Weed Eater 530163506 User manual

RTrademark
WARNING:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
ADVERTENCIA:
Lea el manual de instrucciones y siga todas las advertencias e
instrucciones de seguridad. El no hacerlo puede resultar en lesiones
graves.
AVERTISSEMENT:
Lire le manuel d’instructions et bien respecter tous les avertisse-
ments et toutes les instructions de sécurité. Tout défaut de lefaire
pourrait entraîner des blessures graves.
Instruction Manual
Manual de Instrucciones
Manuel d’Instructions
ENGLISH ESPAÑOL FRANÇAIS
530163506 4/23/03
Please do not return unit to retailer.
Por favor, no devuelva el aparato al lugar de compra.
Veuillez ne pas retourner l’outil au détaillant.
1-800-554-6723
www.weedeater.com
Electrolux Home Products, Inc.
250 Bobby Jones Expressway
Augusta, GA 30907
Copyright E2003 Electrolux Home Products, Inc.
For Occasional Use Only
XT 400

2
SAFETY RULES
WARNING: When using gardening
appliances, basic safety precautions must al-
ways befollowed to reduce the risk of fire and
serious injury. Read and follow all instruc-
tions.
This power unit can be dangerous! Operator is
responsible for following instructions and warn-
ings on unit and in manual. Read entire instruc-
tion manual before using unit! Be thoroughly fa-
miliarwiththe controlsand the properuse ofthe
unit. Restrict the use of this unit to persons who
have read, understand, and will follow the
instructions and warnings on the unit and in the
manual. Never allow children to operate this
unit.
SAFETY INFORMATION
ON THE UNIT
INSTRUCTION
MANUAL
DANGER:Neveruseblades orflailing
devices. This unit is designed for line trimmer
use only. Use of any other accessories or at-
tachments will increase the risk of injury.
WARNING: Trimmer line throws ob-
jects violently. You and others canbe blinded/in-
jured. Wear eye and leg protection. Keep body
parts clear of rotating line.
Eye Protection
Boots
HazardZone
50 ft.
(15 m)
Keep children, bystanders, and animals 50 feet
(15 meters) away. If approached stop unit im-
mediately.
If situations occur which are not covered in
this manual, use care and good judgment. If
youneedassistance, contact yourauthorized
service dealer or call 1-800-554--6723.
OPERATOR SAFETY
SDress properly. Always wear safety glasses
or similar eye protection when operating, or
performing maintenance, on your unit (safety
glasses areavailable). Eye protection should
be marked Z87.
SAlways wearface ordust mask if operation is
dusty.
SAlways wearheavy, long pants, long sleeves,
boots, and gloves. Wearing safety legguards
is recommended.
SAlways wearfoot protection. Do not gobare-
foot or wear sandals. Stay clear of spinning
line.
SSecurehairaboveshoulder length. Secureor
remove loose clothing or clothing withloosely
hanging ties, straps, tassels, etc. They can
be caught in moving parts.
SBeing fully covered also helps protect you
from debris and pieces of toxic plants thrown
by spinning line.
SStay Alert. Do not operate this unit when you
are tired, ill, upset or underthe influence ofal-
cohol, drugs, or medication. Watch what you
are doing; use common sense.
SWear hearing protection.
SNever start or run inside a closed room or
building. Breathing exhaust fumes can kill.
SKeep handles free of oil and fuel.
UNIT / MAINTENANCE SAFETY
SDisconnect the spark plug before performing
maintenance except carburetor adjustments.
SLook for and replace damaged or loose parts
before each use. Look for and repair fuel
leaks before use. Keep in good working
condition.
SReplace trimmerhead parts that arechipped,
cracked, broken, or damaged in any other
way before using the unit.
SMaintain unit according to recommended pro-
cedures. Keep cutting line at proper length.
SUse only 0.080!(2 mm) diameter Weed Eat-
er"brand line. Never use wire, rope, string,
etc.
SInstall required shield properly before using
the unit. Use only specified trimmer head;
make sureit is properly installed and securely
fastened.
SMake sure unit is assembled correctly as
shown in this manual.
SMake carburetor adjustments with lower end
supported to prevent line from contacting any
object.
SKeep others away when making carburetor
adjustments.
SUse only recommended Weed Eater"ac-
cessories and replacement parts.
SHave all maintenance and service not ex-
plained in this manual performedby anautho-
rized service dealer.
FUEL SAFETY
SMix and pour fuel outdoors.
SKeep away from sparks or flames.
SUse a container approved for fuel.
SDo not smoke or allow smoking near fuel or
the unit.
SAvoid spillingfuel oroil. Wipe upall fuel spills.
SMove at least 10 feet (3 meters) away from
fueling site before starting engine.
SStop engine and allow to cool before remov-
ing fuel cap.
SAlways store gasoline in a container ap-
proved for flammable liquids.

3
CUTTING SAFETY
WARNING: Inspect the area before
each use. Remove objects (rocks, broken
glass, nails, wire, etc.) which can be thrown
by or become entangled in line. Hard objects
can damage the trimmer head and be thrown
causing serious injury.
SUse only for trimming, scalping, mowing,
edging and sweeping. Do not use for prun-
ing or hedge trimming.
SKeep firm footing and balance. Do not over-
reach.
SKeep all parts of your bodyaway frommuffler
and spinning line. Keep engine below waist
level. A hot muffler can cause serious burns.
SCut from yourright to your left. Cutting on left
side of the shield will throw debris away from
the operator.
SUse only in daylight or good artificial light.
SUse only for jobs explained in this manual.
TRANSPORTING AND STORAGE
SAllow engine to cool; secure unit before stor-
ing or transporting in vehicle.
SEmpty the fuel tank before storing or trans-
porting the unit. Use upfuel left in thecarbure-
torby startingthe engineand letting it rununtil
it stops.
SStore unit and fuel in area where fuel vapors
cannot reach sparks or open flames from wa-
ter heaters, electric motors or switches, fur-
naces, etc.
SStoreunit soline limiterblade cannot acciden-
tally cause injury. Theunit can behung bythe
tube.
SStore unit out of reach of children.
SAFETY NOTICE: Exposure to vibrations
through prolonged use of gasoline powered
hand tools could cause blood vessel ornerve
damage in the fingers, hands, and joints of
people prone to circulation disorders or ab-
normal swellings. Prolonged use in cold
weather hasbeen linked toblood vessel dam-
age in otherwise healthy people. If symptoms
occur such as numbness, pain, loss of
strength, change in skin color or texture, or
loss of feeling in the fingers, hands, or joints,
discontinue the use of this tool and seekmed-
ical attention. An anti--vibration system does
not guarantee the avoidance of these prob-
lems. Users who operate power tools on a
continual and regular basis must monitor
closely their physical condition and the condi-
tion of this tool.
SPECIAL NOTICE: This unit is equipped
with a temperature limiting muffler and spark
arresting screen which meets the require-
ments of California Codes 4442 and 4443. All
U.S. forest land and the states of California,
Idaho, Maine, Minnesota, New Jersey, Ore-
gon, and Washington require by law that
many internal combustion engines be
equipped with asparkarresting screen. If you
operate in alocale where such regulations ex-
ist, you arelegally responsible for maintaining
the operating condition of these parts. Failure
to do so is a violation of the law. For normal
homeowner use, the muffler and sparkarrest-
ing screen will not require any service. After
50 hours of use, we recommend that your
mufflerbeserviced orreplaced byyourautho-
rized service dealer.
ASSEMBLY
WARNING: If received assembled,
repeat all steps to ensure your unit is properly
assembled and all fasteners are secure.
Examine parts for damage. Do not use dam-
aged parts.
NOTE: If you need assistance or find parts
missing or damaged, call 1-800-554-6723.
It is normal for the fuel filter to rattle in the
empty fuel tank.
Finding fuel or oil residue on muffler is normal
due to carburetor adjustments and testing
done by the manufacturer.
ATTACHING THE ASSIST HANDLE
NOTE: Besure toattach the assist handle to
the unit before attaching the shield.
1. Assemble handle to the unit as shown;
make sure bottom of handle is seated in
the groove in the trigger housing.
Groove
NOTE: Knob must be assembled on the
right hand side of the unit as shown in the il-
lustration.
2. Make sure the bolt is seated in the hex--
shaped hole in the handle.
3. Pivot the handle to a comfortable position.
4. Tighten knob securely.
ATTACHING SHIELD
WARNING: The shield must be prop-
erly installed. The shield provides partial protec-
tion from the risk of thrown objects to theopera-
tor and others and is equipped with a line limiter
blade which cuts excess line to the proper
length. The line limiter blade (on underside of
shield) is sharp and can cut you.
For proper orientation of shield, see KNOW
YOUR TRIMMER illustration in OPERATION
section.

4
1. Remove wing nut from shield.
2. Insert bracket into slot as shown.
3. Pivot shield until bolt passesthrough hole in
bracket.
4. Securely tighten wing nut onto bolt.
Slot
Shield
Wing
Nut
Bracket
Line Limiter Blade
OPERATION
KNOW YOUR TRIMMER
READ THIS INSTRUCTION MANUAL AND SAFETY RULES BEFORE OPERATING YOURUNIT.
Compare the illustrations with your unit to familiarize yourself with the location of the various controls
and adjustments. Save this manual for future reference.
Line
Limiter
Blade
Primer Bulb
Fuel Mix
Fill Cap
Assist Handle
Starter
Handle
ON/OFF
Switch Throttle Trigger
Choke Lever
Spark Plug
Shield
Trimmer
Head
Tube
Muffler
ON/OFF SWITCH
The ON/OFF switch is used to stop engine.
MovetheswitchtotheOFFpositiontostopen-
gine.
PRIMER BULB
The PRIMER BULB removes air from the car-
buretor and fuel lines and fills them with fuel.
This allows you to start the engine with fewer
pulls on the starter rope. Activate the primer
bulb by pressing it and allowing it to return to
its original form.
CHOKE
The CHOKE helps to supply fuel to the engine
to aid in cold starting. Activate the choke by
moving the choke lever to the FULL CHOKE
position. Aftertheengineattemptsto start,move
the choke lever to the HALF CHOKE position.
Once engine hasstarted, move the chokelever
to the OFF CHOKE position.
BEFORE STARTING ENGINE
WARNING: Be sure to read the fuel
information in the safety rules before you
begin. If you do not understand the safety
rules, do not attempt to fuel your unit. Call
1-800-554-6723.
FUELING ENGINE
WARNING: Remove fuel cap slowly
when refueling.
This engine is certified to operate on unleaded
gasoline. Before operation, gasoline must be
mixed with a good quality synthetic 2-cycle
air-cooled engine oil designed to be mixed at a
ratio of 40:1. Poulan/Weed Eater brand
synthetic oil is recommended. Mix gasoline and
oil at a ratio of 40:1. A 40:1 ratio is obtained by
mixing 3.2 ounces of oil with 1 gallon of
unleaded gasoline. DO NOT USE automotive
oil or boat oil. These oils will cause engine
damage. When mixing fuel, follow instructions
printed on container. Once oil is added to
gasoline, shake container momentarily to
assure that the fuel is thoroughly mixed. Always
read and follow the safety rules relating to fuel
before fueling your unit.

5
IMPORTANT
Experience indicates that alcohol blended fuels
(called gasohol or using ethanol or methanol)
can attract moisture which leads to separation
and formation of acids during storage. Acidic
gas can damage the fuel system of an engine
while in storage. To avoid engine problems,
empty the fuel system before storage for 30
days or longer. Drain the gas tank, start the en-
gine and let it run until the fuellines andcarbure-
tor are empty. Use fresh fuel next season.
Never use engine or carburetor cleaner prod-
ucts in the fuel tank or permanent damage may
occur. See the STORAGE section for addi-
tional information.
HOW TO STOP YOUR UNIT
STo stop the engine, move the ON/OFF
switch to the OFF position.
SIf engine does not stop, move choke to the
FULL CHOKE position.
Engine
ON/OFF
Switch
Choke Lever
FULL HALF OFF
HOW TO START YOUR UNIT
WARNING: The trimmer head will
turn while starting the engine. Avoid any con-
tact with the muffler. A hot muffler can cause
serious burns.
STARTING A COLD ENGINE (or a
warm engine after running out of
fuel)
Starting Position
1. Set unit on a flat surface.
2. Move ON/OFF switch to the ON position.
3. Slowly press the primer bulb 6 times.
4. Move choke lever to the FULL CHOKE
position.
5. Squeeze the throttle trigger fully and hold
through all remaining steps.
Choke
Lever
Primer Bulb
Starter Handle
Muffler
6. Pull starter rope handle sharply until engine
sounds as if it is trying to start, but do not
pull rope more than 6 times.
7. As soon as enginesounds as if itis trying to
start, move choke lever to HALF CHOKE
position.
8. Pull starter rope sharply until engine runs,
but no more than 6 pulls.
NOTE: If the engine doesn’t start after 6
pulls (at the HALF CHOKE position),
move the choke lever to the FULL
CHOKE position and press the primer
bulb 6 times. Squeeze and hold the
throttle trigger and pull the starter rope 2
more times. Move the choke lever to the
HALF CHOKE position and pull the start-
er rope until the engine runs, but nomore
than 6 pulls. If the engine still doesn’t
start, it is probably flooded. Proceed to
STARTING A FLOODED ENGINE.
9. Once the engine starts, allow it to run 10
seconds, then move the choke lever to
the OFF CHOKE position. Allow the unit
to run for 30 more seconds at OFF
CHOKE before releasing the throttle trig-
ger.
NOTE: If engine dies with the choke le-
ver in the OFF CHOKE position, move
the choke lever to the HALF CHOKE
position and pull the rope until engine
runs, but no more than 6 pulls.
STARTING A WARM ENGINE
1. Move ON/OFF switch to the ON position.
2. Move the choke lever to the HALF CHOKE
position.
3. Squeeze and hold the throttle trigger. Keep
throttle trigger fully squeezed until the en-
gine runs smoothly.
4. Pull starter rope sharply until engine runs,
but no more than 5 pulls.
5. Allow engineto run 15 seconds, thenmove
the choke lever to OFF CHOKE.
NOTE: If engine has not started, pull starter
rope 5more pulls. If engine still does not run,it
is probably flooded.
STARTING A FLOODED ENGINE
Flooded engines can be started by placing
the choke lever in the OFF CHOKE position;
then, pull the rope to clear the engine of ex-
cess fuel. This couldrequire pulling the starter
handle many times depending on how badly
the unit is flooded.
If the unit still doesn’t start, refer to
TROUBLESHOOTING TABLE or call
1-800-554-6723.

6
OPERATING INSTRUCTIONS
OPERATING POSITION
Eye Protection
Long Pants
Heavy Shoes
ALWAYS WEAR:
Cut from your right to your left.
WARNING: Always wear eyeprotec-
tion. Never lean over the trimmer head.
Rocks ordebris canricochet orbe throwninto
eyes and face and cause blindness or other
serious injury.
Do not run the engine at a higher speed than
necessary. The cutting line will cut efficiently
when the engine is run at less than full throttle.
At lower speeds, there is less engine noise and
vibration. The cutting line will last longer and will
be less likely to “weld” onto the spool.
Always release the throttle trigger and allow the
engine to return to idle speed when not cutting.
To stop engine:
SRelease the throttle trigger.
SMove the ON/OFF switch to the OFF posi-
tion.
TWIST AND EDGE
The Twist and Edge feature allows for easy
edging of sidewalks, patios, driveways, etc.
1. Pull the tab toward the engine.
2. Twist the tube to the edging position; re-
lease tab.
Tab
TRIMMER LINE ADVANCE
Thetrimmerline will advance approximately 2
in. (5 cm)each time the bottom of the trimmer
head is tapped on the ground with the engine
running at full throttle.
The most efficient line length is the maximum
length allowed by the line limiter.Always keep
the shield in place when the tool is being oper-
ated.
To advance line:
SOperate the engine at full throttle.
SHold the trimmer head parallel to and above
the grassy area.
STap the bottom of the trimmer head lightly
on the ground one time. Approximately 2in.
(5 cm) of line will be advanced with each
tap.
Always tap the trimmer head on a grassy
area. Tapping on surfaces such as concrete
or asphalt can cause excessive wear to the
trimmer head.
If the line is worn down to 2 inches (5 cm) or
less, more than one tap will be required to ob-
tain the most efficient line length.
WARNING: Use only 0.080” (2 mm)
diameter line. Other sizes and shapes of line
will not advance properly and will result in im-
proper cutting head function or can cause se-
rious injury. Do not use other materials such
as wire, string, rope, etc. Wire can break off
during cutting and become a dangerous mis-
sile that can cause serious injury.
CUTTING METHODS
WARNING: Use minimum speed
and do not crowdthe line when cutting around
hard objects (rock, gravel, fence posts, etc.),
which candamage the trimmer head, become
entangled in the line, or be thrown causing a
serious hazard.
SThe tip of the line does the cutting. You will
achieve the best performance and mini-
mum line wear by not crowding the line into
the cutting area. The right and wrong ways
are shown below.
Tip of the Line
Does The Cutting
Right Wrong
Line Crowded Into
Work Area
SThe line will easily remove grass and
weeds fromaround walls, fences, trees and
flower beds, but it also can cut the tender
bark of trees or shrubs and scar fences. To
help avoid damage especially to delicate
vegetation or trees with tender bark,
shorten line to 4--5 inches (10--13 cm) and
use at less than full throttle.
SFor trimming or scalping, use less than full
throttle to increase line life and decrease
head wear, especially:
SDuring light duty cutting.
SNear objects around which the line can
wrap such as small posts, trees or fence
wire.
SFor mowing orsweeping, usefull throttle for
a good clean job.
TRIMMING -- Hold the bottom of the trimmer
head about 3 inches (8 cm)above the ground
and at an angle. Allow only the tip of the line to
make contact. Do not force trimmer line into
work area.
Trimming
3 inches (8 cm)
above ground
SCALPING -- The scalping technique re-
moves unwanted vegetationdown to the
ground. Hold the bottom of the trimmer head
about 3 in. (8 cm) above the ground and at an

7
angle. Allow the tip of the line to strike the
ground around trees, posts, monuments, etc.
This technique increases line wear.
Scalping
MOWING -- Your trimmer is ideal for mowing
in places conventional lawn mowers cannot
reach. In the mowing position, keep the line
parallel to the ground. Avoid pressing the
head into the ground as this can scalp the
ground and damage the tool.
Mowing
SWEEPING -- The fanning action of the rotat-
ing line can be used for a quick and easy
clean up. Keep the line parallel to and above
the surfaces being swept and move the tool
from side to side.
Sweeping
EDGING-- Adjust trimmer to the edging posi-
tion (see TWIST AND EDGE section). Allow
only the tip of the line to make contact. Donot
force trimmer line into work area.
Edging
MAINTENANCE
WARNING: Disconnect the spark
plug before performing maintenance except
for carburetor adjustments.
CHECK FOR LOOSE
FASTENERS AND PARTS
SSpark Plug Boot
SAir Filter
SHousing Screws
SAssist Handle Screws
SDebris Shield
CHECK FOR DAMAGED OR
WORN PARTS
Contact an authorized service dealer for re-
placement of damaged or worn parts.
SON/STOP Switch -- Ensure ON/STOP
switch functions properly by pushing and
releasing the switch. Make sure engine
stops. Wait 5 seconds before attempting to
restart unit to allow switch to reset. Restart
engine and continue.
SFuel Tank -- Discontinue use of unit if fuel
tank shows signs of damage or leaks.
SDebris Shield -- Discontinue use of unit if
debris shield is damaged.
INSPECT AND CLEAN UNIT AND
LABELS
SAfter each use, inspect complete unit for
loose or damaged parts. Clean the unit and
labels using a damp cloth with a mild deter-
gent.
SWipe off unit with a clean dry cloth.
CLEAN AIR FILTER
A dirty air filter decreases engine perform-
ance and increases fuel consumption and
harmful emissions. Always clean after every
5 hours of operation.
1. Clean the cover and the area around it to
keep dirt from falling into the carburetor
chamber when the cover is removed.
2. Remove parts as illustrated.
NOTE: To avoid creating a fire hazard or
producing harmful evaporative emissions, do
not clean filter in gasoline or other flammable
solvent.
3. Wash the filter in soap and water.
4. Allow filter to dry.
5. Add a few drops of oil to the filter; squeeze
the filter to distribute oil.
6. Replace parts.
Air Filter Cover
Air Filter
Screws
REPLACE SPARK PLUG
Replace the spark plug each year to ensure
the engine starts easier and runs better. Set
spark plug gap at 0.025 inch. Ignition timing is
fixed and nonadjustable.
1. Twist, then pull off spark plug boot.
2. Remove spark plug from cylinder and dis-
card.
3. Replace with Champion RCJ-6Y spark
plug and tighten securely with a 3/4 inch
socket wrench.
4. Reinstall the spark plug boot.

8
SERVICE AND ADJUSTMENTS
LINE REPLACEMENT
1. Remove spool by firmly pulling on tap
button.
2. Clean entire surface of hub and spool.
3. Replace with a pre-wound spool, or cut two
lengths of 12-1/2 feet of 0.080!(2 mm) di-
ameter Weed Eaterrbrand line.
WARNING: Never use wire, rope,
string, etc., which can break offand become a
dangerous missile.
4. Insert ends of the lines about 1/2 inch (1
cm) into the small holes on the inside of
spool. Small
Holes
Spool
Hub
Line in Notch
Line in Notch
Line exit holes
5. Wind the line evenly and tightly onto the
spool. Wind in the direction of the arrows
found on the spool.
6. Push thelines into the notches, leaving 3to
5 inches (7 -- 12 cm) unwound.
7. Insert the lines into the exit holes in the hub
as shown in the illustration.
8. Align the notches with the line exit holes.
9. Push spool into hub until it snaps into place.
10. Pullthelinesextendingoutside of thehubto
release the lines from the notches.
CARBURETOR ADJUSTMENT
Your carburetor is equipped with limiter caps.
Carburetor adjustment is a complicated task.
We recommend that you take your unit to an
authorized service dealer. Damage will occur
if you turn the needles beyond the limiter
stops.
STORAGE
WARNING: Perform the following
steps after each use:
SAllow engine to cool, and secure the unit
before storing or transporting.
SStore unit and fuel in a well ventilated area
where fuel vapors cannot reach sparks or
open flames from water heaters, electric
motors or switches, furnaces, etc.
SStore unit with all guards in place. Position
unit so that any sharp object cannot acci-
dentally cause injury.
SStore unit and fuel well out of the reach of
children.
SEASONAL STORAGE
Prepare unit for storage at end of season or if
it will not be used for 30 days or more.
If your unit is to be stored for a period of time:
SClean the entire unit before lengthy storage.
SStore in a clean dry area.
SLightly oil external metal surfaces.
FUEL SYSTEM
Under FUELING ENGINE in the OPERA-
TION section of this manual, see message la-
beledIMPORTANT regarding the use of ga-
sohol in your engine.
Fuel stabilizer is an acceptable alternative in
minimizing the formation of fuel gumdeposits
during storage. Add stabilizer to the gasoline
in the fuel tank or fuel storage container. Fol-
low the mix instructions found on stabilizer
container. Run engine at least 5 minutes after
adding stabilizer.
ENGINE
SRemove spark plug and pour1 teaspoon of
40:1, 2-cycle engine oil (air cooled) through
the spark plug opening. Slowly pull the
starter rope 8 to 10 times to distribute oil.
SReplace spark plug with newone of recom-
mended type and heat range.
SClean air filter.
SCheck entire unit for loose screws, nuts,
and bolts. Replace any damaged, broken,
or worn parts.
SAt the beginning of the next season, use
only fresh fuel having theproper gasoline to
oil ratio.
OTHER
SDo not store gasoline from one season to
another.
SReplace your gasoline can if it starts torust.

9
TROUBLE CAUSE REMEDY
Engine will not
start. 1. ON/OFF switch in OFF
position.
2. Engine flooded.
3. Fuel tank empty.
4. Spark plug not firing.
5. Fuel not reaching
carburetor.
6. Carburetor requires
adjustment.
1. Move ON/OFF switch to ON.
2. See “Starting a Flooded Engine” in
Operation Section.
3. Fill tank with correct fuel mixture.
4. Install new spark plug.
5. Check for dirty fuel filter; replace.
Check for kinked or split fuel line;
repair or replace.
6. See “Carburetor Adjustment” in
Service and Adjustments Section.
Engine will
not idle
properly.
1. Carburetor requires
adjustment.
2. Crankshaft seals worn.
3. Compression low.
1. See “Carburetor Adjustment” in
Service and Adjustments Section.
2. Contact an authorized service dealer.
3. Contact an authorized service dealer.
1. Air filter dirty.
2. Spark plug fouled.
3. Carburetor requires
adjustment.
4. Carbon build-up on
muffler outlet screen.
5. Compression low.
Engine will not
accelerate,
lacks power,
or dies under
a load.
1. Clean or replace air filter.
2. Clean or replace plug
and regap.
3. See “Carburetor Adjustment” in
Service and Adjustments Section.
4. Contact an authorized service dealer.
5. Contact an authorized service dealer.
Engine
smokes
excessively.
1. Choke partially on.
2. Fuel mixture incorrect.
3. Air filter dirty.
4. Carburetor requires
adjustment.
1. Adjust choke.
2. Empty fuel tank and refill with
correct fuel mixture.
3. Clean or replace air filter.
4. See “Carburetor Adjustment” in
Service and Adjustments Section.
Engine runs
hot. 1. Fuel mixture incorrect.
2. Spark plug incorrect.
3. Carburetor requires
adjustment.
4. Carbon build-up on
muffler outlet screen.
1. See “Fueling Engine” in Operation
section.
2. Replace with correct spark plug.
3. See “Carburetor Adjustment” in
Service and Adjustments Section.
4. Contact an authorized service dealer.
WARNING: Always stop unit and disconnect spark plug before performing all of the
recommended remedies below except remedies that require operation of the unit.
TROUBLESHOOTING TABLE

10
LIMITED WARRANTY
ELECTROLUX HOME PRODUCTS, INC.,
warrantsto theoriginal purchaserthat each new
Weed Eaterrbrandgasolinetool or attachment
is free from defects in material and
workmanship and agrees to repair or replace
under this warranty any defective gasoline
product or attachment as follows from the
original date of purchase.
2 YEARS -- Parts and Labor, when used for
household purposes.
60 DAYS -- Parts and Labor, when used for
commercial, professional, or income producing
purposes.
30 DAYS -- Parts and Labor, if used for rental
purposes.
This warranty is not transferable and does not
cover damage or liability caused by improper
handling, improper maintenance, or the use of
accessories and/or attachments not specifically
recommended by ELECTROLUX HOME
PRODUCTS, INC., for this tool. Additionally,
this warranty does not cover tune--ups, spark
plugs, filters, starter ropes, starter springs,
cutting line, or rotating head parts that will wear
and require replacement with reasonable use
during the warranty period. This warranty does
not cover predelivery setup or normal
adjustmentsexplainedinthe instructionmanual.
THIS WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS, AND YOU MAY HAVE
OTHER RIGHTS WHICH VARY FROM
STATE TO STATE.
NO CLAIMS FOR CONSEQUENTIAL OR
OTHER DAMAGES WILL BE ALLOWED,
AND THERE ARE NO OTHER EXPRESS
WARRANTIES EXCEPT THOSE
EXPRESSLY STIPULATED HEREIN.
SOME STATES DO NOT ALLOW
LIMITATIONS ON HOW LONG ANIMPLIED
WARRANTY LASTS OR THE EXCLUSION
OR LIMITATIONS OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE
ABOVE LIMITATIONS OR EXCLUSION
MAYNOTAPPLYTOYOU.
The policy of ELECTROLUX HOME
PRODUCTS, INC., is to continuously improve
its products. Therefore, ELECTROLUXHOME
PRODUCTS, INC., reserves the right to
change, modify, or discontinue models,
designs, specifications, and accessories of all
products at any time without notice or obligation
to any purchaser.
U.S. EPA
EMISSION CONTROL WARRANTY STATEMENT
YOUR WARRANTY RIGHTS AND OBLIGA-
TIONS: The U. S. Environmental Protection
Agency and POULAN/WEED EATER, DIVI-
SION OF WCI OUTDOOR PRODUCTS, INC.,
are pleased to explain the emissions control
system warrantyon youryear2001--2004 small
off--road engine. POULAN/WEED EATER
must warrant the emission control system on
your small off--road engine for the periods of
time listed below provided there has been no
abuse, neglect, or improper maintenance of
your small off--road engine. Your emission con-
trol system includes parts such as the carbure-
tor and the ignition system. Where a warrant-
able condition exists, POULAN/WEED EATER
will repair your small off--road engine at no cost
to you. Expenses covered under warranty in-
clude diagnosis, parts and labor. MANUFAC-
TURER’S WARRANTY COVERAGE: If any
emissions related part on your engine (as listed
under Emissions Control Warranty Parts List)is
defective or a defect in the materials or work-
manshipof theenginecauses thefailureofsuch
anemission relatedpart, the partwill be repaired
or replaced by POULAN/WEED EATER.
OWNER’S WARRANTY RESPONSIBILI-
TIES: As the small off--road engine owner, you
are responsible for the performance of the re-
quired maintenance listed in your instruction
manual. POULAN/WEED EATER recom-
mends that you retain all receipts covering
maintenance on your smalloff--road engine, but
POULAN/WEED EATER cannot deny warran-
tysolelyforthe lackof receiptsorforyourfailure
to ensure the performance of all scheduled
maintenance. As the small off--road engine
owner, you should be aware that POULAN/
WEED EATER may deny you warranty cover-
age if your small off--road engine or a part of it
hasfailed dueto abuse,neglect, impropermain-
tenance, unapproved modifications, or the use
of parts not made or approved by the original
equipment manufacturer. You are responsible
for presenting your small off--road engine to a
POULAN/WEED EATER authorized repair
center as soon as a problem exists. Warranty
repairs should be completed in a reasonable
amount of time, not to exceed 30 days. If you
have any questions regarding your warranty
rights and responsibilities, you should contact
your nearest authorized service center or call
POULAN/WEED EATER at 1--800--554--6723.
WARRANTY COMMENCEMENT DATE: The
warranty period begins on the date the small
off--road engine is purchased. LENGTH OF
COVERAGE: This warranty shall be for a peri-
od of two years from the initial date of purchase.
WHAT IS COVERED: REPAIR OR RE-
PLACEMENT OF PARTS. Repair or replace-
ment of any warranted part will be performed at
no charge to the owner at an approved POU-
LAN/WEED EATER servicing center. If you
have any questions regarding your warranty
rights and responsibilities, you should contact
your nearest authorized service center or call
POULAN/WEED EATER at 1--800--554--6723.
WARRANTY PERIOD: Any warranted part
which is not scheduled for replacement as re-
quired maintenance, or which is scheduled only
for regular inspection to the effect of ”repair or

11
replace as necessary” shall be warranted for 2
years. Any warranted part which is scheduled
for replacement as required maintenance shall
be warrantedfor the period oftime up to the first
scheduled replacement point for that part.
DIAGNOSIS: The owner shall not be charged
for diagnostic labor which leads to the deter-
mination that a warranted part is defective if the
diagnostic work is performed at an approved
POULAN/WEED EATER servicing center.
CONSEQUENTIAL DAMAGES: POULAN/
WEED EATER may be liable for damages to
other engine components caused by the failure
of a warranted part still under warranty. WHAT
IS NOT COVERED: All failures caused by
abuse, neglect, or improper maintenance are
not covered. ADD--ON OR MODIFIED
PARTS: The use of add--on or modified parts
canbe groundsfor disallowinga warrantyclaim.
POULAN/WEED EATER is not liable to cover
failures of warranted parts caused bythe use of
add--on or modified parts. HOW TO FILE A
CLAIM: If you have any questions regarding
your warranty rights and responsibilities, you
should contact your nearest authorized service
center or call POULAN/WEED EATER at
1--800--554--6723. WHERE TO GET WAR-
RANTY SERVICE: Warranty services or re-
pairs shall be provided at all POULAN/WEED
EATER service centers. Call 1--800--554--6723.
MAINTENANCE, REPLACEMENT AND RE-
PAIR OF EMISSION RELATED PARTS: Any
POULAN/WEED EATER approved replace-
ment part used in the performance of any war-
rantymaintenance orrepairon emission related
parts will beprovided without chargeto the own-
er if the part is under warranty. EMISSION
CONTROL WARRANTY PARTS LIST: Car-
buretor, Ignition System: Spark Plug (covered
up to maintenance schedule), Ignition Module.
MAINTENANCE STATEMENT: The owner is
responsible for the performance of all required
maintenance as defined in the instruction
manual.
This engine is certified to be emissions compliant for the following use:
Moderate (50 hours)
Intermediate (125 hours)
Extended (300 hours)
