S A W H O R S E W I T H C H A I N S A W H O L D E R
OWNER’S MANUAL
WARNING: Read carefully and understand all
INSTRUCTIONS before operating. Failure to follow the
safety rules and other basic safety precautions may result
in serious personal injury.
Item # 20668

Page of 8
2
Thank you very much for choosing a Wel-Bilt™ product! For future reference, please complete
the owner’s record below:
Model: _______________ Purchase Date: _______________
Save the receipt, warranty and these instructions. It is important that you read the entire manual
to become familiar with this product before you begin using it.
This product is designed for certain applications only. The distributor cannot be responsible for
issues arising from modification. We strongly recommend this product not be modified and/or
used for any application other than that for which it was designed. If you have any questions
relative to a particular application, DO NOT use the product until you have first contacted the
distributor to determine if it can or should be performed on the product.
For technical questions please call 1-800-222-5381.
INTENDED USE
This sawhorse with chain saw holder that easily attaches to most chain saws (chain saw not included)
to cut the logs.
TECHNICAL SPECIFICATIONS & PACKING LIST
Item
Description
Max. Capacity
220lbs. (100kg)
Product Dimensions (in use)
34.6in. x 28in. x 33.9in. (88 x 71 x 96cm)
Product Dimensions (folded)
34.6in. x 6.1in. x 3.8in. (88 x 15.5 x 9.7cm)
GENERAL SAFETY RULES
WARNING: Read and understand all instructions. Failure to follow all instructions listed
below may result in electric shock, fire and/or serious injury.
WARNING: The warnings, cautions, and instructions discussed in this instruction
manual cannot cover all possible conditions or situations that could occur. It must be
understood by the operator that common sense and caution are factors which cannot be built into
this product, but must be supplied by the operator.
SAVE THESE INSTRUCTIONS
WORK AREA
Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause
accidents.
Do not use your tool where there is a risk of causing a fire or an explosion; e.g. in the
presence of flammable liquids, gasses, or dust. Power tools create sparks, which may ignite the
dust or fumes.
Keep children and bystanders away while operating a power tool. Distractions can cause you
to lose control, so visitors should remain at a safe distance from the work area.

Page of 8
3
Be aware of all power lines, electrical circuits, water pipes and other mechanical hazards in
your work area, particularly those hazards below the work surface hidden from the operator’s
view that may be unintentionally contacted and may cause personal harm or property damage.
Be alert of your surroundings. Using power tools in confined work areas may put you
dangerously close to cutting tools and rotating parts.
PERSONAL SAFETY
Stay alert, watch what you are doing and use common sense when operating a chain saw with
this sawhorse. Do not use a chain saw while you are tired or under the influence of drugs, alcohol
or medication. A moment of inattention while operating power tools may result in serious
personal injury.
Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewelry or long hair can be caught in moving
parts. Air vents often cover moving parts and should be avoided.
Use safety apparel and equipment. Use safety goggles or safety glasses with side shields
which comply with current national standards, or when needed, a face shield. Use as dust mask
in dusty work conditions. This applies to all persons in the work area. Also use non-skid safety
shoes, hardhat, gloves, dust collection systems, and hearing protection when appropriate.
Do not overreach. Keep proper footing and balance at all times.
TOOL USE AND CARE
Place the wood on the log table, pushing the end to the measuring rod. Hold the wood
down firmly with your left hand, keeping your hand well clear of the cutting edge of the chain saw,
and arc the chain saw down to cut.
The Log Horse chain guard is designed for a chain saw with a cutting bar not longer than
17.7in.(45cm). A chain saw with a cutting bar longer than 17.7in.(45cm) (which protrudes beyond
the chain guard) should not be used with this sawhorse.
The pivot clamp and guard must be detached when using the chain saw separately from the
Log Horse..
The Log Horse must be used on the flat surface only.
Ensure the nuts and bolts on the pivot clamp and guard are kept tight at all times. When
using a chain saw with the Log Horse it is essential that all safety codes and practices of the chain
saw manufacturer and local authorities are fully followed.

Page of 8
4
ASSEMBLY
Pivot Clamp Support and Measuring Rod
Insert the pivot clamp support (adjustable vertically) into the saw horse table with the measuring rod
holder (adjustable horizontally), using the bolt and washer supplied.The vertical adjustment for the
pivot clamp support is to accommodate different sized chain bars – the larger and longer the bar, the
higher the pivot clamp should be placed. Adjust so that the tip of the chain bar extends beyond the
table, so that it is cutting completely through the log. The measuring rod can be adjusted horizontally
to allow each log to be cut to the desired length.
Pivot Clamp
Insert the male rod on the pivot clamp into the female cylinder on the pivot support clamp and secure
with the R-clip.
Carefully lower the chain saw bar into position between the two solid blocks in the pivot
clamp and ensure a 0.9in. (2cm) gap between the body of the chain saw and clamp. Make sure
that the bar is approximately 90° to the clamp and well clear of the chain before tightening the bolt.
Once tightened, test the arc of travel to make sure that the chain bar does not touch any part of the
saw bench.

Page of 8
5
Position the chain saw bar guard around the top rod of the pivot clamp. Securely tighten the
bar guard with bolt and nut provided.
Slide the guard backwards and forward as necessary to a position in which the guard is well
clear of the chain. Tighten the bolt. Re-check for clearance. The sawhorse is now ready for use.

Page of 8
6
MAINTENANCE
Maintain your tools. It is recommended that the general condition of any tool be examined
before it is used. Keep your tools in good repair by adopting a program of conscientious repair
and maintenance in accordance with the recommended procedures found in this manual. If any
abnormal vibrations or noise occurs, turn the tool off immediately and have the problem
corrected before further use. Have necessary repairs made by qualified service personnel.
Cleaning. Use only soap and a damp cloth to clean your tools. Many household cleaners are
harmful to plastics and other insulation. Never let liquid get inside a tool.

Page of 8
7
DIAGRAM & PARTS LIST
Part#
Description
Qty.
1
Bolt M8X30
8
2
Bolt M8X35
6
3
Bolt M8X45
2
4
Bolt M8X70
1
5
Bolt M10X20
1
6
Bolt M8X12
6
7
R Clip
1
8
Support
1
9
Nut M8
17
10
Bolt M12X30
1
11
Bolt M10X20
1
12
Plastic cover
2
13
Rod
2
For replacement parts and technical questions, please call 1-800-222-5381.

Page of 8
8
WARRANTY
One-Year Limited Warranty
WARNING
Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains
chemicals known to the State of California to cause cancer, birth defects or other reproductive harm.
Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry products, and
• arsenic and chromium from chemically treated lumber.
Your risk from these exposures varies, depending on how often you do this type of work. To reduce your
exposure to these chemicals: work in a well-ventilated area, and work with approved safety equipment,
such as those dust masks that are specially designed to filter out microscopic particles.
Distributed by
Northern Tool + Equipment Co.,
Burnsville, MN 55337-0499
Made in China
