Wenglor B50 User manual

B50
C50
Smart Camera / Vision Sensor / 1D- / 2D-Code Scanners / OCR Reader
Operating Instructions
Translation of the Original Operating Instruction
Subject to change without notice
Available as PDF version only
Version: 2.1.0
Status: 18.06.19
www.wenglor.com
EN

2Table of Contents
Table of Contents
1. General ...................................................................................................................................4
1.1 Information Concerning these Instructions ............................................................................................. 4
1.2 Explanations of Symbols ......................................................................................................................... 4
1.3 Limitation of Liability................................................................................................................................. 5
1.4 Copyrights................................................................................................................................................ 5
2. For Your Safety.......................................................................................................................6
2.1 Use for Intended Purpose........................................................................................................................ 6
2.2 Use for Other than the Intended Purpose................................................................................................ 6
2.3 Personnel Qualifications .......................................................................................................................... 7
2.4 Modification of Products .......................................................................................................................... 7
2.5 General Safety Precautions ..................................................................................................................... 7
2.6 Approvals and protection class ............................................................................................................... 7
3. Technical Data ........................................................................................................................8
3.1 List of Technical Data............................................................................................................................... 8
3.2 Sensors with Monochrome Image Chip .................................................................................................. 9
3.3 Sensors with monochrome image chip and C-mount .......................................................................... 10
3.4 Sensors with Color Image Chip and Autofocus .................................................................................... 10
3.5 Sensors with color image chip and C-mount ........................................................................................ 11
3.6 Housing Dimensions..............................................................................................................................11
3.7 Connection Diagrams ............................................................................................................................12
3.8 Complementary Products ...................................................................................................................... 12
3.9 Layout..................................................................................................................................................... 13
3.10 Control Panel........................................................................................................................................ 13
3.11 LED Display..........................................................................................................................................14
3.12 Scope of Delivery .................................................................................................................................15
4. Transport and Storage .........................................................................................................16
4.1 Transport ................................................................................................................................................16
4.2 Storage...................................................................................................................................................16
5. Installation and Connection ................................................................................................17
5.1 System Overview.................................................................................................................................... 17
5.2 Installation ..............................................................................................................................................19
5.3 Electrical Connection .............................................................................................................................19
5.4 Operation at a Controller........................................................................................................................ 20
5.5 Port Assignments ...................................................................................................................................21
5.5.1 Industrial Ethernet Cable............................................................................................................. 21
5.6 Diagnostics.............................................................................................................................................21
6. Functions Overview .............................................................................................................22
6.1 Menu Structure....................................................................................................................................... 22

3
Image Processing and Smart Cameras
7. Settings.................................................................................................................................24
7.1 Run .........................................................................................................................................................24
7.2 Teach-In.................................................................................................................................................. 24
7.3 Teach+...................................................................................................................................................25
7.4 Display ................................................................................................................................................... 26
7.4.1 Intensity .......................................................................................................................................26
7.4.2 Mode............................................................................................................................................ 27
7.5 Assistant .................................................................................................................................................28
7.6 Projects................................................................................................................................................... 29
7.6.1 Current Project ............................................................................................................................ 29
7.6.2 Loading a Project ........................................................................................................................29
7.6.3 Selecting the Start Project........................................................................................................... 30
7.7 Configuration.......................................................................................................................................... 30
7.8 Interface..................................................................................................................................................30
7.8.1 Serial interface.............................................................................................................................30
7.8.2 Ethernet .......................................................................................................................................31
7.9 Language ...............................................................................................................................................32
7.10 Info........................................................................................................................................................32
7.11 Restart ..................................................................................................................................................33
7.12 Reset.....................................................................................................................................................33
7.13 Password.............................................................................................................................................. 33
7.14 Status Information ................................................................................................................................ 34
8. Software................................................................................................................................34
9. Maintenance Instructions ....................................................................................................34
10. Proper Disposal ...................................................................................................................34
11. Appendix...............................................................................................................................35
11.1 Change Index, Operating Instructions................................................................................................. 35
11.2 EU Declaration of Conformity ..............................................................................................................35

4General
1. General
1.1 Information Concerning these Instructions
• These instructions apply to the product with ID code B50/C50.
• They make it possible to use the product safely and efficiently.
• These instructions are an integral part of the product and must be kept on hand for the entire duration of
its service life.
• Local accident prevention regulations and national work safety regulations must be complied with as well.
• The product is subject to further technical development, and thus the information contained in these oper-
ating instructions may also be subject to change. The current version can be found at
www.wenglor.com in the product’s separate download area.
NOTE!
The operating instructions must be read carefully before using the product and must be kept
on hand for later reference.
1.2 Explanations of Symbols
• Safety precautions and warnings are emphasized by means of symbols and attention-getting words
• Safe use of the product is only possible if these safety precautions and warnings are adhered to
The safety precautions and warnings are laid out in accordance with the following principle:
Attention-Getting Word!
Type and Source of Danger!
Possible consequences in the event that the hazard is disregarded.
• Measures for averting the hazard.
The meanings of the attention-getting words, as well as the scope of the associated hazards, are listed below.
DANGER!
This word indicates a hazard with a high degree of risk which, if not avoided, results in death
or severe injury.
WARNING!
This word indicates a hazard with a medium degree of risk which, if not avoided, may result
in death or severe injury.
CAUTION!
This word indicates a hazard with a low degree of risk which, if not avoided, may result in
minor or moderate injury.
ATTENTION!
This word draws attention to a potentially hazardous situation which, if not avoided, may
result in property damage.
NOTE!
A note draws attention to useful tips and suggestions, as well as information regarding
efficient, error-free use.

5
Image Processing and Smart Cameras
1.3 Limitation of Liability
• The product has been developed in consideration of the current state-of-the-art and applicable standards
and guidelines. Subject to change without notice.
• A valid declaration of conformity can be accessed at www.wenglor.com in the product’s separate down-
load area.
• wenglor sensoric elektronische Geräte GmbH (hereinafter referred to as “wenglor”) excludes all liability in
the event of:
• Non-compliance with the instructions
• Use of the product for purposes other than those intended
• Use by untrained personnel
• Use of unapproved replacement parts
• Unapproved modification of products
• These operating instructions do not include any guarantees from wenglor with regard to the described
procedures or specific product characteristics.
• wenglor assumes no liability for printing errors or other inaccuracies contained in these operating instruc-
tions, unless wenglor was verifiably aware of such errors at the point in time at which the operating instruc-
tions were prepared.
1.4 Copyrights
• The contents of these instructions are protected by copyright law.
• All rights are reserved by wenglor.
• Commercial reproduction or any other commercial use of the provided content and information, in particu-
lar graphics and images, is not permitted without previous written consent from wenglor.

6For Your Safety
2. For Your Safety
2.1 Use for Intended Purpose
The wenglor weQube is an optoelectronic sensor which is used for contactless inspection of specific objects.
The sensor unites a camera unit, illumination, optics with auto-focus and an analysis module in a single hous-
ing. The sensors work with a CMOS color or monochrome image sensor.
Image processing functions including measurement, object counting, checking for the presence of objects,
pixel comparison, shape analysis, pattern matching, optical character reading and reference image compari-
son can be configured by means of a PC or laptop via the integrated Ethernet port. 1D and 2D codes can be
read as well.
These image processing functions can be executed in trigger mode operation, as well as during continuous
monitoring, and objects can be detected regardless of position thanks to tracking. Six convertible I/O switch-
ing outputs are available, which can be used as either inputs or outputs. Beyond this, an external lamp can
also be connected to the weQube, and the integrated illumination can be partially or completely switched off.
This product can be used in the following industry sectors:
• Special machinery manufacturing
• Heavy machinery manufacturing
• Logistics
• Automotive industry
• Food industry
• Packaging industry
• Pharmaceuticals industry
• Clothing industry
• Plastics industry
• Woodworking industry
• Beverages industry
• Consumer goods industry
• Paper industry
• Electronics industry
• Glass industry
• Steel industry
• Printing industry
• Aviation industry
• Construction industry
• Chemicals industry
• Agriculture industry
• Alternative energy
• Raw materials extraction
2.2 Use for Other than the Intended Purpose
• Not a safety component in accordance with 2006/42/EC (Machinery Directive)
• The product is not suitable for use in potentially explosive atmospheres.
• The product may only be used with accessories supplied or approved by wenglor, or combined with
approved products. A list of approved accessories and combination products can be accessed at
www.wenglor.com on the product detail page.
DANGER!
Risk of personal injury or property damage in case of use for other than the intended
purpose!
Use for other than the intended purpose may lead to hazardous situations.
• Observe instructions regarding use for intended purpose.

7
Image Processing and Smart Cameras
2.3 Personnel Qualifications
• Suitable technical training is a prerequisite.
• In-house electronics training is required.
• Trained personnel must have uninterrupted access to the operating instructions.
DANGER!
Risk of personal injury or property damage in case of incorrect initial start-up and
maintenance!
Personal injury and damage to equipment may occur.
• Adequate training and qualification of personnel.
2.4 Modification of Products
DANGER!
Risk of personal injury or property damage if the product is modified!
Personal injury and damage to equipment may occur. Non-observance may result in loss of
the CE marking and the guarantee may be rendered null and void.
• Modification of the product is impermissible.
2.5 General Safety Precautions
NOTE!
• These instructions are an integral part of the product and must be kept on hand for the
entire duration of its service life.
• In the event of possible changes, the respectively current version of the operating instruc-
tions can be accessed at www.wenglor.com in the product’s download area.
• Read the operating instructions carefully before using the product.
• Protect the sensor against contamination and mechanical influences.
2.6 Approvals and protection class
RoHS

8Technical Data
3. Technical Data
3.1 List of Technical Data
Optical Characteristics
Working range ≥20 mm (weQube with auto-focus)
Resolution 736 px × 480 px
Field of vision See “Range of Vision Table”
Image chip See section 3.2 on available sensor types
Type of light See section 3.2 on available sensor types
Refresh rate (monochrome) ≤25 Hz
Refresh rate (color) ≤15 Hz
Service life 100,000 hours
Risk group (EN 62471) Free group
Electrical Characteristics
Supply power * 18 to 30 V DC
Current consumption (operating voltage = 24 V) < 200 mA
Response time (monochrome) < 40 ms
Response time (color) < 66 ms
Temperature range –25…55 °C **
Number of digital I/Os 6
Switching output voltage drop < 2.5 V
Switching output switching current 100 mA
Short-circuit proof Yes
Protected against polarity reversal Yes
Overload-proof Yes
Protection class III
Interfaces Ethernet 10/100 Base TX; Ethernet or Profinet (see section 3.2 on avail-
able sensor types)
Mechanical Characteristics
Configuration interface Ethernet port
Housing material Aluminum
Protection IP67
Connector type M12×1, 12-pin
Ethernet connector type M12×1, 8-pin
Configurable as PNP, NPN or push-pull Yes
Can be switched to NC or NO operation Yes
Illumination output Yes
RS-232 interface Yes ***
General Data
Webserver Yes (all Ethernet and Industrial Ethernet Devices, see section 3.2)
* Supply voltage residual ripple may not exceed 10 % (within the specified voltage range).
** –25 °C: Ambient conditions should not result in condensation; avoid the formation of ice on the front panel!
55 °C: Continuous illumination at max. 1 % or flash mode at 100 % brightness with an exposure time of ≤5 ms: may affect the service life of
the product.
*** Maximum connection length: 30 m

9
Image Processing and Smart Cameras
Range
of vision
Range of vision table (weQube with auto-focus):
Working distance 20 mm 100 mm 200 mm 1000 mm 5000 mm
Range of vision 16×12 mm 64×48 mm 120×90 mm 600×450 mm 3000×2250 mm
Range of vision for C mount variant depends on the utilized lens.
3.2 Sensors with Monochrome Image Chip
Sensor type Light
Connection White Light IR Red Light
weQube Vision
Ethernet B50S002 B50S003 -
B50S005 B50S006 -
Industrial Ethernet B50S101 B50S102 -
B50S104 B50S105 -
Ethernet B50S005 B50S006 -
Industrial Ethernet B50S104 B50S105 -
weQube Decode Ethernet C50C001 C50C002 C50C003
Industrial Ethernet C50C100 C50C101 C50C102
weQube Ethernet B50M002 B50M003 B50M004
Industrial Ethernet B50M101 B50M102 B50M104
weQube OCR
Ethernet B50R001 - -
Industrial Ethernet B50R100 - -
Ethernet - B50R002 -
Industrial Ethernet - B50R101 -

10 Technical Data
3.3 Sensors with monochrome image chip and C-mount
Sensor type Connection Monochrome
weQube Vision
Ethernet B50S012
B50S014
Industrial Ethernet B50S111
B50S113
Ethernet B50S014
Industrial Ethernet B50S113
weQube Decode Ethernet C50C011
Industrial Ethernet C50C110
weQube OCR Ethernet B50R011
Industrial Ethernet B50R110
weQube Ethernet B50M012
Industrial Ethernet B50M111
3.4 Sensors with Color Image Chip and Autofocus
Sensor type Light
Connection White light
weQube Vision
Ethernet B50S001
B50S004
Industrial Ethernet B50S100
B50S103
Ethernet B50S004
Industrial Ethernet B50S103
weQube Ethernet B50M001
Industrial Ethernet B50M100

11
Image Processing and Smart Cameras
3.5 Sensors with color image chip and C-mount
Sensor type Connection Monochrome
weQube Vision
Ethernet B50S011
B50S013
Industrial Ethernet B50S110
B50S112
Ethernet B50S013
Industrial Ethernet B50S112
weQube Ethernet B50M011
Industrial Ethernet B50M110
The following table specifies plug tightening torques and mounting options in order to assure compliant,
error-free operation:
Connection Tightening Torque (Nm)
12-pin M12 0.6
8-pin M12 0.4
3.6 Housing Dimensions

12 Technical Data
3.7 Connection Diagrams
Plug No. 1 Plug No. 2
002
Legend
Wire Colors according to IEC 60757
Platinum measuring resistor
not connected
Test Input
Test Input inverted
Trigger Input
Ground for the Trigger Input
Analog Output
Ground for the Analog Output
Block Discharge
Valve Output
Valve Control Output +
Valve Control Output 0 V
Synchronization
Ground for the Synchronization
Receiver-Line
Emitter-Line
Grounding
Switching Distance Reduction
Ethernet Receive Path
Ethernet Send Path
Interfaces-Bus A(+)/B(–)
Emitted Light disengageable
Magnet activation
Input confirmation
Contactor Monitoring
Black
Brown
Red
Orange
Yellow
Green
Blue
Violet
Grey
White
Pink
Green/Yellow
Supply Voltage +
Supply Voltage 0 V
Supply Voltage (AC Voltage)
Switching Output (NO)
Switching Output (NC)
Contamination/Error Output (NO)
Contamination/Error Output (NC)
Input (analog or digital)
Teach Input
Time Delay (activation)
Shielding
Interface Receive Path
Interface Send Path
Ready
Ground
Clock
Output/Input programmable
Power over Ethernet
Safety Input
Safety Output
Signal Output
Ethernet Gigabit bidirect. data line (A-D)
Encoder 0-pulse 0-0 (TTL)
Encoder A/A (TTL)
Encoder B/B (TTL)
Encoder A
Encoder B
Digital output MIN
Digital output MAX
Digital output OK
Synchronization In
Synchronization OUT
Brightness output
Maintenance
reserved
PT
3.8 Complementary Products
wenglor can provide you with suitable connection technology for your product.
Suitable mounting technology no.
560
Suitable connection technology no.
50
87
S81 S89

13
Image Processing and Smart Cameras
3.9 Layout
1
2
3
44
32
1
1 = image chip
2 = control keys
3 = display
4 = connector plug
3.10 Control Panel
23 20 22
60
X2
60: display
20: enter key
22: up key
23: down key

14 Technical Data
3.11 LED Display
85
84
78
T12
Profinet
LED Function
84 Communication status
78 Module status
85 Link/act LED
Designation Status Function
CS (communication status)
(only available with Profinet
devices)
Off Connection (AR) established with controller
Green Protocol not initialized
Red No connection (AR) to controller
MS (module status)
(only available with Profinet
devices)
Red Error (class: fatal)
Blinking red Detection function, can be switched on via engineer-
ing tool
L/A Green Link available
Blinking green Communication

15
Image Processing and Smart Cameras
Ethernet/IP
LED Function
84 Network status
78 Module status
85 Link/Act-LED
Description Status Function
NS (Network status) Off No IP address
green CIP connection
Blinking green IP configured, no CIP connection
red Duplicate IP address
Blinking red CIP connection Timeout
MS (Module status) Off -
green Device works
Blinking green Standby
red Fatal error
Blinking red Device error
L/A Off No Ethernet device connected
green Link available
Blinking green communication
3.12 Scope of Delivery
• B50 / C50
• Quickstart
• Initial start-up instructions

16 Transport and Storage
4. Transport and Storage
4.1 Transport
Upon receipt of shipment, the goods must be inspected for damage in transit. In the case of damage, con-
ditionally accept the package and notify the manufacturer of the damage. Then return the device, making
reference to damage in transit.
4.2 Storage
The following points must be taken into condition with regard to storage:
• Do not store the product outdoors.
• Store the product in a dry, dust-free place.
• Protect the product against mechanical impacts.
• Protect the product against exposure to direct sunlight.
ATTENTION!
Risk of property damage in case of improper storage!
The product may be damaged.
• Storage instructions must be complied with.

17
Image Processing and Smart Cameras
5. Installation and Connection
5.1 System Overview
Connector Cables
M12, 12-pin to open end
ZDCL001 (straight) 2 m
ZDCL002 (straight) 5 m
ZDCL003 (straight) 10 m
ZDCL007 (straight) 30 m
ZDCL004 (angled) 2 m
ZDCL005 (angled) 5 m
ZDCL006 (angled) 10 m
Connection Cable
M12, 8-pin to RJ45
ZC1V001 (straight) 2 m
ZAV50R502 (straight) 5 m
ZC1V002 (straight) 10 m
ZC1V013 (straight) 30 m
ZC1V009 (angled) 2 m
ZC1V010 (angled) 5 m
ZC1V011 (angled) 10 m
ZC1V003 (straight)* 5 m
ZC1V014 (straight)* 10 m
ZC1V015 (angled)* 10 m
Mounting system
ZMBID1202 Mounting
system
ZMWZF0001
Angle bracket
for mounting ring
light and camera
Alternative Micro SD Card
ZNNG013
Replacement Disc weQube
ZNNG012
Polarization Filter, Circular
ZNNG004
Legend
Necessary
accessories
Optional
accessories
Drag Chain Suitable
*
Protection Housing
ZNNS001
ZNNS002
Connection Cable
M12, 12-pin to M12, 12-pin
ZDCV001 2 m
ZDCV002 5 m
ZDCV003 10 m
M12, 4-pin to M12, 4-pin
BW2SG2V1-2M 2 m
BG2SG2V1-2M 2 m
BG2SG2V3-2M 2 m
BG2SG2V3-06M 0,6 m
Connecting Module
M12, 12-pin to
trigger/illumination
ZDCG001
Interface Cable
M12, 12-pin to RS-232
ZDCG002
Mounting bracket for
protective housing
ZNNX001
Connection line
for illumination
M12, 5-pin to open end
ZDDL001 2 m
ZDDL002 5 m
ZDDL003 10 m
Connection module for
ring lights and back-
lights in the flash mode
5-pin M12 to camera connection
module and to 5-pin M12
ZC4G001
Illuminations
Further information
is available > here
Connection Cable

18 Installation and Connection
Connector Cables
M12, 12-pin to open end
ZDCL001 (straight) 2 m
ZDCL002 (straight) 5 m
ZDCL003 (straight) 10 m
ZDCL007 (straight) 30 m
ZDCL004 (angled) 2 m
ZDCL005 (angled) 5 m
ZDCL006 (angled) 10 m
Connection Cable
M12, 8-pin to RJ45
ZC1V001 (straight) 2 m
ZAV50R502 (straight) 5 m
ZC1V002 (straight) 10 m
ZC1V013 (straight) 30 m
ZC1V009 (angled) 2 m
ZC1V010 (angled) 5 m
ZC1V011 (angled) 10 m
ZC1V003 (straight)* 5 m
ZC1V014 (straight)* 10 m
ZC1V015 (angled)* 10 m
Connection Cable
M12, 12-pin to M12, 12-pin
ZDCV001 2 m
ZDCV002 5 m
ZDCV003 10 m
M12, 4-pin to M12, 4-pin
BW2SG2V1-2M 2 m
BG2SG2V1-2M 2 m
BG2SG2V3-2M 2 m
BG2SG2V3-06M 0,6 m
Connecting Module
M12, 12-pin
to trigger / illumination
ZDCG001
Interface Cable
M12, 12-pin to RS-232
ZDCG002
Legend
Necessary
accessories
Optional
accessories
Drag Chain Suitable
*
Lens
LAC9-14-K01 9 mm
LAC16-14-K01 16 mm
LAC25-14-K02 25 mm
LAC35-16-K02 35 mm
LAC50-23-K01 50 mm
LAC75-28-K01 75 mm
Illuminations
Further information
is available > here
Alternative Micro SD Card
ZNNG013
Protection Housing
ZSZ-02-01
ZSZ-03-01
Mounting System
ZB6Z01 Mounting
System
ZMWZF0001
Angle bracket
for mounting
ring light and
camera
Threaded pins
for lenses
Z0070
Connection module for
ring lights and back-
lights in the flash mode
5-pin M12 to camera connection
module and to 5-pin M12
ZC4G001
Connection line
for illumination
M12, 5-pin to open end
ZDDL001 2 m
ZDDL002 5 m
ZDDL003 10 m
Connection Cable
Connector Cables

19
Image Processing and Smart Cameras
5.2 Installation
• Protect the product from contamination during installation.
• Observe all applicable electrical and mechanical regulations, standards, and safety rules.
• Protect the product against mechanical influences.
• Make sure that the sensor is mounted in a mechanically secure fashion.
• Specified torque values must be complied with (see section “3. Technical Data”, page 8).
ATTENTION!
Risk of property damage in case of improper installation!
The product may be damaged.
• Installation instructions must be complied with.
CAUTION!
Risk of personal injury or property damage during installation!
Personal injury and damage to the product may occur.
• A safe installation environment must be assured.
5.3 Electrical Connection
Connect the sensor to 18 to 30 V DC (see “3.7 Connection Diagrams” on page 12).
DANGER!
Risk of personal injury or property damage due to electric current!
Voltage conducting parts may cause personal injury or damage to equipment.
• The electric device may only be connected by appropriately qualified personnel.

20 Installation and Connection
5.4 Operation at a Controller
If you want to place the device into service at a controller, please complete the following steps:
• Connect the weQube to supply power and then to the controller via one of the Ethernet ports. Suitable
connector technology can be found on wenglor’s website.
• Install the respective device-specific electronic description file (or the GSDML file in the case of PROFINET)
to the controller’s hardware manager. The required file can be downloaded from: www.wenglor.com 
Product World Product search (enter the product number) Download Device Description
File.
• Proceed as follows (using the Step 7 Engineering Tool of a Siemens Simatic-S7 controller as an example):
– Add the device to the PROFINET line.
– Then access the device’s object attributes.
– Assign any desired name to the device.
– Assign an Ethernet address to the device.
– Allocate the product by means of its device name / IP address (detection via MAC address).
– Transfer the configuration to the controller.
NOTE!
A detailed description for various controllers and for installing the files, as well as for project
engineering of the network, can be found in the help files of the respective controller. Based
on the example of a Siemens Simatic-S7 controller and the appropriate Step 7 Engineer-
ing Tool (software), wenglor provides brief instructions for starting up a PROFINET device
(www.wenglor.com Product World Product search (enter the product number) 
Download General Instructions).
