Watex 6738 Installation manual

#6738 - Watex Solar Tap Timer Operation Manuals
B. Rechargeable Battery Included
①SwivelConnector
② Solar Panel
③ Enter Button
⑧ 3/4" Male Thread
④ Run Time Knob (Green)
⑥ Transparent Cover
⑦ LED Indicate Light
A.Product Overview
INTERVAL
⑤ Interval Knob (Blue)
Ni MH battery set
3.6V AA 1200mAh

C. Auto Irrigation Program set up
#6738 - Watex Solar Tap Timer Operation Manuals
1. Select a watering run time by turning the Green knob
enable the mark point to the watering duration you
want.
Ex. the below drawing shown a watering run time of 30
minutes.
2. Select an interval of next watering cycle by turn the
Blue knob enable the mark point to the interval you
want.
Ex. the below drawing shown an interval of 24 hours.
3. Push the enter button and then the LED light will be
flashing as confirmation. The timer will execute the first
watering right away.
Ex. the below drawing shown the timer will watering 30
minutes and repeating with 24 hours interval.
INTERVAL
D. Manual on Watering
INTERVAL
INTERVAL
E. Watering Manual Off
1. Turn Blue interval knob enable the mark point
to Manual on position.
2. Selection the duration by Green Run Time knob.
3. Pushing enter button to start watering and the
timer will shut off when run time is over.
Ex. the right drawing shown a 2 minutes manual on
watering cycle.
1. Turn the Green Run Time knob enable the mark point to
Manual off position and pushing the enter button to stop
current watering cycle.
2. Turn the knob away from Manual off position the timer
will be back to previous setting watering program without
pushing the enter button.
3. Once the enter button has been pushed the watering
program will be changed to the status as the position
pointed by both of Run Time and Interval knobs.
INTERVAL
The LED lights
will be flashing
3 times as
confirmation.
INTERVAL
