Haws H1109.8 Guide

03/20 Model H1109.8 Page 1 of 7
1455 Kleppe Lane Sparks, NV 89431-6467 [phone] Fax [phone]
E-mail: [email protected]  website: www.hawsco.com
No. 0002080252 (19)
Model H1109.8
Water Cooler
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material or
poor workmanship for a period of one year from date of shipment. HAWS liability
under this warranty shall be discharged by furnishing without charge F.O.B. HAWS
Factory any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of first class workmanship, provided that
claim is made in writing to Haws within a reasonable period after receipt of the
product. Where claims for defects are made, the defective part or parts shall be
delivered to the Company, prepaid, for inspection. HAWS will not be liable for the
cost of repairs, alterations or replacements, or for any expense connected therewith
made by the owner or his agents, except upon written authority from HAWS,
Sparks, Nevada. HAWS will not be liable for any damages caused by defective
materials or poor workmanship, except for replacements, as provided above. Buyer
agrees that HAWS shall not be liable for general, special, or consequential damages
claimed to arise under the contract of sale. The drinking fountain manufactured by
HAWS is warranted to function if installation and maintenance instructions provided
are adhered to. The units also must be used for the purpose for which they were
intended.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED,
PROVIDED OR GIVEN BY HAWS.
CAUTION! Prior to making any electrical connections, verify with a voltmeter that power from the
service panel is off.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
Haws electric water cooler’s are not designed or recommended for outdoor or corrosive
environments such as enclosed chlorinated pool areas.
Consideration must be made at the time of installation to adhere to state and/or local codes and
environmental/atmospheric conditions such as, but not limited to, dust, corrosion, freezing etc.
These conditions will void the warranty.

03/20 Model H1109.8 Page 2 of 7
RECOMMENDED TOOLS: Hack saw, pipe joint sealant, screwdriver, level, 12" adjustable
wrench, 10" pipe wrench, 5/64“ hex key wrench, 9/16”, 1/2", 7/16” socket wrench or open end
wrench.
LOCATION OF UNIT: The Model H1109.8 Cooler is a wheelchair accessible drinking water
facility. The height dimensions shown, meet current ADA requirements. When installing this
unit, local, state or federal codes should be adhered to. If height other than shown is
required, then dimensions must be adjusted accordingly.
SUPPLY LINE: The minimum recommended line size is 1/2“IPS with 30-90 psi (2-6 ATM)
flowing pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.
PLUMBING CONNECTIONS: Inlet is 3/8” O.D. tube. Waste trap outlet is female 1-1/4” IPS.
ELECTRICAL CONNECTIONS: 115VAC, 60HZ, 4.7 AMPS. Chiller wired direct to incoming
line, by others.
PARTS LIST
MODEL PACKAGE
QUANTITY
ITEMS INCLUDED
MTGFR.SM
1
Mounting Frame (Required –Sold
Separately)
3
#10 Sheet Metal Screws
HCR8
1
Chiller
H1109.8
1
Bowl Assembly
1
Package supply tubing assembly and
2 fittings
1
Panel-bowl back
1
Grille
1
Trap 1-1/4” IPS
1
Package of two each: grille
attachment, attachment clips, clip nuts,
#10 sheet metal screws and 6-32
screws
4
5/16 -18 retainer nuts
4
5/16 –18 x 1 hex head screws
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297

03/20 Model H1109.8 Page 3 of 7
INSTALLATION PROCEDURE
GENERAL NOTES:
The Model H1109.8 Water Cooler assembly requires installation of the mounting frame as
described in Steps 1 - 2, then mounting the fountain bowl assembly as described in Steps 3 - 6,
and finally completing chiller water and electrical connections and starting chiller per Steps 7 -
11. First check that all required parts are received.
Grounding may cause electrical feedback into the electric drinking fountain causing an
electrolysis, which creates a metallic taste or an increase in the metal content of the
water. This condition can be avoided by using dielectric couplings in the assembly. The
waste line, which is supplied by the installer, should also have a dielectric (plastic)
coupling to completely isolate the assembly from the building plumbing system.
NOTES:
1. For all plastic push-in type fitting connections, only connect NSF-61 copper or
plastic tubing. Stainless steel or glass tubing is not recommended. The
following assembly instructions must be followed to ensure a watertight
connection:
a. Cut tubing square and clean.
b. Mark from end of tube the length of insertion (See table below).
c. Push tube into the fitting until it bottoms out.
d. To remove, depress collet and pull tubing out.
Tube Sizes
O.D.
Tolerance
Insertion Depth
1/4”
±.005”
11/16”
3/8”
±.005”
3/4”
1/2”
±.005”
7/8”
STEP 1: Provide wall opening as detailed in Installation Drawing. Frame must be positioned
such that frame flanges overlap and butt against finished wall surface. Mounting
holes are provided for #6 sheet metal screws. After frame is positioned in wall, swing
chiller support tray into position (See Installation Drawing), align tray holes with holes
in frame and fasten with #10 sheet metal screws. Mounted frame must support 50-
pound chiller in addition to fountain weight and user generated forces.
STEP 2: Install waste, supply and electrical lines in locations shown in Installation Drawing.
Waste and supply lines may be installed for either rear or side entry. Verify proper
waste, supply, electrical and frame locations. Use level to verify horizontal and
vertical frame mounting to insure proper bowl drainage.
STEP 3: Installation Drawing shows fountain bowl, back panel and grille locations. Unpack
bowl and remove bottom plate using 5/64” hex-allen wrench. Install back panel on
frame with narrower edge to bottom. Position nut retainers into mounting frame and
use two 5/16-18x1 hex head screws partially started in outside holes to support
panel. Install bowl/bracket assembly onto panel using four 5/16-18x1 hex head
screws hand tightened. See sheet 2 of Installation Drawing for appropriate bowl
mounting pattern to use for this model.

03/20 Model H1109.8 Page 4 of 7
INSTALLATION PROCEDURE…
STEP 4: Remove 1-1/4” IPS outlet elbow from trap as supplied. Install elbow inside frame
onto waste stub-outs.
STEP 5: Assemble waste trap onto bowl strainer using seal washer provided and tighten nut
hand tight.
STEP 6: See Figure 1 for detail section view of side screw grille attachment. Unpack grille and
insert upper lip behind bottom of back panel, align sides and hold up flush to bottom
of back panel. Hold grille against wall and mark centers of grille side slots on wall.
Masking tape may be used to prevent finished wall damage from mark. Install the “s”
clips in mounting frame using #10 sheet metal screws into pre-drilled holes on lower
end of each side of frame. Tighten #10 screw while holding “s” clips centered on wall
marks. Check grille fit by installing grille and partially tightening #6-23 socket head
screws through side of grille. Insure proper panel and grille alignment, then tighten
four 5/16-18x1 hex head screws.
STEP 7: Unpack and remove chiller from carton. Remove front panel screws and panel. Do
not remove insulating putty and foam from copper tubes or Styrofoam insulation from
evaporator coil. Remove any inner packing, which may be around compressor. If
applicable, remove junction box cover and electrical knock out on lower right side of
housing. Install fittings (supplied) on chiller inlet and outlet tubes (see Installation
Drawing).
STEP 8: Thoroughly flush supply line to remove all foreign matter. Connect 1/2" IPS supply
screwdriver stop (not supplied) to stub-out in wall. Place chiller on chiller support tray
against right hand side, fully to rear, with condenser (open panel) side facing to front.,
Install supply 3/8” O.D. tubing (not supplied) between screwdriver stop and chiller
inlet. (Cut tubing to proper length, and follow general notes for proper connection
procedures for push-in type fittings). Tubing insulation is not normally required on
inlet side of chiller. Install insulated tube between fountain and chiller outlet. Open
screwdriver stop wide open while checking for leaks at all connections. Also check
waste for leaks.
FIGURE 1

03/20 Model H1109.8 Page 5 of 7
INSTALLATION PROCEDURE …
STEP 9: Adjust bubbler stream height using a small flathead screwdriver inserted through a
hole in the center of the push button for increased flow turn clockwise and for
decreased flow turn counterclockwise. If flow problems arise, see troubleshooting
guide for additional instructions to correct problem. Bubbler stream may lower during
short break-in period. Set initial stream height a little high to minimize or eliminate
the need for break-in period readjustment.
STEP 10: Verify that electrical power is off and power supply voltage, phase and cycle match
specifications printed on chiller label. In accordance with local codes, wire directly to
incoming lines at internal chiller junction box. Verify that all inner packing is removed
and hand rotate fan blade to verify free rotation. Reattach chiller front panel. Turn
power on and verify that chiller cycles off after water reaches proper temperature.
Finally check for leaks.
STEP 11: Install grille and tighten outer side screws. Verify there is chilled water out of bubbler.
MAINTENANCE
STEP 1: Periodically clean the strainer located inside the valve body. Refer to 5874 Series
Valve Manual for more information.
STEP 2: The condenser fins on chiller should be periodically cleaned with brush, air hose or
vacuum cleaner. Care should be taken not to bend or deform the condenser fins.
STEP 3: The chiller temperature control is factory set for 50º F water under normal conditions.
For colder water, adjust control clockwise. For warmer water, turn counterclockwise.
Remove front chiller panel for access to temperature control. After adjustment allow
unit to cycle off before checking outlet water temperature.
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1.
Insufficient bubbler flow.
1a.
Check that inlet screwdriver stop valve is in wide-
open position.
b.
Verify minimum 30 psi flowing supply pressure.
c.
Clean strainer. See 5874 Series Valve Manual.
d.
Adjust valve to increase flow. Use front adjust
screw or see 5874 Series Valve Manual.
2.
Water too warm or cold.
a.
Adjust chiller temperature control, clockwise for
colder water.
For more information about Haws products, see our website: www.hawsco.com
© 2020 Haws®Corporation –All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

STRAINER ASSEMBLY
BACK PANEL
BUTTON, PUSH, FLANGED, ASSY
BUBBLER HEAD
BOTTOM PLATE
BUTTON, PUSH, FLANGED, WITH VALVE
PARTS BREAKDOWN
MOUNTING FRAME
CHILLER
8
1
3
4
5
7
6
2
9
SPANNER WRENCH
TRAP
10
A
DRIVER, NOZZLE .25 HEX (OPTIONAL)
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
ITEM DESCRIPTION
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
PART NO.
F. VASQUEZ
08-25-08
19
0002080252
H1109.8
.
1:5
11
FV 04/02/20
.
DP
6 OF 7
PARTS BREAKDOWN
5527
2020
FV
1
2
4
3
7
8
6
5
9
11
10
6462
BP3
PBA6
5703M
PBM1109
5874PBF
MTGFR.SM
HCR8
0006983506
0005982900
0002082253
5REF
ROTATED 90° INTO VIEW
DETAIL A
REMOVE INSERT
WITH 5/6 HEX SOCKET
(NOT SUPPLIED)
2
NOTES:
1 5874PBF (ITEM 5) INCLUDES VRK5874 CARTRIDGE ASSEMBLY
(ITEM 12) AND PBA6 FLANGED PUSH BUTTON (ITEM 4).
2 ENSURE TUBE IS DISCONNECTED FROM PUSH BUTTON
VALVE BODY PRIOR TO REMOVAL. APPLY ONE DROP OF
LOCTITE 222MS TO NOZZLE THREADS PRIOR TO
FASTENING BACK ONTO BUBBLER HEAD. RE-ATTACH
TUBE TO VALVE.
12 VALVE REPAIR KIT VRK5874
12
1
1
1
**
** REQUIRED - SOLD SEPARATELY

864mm
(14mm)
(9/16")
34"
51mm SUPPLY
2"
457mm
15"
381mm
18"
13mm
1/2"
CHILLER SUPPORT TRAY
1-1/4" IPS TRAP
(SUPPLIED)
MOUNTING FRAME
27"
ELECTRICAL ACCESS
FLOOR
LINE
686mm
25-1/8"
SUPPLY
638mm
791mm
31-1/8"
WASTE
1-1/4" IPS WASTE
(BY OTHERS).
3/8" O.D. TUBING
SUPPLY STOP AND
IMPORTANT: MOUNTING
FRAME MUST BE IN-
STALLED SO THAT LIP OF
FRAME BUTTS AGAINST
FINISHED WALL FACE.
(BY OTHERS)
WALL FACE
WIDTH
FRAME
MOUNTING
ROUGH-IN
MIN. FOR
ALT SIDE
102mm
5"
127mm
4"
FLANGE
FRAME
STUD
152mm
6"
12"
305mm 2-1/8"
54mm
NOTES:
4
5
5
MTGFR.SM
BOWL MOUNTING PATTERN DETAIL
SCREW
7
6
7
359mm
14-1/8"
1-3/16"
30mm
32-1/8"
816mm 34-1/2"
876mm
*
**
INLINE STRAINER,
1/4" OD TUBE X
3/8" OD TUBE
INLET (SUPPLIED)
(SUPPLIED)
3/8" O.D.
& FITTINGS
INSULATION
TUBING,
HCR8
CHILLER
12"
305mm
53
ROUGH-IN
ROUGH-IN
CLEARANCE
*
1. HOLD ROUGH-IN DIMENSIONS ±1/8" (3.2mm)
2. WHEN INSTALLING THIS UNIT, LOCAL, STATE, OR FEDERAL CODES SHOULD BE
ADHERED TO. FORINSTALLATION HEIGHTS OTHER THAN SHOWN, DIMENSIONS
MARKED (*) MUST BE ADJUSTED ACCORDINGLY.
3 ALIGN HOLES IN CHILLER SUPPORT TRAY WITH HOLES IN FRAME
AND FASTEN WITH #10 SHEETMETAL SCREWS.
4 REFER TO 5874 SERIES OPERATION AND MAINTENANCE MANUAL
FOR PUSH BUTTON AND VALVE INSTALLATION/MAINTENANCE INSTRUCTIONS.
5 REFER TO MTGFR.SM INSTALLATION DRAWING FOR ROUGH-IN DIMENSIONS.
6 INSERT 5/16"-18 PANEL INSERTS FROM OPPOSITE SIDE AT LOCATIONS
SHOWN BY DARKENED HOLES.
7 FOUNTAIN REMOVAL: FIRST REMOVE SCREWS AND THEN SQUEEZE
CLIPS ON NUT RETAINER TO POP OUT. INSTALL IS REVERSE OF
REMOVAL.
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
F.VASQUEZ
08-01-98
19
0002080252.D
H1109.8
.
1:15
11
FV 04/02/20
.
DP
INSTALLATION
5527
2020
FV
REQUIRED -
SOLD SEPARATELY
