weBoost Home 4G User manual

Connect 4G
SKU: 470103 MAP: $549.99
FEATURES
• Boosts 4G LTE & 3G signals for entire home or small oce
• Coverage area up to 5,000 sq. ft.
• For multiple devices and users
• Works on ALL cellular devices with ALL carriers simultaneously
• Enhances talk, text, and high-speed 4G LTE internet
About
The Connect 4G allows users to get better voice and data
signal with fewer dropped calls, improved voice quality,
faster uploads and downloads. Our 4G signal booster in-
creases cell signals up to 32x and enhances 4G LTE and 3G
signals for buildings up to 5,000 sq ft. Compatible with all
US networks, it works on Verizon, AT&T, Sprint, T-Mobile, US
Cellular, Straight Talk and more.
Installation guide available for download and all parts are
included in the kit with trained support staff on call to assist.
All boosters come with a 2-year warranty.
Specifications
MODEL NUMBER
FREQUENCIES
MAX GAIN
IMPEDANCE
POWER
CONNECTORS
BOOSTER DIMENSIONS
BOOSTER WEIGHT
470103†
Band 12/17 700 MHz
Band 13 700 MHz
Band 5 850 MHz
Band 4 1700/2100 MHz
Band 2 1900 MHz
65 dB
75 Ohm
110-240 V AC, 50-60 Hz, 8 W
F-Female
6.5 x 4.25 x 1.25 in
0.445 lbs
Coverage Area
IF YOUR OUTSIDE SIGNAL IS
About 5 bars
About 3 to 4 bars
About 1 to 2 bars
No existing will not work
-89 AND LOWER
-90 dB
-100 dB
UP TO 5,000 sq. ft.
UP TO 3,500 sq. ft.
UP TO 1,000 sq. ft.
A signal booster likely
YOUR BOOSTED SIGNAL MAY BE
FASTEST
NETWORK
SPEEDS
MULTI-USER
WIRELESS
BOOSTER
UP TO
+65 dB GAIN
UP TO 5,000 sq. ft.
COVERAGE
Flat Window
Cable
(951177)
Kit Includes
Connect 4G Outside Directional
Antenna
(314475)
Inside Panel Antenna
(311155)
Power Supply
(850012)
(x2) 15’ & (x1) 30’ White
Low Loss RG6 (75 Ohm)
Coax Cable
(950615-950630)
WARNING: This product can expose you to chemicals including Nickel, which
is known to the State of California to cause cancer, and Bisphenol A, which is
known to the State of California to cause birth defects or other reproductive
harm. For more information go to www.P65Warnings.ca.gov
!
†

Installation
Package Dimensions Support
Website: http://support.weboost.com
Phone: [phone]
Monday to Saturday
470103_Connect4G_SS_Rev02_100918
7.548 lbs.
FOR PARTNER’S USE
2 Year Warranty from Purchase.
7.25 L x 14 W x 11 H
7.25 in.
x
14 in.
7.25 in.
x
11 in.
11 in.
x
14 in.
1
2
3
Receives signal: The powerful antenna
reaches out to access a voice and 3G,
4G, and LTE data signal, and delivers it
to the booster.
Boost signal: The booster receives
the signal, amplifies it, and serves as
a relay between your phone and the
nearest cell tower.
Broadcasts signal: Your devices get a
stronger signal, and calls and data are
fed through the booster back to the
network.
Available Accessories
Optional Antenna Kits
MASTER CARTON: 25 L x 20 W x 15 H |39 lbs.
FRONT SIDE TOP/BOTTOM WEIGHT
UPC
CONNECT 4G
8 11815 02452 1
4G Interior Wall
Mount Panel
Antenna
311155*
RG-6 F-Male /
F-Male, 2ft White
Cable
950602†
Lightning Surge
Protector 75 Ohm
859992†
-3dB 2-Way
Splitter75 Ohm
850034*
20 ft. White RG6
Low Loss Coax
950620*
F-Female to
F-Female Barrel
Connector
971129*
