker be installed on the inlet plumbing.
4. Rotate bypass valve to the bypass position (position of lever is at right angle to inlet / outlet piping).
5. Turn the main supply line on to restore water service to the home.
6. OPEN nearest faucet to evacuate air and repressurize plumbing lines.
7. Check for leaks!
Installation

8
- Drain Line Connection -
1. The drain line ow control assembly is pre-assembled for your convenience. Should you choose to hard
plumb the drain line, please remove the barb tting. The ow control housing can be removed by remov
ing the clip and pulling straight out on housing.
Note: When re-installing the drain line ow control housing, be sure you hear and feel the O-Ring pop into
place before inserting the clip.
2. Install 1/2” I.D. drain line tubing (not included) from hose barb to an open drain. A 4” gap between end of
the drain line and the open drain is required to prevent waste water backow. Keep the drain line as
short as possible. An overhead drain line can be used if necessary, but should discharge below the con
trol valve. A syphon trap (taped loop) at the outlet of the drain line is advisable to keep the drain line full
and assure correct ow during backwash. Elbows or other ttings must be kept at a bare minimum.
Note: Where the drain line is elevated above the control valve or exceeds 20 feet in length, 3/4” I.D. drain
line tubing should be used.
-Brine Line and Overow Connection-
1. The brine line tubing is already installed for you.
2. Install 1/2” I.D. drain line tubing (not included) to the overow tting on brine tank located just below
the brine line.
3. Run the opposite end of brine tank drain line to a suitable drain.
- Electrical Connection and Battery Back Up-
1. Connect one end of power supply into a power cord and the other end into a 115 volt / 60 Hz receptacle.
Note : Do not plug into an outlet controlled by a wall switch or pull chain that could inadvertently be
turned o
Attach Power Cord Here
Battery Backup (optional)
1. Lift top half of cabinet and attached to the circuit board a 9 volt battery can be placed as shown.
9 Volt Battery
Installation

9
- Pressurizing The System -
1. Make certain the Control Valve is in SERVICE position.
2. Slowly rotate bypass valve to the SERVICE position. (Position of bypass lever is parallel to inlet / outlet
piping.)
3. Open the nearest faucet to evacuate air from plumbing lines.
4. Check for leaks! If water is observed leaking from bottom of bypass, close and open bypass lever several
times to seat o-rings.
5. After air is evacuated from plumbing lines, close bypass (position of bypass lever is perpendicular to the
direction of inlet pipe) on bypass valve.
- Programming The Control Valve -
Main Menu
12:00
1. To enter Main Menu, press the Menu/Enter button.
(Time of Day will ash)
2. To set the Time of Day, press the Set/Change button.
(First digit will ash) Example [12:00]
- To change digit value, press the Set/Change button.
- To accept the digit value, press the Menu/Enter button.
- Next digit will ash to begin setting.
- Once the last digit display is accepted, all digits will ash.
3. To set A.M. or P. M ., press the Menu/Enter button.
- To change digit value, press the Set/Change button. Example [ A ]
- To accept the digit value, press the Menu/Enter button.
- Once A.M. or P.M. is accepted, the next menu item will ash.
4. To set Hardness an “H” will appear to enter Compensated Hardness in grains per gallon (gpg)
Default setting is 25 gpg. Example [ H - 25]
5. To Exit Main Menu, press the Menu/Enter button.
Note: If no buttons are pressed for 60 seconds, the Main Menu will be exited automatically.
MENU / ENTER
BUTTON
SET / CHANGE
BUTTON
Installation

10
Start Up Procedure
1. Set time of day.
2. Set a.m. or p.m.
3. Set water hardness in grains per gallon (gpg).
Note : If the water contains iron and / or manganese, multiply the total parts per million (ppm) by “four”
(4) and then add to the grains per gallon (gpg) of hardness. Use this COMPENSATED HARDNESS
level when programming the regeneration frequency.
1. Set regeneration day override if other than (7) days is desired. (This is particularly useful when iron is
being treated to prevent fouling of the resin.)
2. Set regeneration time, if other than 2:00 a.m. is desired.
-Start Up Procedure-
- Disinfection -
For disinfection of your unit, please follow the Sani-System Procedure on the back of the packet provided.
1. Advance control valve to BACKWASH (cycle 1) position and allow water to run to drain for 3 to 4 minutes.
Warning : Close valve on bypass prior to selecting the backwash position. After backwash position has
been established, slightly open bypass to evacuate air from the media tank. Fully open valve
when all air is depleted. This procedure will prevent media from being uplifted into control valve.
2. Advance control valve to BRINE REFILL (cycle 4) position and allow the brine tank to ll just over the salt
grid plate.
3. Advance control valve to BRINE & RINSE (cycle 2) and allow the control valve to draw water from the
brine tank until it stops. If no draw is observed, check tightness of brine line compression ttings.
4. Advance control valve to RAPID RINSE (cycle 3) position and let run to drain for 3 - 4 minutes.
5. Advance control valve to BRINE TANK REFILL (cycle 4) position and allow the control valve to automatical
ly ll the brine tank.
Note : Control valve will advance to service position automatically.
- Filling The Brine Tank With Salt -
To expect a high level of performance and reliability, a salt manufactured specically for water softeners
must be used. Salt of this grade is virtually free from dirt and other particulates that would eventually cause
the softener to malfunction. A pellet type salt is recommended, although any high quality water softener
salt (such as solar salt) will suce. If iron is present in raw water, use of iron inhibiting salt is recommended.
The salt level will decrease after each regeneration cycle. Consequently, the salt compartment will need to
be checked and replenished periodically.
1. Fill the salt compartment with water softener salt as described above. This will be approximately 150
pounds of salt.
Warning : Do not ll salt above level of the brine well.
2. Close cabinet brine tank lid.

11
- Final Check -
1. Be certain the bypass valve is in the SERVICE position.
2. Make sure the power supply is connected to an uninterrupted 115-volt outlet.
3. Check that the time of day is set
4. Double check regeneration schedule.
5. Make nal check for leaks!
6. Fill out warranty card online at www.watersoftinc.com
7. Leave all manuals with unit.
- Operation, Care and Cleaning -
When the bypass valve is in the SERVICE position (position of bypass lever is parallel to the inlet / outlet
piping), water is directed through the water softener. Water may be bypassed by turning the lever to the
bypass position (position of bypass lever is at right angles to inlet / outlet piping). Water to the home will
bypass the softener and be untreated.
You should manually bypass the softener if :
1. The outside lines do not bypass the water softener and water is to be used for lawn sprinkling or other
similar uses.
2. Servicing the water softener.
3. A water leak from the water softener is evident.
4. Shock treating water well and piping with chlorine or other disinfectant.
- General Care and Cleaning -
1. Do not place heavy or sharp objects on water softener or cabinet.
2. Use only mild soap and warm water to clean exterior of the unit. Never use harsh, abrasive cleaners.
3. Protect the water softener and drain line from freezing.
4. Reset time for daylight saving time periods.
5. Inspect and clean the brine tank when sediment appears in the bottom of the salt compartment.
6. Always keep the brine tank supplied with good quality salt, a type designed for use in water softeners.
Start Up Procedure

12
Starting Extra Regeneration Cycle
1. To Start Delayed Extra Cycle
- Press and hold the Set/Change button for 3 seconds until the display reads ‘0000’
- Regeneration cycle will initiate at the next designated regeneration time.
2. To start Immediate Extra Cycle First complete above step.
- With Gallons Remaining Until Next Regeneration at ‘0000’,
- Press and hold the Set/Change button.
- After 3 seconds, the regeneration cycle will begin.
3. To Fast Cycle thru regeneration First complete above 2 steps.
Note:Press and hold the Set/Change button for 3 seconds to advance to the next cycle step.
Fast Cycle is not necessary unless desired to manually step through each cycle step.
(Repeat until valve returns to the home display)
Normal Operation
1. Home Display
The RS1 model will alternate the Time of Day and Gallons left until the next regeneration. The me
ter will count down to zero (0000) and then regenerate at the scheduled time set.
Softeners Default (Min)
Step 1 Backwash 10
Step 2 Brine & Rinse 60
Step 3 Rapid Rinse 10
Step 4 Brine Rell 9 lbs/ cu ft
Start Up Procedure

13
Master Programming Mode
Master Programming Mode
To enter Master Programming Mode, press and hold both buttons for 5 seconds.
Note: All Master Programming functions have been preset at the factory. Unless a change is desired, it is
NOT necessary to enter Master Programming Mode.
1. Regeneration Time ( r ) Example [ r 2A ]
- The time of day at which regeneration may take place is designated by the letter “r”.
- Default regeneration time setting for SOFTENERS is 2a
- The rst display digit indicates A.M. or P.M. To change the value, press the Set/Change button.
- Press Menu/Enter button to accept the value and move to the next digit.
- The second and third display digits indicate the hour at which the regeneration will occur.
- Change the digits with the Set/Change button and accept with the Menu/Enter button.
- After the entire display ashes, press the Menu/Enter button to move to the next menu item.
2. Regeneration Day Override (A)
- Press Menu/Enter button. This display is used to set the maximum amount of time (in days)
the unit can be in service without regeneration. This setting is identied by the
letter “A” in the left digit. Regeneration will begin at the scheduled time. A setting of zero
will cancel this feature.
- Example: Override every 7 days (A-07), default setting, or cancel setting (A-00). Maximum is 29.
3. Regeneration Cycle Step Times (Steps 1, 2, 3, 4)
Example [ 3 - 10 ]
- The next 4 displays set the duration of time in minutes for each regeneration cycle step.
- The step number which is currently modiable is indicated on the far left of the display screen.
- The number of minutes allotted for the selected backwash step is displayed on the far right.
- Change the digit values using the Set/Change and Menu/Enter buttons as described above.
Warning : Do not reduce salt settings below 9 lbs. as the water level in the brine tank will not reach the grid
plate.
4. System Capacity in Grains ( c )
- Press the Menu/Enter button. This display is used to set the system capacity in grains
and is used in conjunction with the hardness setting to calculate total gallons of treated water
available between regenerations. This option is identied by the letter “c” in the left digit.
The maximum value for this item is 399. Example: 32,000 grain capacity ( c 032 ).
5. Reserve Capacity Setting % Example (p - 25)
6. Bluetooth Enabled BE - 1 (ON)
BE - 0 (OFF)
7. Bluetooth Password BBPP is displayed for one second, then password is displayed.
8. To Exit the Master Programming Mode, press the Menu/Enter button until time of day returns.
Note: If no buttons are pressed for 60 seconds, the Master Programming Mode will be exited automatical
ly.

14
For simplied set up and control, please install the Legacy View on a compatible Bluetooth 4.0+ enabled
smart phone or tablet.
1. Download and install the Legacy View app from the Google Play Store, Apple App Store
2. Open the Legacy View app
• Choose a valve device at any time from the list of available devices to connect to by clicking on it.
• If the valve you want to connect to doesn’t show up, or there is a problem connecting to a device
you can press the “Scan for Devices” button or the Legacy View logo at any time to refresh the list
and start the process over.
• If the valve device is a BTLE valve and it has a password other than the default password, the rst
time you connect to it the app will ask you to enter the password. After entering it the rst time
you should not need to enter it again unless it changes.
3. BTLE Valve devices can be updated by the App. When the app is updated from the Google Play Store or
the Apple App Store, it may contain an updated rmware program for the valve devices. These updates
could contain new features or operational improvements. It is up to the user to allow these updates to be
sent to the valve device. Uploading a new program takes approximately 1 minute.
Dashboard
NOTE: Consult your dealer before making any changes
From the Dashboard, all items in ORANGE can be changed, while blue fields are informational only.
If you are unsure about the function of the eld click the for more information.
Utilizing Bluetooth Control

15
Set Up Utilizing Bluetooth App
Advanced Settings
NOTE: Consult your dealer before making any changes. We do not recommend changing Advanced
Settings unless you have a good understanding of the system operation.
From the Advanced Settings, all items in ORANGE with a “set” button can be changed.
For Filters:
Set Backwash Frequency
This sets the amount of day between backwash cycles
Change Time of Day (Press “SET” to set time automatically based on
device).
Set Regeneration Time
Example: For 2a.m., just type 2, choose a.m., and press ‘OK’
Note: If you have a lter and a softener the valves should be set to re-
generate at dierent times. Factory default times are 12a.m. for
lters, and 2 a.m. for softeners.

16
Status and History
From the Status and History, all items in ORANGE can be reset.
1. Start a regeneration or backwash cycle
Option 1: Click the “Regenerate Unit Now.”
Once a regeneration has been started, if you would like to force the
unit into the next cycle step click “Go to Next Regeneration Step”.
Option 2:
Touch any graph to enlarge and see
details. Enlarged graphs are able to
be zoomed in by pinching with two
fingers.
(Enlarged graph shown below)
“Regenerate Unit at Next Regen Time” button
This will take the system into a backwash cycle at the next regenera-
tion time.
Set Up Utilizing Bluetooth App
Pressing the .csv logo in the corner
will allow the graph data to be
exported and shared.
Enlarged graph showing water usage
Pressing this icon will show a list of
the data that is in the graph.

17
Powerhead Assy.
7
1
2
4
5
Motor Power Flow Meter
A
A
3
6
8
No. Part No. Description Qty.
120016X002 RS1 FRONT PLATE 1
220001X007 ENCODER WHEEL 1
3 20016X101 CABINET LEGACY BOARD ASSEMBLY 1
421001X120 MAIN GEAR 1
5 20016X002 RS1 BACK PLATE 1
6 20016X006 SIGNATURE MOTOR 1
7 20001X122 BRINE CAM 1
8 SC2 SC2, MTR SCREW 1
9 SC10 SC10 SCREW 1
10 20001X127 12V POWER SUPPLY 1
11 20016X108 20" POWER CORD 1
9
Power
Flow Meter
Motor
10
11
Ref Description Part Number Qty
1 Front Plate 20016X001 1
2 Encoder Wheel 20001X007 1
3Cabinet Legacy Board Assembly 20016X101 1
4 Main Gear 21001X120 1
5Back Plate 20016X002 1
6Motor Assy. 20016X006 1
7 Brine Cam 20001X122 1
8 SC2 SC2, Motor Screw 1
9 SC10 SC10 Screw 1
10 12V Power Supply 20001X125 1
11 Power Cord MTR-CORD-BT 1

18
Valve Body Assembly
2
1
3
13 14
12
19
20
22/23
18
4
21
9
16
17
10
11
8
15
5
6
7
6A
REF DESCRIPTION PART NO. QTY
1 Piston Assembly 20001X231 1
2Screw 20001X001 2
3Seal & Spacer Kit 20561X253 1
4 Bottom Spacer N/A 1
5DLFC Button 2.0 20251X267 1
6 Flow Control Housing 20017X100 1
7 Drain Elbow 20017X266 1
8DLFC Clip 20017X214 1
9 Brine Valve 20251X225 1
10 BLFC Assy 20001X228 1
11 Brine Line Ferrule 20251X305 1
REF DESCRIPTION PART NO. QTY
12 Injector Cap Screw 20001X226 2
13 Injector Cap 20001X223 1
14 Injector Seal 20001X224 1
15 Injector - White 20017X219 1
16 Screen 20001X222 1
17 Plug 20001X217 1
18 Basket 33000X003 1
19 Valve O-Ring 20561X205 1
20 Dist. O-Ring 20561X204 1
21 Meter Assy 20017X203 1
22 Valve Body Assy VH1-A-
RS1-D15
1

19
Cabinet Body Assembly
REF DESCRIPTION PART NO. QTY
1Cabinet Tank Base 20016X007 1
2Resin Tank 30935X000 1
3 Brine Well Assembly 20016X008 1
4 Cabinet Cap 20016X009 1
5Cabinet Lid 20016X010 1
6 Top Insert 20018X008 1
7 Front Insert 20018X009 1
8Clear 3/8” Tubing, .5ft 57005X002 1
9 Self Threading Screw 20016X015 1
10 Grid Plate 40450X106 1

20
Bypass Assembly
REF DESCRIPTION PART NO. QTY
1 D15 Bypass 20017X283 1
21” NPT 90 ° Elbow Set 20017X284 1
1
2
120017X283 D15 Bypass
220017X284 1" NPT 90° Elbow Set
