Wayne RUP160 Service manual

620004-001 B 08/18© 2018, WAYNE/Scott Fetzer Company.
Submersible Multi-Use Pump
www.waynepumps.com
Intended for Indoor Use Only
Please read and save these instructions. Read carefully before attempting to assemble, install,
operate or maintain the product described. Protect yourself and others by observing all safety
information. Failure to comply with instructions could result in personal injury and/or property
damage! Retain instructions for future reference.
Operating Instructions and Parts Manual RUP160
SPECIFICATIONS
POWER SUPPLY REQUIREMENTS 120 V, 60 Hz
MOTOR Single Phase
HORSEPOWER 1/6 HP
CIRCUIT REQUREMENT 15 A (minimum)
LIQUID TEMPERATURE RANGE 40° F- 120° F
PERFORMANCE
Model HP Discharge Head 0 ft. 5 ft. 10ft. 15 ft. 20 ft.
RUP160 1/6 Gal/hr 3100 2350 1600 900 250
CONSTRUCTION
MOTOR HOUSING Thermoplastic
MOTOR SHAFT Stainless Steel
IMPELLER Thermoplastic
VOLUTE Stainless Steel
PUMP DISCHARGE 1-1/4 in. NPT with Included Adapter

Operating Instructions and Parts Manual
2
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
GENERAL SAFETY INFORMATION
CALIFORNIA PROPOSITION 65
This product can expose you to chemicals, including DEHP,
which is known to the State of California to cause cancer,
birth defects and reproductive harm. For more information,
go to www.P65Warnings.ca.gov.
Ce produit peutvous exposer à des produits chimiques,
notamment du DOP, reconnus par l’État de Californie comme
étant cancérigènes et à l’origine d’anomalies congénitales
et de problèmes de l’appareil reproductif. Pour plus de
renseignements, visiter le site www.P65Warnings.ca.gov.
GENERAL SAFETY
• Read all manuals included with this product carefully. Be
thoroughly familiar with the controls and the proper
use of the equipment. Follow all instructions.
• Only persons well acquainted with these rules of safe
operation should be allowed to use the unit. Keep
away from children.
Do NOT pump flammable or explosive fluids
such as gasoline, fuel oil, kerosene, etc. Do NOT use in a flammable
and/or explosive environment. This pump is intended for use with only
clear water. Personal injury and/or property damage will
result, and void warranty.
NE PAS pomper de fluides
inflammables ou explosifs tels que l’essence, le mazout, le
kérosène, etc. NE PAS utiliser dans un environnement inflammable et/
ou explosif. Cette pompe est destinée à être utilisée avec de l’eau claire.
Si ce n’est le cas, des blessures corporelles et des dégâts matériels
peuvent en résulter, et annuler la garantie.
DESCRIPTION
This portable, submersible utility pump is designed for non-automatic
use in water. The units are equipped with a 9ft. 3-prong grounding
type power cord. The discharge fitting is designed for convenient
attachment to a garden hose, in a temporary application.
UNPACKING
Inspect this unit before it is used. Occasionally, products are damaged
during shipment. If the pump or components are damaged, contact
customer service at 1-800-237-0987.
SAFETY SIGNAL WORDS
This manual contains information that is very important to know
and understand. This information is provided for SAFETY and
to PREVENT EQUIPMENT PROBLEMS. To help recognize this
information, observe the following symbols.
Danger indicates an imminently hazardous
situation which, if NOT avoided, WILL result in death or serious injury.
La mention Danger indique une situation
dangereuse imminente qui, si elle n’est pas évitée, ENTRAÎNE la mort ou
des blessures graves.
Warning indicates a potentially hazardous
situation which, if NOT avoided, COULD result in death or serious injury.
La mention avertissement indique une
situation potentiellement dangereuse qui, si elle n’est pas évitée, risque
d’entraîner des lésions corporelles graves ou même la mort.
Caution indicates a potentially hazardous
situation which, if NOT avoided, MAY result in minor or moderate injury.
MISE EN GARDE La mention mise en garde indique une
situation potentiellement dangereuse qui, si elle n’est pas évitée,
pourrait entraîner des blessures mineures ou modérées.
Notice indicates important information, that if
NOT followed, MAY cause damage to equipment.
This is the safety alert symbol. It is used to alert you to
potential bodily injury hazards. Obey all safety messages
that follow this symbol to avoid possible harm.
NOTE: Information that requires special attention.

Operating Instructions and Parts Manual
3
RUP160
GENERAL SAFETY INFORMATION (CONT’D)
Risk of electric shock! This pump has NOT been
tested for use in swimming pool or marine areas. NEVER
place pump in pools while people are in the water.
Risque de choc électrique! Cette
pompe N’a PAS été testée pour une utilisation dans une
piscine ou dans des aires marines. NE JAMAIS placer la pompe dans les
piscines pendant que les gens sont dans l’eau.
Do NOT handle pump with wet hands or when
standing in water or on a damp surface.
NE PAS manipuler la pompe avec les mains
humides ou debout dans l’eau ou sur une surface humide.
Risk of electric shock! This pump is supplied
with a grounding conductor and grounding type attachment plug. Use a
grounded (GFCI) receptacle to reduce the risk of fatal electrical shock.
Risque de choc électrique! Cette pompe est
fournie avec un conducteur de mise à la terre et une fiche de terre.
Utiliser une prise équipée d’un disjoncteur de fuite à la terre (GFCI) pour
réduire le risque de choc électrique mortel.
1. Wear safety glasses at all times when working with pumps.
2. It is required that this unit be plugged into a Ground Fault Circuit
Interrupter (GFCI). Consult a local electrician for installation and
availability.
3. Use the handle supplied on the pump to carry or move pump.
Otherwise, damage to the power cord or discharge hose may
occur and void warranty.
APPLICATION AND OPERATION
This unit is NOT desinged for use in septic
tanks or underground vaults to pump raw sewage or effluents. Never
use in hazardous or explosive locations.
Cette unité n’est PAS desinged pour une
utilisation dans des fosses septiques ou des voûtes souterraines pour
pomper les eaux usées ou des effluents. N’utilisez jamais dangereux ou
à explosion.
1. This pump has been designed with 1-1/4 in. NPT discharge
size. Connect pipe or fitting to the discharge threads, or connect
the supplied garden hose elbow fitting to the pump. Thread the
female end of the garden hose to the male discharge on the
pump.
2. To reduce leakage between the pump and the hose, place a hose
washer (not included) on the garden hose before installing to the
pump, and placed Teflon®tape on the adapter (not included).
3. For best pump performance, unwind the hose before starting the
pump. This will help remove any kinks or binds in the hose and
allow the unit to pump with less restriction.
4. Set the pump on a hard, flat surface in the water. Do not set the
pump directly on mud or sand surfaces. This will cause the inlet
screen to clog.
5. The water level must be at least 1-3/4 in. for the pump to prime
and operate.
NOTE: Water levels less than 1-3/4 in. will not allow the impeller
to contact water and no water will be pumped.
Do NOT allow pump to run dry.
The shaft seal depends on water for lubrication. Operating
pump without water WILL damage the shaft seal and cause
pump failure, and void warranty.

Operating Instructions and Parts Manual
4
Figure 1 - Water Level
20 Ft. Max.
Water Level
APPLICATION AND OPERATION (CONT’D)
Do NOT handle pump with wet hands or when
standing in water or on a damp surface when the unit is operating
or fails to operate. ALWAYS disconnect pump power cord from power
source before handling.
NE PAS manipuler la pompe avec les mains
humides ou debout dans l’eau ou sur une surface humide lorsque
l’appareil fonctionne ou ne fonctionne pas correctement. TOUJOURS
débrancher le cordon d’alimentation de la pompe de la source
d’alimentation avant toute manipulation.
6. Plug the power cord into a grounded 115 volt GFCI power outlet.
The pump will start operating as soon as the power cord is
plugged into the power outlet.
7. The pump will remove water down to 3/8 in. above the hard
surface the pump was placed on.
8. The pump should be turned off once the water level reaches the
3/8 in. mark.
MAINTENANCE/TROUBLESHOOTING
ALWAYS disconnect electric supply before
attempting to install, service, relocate, or perform any maintenance.
Failure to do so COULD result in fatal electrical shock.
TOUJOURS couper le courant avant d’essayer
d’installer, de réparer, de déplacer ou de faire tout entretien. Le
non-respect de ces instructions POURRAIT entraîner une décharge
électrique mortelle.
There are no internal servicable parts. If pump should fail to operate,
perform the following troubleshooting guidelines, contact Customer
Support at 1-800-237-0987, or replace the pump:
Disassembly of the motor housing or alteration
of the power cord COULD result in fatal electrical shock, and void
warranty.
Démonter le boîtier du moteur ou modifier le
cordon d’alimentation POURRAIT entraîner une décharge électrique
mortelle et annuler la garantie.
1. To verify pump is operating correctly:
a. Disconnect pump from power source.
b. Disconnect discharge hose from pump.
c. Immerse pump in a bucket or tub of water.
d. Plug power cord into a grounded 115 volt GFCI power outlet.
If pump operates correctly, proceed to next step. If pump
does NOT operate, unplug power cord and proceed to step
#3 in this section.
2. To verify discharge hose is free from a blockage:
• Connect hose to another water source such as a faucet. If
water is restricted, verify discharge hose is unwound. Remove
all kinks, bends, or obstructions in hose.
Verify pumping height does NOT exceed 20 feet
(See Figure 1). If pumping height is greater than 20 feet, this pump will
NOT work.
3. Periodic cleaning of pump is required to maintain performance of
the pump. Follow the cleaning steps listed below:
a. Unplug the power cord.
b. Remove the 4 screws in the bottom of the base.
c. Remove the base and inlet plate.
d. Remove the debris and make sure the impeller turns freely.
e. Reinstall inlet plate, base, and screws.

Operating Instructions and Parts Manual
5
RUP160
For Replacement Parts or Customer Support, Call 1-800-237-0987
Ref.
No. Description RUP160 Qty
1Elbow adapter 62060-001 1
1
Please provide following information:
- Model number
- Serial number (if any)
- Part description and number as shown in parts list
Address parts correspondence to:
Wayne Water Systems
101 Production Drive
Harrison, OH 45030 U.S.A.

6
Operating Instructions and Parts Manual
LIMITED WARRANTY
For one year for the RUP160 model from the date of purchase, from an authorized dealer, Wayne Water Systems will repair or replace, at its option for the original
purchaser, any part or parts of its Multi-Use or Water Pumps (“Product”) found upon examination by Wayne Water Systems to be defective in materials or workmanship.
Please call Wayne Water Systems (800-237-0987) for warranty instructions. Be prepared to provide the model number and the serial number when exercising this
warranty. All transportation charges on Products or parts submitted for repair or replacement must be paid by purchaser.
This Limited Warranty does not cover Products which have been damaged as a result of accident, abuse, misuse, neglect, improper installation, improper maintenance,
or failure to operate in accordance with Wayne Water Systems’ written instructions.
THIS WARRANTY IS IN LIEU OF ANY AND ALL OTHER WARRANTIES, OBLIGATIONS OR AGREEMENTS, EXPRESSED OR IMPLIED, INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE, AND ANY RIGHTS OR REMEDIES AGAINST ANY PERSON OR ENTITY UNDER THE UNIFORM
COMMERCIAL CODE OR OTHERWISE WITH RESPECT TO THE SALE OF THE PRODUCT. THE REMEDIES AND OBLIGATIONS STATED IN THIS WARRANTY ARE THE SOLE
AND EXCLUSIVE REMEDIES OF AND OBLIGATIONS TO THE OWNER FOR ANY AND ALL MATTERS ARISING WITH RESPECT TO OR IN ANY WAY CONNECTED WITH
THE PRODUCT, REGARDLESS OF THE SOURCE OR PROVIDER OF SUCH GOODS. IN NO EVENT, WHETHER AS A RESULT OF BREACH OF CONTRACT, WARRANTY TORT
(INCLUDING NEGLIGENCE) OR OTHERWISE, SHALL WAYNE WATER SYSTEMS OR ANY AFFILIATE BE LIABLE FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES.
You MUST retain your purchase receipt along with this form. In the event you need to exercise a warranty claim, you MUST send a copy of the purchase receipt along
with the material or correspondence. Please call Wayne Water Systems (800-237-0987) for return authorization and instructions.
DO NOT MAIL THIS FORM TO Wayne Water Systems.Use this form only to maintain your records.
MODEL NO._____________________ SERIAL NO._________________________ INSTALLATION DATE __________________________
ATTACH YOUR RECEIPT HERE

7
NOTES
Operating Instructions and Parts Manual

8www.waynepumps.com
