We Are 3D MagiCube User manual

User Manual
Rev. A

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 2
1. Contents
2. Getting to know your MagiCube printer!.........................................................................................!4!
2.1.!Welcome to We Are 3D Inc.!............................................................................................................................!4!
2.2.!What’s in the box!...............................................................................................................................................!5!
2.3.!Specifications!......................................................................................................................................................!6!
2.4.!What is 3D Printing?!..........................................................................................................................................!7!
2.5.!MagiCube Overview!..........................................................................................................................................!8!
2.5.1.!Component Names - Front!..................................................................................................................!8!
2.6.!Safety!...................................................................................................................................................................!9!
3. Getting Started!......................................................................................................................................!10!
3.1.!3D Printing: From Idea to Print!......................................................................................................................!10!
3.2.!Initial setup!.......................................................................................................................................................!11!
3.2.1.!Unpacking the Printer!..........................................................................................................................!11!
3.2.2.!Install the Software!..............................................................................................................................!11!
3.2.3.!Load the filament!.................................................................................................................................!12!
4. LCD interface!..........................................................................................................................................!13!
4.1.!Navigating the menu!.......................................................................................................................................!13!
4.2.!The main screen!...............................................................................................................................................!13!
4.3.!Changing filament using the LCD!.................................................................................................................!13!
5. AnyPrint software!........................................................................................................................................!14!
5.1.!Program Layout!................................................................................................................................................!14!
5.2.!Controlling the View and Moving the Mode!...............................................................................................!14!
5.2.1.!Using the Mouse!..................................................................................................................................!14!
5.2.2.!Using the Keyboard!.............................................................................................................................!14!
5.3.!Print and Printer Controls!...............................................................................................................................!15!
6. How to Print!.................................................................................................................................................!16!
6.1.!Preparing the Printer!.......................................................................................................................................!16!
6.1.1.!Tape the Bed!........................................................................................................................................!16!
6.1.2.!Remove any Debris from Enclosure!..................................................................................................!16!
6.1.3.!Route the Filament!..............................................................................................................................!16!

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 3
6.1.4.!Power the Printer!..................................................................................................................................!16!
6.2.!Finding a Model!...............................................................................................................................................!17!
6.2.1.!Download Online!.................................................................................................................................!17!
6.2.2.!Design Your Own!.................................................................................................................................!17!
6.2.3.!3D Scanning!..........................................................................................................................................!17!
6.3.!Slicing the Model!.............................................................................................................................................!17!
6.4.!Starting the Print!..............................................................................................................................................!17!
6.4.1.!From SD Card!.......................................................................................................................................!17!
6.4.2.!From USB!..............................................................................................................................................!18!
6.5.!During the Print!................................................................................................................................................!18!
6.6.!Pausing or Cancelling!......................................................................................................................................!18!
6.7.!After the Print!...................................................................................................................................................!18!
7. Maintenance!............................................................................................................................................!19!
7.1.!Before performing maintenance!....................................................................................................................!19!
7.2.!Clearing a Jam!.................................................................................................................................................!19!
7.2.1.!Cut the filament!....................................................................................................................................!19!
7.2.2.!Remove the extruder cover!................................................................................................................!20!
7.2.3.!Determine where the jam is!...............................................................................................................!20!
7.2.4.!If the jam is inside the extruder!.........................................................................................................!21!
7.2.5.!Push the filament in the direction of the jam!...................................................................................!21!
7.2.6.!Cut the filament bulb off!.....................................................................................................................!21!
7.2.7.!Put the extruder back together!..........................................................................................................!22!
7.2.8.!Carefully attach extruder cover!..........................................................................................................!22!
8. Support!.....................................................................................................................................................!23!
8.1.!Troubleshooting!...............................................................................................................................................!23!
8.2.!If all else fails!.....................................................................................................................................................!23!
9. Appendix!..................................................................................................................................................!24!
!

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 4
2. Getting to know your MagiCube printer
2.1. Welcome to We Are 3D Inc.
Thanks for choosing us. You rock!!
We’re so happy you bought our MagiCube 3D printer! Your printer was fully tested in Canada, and the
enclosed print sample was created on your printer!
We want you to as confident with your printer as possible so we put together this user manual to help you set
up for success. We also have a Quick Start guide if you want to get started right away. You can find the Quick
Start guide at www.WeAre3D.ca/user-manual. If you still have questions after reading the manual, we want to
hear from you. Email us at supp[email protected].
Have you wondered what you might print with your new printer? Finding inspiration can be tough, so we have
some suggestions on our website: www.WeAre3D.ca/3d-models/
And most importantly, we’re here to help you get the most out of your 3D printer. Visit us at www.WeAre3D.ca
for helpful hints and projects, or send us an email at [e-mail].
You’re ready. Make stuff.

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 5
2.2. What’s in the box
1. MagiCube printer
2. 130mm (5”) spool of PLA filament
3. Blue painter’s tape
4. Power supply with power cord
5. USB cable
6. 2 Allen (Hex) keys
7. USB drive with Installation Software and Manuals
8. USB Software Security Dongle (for 3DMagic design software)
9. microSD (TF) card with test prints
10. Phillips screw driver
11. Side cutters
12. Plastic scraper

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 6
2.3. Specifications
Printing technology: FFF (Fused Filament Fabrication)
Build volume: 100 W x 100 L x 100 H mm (4” W x 4” L 4” H)
Layer height: 0.1 – o.2 mm
Print resolution: X: 11 microns
Y: 11 microns
Z: 2.5 microns
Filament Diameter: 1.75mm (0.069”)
Nozzle Diameter: 0.4mm
Electrical:
Power Supply Input: 100-220V, 50/60HZ
Printer Input: 24VDC
Temperature limits:
Operational: 15°C to 32°C
Storage: 0°C to 32°C

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 7
2.4. What is 3D Printing?
3D printing (or additive manufacturing, AM) is any of various processes to make a three-dimensional
object.[1] In 3D printing, additive processes are used, in which successive layers of material are laid down under
computer control.[2] These objects can be of almost any shape or geometry, and are produced from a 3D model
or other electronic data source. A 3D printer is a type of industrial robot.
The MagiCube uses a technology called FFF (Fused Filament Fabrication). FFF is an additive
manufacturing technology commonly used for modeling, prototyping, and production applications. It is one of
the techniques used for 3D printing.
FFF works on an "additive" principle by laying down material in layers; a plastic filament is unwound from a coil
and supplies material to produce a part.
Fused Filament Fabrication:
1. Nozzle ejecting molten plastic
2. Deposited material (modeled part)
3. Controlled movable table and nozzle
Image created by Zureks, used under the GNU Free Documentation License http://commons.wikimedia.org/wiki/File:FDM_by_Zureks.png
VIDEO
How 3D Printing Works:
https://www.youtube.com/watch?v=Llgko
_GpXbI&feature=youtu.be

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 8
2.5. MagiCube Overview
2.5.1.Component Names - Front

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 9
1. Filament entrance – This is where the filament is pulled into the print head.
2. Nozzle – This is attached to the print head, which extrudes the filament and places it into position while
printer is operating.
3. Filament – This is the material that will build the object. The 130mm spool that is included with the
printer mounts to the rear door. Optional larger spools are available that will mount on a separate
spool holder.
4. Print bed – This the surface on which the printed object will stand. It can be removed from the printer
easily to allow the finished part to be detached after completion.
5. Print bed carriage – This holds the print bed in place, and moves it back and forth during the print.
6. LCD screen – Displays the printer menus and the status of current print.
7. Interface control button– Can be rotated and pressed to navigate the menus.
8. Power input – The MagiCube power supply plugs in here.
9. USB port – This port can be used to connect with a computer.
10. microSD (TF) slot – A microSD card can be inserted here to print without a computer (preferred).
2.6. Safety
High Temperatures
Warning: The MagiCube generates high temperatures at the print head. Never reach into the print area
while the printer is in operation. Always allow the printer to cool down before reaching anywhere near the print
head. Keep combustible or flammable materials away from the print head and the print surface.
Pinch Points
Warning: The MagiCube includes moving parts that can cause injury. While printing, filament, print head,
and print bed will be in motion. Keep the enclosure free of hands, clothing, hair, jewellery, and any other
objects when the printer is on.
Ventilation
Caution: During its operation the MagiCube melts plastic, which can release odours. Ensure the printer is
operated in a well-ventilated area.
Electrical
Caution: Maintain easy and clear access to electrical connections, and do not overload electrical supplies. In
case of emergency, disconnect the MagiCube power supply from the wall socket.
Safety Enclosure
Caution: To meet safety regulations, the printer must be operated with the safety enclosure installed.

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 10
3. Getting started
3D printing is such an exciting technology – it can help you solve problems, complete projects and just have
fun. How does 3D printing happen? It all starts with an idea…
3.1. 3D printing: from idea to print
!
3D idea: The process starts with an idea for a 3D object to print. This part is up to you, and it can be anything
from a Yoda head to a part for your new supercar design.
Design software: This is where you create a 3D drawing of your idea. There are many different software
options available for designing, both open-source and proprietary. These software packages are often referred
to as CAD (Computer-aided Design) software. The output of this software will usually be an .stl file when being
used for 3D printing.
The MagiCube works well with the included design software 3D Magic. This software is designed to be able
to help anyone create a 3D object ready for printing. For more information on 3D Magic, visit weare3d.ca/our-
3d-products/3d-magic-design-and-modelling-software/.
Existing design: If you just want to start printing with an existing design, there are thousands of designs
available at repository sites, such as thingiverse.com, or on our website at weare3d.ca/3d-models/.
Slicing and interface software: The MagiCube uses a program called Anyprint to slice the model into
layers for the printer to print, and to communicate with the printer. Using Anyprint you can export the .x3g to
a microSD card and use the printer’s LCD interface to start the print, or plug The MagiCube in with a USB
cable to print.
3D printing: Once you have setup your printer, and loaded the filament, you can start the print from the
printer if the .x3g file is on the SD card. If using AnyPrint to run the print then the printer will receive the G-
code over the USB connection, the built-in printer firmware will interpret the instructions to create your print.

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 11
3.2. Initial setup
3.2.1.Unpacking the printer
The MagiCube 3D Printer comes fully assembled, and setup can take as little as 10 minutes. Simply follow
these instructions:
1. Take the MagiCube out of the box and place it on a flat surface, any stable table or desk will be fine.
Turn it so that the power and data ports are on the right side.
2. Remove tape that is securing the access doors on the front and back of the printer
3. Push and release the center squares on the front and rear sides to open the access doors.
4. Carefully remove the tape and packing foam from inside the printer.
5. Remove the eight red spacers that hold the print head stationary.
6. Plug the power supply into the wall outlet, and into the power port.
3.2.2. Install the software
The MagiCube 3D Printer comes with its own software provided on the USB drive.
1. Connect the USB drive to your computer.
2. Run Anyprint 1.x.x- EN.exe
3. Press ‘Next’ to begin the installation.
4. Choose a place to install AnyPrint, or press next to install in the default location.
5. Press ‘Next’ to run the installation.
6. When the “Driver Setup” Dialogue box appears, click INSTALL.
7. After the driver setup is complete, close the dialogue box.
8. Press ‘Exit’ to close the installer.

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 12
3.2.3. Load the filament
1. Open the mini roll of filament and trim off the bent end that was used to secure the roll
2. Take the mini roll of filament and snap it onto the rear spool holder.
3. Thread the filament through the guide tube on the side of the enclosure.
4. Thread the filament into the filament entrance
on the top of the print head, and push it down
until you feel resistance.
5. Turn the control knob on the printer to the left
so that the arrow on the left side is beside the
option “Change Filament”
6. Press the control knob in briefly to activate the
selection.
7. Turn the knob so that “Load” is selected.
8. Press the control knob in briefly to activate the
selection.
9. Wait for the nozzle to heat. When the nozzle is
at temperature, the screen will read
“Please Push the Filament”
10. Gently push the filament into the top of the
extruder until you can feel the extruder pulling
the filament.
11. Wait for the filament to start coming out of the
nozzle, then press the control knob briefly 3
times to stop the loading.
12. Remove extruded filament from the nozzle
using tweezers, or a similar tool.
13. Press and hold control knob for 2 seconds to
return to the previous menu (main)

4. LCD interface
4.1. Navigating the menu
There is a small selector on the left hand side of the screen to show which option is selected. To change the
selected option, rotate the knob in either direction. To activate the selection press the knob in briefly. To go
back, press and hold the knob for 2 seconds.
4.2. The main screen
The main menu on the LCD has 2 options.
1. The first is to “Build from SD”. This will allow you to pick
an .x3g file from the SD card to print. (Files must be .x3g
files, and must not have a name longer than 8 characters
before the extension.)
2. The second option is to “Change Filament”.
4.3. Changing filament using the LCD
Selecting “Load” will heat up the extruder, and then feed filament
down into the print head.
Selecting “Unload” will heat up the extruder, briefly feed filament
forward, and then feed filament up out of the print head.
!

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 14
5. AnyPrint software
Each MagiCube 3D printer comes with AnyPrint software. This software does all of the slicing for your
models and allows you to print without having to export your model to an SD card or USB.
5.1. Program layout
5.2. Controlling the view and moving the object
5.2.1.Using the mouse
Change the view angle
Right-click and drag the screen.
Change the object position
Left-click and drag the object
around the print bed.
Change zoom level
Scroll the mouse wheel towards you
to zoom out, scroll the mouse wheel
away from you to zoom in.
5.2.2.Using the keyboard
Shortcuts for changing the view angles
Shortcuts for controlling the model
W
Zoom In
J
Move Left
2mm
S
Zoom Out
L
Move Right
2mm
D
Turn Clockwise
I
Move Back
2mm
A
Turn Counter-Clockwise
K
Move Forward
2mm
C
Tilt Forward
M
Rotate Clockwise
1 degree
V
Tilt Back
N
Rotate Counter-Clockwise
1 degree
Y
Scale Up
1 %
Other shortcuts
U
Scale Down
1 %
Delete
Removes selected object from AnyPrint

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 15
5.3. Print and printer controls
!
!
!
!
!
Import File – Load .stl file to prepare for printing.!
To Platform – Move Object to the base of the print area
Move – Allows the model to be moved around the print area
Scale – Allows the model to be scaled up or down
Rotate – Allows the model to be rotated in the print area!
PLA – Standard filament type for the MagiCube
Low – Lowest printing speed.
Med – Medium printing speed.
High – Highest printing speed.!
High – Sets layer height to high resolution, which is 0.2mm thick for each
layer. The print will take longer, but surfaces will be smoother.
Low – Sets layer height to low resolution, which is 0.3mm thick for each layer.
The print will be completed faster, but the surfaces may not be as smooth.!
Raft – Prints a layer of filament under the object. This can help certain models
adhere to the print bed.
Support Structures – Generate break-away support structures for more
difficult prints that contain overhangs.!
Preheat – Heat up the print head
Load – Pushes filament through print head, and primes the nozzle.
(Must pre-heat first)
Unload – Pulls filament out of the nozzle, and out the top of the print head.
(Must pre-heat first)
Status – Shows “Connected” or “Disconnected” depending on whether
printer is plugged in and powered.
Print – Begin printing over USB.
Export X3g – Generates an .X3g file that can be printed from SD card
(recommended method)

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 16
6. How to print
6.1. Preparing the printer
Before you can get started printing, we’ll need to do a couple of things to make sure that your printer is ready
to print.
6.1.1. Tape the bed
The MagiCube uses blue painting tape to print on.
This offers good adhesion to the print bed for PLA.
The tape will wear out over time and need to be
replaced. If the tape is scratched, feels smooth in
places, or your prints are having trouble staying on the
bed, it is time to replace your tape.
The MagiCube comes with one roll of replacement
tape, but you can buy more at a local hardware store.
Other colours of painters tape can also work, but blue
painters tape will last the longest.
6.1.2. Remove any debris from enclosure
During a print it is possible that plastic debris could collect in the printer enclosure. Any debris should be
removed before printing again. Also make sure not to have any tools or objects in the enclosure while the
MagiCube is printing.
6.1.3. Route the filament
The MagiCube comes with a mini spool of PLA filament. This spool is designed to snap onto the rear hatch.
For detailed instructions on how to load the filament, see section 3.2.3 on page 13.
Important: When routing the filament into the extruder, make sure it goes through the tube at the back of the
enclosure before entering the print head.
6.1.4.Power the printer
Plug the MagiCube into an AC power outlet using the included power supply. Do not use any other power
supply with this printer.

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 17
6.2. Finding a model
3D printing requires a 3D design to print. There are a few ways you can get 3D models:
6.2.1.Download online
There are multiple websites that allow you to download 3D models to print. A very popular site is
Thingiverse.com, but there are others. Most of these sites will allow you to download and use their models
for free. You can find a list of some of them on our website, at weare3d.ca/3d-models.If you need help
downloading, check out our Quick Start guide for step-by-step instructions.
6.2.2.Design your own
There are many different 3D modeling software programs on the market, and you can use any of them that can
output an .stl file. Included with your MagiCube is a program called 3D Magic, which is an easy to use 3D
modelling program. Visit our website at weare3d.ca/our-3d-products/3d-magic-design-and-modelling-software
for more information.
There are also advanced level 3D design programs such as Autodesk Inventor and SolidWorks that allow you to
design more complicated objects that can be 3D printed or manufactured, as well as free or open source
software such as Sketckup Make, or OpenSCAD.
6.2.3.3D scanning
A 3D scanner will allow you to capture real life objects or people, and create 3D models them. There is are two
scanners available on our website here: weare3d.ca/our-3d-scanner-and-software/ .
6.3. Slicing the model
The MagiCube uses a program called AnyPrint to slice the models for printing. See section 5 fin this manual
or information about AnyPrint and how to operate the software. Although you can print right from AnyPrint,
you can also generate an .x3g file that you can load onto a microSD card and print using the printer’s LCD
display. The .x3g file’s names should not be longer than 8 characters before the file extension (.x3g), or the file
will not show up on the LCD display.
6.4. Starting the print
6.4.1.From SD card
1. Ensure printer enclosure is free of foreign objects.
2. Make sure print bed is properly seated, and that the blue tape is not worn out or smooth.
3. Make sure filament is loaded into the hot-end and routed through the guide tube at the back of the
enclosure.
4. Insert the SD card with .x3g file into the printer.
5. Choose “Build from SD” on the printer’s interface.
6. Select the file you want to print, and push the control button.

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 18
7. Wait for printer to home and heat up.
8. Print will start after heating up is done.
6.4.2.From USB
1. Ensure printer enclosure is free of foreign objects.
2. Make sure print bed is properly seated, and that the blue tape is not worn out or smooth.
3. Make sure filament is loaded into the hot-end and routed through the guide tube at the back of the
enclosure.
4. Plug the printer in using the USB cable provided.
5. Open AnyPrint from the Start Menu on your computer.
6. Choose ‘Import File’
7. Select preferred options. For more information refer to the AnyPrint section of this manual.
8. Click ‘Print’.
9. Wait for printer to home and heat up.
10. Print will start after heating up is done.
6.5. During the print
•Keep hands and objects out of the printer.
•Make sure Print doesn’t detach from bed in the first layers.
•Make sure that filament does not run out.
•If the filament was not routed properly, it may get stuck and cause the print head to get misaligned. Be
sure to watch for any disruptions while printing.
6.6. Pausing or cancelling
To interrupt a print, press the knob for 2 seconds, you can then select ‘Pause’ or ‘Cancel’. If you are printing
from the computer you can also pause the print using the print dialog box.
Pausing will allow you to resume afterwards. If the printer loses power or the print head or bed move while the
print is paused, the printer will lose its place on the print. This will cause an offset part.
Cancelling will stop the print and move the head out of the way to allow you to remove the print.
6.7. After the print
1. Wait for the print head to move out of the way and cool down. (5 minutes)
2. Lift the bed out of the printer with the part attached.
3. Remove part from bed by using plastic scraper, a razor blade, or pry it off with your hands.
4. Clean off any excess filament on the bed.
5. Inspect the enclosure for plastic debris and remove if you see any.
6. Re-tape the bed if tape has worn out.
7. Place bed back into the printer for next print and ensure it is properly seated.!

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 19
7. Maintenance
7.1. Before performing maintenance
Make sure power and USB are unplugged from the printer.
7.2. Clearing a jam
Sometimes filament can jam in the extruder. You’ll know it’s jammed if no more layers are being produced
while printing and you hear a clicking sound coming from the print head. If that happens follow these steps:
7.2.1.Cut the filament
Using!the!side!cutters!provided!with!the!printer,!cut!the!filament!just!above!the!print!head.!
!

!
MagiCube User Manual
WeAre3D.ca Copyright 2015 We Are 3D Inc. Page 20
7.2.2.Remove the extruder cover
Use the 2.5mm Allen key included with the printer to loosen the screws on the extruder cover. Do not remove
the screws from the cover, keep them in place so that the fan and heat-sink will stay in place.
When removing the cover be careful of the wires on the left side, make sure they aren’t being pinched or pulled
as you remove and replace the extruder cover.
!!!! !
7.2.3.Determine where the jam is
The jam could be in the extruder gear mechanism, or below the extruder gear mechanism.
! !! !
