Weishaupl Loft Table User manual

Scope of delivery:
4 x cylinder head screw with hexagon soc et M8 x 16 mm, 4 x washer
1 x adjuster for table top, 8 x connecting sleeve M8 x 20 mm
16 x countersun screw with hexagon soc et M8 x 20 mm
2 x Allen ey 5 mm
ASSEMBLY INSTRUCTIONS
L O F T T A B L E
Fig re 1:
Place the table upside-down on a level surface. Screw the legs together as
shown and slightly tighten the screws. To do this, use:
4 x cylinder head screws with hexagon soc et M8 x 16 mm, 4 washers.
Fig re 2:
Now screw the adjuster for the table top into the center fixture.
2
1

ASSEMBLY INSTRUCTIONS
L O F T T A B L E
Fig re 3:
Now insert the x-shaped support into the recesses provided for this purpose in
the table legs and screw them tight as shown in the diagram.
To do this, use: 8 x connecting sleeve M8 x 20 mm
16 x countersun screws with hexagon soc et M8 x 20 mm
Fig re 4:
Chec that the adjuster for the table top is in the right position in the
x-shaped support (bore hole in the centre of the x). Finally, tighten all screws.
3
4

ASSEMBLY INSTRUCTIONS
L O F T T A B L E
Fig re 5:
The table top can be aligned horizontally using the adjuster.
5
