Dremel DigiLab 3D45 User manual

Re d the Dremel 3D45 m nu l nd
these instructions. F ilure to comply
with the w rnings nd instructions m y result in fire,
equipment d m ge, property d m ge, or person l injury.
Alw ys unplug Dremel 3D45 from its power before per-
forming ny service procedures. Failure to do so may re-
sult in personal injury and equipment damage.
Use only Dremel pproved m teri ls nd components.
Use of object materials, or 3D objects other than Dremel
approved object materials and genuine Dremel components
may void warranty.
Repairs on the Dremel 3D45 may require the use of special
tools (pulling devices and bearing press). Authorized repair
centers have trained repair technicians and equipment
necessary to perform these repairs.
For the location of the repair center near you, please call
1-844-4DRML3D (1-844-437-6533) Monday thru Friday,
8AM to 6 M CST. Or, look on our web site at
www.Dremel3D.com and follow the link for ‘Support’.
3D45 Print Remov l
PRINT REMOVAL INSTRUCTIONS
CONTINENTAL UNITED STATES CANADA
Dremel Service Center
4915 21st Street
Racine, WI 53406
hone: 1-844-4DRML3D
Giles Tool Agency
47 Granger Ave,
Scarborough, ON
M1K 3K9, Canada
hone:1-416-287-3000
West Coast Tool
4008 Myrtle Street
Burnaby, B.C. V5C 4G2
hone: 1-604-873-5394
Tools Required:
• Object removal tool
Removing the printed part from the build platform can be
performed in different ways. Be cautious when removing the
part as injuries can occur when using the objet removal tool.
Below is the suggested way to remove a part from the build
plate:
Step 1: Bring Printer to S fe St te
Allow the build plate and nozzle to cool down below 60°C
before handling. To ensure this, using the touchscreen go to
tools, preheat, then select pause on both nozzle tempera-
ture, and platform temperature icons, check the temperature,
allow it to drop below 60°C on both nozzle and platform. The
build platform may take up to 20 minutes to cool down before
it is safe for you to get in contact with it.
Do not touch the extruder tip or he ted build pl tform during Dremel 3D45 oper tion or until it
h s cooled down to t le st 60ºC (140ºF). Contact with the extruder tip or build platform during or after
operation before tip and build platform has cooled may result in personal injury.
Use person l protective equipment. The use of protective equipment such as heat resistant gloves
and safety glasses will reduce personal injuries.
Be w re of your body position when using h nd tools to remove objects from the build pl tform.
Sudden tool slip and improper body position during object removal from build platform may result in
personal injury.
Do not drop the build pl tform. Tempered glass plate may break and result in personal injury.
Do not twist or bend the build pl tform while removing objects. Tempered glass plate may separate
from plastic holder and result in personal injury.
Avoid scratching the build platform when removing objects. Scratches in the build platform will result in
improper object creation.
Ensure there are no by-standers when the instructions are being executed.
All manuals and user guides at all-guides.com
all-guides.com

Step 2: Remove build pl te from printer
a. Remove the build plate from the printer using the tabs on
right and left side of build plate (shown in picture 1). lace
it vertically against a sturdy surface (shown in picture 2).
b. Ensure the build plate is well secure and will not slip once
object removal tool is being used.
Step 3: Remove the printed p rt
a. lace the tip of the object removal tool where the print is
attached to the build plate (shown in the figure below).
b. Give a firm bump on the top part of the object removal tool
(see red arrow).
c. Repeat this process if needed until the part detaches from
the build plate.
Congr tul tions!
You are now ready to build. Build On.
2610038113 08/2018
1.
2.
