Welby ABO 523 User manual

BLOOD PRESSURE
MONITOR
TENSIÓMETRO
English ........06
Español .......37
User Manual
Manual
del usuario
ZurFreigabe_V3

QR codes take you where you want to go
quickly and easily
Whether you require product information, spare parts or accessories,
details on warranties or after sales services, or if you want to watch a
product demonstration video, our QR codes will take you there in no
time at all.
What is a QR code?
A QR code (QR = Quick Response) is a type of matrix that can be read
with a smartphone camera and that contains a link to a website or
contact details, for example.
Advantage: You do not need to manually enter a website address or
contact details.
How it works
To scan the QR code, all you need is a smartphone with QR code reader
software and an internet connection.
This type of software can be downloaded for free from your
smartphone’s app store.
Try it out now
Just scan the QR code with your smartphone and
find out more about the ALDI product you have
purchased.
Your ALDI Service Portal
All details mentioned above can also be found in
the ALDI Service Portal at www.aldi.us.
Depending on your smartphone plan you may be charged for the connection.
ZurFreigabe_V3

Dok./Rev.-Nr. 195370_20170714
Contents
Overview .................................4
Use............................................5
Package contents/
device parts.............................6
General information ...............7
Reading and storing the
user manual...........................7
Explanation of symbols .......7
Safety.......................................8
Proper use.............................8
Safety instructions...............9
Battery notes.......................13
Safe use of the power
supply unit...........................15
First use ..................................17
Checking the blood
pressure monitor and
package contents...............17
Inserting or changing
batteries ...............................17
Using a power supply unit...18
System settings..................... 18
Advice on use ........................20
Performing a measurement... 22
Fitting the cuff.................... 23
Assuming the correct
posture ................................ 23
Starting a blood pressure
measurement..................... 24
Deleting or storing
measurement results........ 25
Deactivation........................ 25
Evaluating the
measurements ......................26
About blood pressure....... 26
Cardiac arrhythmia ........... 26
Average of measurement
results .................................. 27
Checking memory ............. 27
Deleting memory............... 27
WHO classifications............28
Cleaning and maintenance ..29
Changing the batteries.....29
Storage ..................................30
Troubleshooting ...................30
Technical data .......................32
Full display reference...........34
Manufacturer information ...35
Disposal .................................35
Disposing of the
packaging...........................35
Disposing of the
blood pressure monitor....35
ZurFreigabe_V3

4
A
SYS
DIA
PULSE
M
SET
mmHg
mmHg
/min
START
STOP
1~2cm (0 .4~0.8 inch)
22~36cm
（8. 6~ 14 .2 i nch )
Mai n Arte ry
LE F T A RM
IN DEX
1
2
3
4
5
9 10
11
13
12
6
7
8
ZurFreigabe_V3

5
B
AVG
mmHg
kPa
No
(
( )
)
/
14
15
16
18
20
21
22
23
24
25
26
17
19
C
1-2cm ''(0.4-0.8 )
2. 3.
1. 0.4"–0.8"
(1–2 cm)
ZurFreigabe_V3

6
Package contents⁄device parts
The package contents include four
AA 1.5 V batteries.
1Display
2M button (Mode)
3START/STOP button
4SET button
5Battery compartment cover
6Battery compartment
7Air plug jack
8Power plug jack
9Cuff
10 Cuff hose
11 Air plug
12 Batteries
13 Storage bag
14 User icon ( or )
15 Indicator for systolic pressure
16 Indicator for diastolic pressure
17 Pulse rate indicator
18 Pulse rate/memory slot
19 Memory slot indicator
20 Date
21 Time
22 Arrhythmia indicator
23 Average indicator
24 Air release indicator
25
Indicator for measurement
classification according to
the WHO
26 Low battery indicator
ZurFreigabe_V3

General information
7
General information
Reading and storing the user manual
This user manual accompanies this blood pressure
monitor. It contains important information about
using and handling the product.
Before using the blood pressure monitor, read the user manual
carefully. This particularly applies to the safety instructions.
Failure to heed this user manual may result in severe injury or
damage to the blood pressure monitor.
Store the user manual for future use. Make sure to include this
user manual when passing the blood pressure monitor on to
third parties.
Explanation of symbols
The following symbols and signal words are used in this user
manual, on the blood pressure monitor or on the packaging.
WARNING!
This signal symbol/word designates a hazard with moderate
degree of risk which may lead to death or severe injury if not
avoided.
CAUTION!
This signal symbol/word designates a hazard with low risk
that, if not avoided, may result in minor or moderate injury.
ZurFreigabe_V3

Safety
8
NOTICE!
This signal word warns against potential damages to property.
This symbol provides you with useful
supplementary information on use.
This symbol identifies devices classified as type BF.
This symbol indicates that you should read the
user manual and hold onto it.
This symbol identifies information from the
manufacturer (see chapter “Manufacturer
information”).
This symbol marks the serial number of the
device.
This symbol indicates that the middle (tip) of the
output plug is positive (+) and the body (ring) of
the output plug is negative (–).
Safety
Proper use
The blood pressure monitor is only designed for the non-
invasive measurement of systolic diastolic blood pressure and
pulse rate of adults using the oscillometric method. The results
are shown on the display of the blood pressure monitor.
ZurFreigabe_V3

Safety
9
The blood pressure monitor issues a warning in the event of
possible cardiac arrhythmia. The levels measured are classified
and rendered in accordance with the guidelines of the WHO
(World Health Organization).
The blood pressure monitor is not intended to be used for
toddlers and children.
The blood pressure monitor is exclusively intended for private
use and is not suitable for commercial or clinical use.
The measurement position is on an adult’s upper arm only.
Only use the blood pressure monitor as described in this user
manual. Any other use is deemed improper and may result
in damage to property or even personal injury. The blood
pressure monitor is not a children’s toy.
The manufacturer or vendor accepts no liability for damage
caused by improper or incorrect use.
Safety instructions
WARNING!
Danger for children and persons with
impaired physical, sensory or mental
capacities (e.g. partially disabled
persons, older persons with reduced
physical and mental capacities) or lack
of experience and knowledge (e.g. older
children).
ZurFreigabe_V3

Safety
10
− This blood pressure monitor may be
used by children ages eight and over as
well as persons with impaired physical,
sensory or mental capacities or those
lacking experience and knowledge
if they are supervised or have been
instructed in how to safely use the blood
pressure monitor and have understood
the risks associated with operating it.
Children must not play with the blood
pressure monitor. Cleaning and user
maintenance must not be performed by
unsupervised children.
− Keep children under eight years of age
away from the blood pressure monitor.
− Do not let children play with the
packaging. Children may get caught in
it when playing and suffocate.
WARNING!
Risk of injury!
Improper use of the blood pressure monitor
may result in injury.
ZurFreigabe_V3

Safety
11
− Only use the blood pressure monitor for
its intended purpose. Do not misuse in
any way.
− The blood pressure monitor is not
suitable for infants or individuals who
cannot express their intentions.
− People with serious circulation problems
may experience discomfort. Consult
a physician before you use the blood
pressure monitor.
− Contact your physician if test results
regularly indicate abnormal readings.
Do not attempt to self-treat these
symptoms without consulting a
physician.
NOTICE!
Risk of damage!
Improper use of the blood pressure monitor
may result in inaccurate measurements and
damage to the blood pressure monitor.
− Do not disassemble or attempt to repair
the blood pressure monitor.
ZurFreigabe_V3

Safety
12
− Do not subject the blood pressure
monitor to strong magnetic fields
(e.g. transformers). Otherwise this could
cause errors in readings or damage to
the blood pressure monitor.
− Only use the blood pressure monitor
at an ambient temperature of 50°F to
104°F (+10°C to +40°C) and a humidity
of 15% to 90%.
− Do not open the blood pressure monitor.
− Protect the blood pressure monitor against
dirt, direct sunlight, severe temperature
fluctuations, chemicals and mechanical
shocks.
− Do not let the blood pressure monitor
fall down.
− Only use enclosed or original
replacement cuffs to ensure that the
measurements are correct.
− Do not start the measurement process
until the cuff has been fitted.
− Do not immerse the blood pressure
monitor in water and do not rinse it off
under running water.
− Protect the cuff and its hose from sharp
and pointed objects.
ZurFreigabe_V3

Safety
13
− Do not kink the cuff hose.
− Do not place any heavy objects on the
blood pressure monitor, the cuff or cuff
hose.
Battery notes
WARNING!
Health hazard!
There is a high health hazard if children or
animals swallow the batteries.
− Store the batteries so they are not
accessible to children and animals. If you
suspect a battery has been swallowed,
seek immediate medical advice.
WARNING!
Risk of explosion and fire!
Using the blood pressure monitor or the
batteries improperly may result in fire or an
explosion.
− Do not throw batteries in an open fire.
ZurFreigabe_V3

Safety
14
− Do not charge any non-rechargeable
batteries.
− Never destroy the batteries.
− Never short circuit the batteries.
− Promptly remove empty batteries from
the battery compartment.
− Only use batteries of the same type
(see chapter “Technical data”).
− Do not use old and new batteries together.
− Before inserting the batteries, make
sure the contacts inside the battery
compartment and on the battery itself are
clean and intact. Clean them if necessary.
WARNING!
Risk of poisoning and chemical burns!
Ingesting batteries or coming into contact
with battery acid can result in poisoning and
chemical burns.
− Store the batteries so that they are not
accessible for children.
− Batteries may be installed or replaced
only by an adult.
ZurFreigabe_V3

Safety
15
− If it is no longer possible to securely
close the battery compartment, dispose
of the blood pressure monitor as
described in the chapter “Disposal”.
− If you suspect that a battery has been
swallowed or otherwise incorporated,
promptly consult a physician.
− Do not touch leaky batteries. If you
do happen to come into contact with
battery acid, wash the affected area
thoroughly with plenty of clean water.
Safe use of the power supply unit
WARNING!
Risk of electric shock!
Improper use of the power supply unit may
result in injury.
− Only use a medical power supply unit
which is suitable for the blood pressure
monitor (DC 6.0V, 600mA, not provided).
− Only use the power supply unit in dry
and indoor areas. Do not let the power
supply unit come into contact with
water or other liquids.
ZurFreigabe_V3

Safety
16
− Connect the power supply unit only
to an alternating current (AC) power
supply. Make sure that the voltage
corresponds with the voltage details on
the power supply unit.
− Only connect the power supply unit to a
properly installed and easily accessible
outlet so that you can quickly pull the
plug in an emergency.
− Never cover the power supply unit.
Ensure that sufficient ventilation is
provided in order to prevent the power
supply unit from overheating.
− Do not use the power supply unit if the
housing or cord is defective or has other
visible damages.
− In the event of damage, only have
the power supply unit serviced by the
manufacturer, its customer service team or
a similarly qualified person to avoid risks.
− Always disconnect the power supply
unit from the outlet if you would like
to clean the blood pressure monitor or
if you do not use the blood pressure
monitor for a prolonged period.
ZurFreigabe_V3

First use
17
First use
Checking the blood pressure monitor and
package contents
NOTICE!
Risk of damage!
If you are not cautious when opening the
packaging with a sharp knife or other
pointed objects, you may quickly damage
the blood pressure monitor.
− Be very careful when opening it.
1. Take the blood pressure monitor out of the packaging.
2. Check to make sure that the delivery is complete (see Fig.A).
3. Check whether the blood pressure monitor or individual
parts are damaged. If this is the case, do not use the blood
pressure monitor. Contact the manufacturer at the service
address specified on the warranty card.
Inserting or changing batteries
NOTICE!
Risk of damage!
Incorrect battery installation may damage
the blood pressure monitor.
ZurFreigabe_V3

System settings
18
− Make sure the polarity of the batteries
(+ or –) is correct.
1. Open the battery compartment 6by removing the
battery compartment cover 5.
2. To replace the batteries 12 , remove the old batteries first.
Insert 4 batteries (size AA) in the battery compartment.
3. Close the battery compartment by replacing the battery
compartment cover.
Using a power supply unit
The blood pressure monitor can also be operated
with a power supply unit (not included in the
package contents). A medical power supply unit
(DC 6.0V, 600mA) is recommended for use. The
adapter connection pin must be positive inside and
negative outside with a 0.08" (2.1mm) coaxial joint.
1. Connect the output plug of the power supply unit
(not provided) to the power plug jack 8.
2. Connect the power supply unit to an outlet.
System settings
The system settings allow you to select users, and set date,
time and time format.
1. Push the SET button 4.
A user icon ( or ) 14 will show on the display 1.
2. Push the M button 2to select either user icon 1 or user icon 2.
This allows up to two users to save and accumulate the test
results (60 memory slots per user).
ZurFreigabe_V3

System settings
19
3. Push the SET button to confirm the setting.
A message “ ” (year) will show on the display.
4. Push the M button to set the year and then push the SET
button to confirm.
5. Repeat steps 3 to 4 to set the month, date, hour time and
minute time.
The date 20 and time 21 are shown at the lower left
corner of the display.
6. After the minute time is set, push the M button to select
12-hour time format or 24-hour time format.
The 12-hour time format is indicated by the message “ ”
and the 24-hour time format by “ ”.
7. Push the SET button to access voice output mode. With the
M button, you can configure voice output “L1” (English), “L2”
(Spanish) or “OFF” for no voice output.
8. Push the SET button to access volume mode. Set the
volume of the voice output with the M button.
9. Push the START/STOP button 3to save the settings.
The blood pressure monitor will also automatically save
all settings and switch itself off without any operation for
3minutes.
It is important to set the date and time. Otherwise,
you will not be able to save the measurement
results correctly and to access them again later.
ZurFreigabe_V3

Advice on use
20
Advice on use
For ideal measurement results, follow the basic
rules below when measuring your blood pressure.
− If possible, always measure your blood pressure at the
same time of day for comparable results.
− Measurement comparisons should only be made when
the blood pressure monitor was used on the same arm, in
the same position and at the same time of the day.
− Morning time or any time you feel relaxed and stress-free
is the best for measurements.
− Do not stand during measurements. Sit or lay down in a
relaxed position and hold your arm at the height of your
heart (see Fig.C).
− Do not move and do not speak while performing a
measurement.
− Relax at least 30 minutes before you perform a measurement.
Do not smoke, eat or drink and avoid physical exertion.
− Give the circulatory system about five minutes to calm
down each time before a measurement is made.
− If the measurements are not plausible, repeat the
measurement.
− Wait at least five minutes before taking another
measurement for the same person.
− The results of the blood pressure measurements are
for information only and are no substitute for a medical
examination. Do not make any medical decisions based
on your own measurements (e.g. with respect to taking
medication or their dosage). Consult your physician if you
have questions about the measurements.
ZurFreigabe_V3
