Weishaupl WIPP EXTENDING TABLE User manual

Scope of delivery:
Wipp extending table with 1 extension piece, 4x washers, 4x M8 lock nuts,
1x protective cover for table extensions.
A second extension is available as an option. This second extension is not
included in the scope of delivery.
Assembly:
Place the table with the tabletop facing downwards on a level surface and
screw on the four table legs as shown. Make sure that the two handwheels
are tightened.
Now turn the table over and release the two handwheels. Stand in the center
of the long side of the table (see Fig. 2), pull the two halves of the table
top apart and re ove the cardboard box protecting the co ponents during
transport. Now fit the protective cover over the two inside extensions, push
the table top sections back together and tighten the handwheels again.
Your extending table is now asse bled and ready for use.
Instructions for use:
To fit the extension, proceed as follows: Release the handwheels on both
sides, and, standing in the center of the long side of the table (see Fig. 2),
pull the two halves of the table top apart. Now re ove the protectiv cover
and take the extension out of the holder. When inserting the extension,
ensure that the positioning brackets for the extension are on the outside of
the table fra e (see Fig. 3, detail view).
Finally, push the two sections of the table top together and tighten the
handwheels again.
Removing t e extensions w ere two extensions are used:
Please ensure that you place the extensions back in the holder as shown in
Fig. 3.
1
2
3
4
ASSEMBLY INSTRUCTIONS
W I P P E X T E N D I N G T A B L E

ASSEMBLY INSTRUCTIONS
W I P P E X T E N D I N G TA B L E
1
Handwheel
2

ASSEMBLY INSTRUCTIONS
W I P P E X T E N D I N G TA B L E
(2 : 5) J (2 : 5)
H
Table top
Positioning bracket
Table fra e
3
4
