Digital Automatic
Blood Pressure Monitor
DIA
mmHg
SYS
mmHg
MX2Basic
PULSE/min
MX2 Basic
MX2 Basic Cover.qxd 9/23/08 1:28 PM Page 1

MX2 Basic Cover.qxd 9/23/08 1:28 PM Page 2

1
MX2 Basic English
1How to obtain meaningful blood
pressure readings 1
2Overview 2
3Preparation 3
4Operation 4
5Error: causes and rectifications 7
6Maintenance and spare parts 7
7Technical data 8
8General information about blood
pressure 10
DIA
mmHg
SYS
mmHg
MX2 Basic
PULSE/min
The OMRON MX2 Basic measures your blood pressure and pulse simply and quickly
from the arm, without the use of an inflation bulb or stethoscope.
The OMRON MX2 Basic includes a standard cuff for arm circumferences ranging from
22-32 cm. Optional large cuffs (32-42 cm) can be applied.
Introduction
1 How to obtain meaningful blood pressure readings
Table of contents
General
• The OMRON MX2 Basic is not suitable
for measuring the frequency of cardiac
pacemakers.
• Consult your doctor during pregnancy,
arrhythmia and arteriosclerosis as this
can influence the measurement.
• Avoid eating, drinking (alcohol),
smoking, sport and taking a bath before
measurement.
• Be calm and relaxed before and during
measurement.
• You should never change the dose of
medicines prescribed by your doctor.
MX2 Basic 01-12 EN.qxd 10/7/08 12:19 PM Page 1

E A
D
C
F BG
H
J
DIA
mmHg
SYS
mmHg
PULSE/min
MX2Basic
2
MX2 Basic English
• Store the OMRON MX2 Basic in a dry,
closed place with a temperature
between -20°C and 60°C.
• Remove the batteries if you not intend
to use the OMRON MX2 Basic for 3
months or more.
Tips for use
• Check your blood pressure at least twice
a day (before breakfast, after work).
• Do not measure your blood pressure
while you are in a vehicle.
• Always measure on the same arm.
• Wrap the cuff around your arm before
start of measurement.
Caution
• Operating temperature between 10°C
and 40°C.
• Operating environment must be free
from excessive vibrations, shocks,
magnetic fields, electrical noise, etc.
• Stay out of sunlight during measuring.
• Keep portable phones 5 meters away
during measurement.
• Do not wrap the cuff around any object
other than your arm.
• Do not fold the cuff and the tube.
• Do not drop the OMRON MX2 Basic.
ADisplay
BStart button
COn/off button
DAC adapter jack
ECuff
FAir tube
GAir plug
HBattery
compartment
JAir jack
2 Overview
MX2 Basic 01-12 EN.qxd 10/7/08 12:19 PM Page 2

3
MX2 Basic English
Insert batteries
1Slide off the battery cover. 2Insert four batteries as indicated in the
battery compartment and close
compartment
Caution! Use four identical 1.5V
batteries type AA!
PULSE/min
SYS
mmHg
DIA
mmHg
MX2B
Connect cuff
1Insert air plug in air jack.
K
F
Fit cuff
Caution! Do not inflate the cuff when not
wrapped around the arm!
1Bare your arm.
Caution! Push up your sleeve: avoid
constricting the blood flow!FAir tube
KRing
3 Preparation
2Pass the end of the cuff through the ring.
Caution! Keep the air tube on the
outside!
3Put your arm through the loop.
Note: keep the tube even with your
middle finger.
1-2 cm
MX2 Basic 01-12 EN.qxd 10/7/08 12:19 PM Page 3

MX2 Basic English
4
Note: for right arm use keep the tube
parallel with your little finger!
4Hold the end of the cuff and wrap it
around your arm.
Caution! Be sure the cuff fits closely;
do not pinch your arm!
PULSE/min
DIA
mmHg
SYS
mmHg
MX2 Basic
C
B
N
L
M
S
R
Q
P
Control functions
BStart button
COn/off button
Measurement
LSystolic blood pressure in mmHg.
MHeart symbol: flash - measurement
takes place, light up - finish
measurement.
NDiastolic blood pressure in mmHg.
PPulse: heartbeats per minute.
QBattery exhausted: batteries are
weak/exhausted.
RDeflation: cuff deflates and
measurement finishes.
SInflation: cuff inflates and measurement
starts.
1-2 cm
4 Operation
MX2 Basic 01-12 EN.qxd 10/7/08 12:19 PM Page 4

MX2 Basic English
5
Caution! Allow an interval of at least three minutes between two successive measurements!
1Sit comfortably at a table with your feet
flat on the floor and rest your arm on
the table.
2Relax your arm and turn your palm
upward.
Caution! Cuff at heart height during
measurement!
PULSE/min
DIA
mmHg
SYS
mmHg
MX2 Basic MX2 Basic MX2 Basic
PULSE/min
DIA
mmHg
SYS
mmHg
PULSE/min
DIA
mmHg
SYS
mmHg
3Press on/off button.
Caution! Wait for zero and the heart symbol to continue!
4Press start button
Note: the unit inflates the cuff to 170
mmHg. If required the unit
automatically increases the pressure by
40 mmHg.
Note: press and hold the start button to
set pressure higher than 170 mmHg.
Caution! Do not inflate over 280
mmHg!
PULSE/min
DIA
mmHg
SYS
mmHg
MX2 Basic
MX2 Basic 01-12 EN.qxd 10/7/08 12:19 PM Page 5

MX2 Basic English
6
Note: the cuff deflates automatically. Caution! Sit still, do not move and do not
speak!
PULSE/min
DIA
mmHg
SYS
mmHg
MX2 Basic
PULSE/min
DIA
mmHg
SYS
mmHg
MX2 Basic
Read display
2Note values in your personal blood
pressure pass.
3Press on/off button to turn off power.
Note: power automatically shuts off in 5
minutes.
PULSE/min
DIA
mmHg
SYS
mmHg
MX2 Basic
PULSE/min
DIA
mmHg
SYS
mmHg
MX2 Basic
PULSE/min
DIA
mmHg
SYS
mmHg
PULSE/min
DIA
mmHg
SYS
mmHg
MX2 Basic MX2 Basic
1Read the values of blood pressure and pulse from the display.
Note: display shows blood pressures and heartbeats alternately.
MX2 Basic 01-12 EN.qxd 10/7/08 12:19 PM Page 6

7
MX2 Basic English
Indication Error Cause Rectification
Correct Cuff pressure
reading low
not
possible Movement
Very weak
artery pulse
Cuff pressure
too high
Low Batteries weak/ Fit four new identical 1.5V
voltage exhausted batteries type AA
Display empty
• Use a soft, slightly moistened cloth to
clean the OMRON MX2 Basic.
Caution! Do not use petrol, thinners or
similar solvents!
• Use a soft, moistened cloth and soap to
clean the cuff.
Caution! Do not wash the cuff!
Caution! Do not use petrol, thinners or
similar solvents!
• Do not carry out repairs of any kind
yourself. If a defect occurs consult your
OMRON retail outlet or distributor as
mentioned on the packaging.
Calibration
• It is recommended to have the OMRON
MX2 Basic inspected every two years to
ensure correct function and accuracy.
Consult your OMRON retail outlet or
OMRON distributor as mentioned on the
packaging.
Replace batteries
• Remove the battery out of the battery
5 Error: causes and rectifications
6 Maintenance and spare parts
Wait for at least three minutes to repeat
measurement.
Inflate the cuff 40 mmHg higher than
previous value.
Follow instructions, repeat
measurement.
Wait for at least three minutes to repeat
measurement.
Inflate the cuff 30 mmHg lower than
previous value.
Follow instructions, repeat
measurement.
MX2 Basic 01-12 EN.qxd 10/7/08 12:19 PM Page 7

Product name OMRON Digital Automatic Blood Pressure Monitor
Model MX2 Basic
Display Digital LCD
Measurement range Pressure: 0 - 299 mmHg / Pulse: 40 - 180 / minute
Accuracy Pressure: ± 3 mmHg
Pulse: ± 5% of display reading
Inflation Automatic by electric pump
Deflation Automatic pressure release valve
Rapid pressure release Automatic exhaust valve
Pressure detection Capacitive pressure sensor
Measurement method Oscillometric method
Power supply 4 x 1.5V batteries type AA
AC adapter (optional part)
Battery life New batteries will last for approximately 300 measurements
Operating temperature/humidity +10°C to +40°C / 30% to max. 85% relative humidity
Operating environment Free from excessive vibrations, shocks, magnetic fields,
electrical noise, etc.
Storage temperature/humidity -20°C to +60°C /10% to max. 95% relative humidity
Weight Approximately 350 g including cuff, excluding batteries
Outer dimensions Approximately 118 mm (W) x 90 mm (H) x 130 mm (D)
Cuff dimensions Approximately 145 mm (W) x 480 mm (L)
Arm circumference 22 cm to 32 cm
Accessories Cuff, instruction manual, guarantee card, blood pressure pass
Optional parts Large cuff for arm circumferences between 32 - 42 cm, AC adapter
Note Subject to technical modification without prior notice
= Type B
Manufacturer OMRON HEALTHCARE Co., Ltd.
24, Yamanouchi Yamanoshita-cho, Ukyo-ku, Kyoto, 615-0084 Japan
EU-representative OMRON HEALTHCARE EUROPE B.V.
Kruisweg 577, NL-2132 NA Hoofddorp
This device fulfils the provisions of the EC directive 93/42/EEC (Medical Device Directive). This blood
pressure monitor is designed according to the European standard EN1060, Non-invasive
sphygmomanometers Part 1: General Requirements and Part 3: Supplementary requirements for
electromechanical blood pressure measuring systems.
8
MX2 Basic English
7 Technical data
compartment and insert four new identical
1.5V batteries type AA.
Spare parts
• Due to high company quality standards,
OMRON considers the main unit as a
non-serviceable part because the need
for proper calibration after replacement
of high tech components.
Attention! Disposal of batteries and the
OMRON MX2 Basic should be
carried out in accordance with
the national regulations for the
disposal of electronic products.
