WebGate OPT-RX16-RS485C User manual
The World’s first certified by
HDcctv Alliance
Instruction Manual Rev 1.1
16 CHANNEL FIBER OPTIC RECEIVER
supports CoC/RS485
OPT-RX16-RS485C
※Please read instruction manual carefully before installing or using this
product.
Product Features
1. This product converts HD-SDI / EX-SDI signal to optical signal and
transmits it.
2. CoC(Control over Coax) and video transmission can be done with a
single coaxial cable.
3. Video/Data (RS485) transmission up to 20 Km through single mode
fiber-optic cable.
4. Supports 1080p25/30 video.
5. LED indicators for power, video, data and fiber-optic status.
Components
Receiver
16Ch RX
Accessories
Instruction Manual
Power Cable
Adapter
WEBGATE Inc.
6F, Hanlim Venture Town B/D, 284 Gongdanro,
Gunpo-Si, Gyeonggi-do, Korea
TEL: +82-31-428-9300
FAX: +82-31-428-9400
Client Service: +82-1644-3421
www.webgateinc.com
Premium to your HD-CCTV solution
Precautions
Fiber-Optic Cable
1. For Cable connection, do not bend the cable
narrower than 30 mm (minimum allowable
refraction range).
2. Do not pull the cable from both ends.
3. Do not spin the optical cable while the cable is
connected to connector.
4. Do not knot the optical cable.
Coax Cable
The impedance of the coaxial cable and BNC connectors must be 75 Ohm.
HD-SDI / EX-SDI maximum transmission distance depends on the cable
manufacturer or installation environment.
Note) When selecting a cable, consider the maximum transmission
distance of the cable which depends on its attenuation at 750 MHz.
(dB/100m < 25dB of attenuation is recommended.)
Note) Foamed or high-foamed insulation cable is recommended.
Note) Double or triple shielded cable is recommended.
Trouble Shooting [FAQ]
Trouble & Symptom
Way to Solve
Can not turn on the
equipment, and LED
indicators do not work.
√Check the power is properly connected
to the equipment.
√Check the input power voltage..
√If it still does not work, please check
the power adapter or replace it.
Nothing shows on the
screen.
√Check video of camera connected to
transmitter. If there is no video output
from camera, nothing could be shown
on the screen.
√Check the power and cable connections
of camera.
√Check the cable connections between
camera, transmitter, receiver and DVR.
Can not control camera’s
OSD menu and PTZ
√Check the RS485 connection among
camera, transmitter, receiver and DVR.
√Check the polarity of RS485(+,-).
√Check the setting of DVR and camera.
If the setting values such as baudrate,
protocol, address are not properly
configured, camera control can not be
achieved.
Device Connection Method
1. Connect camera’s video output to transmitter’s “HD-SDI In” using coaxial cable.
- Non PoC Camera: Connect power supply and RS485 to control PTZ and OSD of camera.
- PoC Camera: No need for power and RS485 connection.
2. Connect transmitter and receiver using single mode LC type fiber-optic cable.
- When connecting optical cable to the converter, insert fully until you hear a click sound.
- As shown in Figure 1, pull the lever to lock the optical cable not to fall off from the converter.
3. Connect receiver’s “HD-SDI Out” to DVR’s “HD-SDI In” using coaxial cable.
- Non PoC DVR: Connect RS485 to control PTZ and OSD of camera.
- PoC DVR: No need for RS485 connection.
- For each channel, set the DIP switch in front of receiver to select CoC or RS485.
4. Check the status of LED indicators to confirm the correct connections.
- Power: Red LED will be lit if the power is on.
- HD-SDI: Green LED will be lit if the video signal is entered through fiber-optic cable.
- Optic: Green LED will be lit if transmitter and receiver are connected each other.
- CoC(RX): Green LED will be lit if the camera control signal is entered.
5. Check the monitor connected at DVR whether all connected channels are properly displayed.
Specification
Model
OPT-RX16-RS485C
Function
16 Channel Fiber Optic Receiver
Video Standard
HD-SDI SMPTE 292M (+ EX-SDI)
Resolution
SMPTE 274M (1080p25/30)
Function
Equalizing, Reclocking, Upstream Signaling, Control over Coax
CoC
Control over Coaxial Baudrate: 57600
Impedance
75 ohm
Fiber Optic Type
Single mode
Optic Connector Type
LC
HD-SDI / EX-SDI Length
Approx. 180m (HD-SDI) / 400m (EX-SDI) @ 5C-HFBT
Fiber Length
Approx. 20Km @ 1.5Gbps
Data Channel
RS485 Upstream (Remote Control from DVR to Camera)
Indicator LED
Power(Red), Optic(Green), HD-SDI(Green), CoC(Green)
Operating Temperature / Humidity
0˚C ~ 50˚C / 20%RH ~ 80%RH
Power Consumption
Max. 30 W
Dimension (W x D x H)
361 x 483 x 44 mm
Weight
4.5 Kg
Certifications
KC, FCC, CE, RoHS
Appearance & Dimension (Unit: mm)
Warranty
Product name
16 CHANNEL FIBER OPTIC RECEIVER
Warranty term
Model name
OPT-RX16-RS485C
2 years after purchase
(This warranty term can be
changed by contract for supply)
Date of purchase
Year Month Day
Warranty term
Year Month Day
Serial number
Customer’s address
Name
Contact
Address of shop (Company name)
Name
Contact
◈Please fill out vacant area before sending products.
★For customer service ★
Please read this manual again before requesting customer service.
Any simple malfunctions due to customer’s misunderstanding on the product could be
resolved by customer.
How to request service?
Please inform details of malfunctions correctly.
Free or non free repair will be decided based on details of warranty card.
WEBGATE Inc.
6F, Hanlim Venture Town B/D, 284 Gongdanro, Gunpo-Si, Gyeonggi-do, Korea
Main TEL: +82-31-428-9300 / Client Service: +82-1644-3421
The damages caused from following conditions will be repaired by customer’s cost.
1. Any damage comes from customer’s carelessness
2. When improper power is entered
3. When you repair unit by yourself
4. Any damage comes from natural disaster like lightening, flood, etc.
5. Consumable parts replacement
