Contents Wavebrite™ Installation, Operation and
Cartridge Replacement Instructions
Section Page
1. Introduction 2
1.1 Important 2
1.2 What It Does 2
1.3 About these instructions 3
1.4 Before you begin 3
2. Tools and Fasteners 3
3. Basic Components 4
4. Wavebrite™ Grey Water Filter System Specifications Fig 1. 4
5. Installing the Components 5
6. Cartridge Replacement 6
7. Functional Checks 6
7.1 Installation check 6
7.2 With pump running, check 6
7.3 Operational / Maintenance check 7
8. Code of Practice 7
Section 1.Introduction
1.1 Important
It is important to us that this product works as advertised and that you enjoy the extra peace of
mind that Wavebrite™ offers by protecting the environment. If you have any queries that can
not be answered by your supplier or engineer, please contact us direct on [phone]
or e-mail [e-mail] or [e-mail]
1.2 What it does
The Wavebrite™ grey water filter system removes contaminants from waste water which is
pumped through the system before discharge overboard or being reused. Grey waste water is
generally produced by showers, hand basins and washing machines. The system is controlled
by a float switch located in the WHALE GREYWASTE WATER SUMP which switches the pump
on and off. This filter system is designed to remove contaminants from grey water, if galley
waste is put throughthe system cartridge life could be drastically reduced.
Wavebrite™ is designed for used in all sizes of boat and can easily be scaled up for larger boats
and Superyachts. The Wavebrite filter modules can be installed in multiples in parallel if the flow
rate and contamination level is high. Differential pressure indicates when the filters and main
Wavebrite™ filter module need changing, see Section 1.4 Check with Wave International
technical department if in doubt.
As an additional feature, a Gulper Pump from Whale (not supplied) can be installed to the
WHALE GREY WASTE WATER SUMP to provide direct pump out should it be required in areas
where it is permitted.
Galley waste water should be directed to the black water system due to the food waste
content and if directed to the Wavebrite system it may significantly reduce cartridge life. A
further FILTER/STRAINER could be installed under sink to help prevent galley waste going to
the WHALE GREY WASTE WATER SUMP and the Wavebrite system if required.
CAUTION
This filter system is
designed to remove
contaminants from
grey water, if galley
waste is put through
the system cartridge
life could be
drastically reduced.

WB12.rev01
3
1.3 About these instructions
The panels on the left of the pages draw attention to SAFETY CONSIDERATIONS of the
adjacent text in accordance with the conventions of the EU Recreational Craft Directive.
DANGER. Indicates a hazard that could easily result in death or serious injury if proper
precautions are not taken. If you have any doubts about what precautions to take, you should
seek expert advice.
WARNING. Indicates a hazard that could result in death or serious injury if proper precautions
are not taken. If you have any doubts about what precautions to take, you should seek expert
advice.
CAUTION. Indicates a hazard that could result in personal injury or damage to your boat or its
equipment if suitable care is not taken.
NOTE. Contains additional information that may be of help.
1.4 Before you begin
Before you start, please read through these instructions carefully. Fitting Wavebrite™ involves:
Cutting in to a section of flexible hose or grey waste water discharge pipe. Making electrical
connections.
Installing Wavebrite™ into the grey waste water discharge system usually using hose tails and
clamps, it may also require screwing into a threaded section of pipe or using flanged and bolted
fittings which are not supplied. Electrical connections should be made by a qualified electrical
installer with reference to the electrical equipment suppliers instructions.
Mounting the Wavebrite™ filter module, pre-filters, pump strainer, pump and grey waste water
sump by bolting or screwing the mounting brackets to a solid fixing point.
The position you mount the Wavebrite™ filter module, pre-filters and pump filter/strainer in must
allow for cartridge replacement. Do not mount in direct sunlight.
Some consideration must be given at this time to location of the components, the
following all affect pump performance:
Suctionhoselengthbetween the pump strainer, grey waste sumpand thepump. Iftoolongthis can
reduce pump performance.
Hose diameter and type, correct hose is supplied from the WHALE GREYWASTE WATER
SUMP.
Discharge head from the pump should be less than 1000 mm
Angles and fittings in hoses all cause a reduction in pump efficiency.
The shorter the pipe runs to and from the WAVEBRITE™ FILTER MODULE with no extra
fittings such as elbows and bends, the better the system will perform. Always check with the
Wave International Technical Department if in doubt.
Section 2. Tools and Fasteners
Wavebrite™ can be installed with the average DIY toolkit. Items you will need:
Fixings/bolts for filter, pump and tank brackets.
Electrical connections, switches, fuses and wire. See Section 1.4 and Fig.2
Thread tape or thread sealing compound.
Suitable pipe cutter (prt. No. WX7950) for the Whale WX 15mm pipe as shown in theWhale
Catalogue. See Whale Pipe Fitting Guide supplied.
CAUTION
If you have any
doubts at any time
about installing this
equipment, please
consult a qualified
person or contact
Wave International
for advice.
WARNING
See Whale Pipe
Fitting Guide
regarding the Whale
WX 15mm pipe.
Take care if using a
sharp knife to cut
the 25mm flexible
hose.
WARNING
Electrical
connections are
required and should
be carried out by
and checked by a
qualified electrical
installer.
DANGER
WARNING
CAUTION
NOTE

WB12.rev01
4
Section 3. Basic Components
Before you start, please check that your system kit contains the following components. If you
think you are short of any items, please call us immediately.
Wavebrite™ Complete System
Item Qty. Description
1. 1 WAVEBRITE™ FILTER MODULE.
2. 2 Saddle clamps for WAVEBRITE™ FILTER MODULE
3. 1 WAVEBRITE WB1 CARTRIDGE™ installed.
4. 1 Filter housing with 5 micron wound cartridge.
5. 1 Filter housing with 0.5 micron wound cartridge.
6. 1 Filter housing with 100 micron screen.
7. 3 Tees for pressure gauges with quick connect.
8. 3 Pressure gauges.
9. 1 Hour Meter.
10. 1 15mm Quick Connect for WAVEBRITE™ FILTER MODULE
11. 3 Stainless steel brackets.
12. 12 Filter housing bracket screws
13. 1 WHALE UNIVERSAL WATER PUMP 12 or 24 volt.
14. 1 WHALE GREY WASTE WATER SUMP 16L.
15. 5 Mtrs 15 mm hose.
16. 1 Mtrs 25 mm braded hose.
17. 4 Hose clips
18. 1 Instruction and information pack.
Refer to Whale Water Systems Catalogue for further information regarding WHALE PUMPS and the WHALE GREY
WASTE WATER SUMP [phone] [e-mail] www.whalepumps.com
Section 4. Wavebrite™ Grey Water Filter System Specifications
FLOW RATE: 1-15 Liters per min.
SYSTEM MAX. PRESSURE: 6.2 bar.
PRE-FILTERS MAX. DIFF. PRESSURE: 2 bar. (@ 2 bar. change cartridge)
WAVEBRITE MODULE MAX. DIFF. PRESSURE: 4 bar. (@ 4 bar. change cartridge)
MAX. TEMP: 45 deg. C.
MIN. TEMP: 1 deg. C.
WAVEBRITE WB1 CARTRIDGE: Part No. WB1
WOUND CARTRIDGE: Part No. WP10P0.5 (0,5 micron)
WOUND CARTRIDGE: Part No. WP10P5 (5 micron)
FILTER SLEEVE: Part No. SFSN10100 (100 micron)
Leave a minimum of 25 mm below each filter
housing to allow cartridge removal.
Leave a minimum of 660 mm at one end of the
WAVEBRITE™ FILTER MODULE.
NOTE
Fixings & electrical
connections to
install in to the boat
are not supplied and
will need to be
obtained prior to
fitting. See Sections
2. & 5.

WB12.rev01
5
Fig 1.
Section 5. Installing the Components
Fitting Wavebrite™. See Fig 1.
Locate a suitable position, refer to Section 1.4 and Fig.1, Note the Wavebrite™ system is
modular and each component and can be fitted remotely. Fix the mounting brackets and saddle
clamps. The FILTER/STRAINER 1 will require the most attention and should be installed where
it can be easily monitored visually and can be accessed with ease.
Attach the filter housings to the mounting brackets using the screws provided; ensuring the flow
direction is correct; there are arrows on the top filter housings and on theWHALE UNIVERSAL
WATER PUMP. The arrows must point in the direction of flow from the WHALEGREY WASTE
WATER SUMP towards the WAVEBRITE™ FILTER MODULE. The flow direction through the
WAVEBRITE™ FILTER MODULE is left to right, but this can be changed by reversing the
WAVEBRITE WB1 CARTRIDGE in the WAVEBRITE™ FILTER MODULE housing if required,
note flow direction arrow on WAVEBRITE WB1 CARTRIDGE.
Connect from the exit of Filter Strainer 1 to the pump and all the filters to the WAVEBRITE™
FILTER MODULE with the 15mm hose supplied, quick connect fittings are supplied. See the
Whale Pipe Fitting Guide supplied in the information pack.
The WHALE GREY WASTER WATER SUMP should be located so the head to the pump is no
more than 1000mm and the required pipe connections must be pre-drilled. The grey water
supply, such as from showers and basins are to go to the top connections, no hose or hose clips
are supplied for this. Connect from the lower 25mm connection to the Filter Strainer 1 using the
25mm flexible braided hose, 2 no. hose clips should be used on each end, these are supplied.
Galley waste water should be directed to the black water system due to the food waste
content and if directed to the Wavebrite system it may significantly reduce cartridge life.
A filter/strainer (not supplied) could be installed under sink to help prevent galley waste going to
the WHALE GREY WASTE WATER SUMP and the Wavebrite system if required.
It is required to have enough space below the filter units (25mm) to remove the filter bowls when
changing cartridges and at one end of the WAVEBRITE™ FILTER MODULE (660mm) check
the system specifications at Section 4 above.
Install the Tees and pressure gauges using thread tape.
Make the electrical connections to the pump, hour meter and WHALE GREYWASTER WATER
SUMP as per the instructions supplied with the electrical components and to required safety
standards. Locate the hour meter in a panel or an appropriate position. All electrical connections
to be carried out by and checked by a qualified marine electrical installer. See section 5.1 Fig 2.
CAUTION
It is advisable to use
two hose clamps on
hose tails, so each
connection is double
clamped.
NOTE
Refer to Whale
Water Systems
Catalogue for further
information if
required.
whalepumps.com
WARNING
Electrical
connections are
required and to be
carried out by and
checked by a
qualified marine
electrical installer.

WB12.rev01
6
5.1 Wiring Diagram
Fig 2.
Section 6. Cartridge Replacement
IMPORTANT. Before replacing the cartridges ensure the pump is switched off and there
is no pressure in the system.
FILTER/STRAINER 1 (100 MICRON) screen requires cleaning periodically and should be
part of a regular maintenance schedule. If the strainer becomes blocked pump performance
will be significantly reduced and cause the flow in the complete system to drop.
The filter cartridge in FILTER 2 (5 MICRON) requires changing when the differential
pressure between gauges PG1 & PG2 reaches 2 bar during pumping.
The filter cartridge in FILTER 3 (0.5 MICRON) requires changing when the differential
pressure between gauges PG2 & PG3 reaches 2 bar during pumping.
When replacing the filter bowls hand tighten only.
Ensure the pump is switched off.
Unscrew the filter bowl and pour the excess water remaining in the bowl back in to the grey or
black water system. Plastic spanners can be supplied and should only be used to remove the
filter bowls they should be replaced by hand and only hand tight.
The WAVEBRITE™ FILTER MODULE requires changing after 20 hours of operation. Also
change if pressure gauge PG3 reaches 4 bar during pumping. It is opened by removing the
plastic circular clip releasing the end cap which can then be removed allowing the removal of
the WAVEBRITE™WB1 CARTRIDGE
Remove the saturated cartridges placing them in a suitable receptacle for onward disposal.
Check the ‘O’ rings on the outside and inside of the end cap are in good condition.
Locate new cartridge in the WAVEBRITE™ FILTER MODULE and replace end cap securely.
Turn on the pump by running water into the grey water system and bleed any air from the filter
housings using the bleed button, check for any leaks.
WARNING
Before replacing the
cartridges ensure
the pump is
switched off and
there is no pressure
in the system.
CAUTION
When replacing the
filter bowls hand
tighten only
WARNING
Place saturated
cartridges in a
suitable receptacle
for responsible
onward disposal

WB12.rev01
7
Section 7. Functional Checks
7.1 Installation Check
Ensure hose clips securing the flexible hose are fully tightened.
All connections must be tight.
Electrical connection to be checked by a qualified marine electrical installer.
Make sure any other components you disturbed or removed during the fitting process have
been refitted correctly.
7.2 With Pump Running Check
If fitted check the pump discharge valve is OPEN.
Pump is controlled by the float switch in the WHALE GREY WASTE WATER SUMP, run
water through the system and check for leaks.
7.3 Operational / Maintenance Check
IMPORTANT. Before opening filter housings ensure the pump is switched off and there is
no pressure in the system.
Apart from making cartridge changes as described in Section 6. make cartridge
replacements part of a regular maintenance programme at the end of the season or after
periods of heavy use.
Galley sink waste should be directed to the black water system due tothe food waste
content, if directed to the Wavebrite™system it may significantly reduce cartridge life and
filter checks must be made more frequently.
Section 8. Code of Practice
Some points to remember
Make sure all grey water lines and connections are in good order and are not leaking.
Regularly check filter gauge pressure during operation.
Where possible prevent particulate or fibrous materials from entering the grey water
system.
If the additional by-pass pump is fitted ensure direct pump out from the WHALE GREY
WASTER WATER SUMP is permitted and reinstate the Wavebrite System as soon as
possible.
Take ashore in proper containers any Wavebrite™ system cartridges to be disposed of at
approved facilities at marinas, lock stations or local authority waste disposal sites.
As far as possible, use biodegradable detergents, soaps and cleaning materials.
All the Wavebrite™ products in this document meet the requirements of the Recreational Craft Directive at 1st January 2000
Wavebrite™ is a Wave International Limited Trade Mark
Wave International limited makes no representations or warranties with respect to the contents or use of this manual and spec ifically disclaims any express or implied warranties of
merchantability or fitness for any particular purpose. Further, Wave International Limited reserves the right to revise this publication and make changes to its content, at any time and to make
changes to any and all parts of Wave International products without obligation to notify any person or entity of such revisio ns or changes.
WARNING
Check the filters and
pressure gauges
regularly. Debris in
the water can affect
the performance of
the system.
Wave International Limited Your local agent is:
Axholme House
Newton Way tel.: [phone]
Colsterworth fax: [phone]
Grantham NG33 5NP email: [e-mail]
UK www.wavebrite.co.uk
www.wavestream.co.uk
DANGER
Before opening filter
housings ensure the
pump is switched off
and there is no
pressure in the
system
Australasia/Pacific
www.tidesmarine.com.au
[email protected]
[phone]
