Weber SUMMIT 56567 User manual

YOU MUST READ THIS OWNER’S GUIDE
BEFORE OPERATING YOUR GAS GRILL.
mDANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
Leaking gas may cause a fire or explosion
which can cause serious bodily injury,
death, or damage to property.
mWARNING:
1. Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
mWARNING: Follow all leak-check
procedures carefully in this manual prior
to barbecue operation. Do this even if the
barbecue was dealer-assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
56567 03/08/11 LP
US - ENGLISH
#56567
mWARNING: Do not ignite this appliance
without first reading the BURNER
IGNITION sections of this manual.
SUMMIT® GRILL CENTER
Guía del Propietario de la Barbacoa de Gas Propano Licuado - Pg. 45
Mode d’emploi du Grill à gaz PL - Pg. 83
GAS GRILL
LP Gas Grill Owner’s Guide
ESNA

2
mDANGER
Failure to follow the Dangers, Warnings and Cautions contained in this Owner’s Manual may result in serious bodily injury or
death, or in a fire or an explosion causing damage to property.
mWARNINGS
mDo not store a spare or disconnected liquid propane
cylinder under or near this barbecue.
mImproper assembly may be dangerous. Please follow the
assembly instructions carefully.
mAfter a period of storage, and/or nonuse, the Weber®gas
barbecue should be checked for gas leaks and burner
obstructions before use. See instructions in this manual for
correct procedures.
mDo not operate the Weber®gas barbecue if there is a gas
leak present.
mDo not use a flame to check for gas leaks.
mCombustible materials should never be within 24 inches (61
cm) of the back or sides of your Weber®gas barbecue.
mDo not put a barbecue cover or anything flammable on, or in
the storage area under the barbecue.
mYour Weber®gas barbecue should never be used by
children. Accessible parts of the barbecue may be very hot.
Keep young children away while it is in use.
mYou should exercise reasonable care when operating your
Weber®gas barbecue. It will be hot during cooking or
cleaning and should never be left unattended, or moved
while in operation.
mShould the burners go out while in operation, turn all
gas valves off. Open the lid and wait five minutes before
attempting to relight, using the igniting instructions.
mDo not use charcoal or lava rock in your Weber®gas
barbecue.
mNever lean over open grill or place hands or fingers on the
front edge of the cookbox.
mShould a grease fire occur, turn off all burners and leave lid
closed until fire is out.
mDo not enlarge valve orifices or burner ports when cleaning
the valves or burners.
mThe Weber®gas barbecue should be thoroughly cleaned on
a regular basis.
mLiquid propane gas is not natural gas. The conversion or
attempted use of natural gas in a liquid propane unit or
liquid propane gas in a natural gas unit is dangerous and
will void your warranty.
mDo not attempt to disconnect any gas fitting while your
barbecue is in operation.
mUse heat-resistant barbecue mitts or gloves when operating
barbecue.
mKeep any electrical supply cord and the fuel supply hose
away from any heated surfaces.
mCombustion byproducts produced when using this product
contain chemicals known to the state of California to cause
cancer, birth defects, or other reproductive harm.
mDo not use this barbecue unless all parts are in place. The
unit must be properly assembled according to the assembly
instructions.
mDo not build this model of grill in any built-in or slide-in
construction. Ignoring this Warning could cause a fire or
an explosion that can damage property and cause serious
bodily injury or death.
mProposition 65 Warning: Handling the brass material on
this product exposes you to lead, a chemical known to the
state of California to cause cancer, birth defects or other
reproductive harm.
(Wash hands after handling this product.) ◆
LIQUID PROPANE GAS UNITS ONLY:
mUse the pressure regulator and hose assembly that is
supplied with your Weber®gas barbecue.
mDo not attempt to disconnect the gas regulator and hose
assembly or any gas fitting while your barbecue is in
operation.
mA dented or rusty liquid propane cylinder may be hazardous
and should be checked by your liquid propane supplier. Do
not use a liquid propane cylinder with a damaged valve.
mAlthough your liquid propane cylinder may appear to be
empty, gas may still be present, and the cylinder should be
transported and stored accordingly.
mIf you see, smell or hear the hiss of escaping gas from the
liquid propane cylinder:
1. Move away from liquid propane cylinder.
2. Do not attempt to correct the problem yourself.
3. Call your fire department. ◆
WARNINGS

WWW.WEbER.CoM®3
TAbLE oF CoNTENTS
WARNINGS ..........................................2
TAbLE oF CoNTENTS .................................3
EXPLoDED VIEW .....................................4
WARRANTY ........................................12
GENERAL INSTRUCTIoNS ............................12
FOR INSTALLATION IN CANADA ....................................12
OPERATING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
STORAGE AND/OR NONUSE....................................... 12
GAS INSTRUCTIoNS .................................13
SAFE HANDLING TIPS FOR LIQUID PROPANE GAS CYLINDERS .........13
IMPORTANT LP CYLINDER INFORMATION ...........................14
LEAK CHECK PREPARATION.......................................14
CHECK FOR GAS LEAKS..........................................17
REFILLING THE LIQUID PROPANE CYLINDER.........................19
LIGHT FEATURES ...................................19
WEBER®GRILL OUT™ HANDLE LIGHT ..............................19
LIGHTED CONTROL KNOBS .......................................19
bEFoRE USING THE GRILL ...........................20
FUEL LEVEL ....................................................20
SLIDE-OUT GREASE TRAY AND DISPOSABLE DRIP PAN ...............20
HOSE INSPECTION ..............................................20
SNAP IGNITIoN oPERATIoN ..........................21
MAIN bURNER IGNITIoN & USAGE .....................22
MAIN BURNER IGNITION ..........................................22
TO EXTINGUISH .................................................22
MAIN BURNER MANUAL IGNITION .................................23
TO EXTINGUISH .................................................23
GRILLING TIPS & HELPFUL HINTS .....................24
PREHEATING ...................................................24
COVERED COOKING .............................................24
DRIPPINGS AND GREASE ........................................24
FLAVORIZER®SYSTEM ...........................................24
SEAR STATION®.................................................24
CooKING METHoDS .................................25
DIRECT COOKING ...............................................25
INDIRECT COOKING .............................................25
SIDE bURNER IGNITIoN & USAGE .....................26
SIDE BURNER IGNITION ..........................................26
TO EXTINGUISH .................................................26
SIDE BURNER MANUAL IGNITION ..................................27
TO EXTINGUISH .................................................27
SIDE BURNER USAGE ............................................28
SEAR STATIoN® IGNITIoN & USAGE ....................29
SEAR STATION®BURNER IGNITION .................................29
TO EXTINGUISH .................................................29
SEAR STATION®BURNER MANUAL IGNITION ........................30
TO EXTINGUISH .................................................30
USING THE SEAR STATION®.......................................30
SMoKER bURNER IGNITIoN & USAGE ..................31
SMOKER BURNER IGNITION.......................................31
TO EXTINGUISH .................................................31
SMOKER BURNER MANUAL IGNITION...............................32
TO EXTINGUISH .................................................32
USING THE SMOKER .............................................33
CLEANING THE SMOKER .........................................33
RoTISSERIE bURNER IGNITIoN & USAGE ...............34
ROTISSERIE BURNER IGNITION....................................34
TO EXTINGUISH .................................................34
ROTISSERIE BURNER MANUAL IGNITION............................35
TO EXTINGUISH .................................................35
IMPORTANT SAFEGUARDS ........................................36
OPERATING THE ROTISSERIE .....................................36
ROTISSERIE COOKING ...........................................37
ROTISSERIE MOTOR STORAGE ....................................37
ROTISSERIE SPIT STORAGE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
TRoUbLESHooTING .................................38
SIDE bURNER TRoUbLESHooTING ....................38
SEAR STATIoN® TRoUbLESHooTING ...................39
RoTISSERIE TRoUbLESHooTING ......................39
GRILL oUT™ HANDLE LIGHT TRoUbLESHooTING .......39
MAINTENANCE .....................................40
CLEANING......................................................40
WEBER®SPIDER/INSECT SCREENS ................................40
BURNER TUBE CLEANING ........................................40
REPLACING MAIN BURNERS ......................................41
SIDE BURNER MAINTENANCE .....................................43
ANNUAL MAINTENANCE ..........................................44

4
7
9
10
25
26
27
28
29
36
38
39
40
41
42
43
50
21
22
23
24
44
49
55
30
31
32
33
34
35
51
54
56
20
45
46
47
48
2
3
4
5
6
1
837
52
53
11
13
14
15
16
17
18
19
12
SUMMIT_6Brn_Grill Center_LP_US_021511
EXPLoDED VIEW • DIAGRAMA DE DESPIECE • VUE ECLATEE

WWW.WEbER.CoM®5
1. Shroud Hardware
2. Shroud
3. Thermometer
4. Thermometer Bezel
5. Handle
6. Grill Out™ Handle Light
7. Warming Rack
8. Cooking Grate
9. Flavorizer®Bar
10. Burner Tube
11. Manifold
12. Control Panel Wiring Harness
13. Control Panel
14. Small Knob Bezel
15. Small Knob
16. Large Knob
1 7. Large Knob Bezel
18. Sear Station®Knob
19. Battery Housing
20. Water Baffle / Heat Shield
21. Disposable Drip Pan
22. Slide-Out Grease Tray
23. Catch Pan
24. Catch Pan Holder
25. Left Door
26. Door Handle
2 7. Right Door
28. Left Frame Panel
29. Bottom Panel
30. IR Burner Cover
31. Infrared Burner
32. IR Burner Box
33. IR Burner Igniter Wire
34. Thermocouple
35. IR Burner Hose
36. Rotisserie Spit Assembly
3 7. Cooking Grate
38. Smoker Box
39. Smoker Bar
40. Smoker Burner Tube
41. Sear Station®Burner
42. Cookbox
43. Bulkhead
44. Manifold Hose
45. Hose / Regulator
46. Side Burner Hose
4 7. Frame Support
48. Rotisserie Spit Storage Bracket
49. Back Panel
50. Right Frame Panel
51. Tank Scale
52. LED Tank Scale Assembly
53. Shelf Bracket
54. Tank Glide
55. Matchstick Holder
56. Adjustable Leg
EXPLoDED VIEW LIST • LISTA DEL DIAGRAMA DE DESPIECE • LISTE DE LA VUE ECLATEE
Accesorios de la cubierta
Cubierta
Termómetro
Moldura decorativa del termómetro
Asa
Lámpara de asa GrillOut™
Rejilla para calentar
Parrilla de cocción
Barra Flavorizer®
Tubo del quemador
Múltiple
Cableado prefabricado
del panel de control
Tablero de control
Moldura decorativa de la perilla pequeña
Perilla pequeña
Perilla grande
Moldura decorativa de la perilla grande
Perilla de la estación
de dorado Sear Station®
Compartimiento de las baterías
Reflector de agua / Pantalla térmica
Bandeja de goteo desechable
Bandeja deslizante de grasa
Plato recolector
Soporte del plato recolector
Puerta izquierda
Asa de la puerta
Puerta derecha
Panel izquierdo del bastidor
Panel inferior
Tapa del quemador infrarrojo
Quemador infrarrojo
Caja del quemador infrarrojo
Cable de encendido
del quemador infrarrojo
Termopar
Manguera del quemador infrarrojo
Ensamble del espetón del asador giratorio
Parrilla de cocción
Caja del ahumador
Barra del ahumador
Tubo quemador del ahumador
Quemador de la estación
de dorado Sear Station®
Caja de cocción
Tabique divisorio
Manguera del múltiple
Manguera / Regulador
Manguera del quemador lateral
Soporte del bastidor
Soporte de almacenaje
del espetón del asador giratorio
Panel posterior
Panel derecho del bastidor
Báscula del tanque
Ensamble de la báscula LED del tanque
Soporte del estante
Deslizadera del tanque
Portacerillos
Pata ajustable
Quincaillerie de l’étui
Etui
Thermomètre
Bec du thermomètre
Poignée
Eclairage de poignée Grill Out™
Grille de maintien au chaud
Grille de cuisson
Barre Flavorizer®
Tube du brûleur
Collecteur
Harnais de câblage du
panneau de commandes
Panneau de commandes
Bec du petit bouton
Petit bouton
Grand bouton
Bec du grand bouton
Bouton Sear Station®
Logement des piles
Baffle à eau / Protection anti-chaleur
Egouttoir jetable
Plateau amovible pour la
récupération des graisses
Egouttoir
Support pour égouttoir
Porte de gauche
Poignée de porte
Porte de droite
Panneau du cadre de gauche
Panneau inférieur
Cache du brûleur IR
Brûleur infrarouge
Boîtier du brûleur IR
Câble de l’allumeur du brûleur IR
Thermocouple
Tuyau du brûleur IR
Assemblage de la broche de la rôtissoire
Grille de cuisson
Boîtier du fumoir
Barre du fumoir
Tube du brûleur du fumoir
Brûleur de la Sear Station®
Boîtier de cuisson
Tête du brûleur
Tuyau du collecteur
Tuyau / Régulateur
Tuyau du brûleur latéral
Support du cadre
Support du rangement de la
broche de la rôtissoire
Panneau arrière
Panneau du cadre de droite
Graduation de la bouteille
Assemblage LED de la
graduation de la bouteille
Support pour étagère
Glissière de la bouteille
Support pour allumette
Pied ajustable

6
EXPLoDED VIEW • DIAGRAMA DE DESPIECE • VUE ECLATEE
11
12
13
14
15
5
6
7
8
9
2
3
4
1
10
SUMMIT_Grill Center Left Cabinet_121610
14
15
18
20
17
16
19
6
7
8
9
10
3
2
4
5
1
13
12
11
SUMMIT_Grill Center SB Cabinet_122110

WWW.WEbER.CoM®7
1. Side Burner Lid
2. Wok Ring
3. Side Burner Grate
4. Side Burner Inner Ring 1
5. Side Burner Outer Ring 2
6. Side Burner Head
7. Side Burner
8. Wire Shelf
9. Control Knob
10. Igniter
11. Shelf Frame
12. Door
13. Door Handle
14. Back Panel
15. Shelf Bracket
16. Water Deflector
1 7. Right Frame
18. Right Frame Skirt
19. Adjustable Leg
20. Bottom Panel
Tapa del quemador lateral
Aro para wok
Rejilla del quemador lateral
Aro interno 1 del quemador lateral
Aro interno 2 del quemador lateral
Cabezal del quemador lateral
Quemador lateral
Estante de alambre
Perilla de control
Encendedor
Bastidor del estante
Puerta
Asa de la puerta
Panel posterior
Soporte del estante
Deflector de agua
Bastidor derecho
Faldón del bastidor derecho
Pata ajustable
Panel inferior
EXPLoDED VIEW LIST • LISTA DEL DIAGRAMA DE DESPIECE • LISTE DE LA VUE ECLATEE
1. Rotisserie Motor
2. Rotisserie Bracket
3. Table
4. Shelf Bracket
5. Left Frame
6. Left End Skirt
7. Adjustable Leg
8. Paper Towel Holder
9. Door
10. Door Handle
11. Back Panel
12. Wire Shelf
13. Shelf Frame
14. Water Deflector
15. Bottom Panel
Motor del asador
Soporte del asador giratorio
Mesa
Soporte del estante
Bastidor izquierdo
Faldón del extremo izquierdo
Pata ajustable
Portatoallas de papel
Puerta
Asa de la puerta
Panel posterior
Estante de alambre
Bastidor del estante
Deflector de agua
Panel inferior
Moteur de la rôtissoire
Support de la rôtissoire
Tablette
Support pour étagère
Cadre de gauche
Jupe d’extrémité gauche
Pied ajustable
Support pour serviette en papier
Porte
Poignée de porte
Panneau arrière
Etagère métallique
Cadre de l’étagère
Déflecteur à eau
Panneau inférieur
Couvercle du brûleur latéral
Bague pour wok
Grille du brûleur latéral
Bague interne du brûleur latéral 1
Bague externe du brûleur latéral 2
Tête du brûleur latéral
Brûleur latéral
Etagère métallique
Bouton de commande
Allumeur
Cadre de l’étagère
Porte
Poignée de porte
Panneau arrière
Support pour étagère
Cadre de droite
Déflecteur à eau
Jupe du cadre de droite
Pied ajustable
Panneau inférieur

8
14
15
16
17
19
18
6
7
8
9
10
3
2
4
5
1
13
12
11
SUMMIT_Grill Center_Social_SB Cabinet_122110
EXPLoDED VIEW • DIAGRAMA DE DESPIECE • VUE ECLATEE
7
8
9
10
11
3
4
2
1
6
SUMMIT_Grill Center Middle Cabinet_121610
5

WWW.WEbER.CoM®9
EXPLoDED VIEW LIST • LISTA DEL DIAGRAMA DE DESPIECE • LISTE DE LA VUE ECLATEE
1. Cooler Lid
2. Cooler
3. Corner Cabinet Top Panel
4. Left Back Panel
5. Door Assembly
6. Front Panel
7. Door Hinge Rod
8. Door
9. Right Back Panel
10. Trash Can
11. Bottom Panel
1. Side Burner Lid
2. Wok Ring
3. Side Burner Grate
4. Side Burner Inner Ring 1
5. Side Burner Outer Ring 2
6. Side Burner Head
7. Side Burner
8. Side Burner Shelf
9. Control Knob
10. Igniter
11. Shelf Frame
12. Door
13. Door Handle
14. Back Panel
15. Shelf Bracket
16. Water Deflector
1 7. Right Frame
18. Adjustable Leg
19. Bottom Panel
Tapa del quemador lateral
Aro para wok
Rejilla del quemador lateral
Aro interno 1 del quemador lateral
Aro interno 2 del quemador lateral
Cabezal del quemador lateral
Quemador lateral
Estante del quemador lateral
Perilla de control
Encendedor
Bastidor del estante
Puerta
Asa de la puerta
Panel posterior
Soporte del estante
Deflector de agua
Bastidor derecho
Pata ajustable
Panel inferior
Couvercle du brûleur latéral
Bague pour wok
Grille du brûleur latéral
Bague interne du brûleur latéral 1
Bague externe du brûleur latéral 2
Tête du brûleur latéral
Brûleur latéral
Etagère du brûleur latéral
Bouton de commande
Allumeur
Cadre de l’étagère
Porte
Poignée de la porte
Panneau arrière
Support pour étagère
Déflecteur à eau
Cadre de droite
Pied ajustable
Panneau inférieur
Tapa del enfriador
Enfriador
Panel superior del gabinete de esquina
Panel izquierdo posterior
Ensamble de la puerta
Panel frontal
Varilla de la bisagra de la puerta
Puerta
Panel derecho posterior
Bote de basura
Panel inferior
Couvercle du refroidisseur
Refroidisseur
Panneau supérieur du meuble de coin
Panneau arrière gauche
Assemblage de la porte
Panneau avant
Tige du gond de la porte
Porte
Panneau arrière droit
Corbeille
Panneau inférieur

10
EXPLoDED VIEW • DIAGRAMA DE DESPIECE • VUE ECLATEE
SUMMIT_Grill Center Social Center_121610
10
11
12
13
14
15
2
3
5
6
7
1
8
4
9
