WaterTech Precision 2.0 User manual

Installation Guide
Need Help? Contact Customer Care at [phone]
Replacing the Water techTM PrecisionTM 2.0Li Motor Box
1
Your new kit will come with the
following items:
Motor Box (P40X003)
Lithium Charger (LC099-3S-US-EU)
(2) Li-Ion Batteries
Phillips screwdriver or drill
(Set at low torque level)
Pliers
You will need the following tools:
STEP 2: Unscrew the two (2) screws holding the
draining port’s cap from the side with the ten (10)
screws. Set cap aside.
STEP 1: Place the unit in at workbench. Identify
the side with the ten (10) screws.

Installation Guide
Need Help? Contact Customer Care at [phone]
Replacing the Water techTM PrecisionTM 2.0Li Motor Box
2
STEP 3: Place the unit at on a workbench
with motor box away from you and pole side to
the left. Detach motor box cap from motor box.
Remove the ten (10) screws from the side of the
shell and separate shell from unit. Place screws
to the side.
STEP 4: The motor box, funnel and pole
attachment should be visible now.

Installation Guide
Need Help? Contact Customer Care at [phone]
Replacing the Water techTM PrecisionTM 2.0Li Motor Box
3
STEP 5: Turn the unit over and remove the four (4)
screws holding the motor box assembly in place.
Separate shell from motor box.
STEP 6: Inspect the side of the shell that has the
motor box cap attached to it. Notice the metal clip
that holds the lanyard to the shell. With a pair of
pliers gently squeeze clip to open it and remove clip
from lanyard. Remove motor box cap from shell.

Installation Guide
Need Help? Contact Customer Care at [phone]
Replacing the Water techTM PrecisionTM 2.0Li Motor Box
4
STEP 7: Slide metal clip o󰀨
new lanyard. Remove new
motor box cap and attached
lanyard from new motor box. String new lanyard through holes (as shown).
Slide clip over both ends of lanyard. Clamp clip with pliers.
STEP 8: Remove old motor box.

Installation Guide
Need Help? Contact Customer Care at [phone]
Replacing the Water techTM PrecisionTM 2.0Li Motor Box
5
STEP 9: Place the shell half with the pole
attachment on workbench with funnel opening
facing towards you. Place new motor box in shell
with ON/OFF button. Make sure the impeller sits
aligned with the funnel.
(Impeller close up) (ON/OFF Button should be next to the metal
pole after placing the new motor box in)

Installation Guide
Need Help? Contact Customer Care at [phone]
Replacing the Water techTM PrecisionTM 2.0Li Motor Box
6
STEP 11: Place shell half with ten (10) screw
openings on top of motor box and funnel. Insert
previously set aside screws into screw openings
and tighten with drill or screwdriver.
STEP 10: Flip unit over and insert four (4)
previously set aside screws into screw openings
and tighten with drill or screwdriver.

Installation Guide
Need Help? Contact Customer Care at [phone]
Replacing the Water techTM PrecisionTM 2.0Li Motor Box
7
STEP 12: Screw the two (2) screws holding the
draining port’s cap from the side with the ten (10)
screws.
Rev.: 132017
