Weidmuller IE-SW-IP67-5M12 Manual

IP67 unmanaged
Fast Ethernet Switches
IE-SW-IP67-5M12
IE-SW-IP67T-5M12
Hardware Installation Guide
First Edition, March 2014
1516620000/00/03.14
Important note:
This document and additional product information can be
downloaded using following link:
http://www.weidmueller.com
► Select Product Catalogue
Select „Industrial Ethernet active“
Select „IP67 unmanaged Switches“
Select Product model
Click and expand section „Downloads“
Download needed documentation
Copyright Notice
Copyright 2014 Weidmüller Interface GmbH & Co. KG
All rights reserved.
Reproduction without permission is prohibited.

2
Overview
The Weidmüller 5-port unmanaged IP67 Ethernet switch provides a
hardened and cost-effective solution for your Ethernet connections. The
Switch is IP67-rated to provide protection against shock and foreign
particles. IP67-rated products have the following characteristics: (1)
dust proof, (2) protection against the effects of temporary immersion in
water.
The Switch is available in 2 variants to operate in 2 temperature ranges
from -25 to 60°C and -40 to75°C. The device is designed to withstand a
high degree of vibration and shock. The rugged hardware design makes
it perfect for ensuring that your Ethernet equipment can withstand the
rigors associated with critical industrial applications. The switches are
rated for use in hazardous locations (Class 1 Division 2) and comply
with CE/FCC and UL standards.
Package Checklist
Your Ethernet Switch is shipped with the following items. If any of these
items is missing or damaged, please contact your Weidmüller customer
service for assistance.
1 Ethernet Switch IE-SW-IP67(T)-5M12
Hardware Installation Guide
3 protective caps for unused ports and 8 port labels
3 screws for mounting the Switch
Features
High Performance Network Switching Technology
5 10/100BaseT(X) ports (4-pin shielded M12 socket with D coding).
Broadcast storm protection.
IEEE802.3/802.3u/802.3x.
Store and Forward switching process type.
10/100M, Full/Half-Duplex, MDI/MDIX auto-sensing.
Industrial Grade Reliability
Active circuit protection.
Robust connection.
Dust and immersion proof.
Rugged Design
Casing design meets IP67 protection standards.
M12 connectors for robust connections.
Operating temperature range of -25 to 60°C, or extended operating
temperature range of -40 to 75°C (T-models).

3
Panel Layout of IE-SW-IP67(T)-5M12
Front Panel View
1. M12 port’s 10/100 Mbps LED.
2. 10/100BaseT(X) port (4-pin female shielded M12 socket with D
coding).
3. Port Label.
4. Power input (5-pin male shielded M12 socket with A coding).
5. Power input (PWR) LED.
6. Device Type.
7. Holes for attaching the IE-SW-IP67(T)-5M12 to a wall with screws
(there are 3 holes: bottom left, bottom right, and top middle).
8. Grounding screws.
Mounting Dimensions (unit = mm)
Ethernet Switch

4
Panel/Wall Mounting
To mount the IE-SW-IP67(T)-5M12 on the wall use the 3 screws
included in the package.
STEP 1: Make 3 screw holes on the wall based on the positions of the
3 screw holes on the switch shown in the mounting
dimensions diagram.
STEP 2: Insert one screw in the top-middle screw hole on the switch
and screw it into the wall.
STEP 3: Screw in the remaining 2 screws through the bottom-left and
bottom-right holes on the switch.

5
Wiring Requirements
WARNING
Turn the power off before disconnecting modules or wires.
The correct power supply voltage is listed on the product
label. Check the voltage of your power source to make sure
that you are using the correct voltage. Do NOT use a
voltage greater than what is specified on the product label.
These devices must be supplied by a SELV source as
defined in the Low Voltage Directive 2006/95/EC and
2004/108/EC.
ATTENTION
Safety First!
Be sure to disconnect the power cord before installing
and/or wiring your Weidmüller switch.
This device has UL508 approval. Use copper conductors
only, 60/75°C, Tighten To 4.5 pound-inches. For use in
Pollution Degree 2 Environment.
ATTENTION
Safety First!
Calculate the maximum possible current in each power wire
and common wire. Observe all electrical codes dictating the
maximum current allowable for each wire size. If the current
goes above the maximum ratings, the wiring could
overheat, causing serious damage to your equipment.
You should also heed the following guidelines:
Use separate paths to route wiring for power and devices. If power
wiring and device wiring paths must cross, make sure the wires are
perpendicular at the intersection point.
NOTE: Do not run signal or communications wiring and power
wiring in the same wire conduit. To avoid interference, wires
with different signal characteristics should be routed
separately.
You can use the type of signal transmitted through a wire to
determine which wires should be kept separate. The rule of thumb is
that wiring that shares similar electrical characteristics can be
bundled together.
Keep input wiring and output wiring separated.
It is strongly advised that you label wiring to all devices in the system
when necessary.

6
Grounding the IE-SW-IP67(T)-5M12
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
ground screw to the grounding surface prior to connecting devices.
ATTENTION
This product is intended to be mounted to a well-grounded
mounting surface such as a metal panel.
10/100BaseT(X) Ethernet Port Connection
The IE-SW-IP67(T)-5M12 has 5 10/100BaseT(X) Ethernet ports (4-pin
shielded M12 socket with D coding). The 10/100BaseTX ports located
on the front panel are used to connect to Ethernet-enabled devices.
Most users configure these ports for Auto MDI/MDI-X mode, in which
case the port’s pinouts are adjusted automatically depending on the
type of Ethernet cable used (straight-through or cross-over), and the
type of device (NIC-type or HUB/Switch-type) connected to the port.
In what follows, we give pinouts for both MDI (NIC-type) ports and MDI-
X (HUB/Switch-type) ports. We also give cable wiring diagrams for
straight-through and cross-over Ethernet cables.
Ethernet Switch

7
Pinouts for sockets on IE-SW-IP67(T)-5M12
TP Port
-Pin 1:
-Pin 2:
-Pin 3:
-Pin 4:
TD +
RD +
TD -
RD -
Power input
-Pin 1:
-Pin 2:
-Pin 3:
-Pin 4:
-Pin 5:
Input V+
Not assigned
Input V-
Not assigned
Function ground
Pinouts for RJ45 (8-pin)
RJ45 (8-Pin)
MDI Port Pinouts
MDI-X Port Pinouts
Pin
Signal
1
Tx +
2
Tx -
3
Rx +
6
Rx -
Pin
Signal
1
Rx +
2
Rx -
3
Tx +
6
Tx -
M12 (4-pin, M) to M12 (4-pin, M) Cross-Over Cable Wiring

8
M12 (4-pin, M) to M12 (4-pin, M) Straight-Trough Cable Wiring
M12 (4-pin, M) to RJ45 (8-pin) Cross-Over Cable Wiring
M12 (4-pin, M) to RJ45 (8-pin) Straight-Trough Cable Wiring

9
LED Indicators
Several LED indicators are located on the IE-SW-IP67(T)-5M12 front
panel. The function of each LED is described in the table below.
LED
Color
State
Description
PWR
AMBER
On
Power is being supplied to the power
input.
Off
Power is not being supplied to the
power input.
LNK/ACT
(10M)
AMBER
On
TP port’s 10 Mbps link is active.
Blinking
Data is being transmitted at 10 Mbps
Off
TP port’s 10 Mbps link is inactive.
LNK/ACT
(100M)
GREEN
On
TP port’s 100 Mbps link is active
Blinking
Data is being transmitted at 100
Mbps.
Off
TP port’s 100 Mbps link is inactive.
Auto MDI/MDI-X Connection
The Auto MDI/MDI-X function allows users to connect IE-SW-IP67(T)-
5M12’s 10/100BaseTX ports to any kind of Ethernet device, without
needing to pay attention to the type of Ethernet cable being used for the
connection. This means that you can use either a straight-through cable
or cross-over cable to connect the IE-SW-IP67(T)-5M12 to Ethernet
devices.
Dual Speed Functionality & Switching
The IE-SW-IP67(T)-5M12 10/100 Mbps switched M12 ports auto
negotiate with the connected device to use the fastest data
transmission rate supported by both devices. All of Weidmüller’s
unmanaged switches are plug-and-play devices, so that software
configuration is not required. The half/full duplex mode for the switched
M12 ports is user dependent and changes (by auto-negotiation) to full
or half duplex, depending on which transmission speed is supported by
the attached device.
Switching and Address Learning
The IE-SW-IP67(T)-5M12 has an address table that can hold up to
1000 node addresses, which makes it suitable for use with large
networks. The address tables are self-learning, so that as nodes are
added or removed, or moved from one segment to another, the IE-SW-
IP67(T)-5M12 automatically keeps up with new node locations. An
address-aging algorithm causes the least-used addresses to be deleted
in favor of newer, more frequently used addresses. To reset the
address buffer, power down the unit and then power it back up.

10
Switching, Filtering, and Forwarding
Each time a packet arrives at one of the switched ports, a decision is
made to filter or forward the packet. Packets with source and
destination addresses belonging to the same port segment will be
filtered, constraining those packets to one port, and relieving the rest of
the network from the need to process them. A packet with destination
address on another port segment will be forwarded to the appropriate
port, and will not be sent to the other ports where it is not needed.
Packets that are used in maintaining the operation of the network (such
as the occasional multi-cast packet) are forwarded to all ports. The IE-
SW-IP67(T)-5M12 operates in the store-and-forward switching mode,
which eliminates bad packets and enables peak performance to be
achieved when there is heavy traffic on the network.
Auto-Negotiation and Speed Sensing
All of the IE-SW-IP67(T)-5M12’s Ethernet ports independently support
auto-negotiation for speeds in the 10BaseT and 100BaseTX modes,
with operation according to the IEEE 802.3u standard. This means that
some nodes could be operating at 10 Mbps, while at the same time,
other nodes are operating at 100 Mbps.
Auto-negotiation takes place when an M12 cable connection is made,
and then each time a LINK is enabled. The Switch advertises its
capability for using either 10 Mbps or 100 Mbps transmission speeds,
with the device at the other end of the cable expected to advertise in the
same way. Depending on what type of device is connected, this will
result in agreement to operate at a speed of either 10 Mbps or 100
Mbps.
Note about possible lost of data packages in case of “Duplex
mismatching”
If the Switch’AutoNeg-Port is connected to a non-negotiating device,
then the Switch will set its port transmission speed same as the
connected device but is unable to correctly detect the duplex mode. As
result the port is set to the correct speed but is using always the half
duplex mode as required by the IEEE 802.3u standard in such cases.
For correct transmission the non-negotiating port has to be set to half-
duplex mode (speed either 10 or 100 Mbit/s).

11
Specifications
Technology
Standards
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X)
IEEE 802.3x for Flow Control
Processing Type
Store and Forward
Flow Control
IEEE 802.3x flow control, back pressure flow
control
Interface
M12 Ports
10/100BaseT(X) auto negotiation speed, F/H
duplex mode, and auto MDI/MDI-X connection
LED Indicators
Power, LNK/ACT
Power
Input Voltage
24 to 45 VDC
18 to 30 VAC (47 to 63 Hz)
Input Current
0.12A @ 24 VDC
0.28A @ 24 VAC
Connection
M12 A-coding 5-pin male connector, single
power input
Overload Current
Protection
1.1 A
Reverse Polarity
Protection
Present
Physical Characteristics
Housing
Plastic, IP67 protection
Dimensions
60 x 125 x 29.6 mm (W x H x D)
Weight
250 g
Installation
Panel/Wall Mounting
Environmental Limits
Operating
Temperature
Standard models: -25 to 60°C (-13 to 140°F)
Wide temp. models: -40 to 75°C (-40 to 167°F)
Storage Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5 to 95% (non-condensing)
Regulatory Approvals
EMI
FCC Part 15, CISPR (EN55022) class A
EMS
EN61000-4-2 (ESD), Level 3
EN61000-4-3 (RS), surpasses Level 3
EN61000-4-4 (EFT), Level 3
EN61000-4-5 (Surge), Level 3
EN61000-4-6 (CS), Level 2
EN61000-4-8, EN61000-4-11
Shock
IEC 60068-2-27
Freefall
IEC 60068-2-32
Vibration
IEC 60068-2-6

12
MTBF (meantime between failures)
Time
370,224 hrs
Database
Telcordia (Bellcore), GB 25°C
WARRANTY
Time Period
5 years
Weidmüller gives a 5 year warranty on this product in accordance with
the warranty terms as described in the general conditions of sale of the
Weidmüller company which has sold the products to you. Weidmüller
warrants to you that such products the defects of which have already
existed at the time when the risk passed will be repaired by Weidmüller
free of charge or that Weidmüller will provide a new, functionally
equivalent product to replace the defective one. Safe where expressly
described otherwise in writing in this catalogue/product description,
Weidmüller gives no warranty or guarantee as to the interoperability in
specific systems or as to the fitness for any particular purpose. To the
extent permitted by law, any claims for damages and reimbursement of
expenses, based on whatever legal reason, including contract or tort,
shall be excluded. Where not expressly stated otherwise in this
warranty, the general conditions of purchase and the expressive liability
commitments therein of the respective Weidmüller company which has
sold the products to you shall be applicable.
Contact Information
Weidmüller Interface GmbH & Co. KG
Postfach 3030
32760 Detmold
Klingenbergstraße 16
32758 Detmold
Germany
Phone [phone]
Fax [phone]
E-Mail [e-mail]
Internet www.weidmueller.com
