webtrol WT Series Installation instructions

Installation & perating Manual
Congratulations on Your Choice in Purchasing this Webtrol Pump!
Its Quality is unsurpassed in material and workmanship and has been factory tested.
If properly installed, it will give many years of trouble free service.
WT/WS Series
02/20 Edition
4” Submersible Water Well Pumps

Subject Page
Pre-Installation 2
Installation 3 & 4
Starting Procedure 5
WT Series SubDrive/Utility Drive Systems 6
Submersible Motor Cooling 6
Electrical 6 - 10
System Trouble Shooting 11 & 12
Owners Information 12
Examine the components carefully to ensure that no damage has occurred to the liquid end, motor, cable or control box
during shipment. Report damage immediately to the shipping carrier or to your dealer. The Webtrol submersible pump
should remain in the shipping carton until it is ready to be installed. Do not drop or mishandle the pump prior to
installation.
Warning: The motor is equipped with an electrical cable. It should NEVER be used to lift or carry the pump.
Damage to the electrical cable can cause shock, burns or death!
Control boxes and panels should never be mounted in direct sunlight or high temperature locations as this will cause a
reduction in capacitor life and unnecessary tripping of the overload protectors. The worst place to mount a control box is
in a damp well pit, or other humid locations, as this accelerates component failure from voltage breakdown or corrosion.
Control boxes with voltage relays, 1 1/2 HP & up, are designed for vertical upright mounting only. Mounting in other posi-
tions will affect the operation of the relay.
Caution: If the pump pressure exceeds the recommended working pressure of the pressure tank, a pressure relief
valve capable of passing the entire pump flow should be installed.
Caution: Be sure that the control box HP and voltage match the motor.
The well driller should fully develop the well. All sand and foreign matter should be removed. If this pump is used to
replace an oil-filled submersible motor that has failed, the well must be bailed free of oil.
Pump performance is based upon pumping clear and cold water that is free of air or gases.
Pumps should be sized properly, for flow and head.
To test the well water for purity, contact your local health department for the proper testing procedure.
Maximum water temperature should not exceed 86° . The pump should be installed at least, 10 feet below the maxi-
mum drawdown level but no less than 10 feet from the bottom of the well to allow for sediment build up.
The pump should be installed according to state water well codes governing the setting of pumps. All wiring must meet
National Electrical Code or Canadian Electrical Code and local code requirements.
Pipe joint compound can cause plastic to crack. Use only teflon tape when sealing joints in plastic pipe.
- 2 -
Table f Contents
Pre-Installation
Three (3) - Wire Control Boxes And Panel Equipment

A typical installation diagram is shown in (Figure 1, page 4). All electrical work should be performed by a competent
electrician in accordance with the National Electrical Code, as well as local codes and regulations.
Never run the pump unless it is completely submerged in water. If operated without water, the pump and motor could be
severely damaged.
The riser pipe should be properly sized and selected based upon the flow rate and friction-loss factors.
Protect all piping, fittings and water system components from freezing.
When lowering the pump into the well, use the discharge pipe. A safety cable may be attached to the pump’s discharge
head lifting eye. Never use the electrical cable to raise or lower the pump. Do not scrape the electrical cable against the
well casing while raising or lowering the pump into well. Secure the cable to the discharge pipe at 10’ intervals with elec-
trical tape and use cable guards every 20’ to avoid cable damage.
Notice: Webtrol 4” Submersible Pumps are assembled with right hand threads. Hold the pump’s discharge head with
a wrench while installing the riser pipe or a check valve. Be sure you do not loosen the discharge in the tube.
Do not hold the pump housing during installation of the riser pipe or a check valve.
Plastic pipe has a tendency to stretch under load. When securing the cable to the riser pipe, allow 2 inches of
slack between the taped intervals.
To ensure that the pump and motor are free to rotate, remove the screen and rotate the shaft by hand.
If the pump is capable of over pumping the well, a liquid level control is required.
Attach the riser pipe to the pump. If plastic pipe is used, provide torque arrestors and safety cable. Review typical
installation shown.
When installing Schedule 80 threaded plastic pipe and extruded couplings, caution should be taken to prevent excessive
tightening which can damage the fitting and/or pipe. The correct degree of tightness may be determined by threading the
extruded coupling hand tight, plus a half turn with a strap wrench. Pipe wrenches or pliers that may indent or scratch the
pipe should not be used. Over tightening may result in eventual or immediate failure due to excessive stress. Do not use
pipe dope. Use teflon tape if needed.
An ohmmeter, or megger should be used to measure the insulation resistance on the power cable every 20 feet as the
pump is lowered. This will locate any fault in the cable.
A check valve should always be installed in submersible pump installations. If the pump does not have a built-in check
valve, a line check valve should be installed in the discharge line. A line check valve should be installed within 25 feet of
the pump, and below the drawdown level of the water supply. or installations deeper than 200 feet, check valves
should be installed in 200 foot intervals.
- 3 -
Installation
Caution: Restarting the motor within 5 seconds after power is removed may cause the motor overload to trip.
Warning: ailure to ground the control box or panel grounding terminal can result in a serious or fatal electrical
shock hazard if a circuit fault occurs.
2-Wire Motor Solid State Controls.

Notice: Never operate the pump with the discharge valve completely closed. The pump can destroy itself if run at
shutoff pressure.
Notice: Never start a pump with the discharge valve completely open, if the pump will operate at high flow - low head
or if the pump is placed in an artesian well. This can cause the pump to up thrust the impellers-shaft
assembly, which can cause premature wear and failure.
To test the well water for clarity, attach a temporary horizontal length of pipe
and gate valve to the riser pipe.
Make sure the controls are in the off position. Connect the motor leads and
power supply to control box, electrical disconnect box or magnetic starter. See
wiring diagrams. Do not start the pump!
Partially open the gate valve and start pump. To make sure the 3 phase motor
is running in the right direction, note the direction of jerk as the motor starts.
If connections are properly made, the pump will jerk clockwise when looking
into the pump discharge when started. If the jerk is counter - clockwise, the
motor is running in the wrong direction. Interchange any two cable leads where
they connect to the lead terminals in the magnetic starter. Restart the pump
and let it operate until the water runs clear of sand, silt and other impurities.
When the water is completely clear at the initial gate valve setting, slowly open
valve in small increments allowing the water to clear before progressing. The
pump should not be stopped until the water runs clear.
Remove the gate valve for permanent installation.
Install a sanitary well seal or pitless adapter, submersible pump/motor, electrical conduit and surface piping according to
local code requirements.
Control Box
or Electrical
Disconnect Box
Temporary Wiring
Temporary Piping
Gate Valve
Pump Installation
for Developing a Well Pump in Well
Figure 1
Make sure that the pump has been properly grounded prior to testing.
Starting Procedure
- 4 -
Pump & Motor
Controller
Clearance
For Airflow
6"
min.
Constant Water
Pressure To House
6 Feet or less
(Pressure tank to
Pressure Sensor)
Pressure Tank
6"
min.
6"
min.
Pressure Sensor
1
2
4
3
Webtrol has added the SubDrive Systems using 3PH motors, and Utility Drive
Systems designed for use with 3 wire motors. Both Systems will deliver water at a
constant pressure. Carefully read and follow all the safety instructions in the
“Installation Manual” that is shipped with the SubDrive/Utility Drive Series Systems.
SubDrive/Utility Drive Systems
Webtrol’s SubDrive/Utility Drive System consists of only 4 components:
1) Webtrol’s standard pump & motor assembly. 3) Pressure tank
2) SubDrive/MonoDrive controller. 4) Pressure sensor.
Pump Flow Rating Controller Model Minimum Tank Size
SubDrive 75 or Utility Drive 2 gallons
Less than 12 GPM SubDrive 100 4 gallons
SubDrive 150 or Utility Drive 4 gallons
SubDrive 300 8 gallons
SubDrive 75 or Utility Drive 4 gallons
12 GPM or higher SubDrive 100 8 gallons
SubDrive 150 or Utility Drive 8 gallons
SubDrive 300 20 gallons
Minimum Pressure Tank Size (Total Capacity)
Figure 2

- 5 -
The submersible motor requires a minimum flow of
water past the motor to insure proper cooling. Table 1
below shows the minimum flow rates in GPM for vari-
ous diameters and motor size.
If the flow rate is less than specified, a flow inducer
sleeve or an alternate method of increasing water
velocity past the motor must be used for proper cooling.
Several conditions requiring a flow sleeve are; the
pump is in an open body of water, the well is top feed-
ing and the well diameter is too large to meet Table 1
flow requirements.
Flow Inducer
Sleeve
Flow Inducer
Discharge Tube
A flow inducer sleeve is
a tube over the motor,
closed off above the
pump intake and
extended to the bottom
of the motor or lower.
The sleeve material is
corrosion resistant
metal or heavy plastic.
If the casing is too small
for a flow inducer sleeve
and the pump cannot be
raised, a tube may be
installed as follows:
A. Tap a 1/4” tube (ID)
into the pump outlet
(below check valve).
B. Clamp it to the pump
and motor.
C. Aim tube upward so
flow is introduced 1
foot below the motor.
D. Protect tube with
spacers and angle iron.
Inches Casing 4” Dia. Motor
or Sleeve I.D. .25 ft/sec GPM
4 1.2
5 7
6 13
Electrical supply must match the motor voltage, phase and frequency found on the nameplate on the motor and control box.
Motor electrical data can be found in tables 4, 4A, 5 & 5A. If voltage variations are larger than + 10%, do not operate the pump.
On 3 phase installations, use a magnetic starter and quick trip overload heaters. ailure to use quick trip heaters in all three lines
will not provide adequate motor protection and the warranty will be void.
Warning: A faulty motor or wiring can be an electrical shock hazard if it or surrounding water is accessible to human
contact. To prevent this from occurring, connect the motor frame to the power supply grounding terminal with
a stranded copper conductor no smaller than the wires carrying current to the motor.
Caution: Use of smaller than recommended cable voids warranty, can cause failure of the motor to start and operate
properly and may cause cable overheating!
Table 1
Submersible Motor Cooling
Electrical
Sizes given are for copper wire. If aluminum wire is used, it must be two sizes larger and oxidation inhibitors must be used on
the connections. Example: If the table calls for #12 copper wire, #10 aluminum wire would be required.
Note: #11 wire is available, but not often used.
Maximum lengths shown maintain motor voltage at 95% of service entrance voltage, running at maximum nameplate amperes.
To comply to CSA, multiply the cable lengths shown by .6 for maximum feet. This will maintain motor voltage at 97% of service
entrance voltage, running at maximum nameplate amperes.
The portion of the total cable length which is between the supply and single phase control box with a line contactor, should not
exceed 25% of total maximum allowable to ensure reliable contactor operation. Single phase control boxes without line contac-
tors may be connected at any point in the total cable length.
Cable Information

- 6 -
Motor Rating 60°C Insulation - AWG Copper Wire Size MCM Copper Wire Size
Volts HP 14 12 10 8 6 4 3 2 1 0 00 000 0000 250 300 350 400 500
1/2 710 1140 1800 2840 4420
3/4 510 810 1280 2030 3160
1 430 690 1080 1710 2670 4140 5140
200 1 1/2 310 500 790 1260 1960 3050 3780
2 240 390 610 970 1520 2360 2940 3610 4430 5420
3 180 290 470 740 1160 1810 2250 2760 3390 4130
5 0 170 280 440 690 1080 1350 1660 2040 2490 3050 3670 4440 5030
7 1/2 0 0 200 310 490 770 960 1180 1450 1770 2170 2600 3150 3560
1/2 930 1490 2350 3700 5760 8910
3/4 670 1080 1700 2580 4190 6490 8060 9860
1 560 910 1430 2260 3520 5460 6780 8290
230 1 1/2 420 670 1060 1670 2610 4050 5030 6160 7530 9170
2 320 510 810 1280 2010 3130 3890 4770 5860 7170 8780
3 240 390 620 990 1540 2400 2980 3660 4480 5470 6690 8020 9680
5 0 230 370 590 920 1430 1790 2190 2690 3290 4030 4850 5870 6650 7560 8460 9220
7 1/2 0 0 260 420 650 1020 1270 1560 1920 2340 2870 3440 4160 4710 5340 5970 6500 7510
1/2 3770 6020 9460
3/4 2730 4350 6850
1 2300 3670 5770 9070
1 1/2 1700 2710 4270 6730
460 2 1300 2070 3270 5150 8050
3 1000 1600 2520 3970 6200
5 590 950 1500 2360 3700 5750
7 1/2 420 680 1070 1690 2640 4100 5100 6260 7680
10 310 500 790 1250 1960 3050 3800 4680 5750 7050
Single Phase Motors
Two or Three Wire Cable, 60HZ (Service Entrance to Motor-Maximum Cable Length In Feet)
Three Phase Motors
Three Phase, Three Wire Cable, 60HZ (Service Entrance to Motor-Maximum Cable Length In Feet)
Table 2
Table 3
Motor Rating 60°C Insulation - AWG Copper Wire Size
Volts HP 14 12 10 8 6 4 3 2 1 0 00 000 0000
115 1/2 100 160 250 390 620 960 1190 1460 1780 2160 2630 3140 3770
1/2 400 650 1020 1610 2510 3880 4810 5880 7170 8720
3/4 300 480 760 1200 1870 2890 3580 4370 5330 6470 7870
1 250 400 630 990 1540 2380 2960 3610 4410 5360 6520
230 1 1/2 190 310 480 770 1200 1870 2320 2850 3500 4280 5240
2 150 250 390 620 970 1530 1910 2360 2930 3620 4480
3 0 190 300 470 750 1190 1490 1850 2320 2890 3610
5 0 0 0 280 450 710 890 1110 1390 1740 2170 2680
7 1/2 0 0 0 0 310 490 610 750 930 1140 1410 1720
60°C Insulation: The maximum temperature rating of the cable insulation. This includes the water temperature and the
increase in the insulation temperature caused by the current flowing thru the wire.
244504 1/2 115 60 1.60 10.0 670 12.0 960 1.0-1.3 64.4 R 35 20 30
Two 244505 1/2 230 60 1.60 5.0 670 6.0 960 4.2-5.2 32.2 R 20 10 15
Wire 244507 3/4 230 60 1.50 6.8 940 8.0 1310 3.0-3.6 40.7 N 25 15 20
244508 1 230 60 1.40 8.2 1210 9.8 1600 2.2-2.7 48.7 N 30 20 25
244309 1 1/2 230 60 1.30 10.6 1700 13.1 2180 1.5-1.9 66.6 M 35 20 30
Franklin Single Phase Motors
Single Phase Motor Specifications (60HZ) 3450 RPM
Table 4
Type Motor HP Volts HZ S. .
Model (2) (2) Res.
Amps Watts Amps Watts M=Main Amps Code
S=Start
Std.
use
Amps
Dual
Element
Time
Delay
Std.
use
Amps
Circuit
Breaker
Or use
Amps
Max Per
NEC
Rated Input
( ull Load)
Maximum
(S. . Load)
Winding (1)
(Resistance
/Ohms)
Locked
Rotor
KVA

- 7 -
214504 1/2 115 60 1.60 Y10.0 670 Y12.0 960 M1.0-1.3 50.5 M 35 20 30
B10.0 B12.0 S4.1-5.1
R0 R0
214505 1/2 230 60 1.60 Y5.0 670 Y6.0 960 M4.2-5.2 23.0 M 20 10 15
B5.0 B6.0 S16.7-20.5
Three R0 R0
Wire 214507 3/4 230 60 1.50 Y6.8 940 Y8.0 1310 M3.0-3.6 34.2 M 25 15 20
B6.8 B8.0 S10.7-13.1
R0 R0
214508 1 230 60 1.40 Y8.2 1210 Y9.8 1600 M2.2-2.7 41.8 L 30 20 25
B8.2 B9.8 S9.9-12.1
R0 R0
224300 1 1/2 230 60 1.30 Y10.0 1660 Y11.5 2100 M1.7-2.2 52.0 J 35 20 30
B9.9 B11.0 S8.0-9.7
R1.3 R1.3
Three 224301 2 230 60 1.25 Y10.0 2060 Y13.2 2610 M1.8-2.3 51.0 G 30 20 25
Wire B9.3 B11.9 S5.8-7.2
W-Run R2.6 R2.6
Cap 224302 3 230 60 1.15 Y14.0 2940 Y17.0 3350 M1.0-1.5 83.5 H 45 30 40
(3) B11.2 B12.6 S3.5-4.4
R6.1 R6.0
224303 5 230 60 1.15 Y23.0 4920 Y27.5 5620 M.68-1.0 121.0 80 45 60
(4) B15.9 B19.1 S1.8-2.2
R11.0 R10.8
Franklin Single Phase Motors
Single Phase Motor Specifications (60HZ) 3450 RPM
Table 4 (Continued)
Type Motor HP Volts HZ S. .
Model (2) (2) Res.
Amps Watts Amps Watts M=Main Amps Code
S=Start
(1) Main winding - black to yellow Start winding - red to yellow
(2) Y=yellow lead, line amps B=black lead, main winding amps R=red lead, start winding amps
(3) Control boxes date coded 02C and older have 35M D run capacitors and the current values will be (Y14.0, B12.2, R4.7 at L) & (Y17.0, B14.5, R4.5 at S load).
(4) Control boxes date coded 01M and older have 60M D run capacitors and the current values will be (Y23.0, B19.1, R8.0 at L.) & (Y27.5, B23.2, R7.8 at S load).
Std.
use
Amps
Dual
Element
Time
Delay
Std.
use
Amps
Circuit
Breaker
Or use
Amps
Max Per
NEC
Rated Input
( ull Load)
Maximum
(S. . Load)
Winding (1)
(Resistance
/Ohms)
Locked
Rotor
KVA
Franklin Three Phase Motors
Three Phase Motor Specifications (60HZ) 3450 RPM
Table 5
Motor KVA
Model HP Volts HZ S. . Line to Line Locked Code
Ohms Rotor Amps
Amps Watts Amps Watts
234501 1/2 200 60 1.6 2.8 585 3.4 860 6.6-8.4 17.5 N 10 5 8
234511 1/2 230 60 1.6 2.4 585 2.9 860 9.5-10.9 15.2 N 8 5 6
234521 1/2 460 60 1.6 1.2 585 1.5 860 38.4-44.1 7.6 N 4 3 3
234502 3/4 200 60 1.5 3.6 810 4.4 1150 4.6-5.9 23.1 M 15 8 10
234512 3/4 230 60 1.5 3.1 810 3.8 1150 6.8-7.8 20.1 M 10 6 8
234522 3/4 460 60 1.5 1.6 810 1.9 1150 27.2-30.9 10.7 M 5 3 4
234503 1 200 60 1.4 4.5 1070 5.4 1440 3.8-4.5 30.9 M 15 10 15
234513 1 230 60 1.4 3.9 1070 4.7 1440 4.9-5.6 26.9 M 15 8 10
234523 1 460 60 1.4 2.0 1070 2.4 1440 19.9-23.0 13.5 M 6 4 5
234504 1 1/2 200 60 1.3 5.8 1460 6.8 1890 2.5-3.0 38.2 K 20 10 15
234514 1 1/2 230 60 1.3 5.0 1460 5.9 1890 3.2-4.0 33.2 K 15 10 15
234524 1 1/2 460 60 1.3 2.5 1460 3.1 1890 13.0-16.0 16.6 K 8 5 8
234534 1 1/2 575 60 1.3 2.0 1460 2.4 1890 20.3-25.0 13.3 K 6 4 5
234305 2 200 60 1.25 7.7 2150 9.3 2700 1.8-2.4 53.6 L 25 15 20
234315 2 230 60 1.25 6.7 2150 8.1 2700 2.3-3.0 46.6 L 25 15 20
234325 2 460 60 1.25 3.4 2150 4.1 2700 9.2-12.0 23.3 L 15 8 10
234335 2 575 60 1.25 2.7 2150 3.2 2700 14.6-18.7 18.6 L 10 5 8
Std.
use
Amps
Dual
Element
Time
Delay
Std.
use
Amps
Circuit
Breaker
Amps
Rated Input Maximum
(S. . Load)

- 8 -
4200511-E 1/2 115 60 1.60 8.4 880 10 1090 2.0-2.5 25 G 25 15 20
Two 4200531-E 1/2 230 60 1.60 4.2 870 5.1 1050 7.2-8.8 14 H 15 10 10
Wire 4200731-E 3/4 230 60 1.50 4.8 1040 6.1 1325 5.7-7.1 17 15 10 15
4201031-E 1 230 60 1.40 7 1570 8 1820 4.7-5.8 22 E 20 15 20
4201531-E 1 1/2 230 60 1.30 9 1980 10.6 2350 2.7-3.3 34 30 20 25
4300511-E 1/2 115 60 1.60 Y9.0 690 Y11.0 1020 M1.5-1.9 41 L 30 20 30
B9.0 B11.0 S3.1-3.9
R0 R0
4300531-E 1/2 230 60 1.60 Y5.0 720 Y5.6 1055 M6.2-7.7 18 K 20 10 15
B5.0 B5.6 S13.0-16.0
Three R0 R0
Wire 4300731-E 3/4 230 60 1.50 Y6.2 980 Y7.4 1390 M4.0-4.9 29 K 20 15 20
B6.2 B4.0 S9.5-11.6
R0 R0
4301031-E 1 230 60 1.40 Y7.4 1235 Y9.0 1670 M3.3-4.1 39 K 25 15 25
B7.4 B9.0 S11.9-14.6
R0 R0
4301531-E 1 1/2 230 60 1.30 Y8.9 1685 Y10.7 2170 M2.6-3.3 43 H 30 20 25
B8.5 B10.4 S8.0-9.8
R1.3 R1.2
Three 4302031A 2 230 60 1.25 Y9.9 2170 Y12.2 2660 M1.6-2.2 49 G 30 20 25
Wire B9.1 B11.7 S4.8-5.9
W-Run R2.6 R2.6
Cap 4303031A 3 230 60 1.15 Y14.3 3170 Y16.5 3620 M1.0-1.4 76 G 45 25 40
(3) B12.0 B13.9 S2.0-2.5
R5.7 R5.6
4305031A 5 230 60 1.15 Y24.0 5300 Y27.0 6030 M.6-.8 101 E 80 45 60
(4) B19.1 B22.0 S1.3-1.7
R10.2 R10.0
Faradyne Single Phase Motors
Single Phase Motor Specifications (60HZ) 3450 RPM
Table 4A
Type Motor HP Volts HZ S. .
Model (2) (2) Res.
Amps Watts Amps Watts M=Main Amps Code
S=Start
(1) Main winding - black to yellow Start winding - red to yellow.
(2) Y=yellow lead, line amps B=black lead, main winding amps R=red lead, start winding amps
Std.
use
Amps
Dual
Element
Time
Delay
Std.
use
Amps
Circuit
Breaker
Or use
Amps
Max Per
NEC
Rated Input
( ull Load)
Maximum
(S. . Load)
Winding (1)
(Resistance
/Ohms)
Locked
Rotor
KVA
Franklin Three Phase Motors
Three Phase Motor Specifications (60HZ) 3450 RPM
Table 5 (Continued)
Motor KVA
Model HP Volts HZ S. . Line to Line Locked Code
Ohms Rotor Amps
Amps Watts Amps Watts
234306 3 200 60 1.15 10.9 2980 12.5 3420 1.3-1.7 71.2 K 35 20 30
234316 3 230 60 1.15 9.5 2980 10.9 3420 1.8-2.2 61.9 K 30 20 25
234326 3 460 60 1.15 4.8 2980 5.5 3420 7.2-8.8 31 K 15 10 15
234336 3 575 60 1.15 3.8 2980 4.4 3420 11.4-13.9 24.8 K 15 8 10
234307 5 200 60 1.15 18.3 5050 20.5 5810 .74-.91 122 K 60 35 50
234317 5 230 60 1.15 15.9 5050 17.8 5810 1.0-1.2 106 K 50 30 40
234327 5 460 60 1.15 8.0 5050 8.9 5810 4.0-4.9 53.2 K 25 15 20
234337 5 575 60 1.15 6.4 5050 7.1 5810 6.4-7.8 42.6 K 20 15 20
234308 7 1/2 200 60 1.15 26.5 7360 30.5 8450 .46-.57 188 K 90 50 70
234318 7 1/2 230 60 1.15 23.0 7360 26.4 8450 .61-.75 164 K 80 45 60
234328 7 1/2 460 60 1.15 11.5 7360 13.2 8450 2.5-3.1 81.9 K 40 25 30
234338 7 1/2 575 60 1.15 9.2 7360 10.6 8450 4.0-5.0 65.5 K 30 20 25
234595 10 460 60 1.15 15.9 10000 17.3 11400 1.8-2.3 116 L 60 30 45
234598 10 575 60 1.15 12.5 10000 13.6 11400 2.8-3.5 92.8 L 45 25 35
Std.
use
Amps
Dual
Element
Time
Delay
Std.
use
Amps
Circuit
Breaker
Amps
Rated Input Maximum
(S. . Load)

Warning: To prevent accidental electrocution, automatic or manual transfer switches must be used any time a
generator is used as standby or back up on power lines. Contact power company for use and approval.
Table 6
Motor HP Minimum Rating of Generator
Externally Regulated Internally Regulated
KW KVA KW KVA
1/2 2.0 2.5 1.5 1.9
3/4 3.0 3.8 2.0 2.5
1 4.0 5.0 2.5 3.13
1 1/2 5.0 6.25 3.0 3.8
2 7.5 9.4 4.0 5.0
3 10.0 12.5 5.0 6.25
5 15.0 18.75 7.5 9.4
7 1/2 20.0 25.0 10.0 12.5
10 30.0 37.5 15.0 18.75
Whenever the submersible pump is going to be operated
using an engine driven generator, the generator manufac-
turer should be consulted. (See Table 6)
There are two types of generators available, externally
and internally regulated (See Table 6). Most are externally
regulated. They use an external mounted voltage regula-
tor that senses the output voltage. As the voltage dips at
motor start up, the regulator increases the output voltage
of the generator.
Internally regulated generators have an extra winding in
the generator stator and are also called self excited. The
extra winding senses the output current to automatically
increase the output voltage.
NOTE: or best starting of two-wire motors the minimum generator ratings
should be 50% higher than shown.
- 9 -
Generator peration
Faradyne Three Phase Motors
Three Phase Motor Specifications (60HZ) 3450 RPM
Table 5A
Motor KVA
Model HP Volts HZ S. . Line to Line Locked Code
Ohms Rotor Amps
Amps Watts Amps Watts
4300523A 1/2 200 60 1.6 2.9 600 3.5 860 4.1 - 5.2 22 R 10 6 10
4300723A 3/4 200 60 1.6 3.9 820 4.7 1150 2.8 - 3.7 30 R 15 10 10
4301023A 1.0 200 60 1.4 4.8 1120 5.7 1470 2.2 - 3.1 34 N 15 10 10
4301523A 1.5 200 60 1.3 6.6 1650 7.6 1950 1.9 - 2.5 40 L 20 10 15
4302023A 2 200 60 1.25 8.0 1960 9.3 2455 1.4 - 2.0 51 K 25 15 20
4303023A 3 200 60 1.15 10.9 2890 12.0 3290 1.2 - 1.5 71 K 35 20 30
4305023A 5 200 60 1.15 18.3 4850 20.2 5515 .7 - .9 113 J 60 35 50
4307523A 7.5 200 60 1.15 27 7600 30 8800 .4 - .6 165 J 80 50 70
4300533A .5 230 60 1.6 2.4 575 3.0 860 5.7 - 7.2 18 R 6 6 6
4300733A .75 230 60 1.5 3.3 805 4.0 1160 3.3 - 4.3 27 R 6 6 6
4301033A 1 230 60 1.4 4.1 1070 4.9 1440 3.2 - 4.2 26 M 10 6 10
4301533A 1.5 230 60 1.3 5.8 1550 6.6 1950 2.5 - 3.1 36 L 15 10 15
4302033A 2 230 60 1.25 6.7 1965 8.0 2465 2.2 - 2.8 44 K 15 15 20
4303033A 3 230 60 1.15 9.2 2880 10.1 3280 1.6 - 2.0 59 J 25 15 25
4305033A 5 230 60 1.15 15.7 4925 17.5 5650 .9 - 1.3 93 J 45 30 40
4307533A 7.5 230 60 1.15 24 7480 26.4 8570 .5 - .9 140 J 70 45 60
4300553A .5 460 60 1.6 1.3 620 1.5 865 23.6 - 26.1 9 R 3 3 3
4300753A .75 460 60 1.5 1.7 825 2.0 1140 14.4 - 16.2 14 R 3 6 3
4301053A 1 460 60 1.4 2.2 1140 2.5 1460 16.8 - 18.6 15 N 6 3 6
4301553A 1.5 460 60 1.3 3.0 1540 3.4 1960 9.5 - 10.5 16 L 10 6 6
4302053A 2 460 60 1.25 3.6 1960 4.1 2440 7.5 - 9.3 23 L 15 6 10
4303053A 3 460 60 1.15 4.8 2920 5.3 3320 6.3 - 7.7 30 J 15 10 15
4305053A 5 460 60 1.15 7.6 4810 8.5 5530 3.9 - 4.9 48 J 25 15 15
4307553A 7.5 460 60 1.15 12.2 7400 13.5 8560 2.1 - 2.7 87 L 40 25 30
4310053A 10 460 60 1.15 15.6 9600 17.2 11000 1.8 - 2.2 110 K 45 25 35
4301563A 1.5 575 60 1.3 2.3 1540 2.6 1970 15.6 - 17.3 15 K 6 3 6
4302063A 2 575 60 1.25 2.7 1610 3.3 2400 10.2 - 12.5 21 M 10 6 10
4303063A 3 575 60 1.15 3.7 2850 4.1 3240 10.2 - 12.5 21 J 10 10 10
4305063A 5 575 60 1.15 7.0 5080 7.6 5750 3.6 - 4.2 55 M 20 15 20
4307563A 7.5 575 60 1.15 9.1 7260 10.0 8310 3.6 - 4.2 55 J 25 20 25
Std.
use
Amps
Dual
Element
Time
Delay
Std.
use
Amps
Circuit
Breaker
Amps
Rated Input Maximum
(S. . Load)

Figure 8
Three Phase
With Push Button
Control
Figure 7
Three Phase
With Pressure
Switch
Figure 6
Three Wire
Connected
through Deluxe
Control Box
Figure 5
Three Wire
Connected to
Pressure Switch
& Control Box
Figure 4
Two Wire-Direct
Connected to
Pressure Switch
230 V Motor
Figure 3
Two Wire-Direct
Connected to
Pressure Switch
115 V Motor
- 10 -
Three Phase Motors
Single Phase Motors

Motor Runs Continuously
Cause of Trouble Checking Procedure Correction Action
Motor Runs But verload Protector Trips
Cause of Trouble Checking Procedure Correction Action
System Trouble Shooting
Motor Does Not Start
Cause of Trouble Checking Procedure Correction Action
A. No power or incorrect voltage. Using voltmeter check the line terminals. Voltage must Contact power company if voltage is incorrect.
be + 10% of rated voltage.
B. uses blown or circuit breakers tripped. Check fuses for recommended size and check for Replace with proper fuse or reset circuit breaker.
loose, dirty, or corroded connections in fuse receptacle.
Check for tripped circuit breaker.
C. Defective pressure switch. Check voltage at contact points. Improper contact of Replace pressure switch or clean points.
switch points can cause voltage less than line voltage.
D. Control box malfunction. See ranklin Electric Maint. and Installation Manual. Repair or replace.
E. Defective cable or motor.
. Defective wiring. Check for loose or corroded connections. Check motor Correct faulty wiring or connections.
lead terminals with voltmeter for power.
G. Bound pump. Locked rotor conditions can result from misalignment If pump will not start with several trials, it must be
between pump and motor or a sand bound pump. pulled and the cause corrected. New installations
Amp readings 3 to 6 times higher than normal will be should always be run without turning off until
indicated. water clears.
A. Pressure switch. Check setting on pressure switch and examine Reset limit or replace switch.
for defects.
B. Check valve stuck open. Damaged or defective check valve will not hold Replace if defective.
pressure.
C. Waterlogged tank (air supply). Check air charging system for proper operation. Clean or replace.
D. Leak in system. Check system for leaks. Replace damaged pipes or repair leaks.
A. Pressure switch. Switch contacts may be “welded” in closed position. Clean contacts, replace switch or readjust setting.
Pressure switch may be set too high.
B. Low level well. Pump may exceed well capacity. Shut off pump, wait Throttle pump output or reset pump to lower level
for well to recover. Check static and drawdown level Do not lower if sand may clog pump.
from well head.
C. Leak in system. Check system for leaks. Replace damaged pipes or repair leaks.
D. Worn pump. Symptoms of worn pump are similar to those of drop Pull pump and replace.
pipe leak or low water level in well. Reduce pressure
switch setting, if pump shuts off worn parts may be at
fault. Sand is usually present in tank.
E. Loose or broken motor shaft. No or little water will be delivered if coupling between Check for damaged shafts if coupling is loose and
motor and pump shaft is loose or if a jammed pump replace worn or defective units.
has caused the motor shaft to shear off.
. Pump screen blocked. Restricted flow may indicate a clogged intake screen Clean screen and reset at less depth. It may be
on pump. Pump may be installed in mud or sand. necessary to clean well.
G. Check valve stuck closed. No water will be delivered if check valve is in closed Replace if defective.
position.
H. Control box malfunction. See ranklin Electric Maint. and Installation Manual. Repair or replace.
A. Incorrect voltage. Using voltmeter, check the line terminals. Voltage must Contact power company if voltage is incorrect.
be within + 10% of rated voltage.
B. Overheated protectors. Direct sunlight or other heat source can make control Shade box, provide ventilation or move box away
box hot causing protectors to trip. The box must not from heat source.
be hot to touch.
C. Defective control box. See ranklin Electric Maint. and Installation Manual. Repair or replace.
D. Defective motor or cable.
E. Worn pump or motor.
- 11 -
Motor Starts Too ften
Cause of Trouble Checking Procedure Correction Action
Trouble shooting continued on back page

wners Information
Name Of Dealer: Phone:
Address:
Pump Model No: GPM: Total Dynamic Head: ( T) Date Installed:
HP: Volts: Phase: HZ: Service actor Amps:
AWG Cable Size: t.:
Well Diameter: (IN). Well Depth: ( T). Amount Of Casing: ( T).
Static Water Level: ( T). Well Drawdown: ( T). Pump Setting: ( T).
Pipe Size In Well: (IN). Length Of Pipe In Well: ( T).
Pipe Material: PVC: Galv.:
Pipe Size rom Well To Discharge Point: (IN). Length Of Pipe rom Well To Discharge Point: ( T).
Pipe Material: PVC: Galv.:
Pressure Tank: U.S. Gallons: Pressure Switch Setting Cut In PSI: Cut Out PSI:
Check Valves At: @: @: @: ( T).
Insulation Resistance: OHMS: OHMS: OHMS
Resistance Between Motor Leads - 3 Wire B/Y: OHMS B/R: OHMS Y/R: OHMS 2 Wire B/B: OHMS
Little r No Liquid Delivered By Pump
Cause of Trouble Checking Procedure Correction Action
A. aulty or incorrectly installed check valve. Inspect check valve. Is it installed backwards? Replace if defective.
B. Worn pump. Reduce pressure switch setting - If pump shuts off worn Pull pump & replace.
parts due to sand - usually present in tank - may be the
problem.
C. Pump bound by sand. Amp readings 3 to 6 times higher than normal will be Pull pump clean & reset depth or reverse rotation
indicated. Warning: Do not reverse rotation with a control
box containing a solid state switch or electronic
relay, failure will occur.
1 phase motor: 1 1/2 HP & up with voltage relay in
control box. Switch the red & black leads in the
control box. Turn on for 4 seconds, turn off for 1
minute, repeat 3 times.
3 Phase motor: interchange any 2 cable leads where
they connect to the lead terminals in the magnetic
starter. Turn on for 4 seconds, turn off for 1 minute,
repeat 3 times.
D. Incorrect motor rotation - 3 phase motor. low rate & pressure will be substantially reduced. or Interchange any 2 cable leads where they connect to
correct rotation the pump should jerk clockwise when the lead terminals in the magnetic starter.
looking into the pump discharge when started.
E. Well contains air or gases. Drain tank. With valve open, turn pump on, if air or Start and stop pump until a constant stream of water
gases are present in the water, flow will be intermittent. is delivered.
Thank You for Purchasing a WT or WS Series 4” Submersible Pump
We at Webtrol are constantly working on new products to make your job easier, while making your systems more efficient, reliable
and affordable. Your opinion means a lot to us, so please let us know what you think about our 4” Submersible Pump.
8417 New Hampshire Ave. | St. Louis, MO 63123
Phone: [phone] Fax: [phone] E-mail: [email protected]
