Wenglor SEFB Series User manual

EN
SEFBxxx
Multi-Beam Safety Light Array
Operating Instructions Translation of the Original Operating Instruction
Subject to technical changes
Available as PDF file only
Revision level: 06/09/2021
Doc. No.: 1038510
Version: 1.1.0
www.wenglor.com

2Table of Contents
Table of Contents
1. General 8
1.1 Information Concerning these Instructions 8
1.2 Target Group 8
1.3 Explanations of Symbols 8
1.4 Limitation of Liability 9
1.5 Copyrights 9
2. For Your Safety 10
2.1 Use for Intended Purpose 10
2.2 Use for Other than the Intended Purpose 11
2.3 Personnel Qualifications 11
2.4 Modification of Products 11
2.5 Important Safety Precautions 12
2.5.1 Important Safety Precautions for Machine Manufacturers 12
2.5.2 Important Safety Precautions for Machine Operators 12
2.6 General Safety Precautions 12
2.7 Approvals and IP Protection 13
3. Product Description 13
4. Technical Data 15
4.1 General Technical Data 15
4.2 Response Times 17
4.3 Weight Tables 17
4.4 Housing Dimensions Safety Light Array 18
4.4.1 SEFB Muting 18
4.4.2 SEFB 19
4.5 Housing Dimensions, Mounting Technology 21
4.6 Control Panel 23
4.6.1 Control Panel Emitter 23
4.6.2 Control Panel Receiver SEFB Muting 23
4.6.3 Control Panel Receiver SEFB 24
4.7 Scope of Delivery 24
4.8 System Overview 25
4.9 Accessory Products 26
4.9.1 Mounting Elements 26
4.9.2 Connection Lines 26
4.9.3 Connection Cables 27
4.9.4 Safety Relays 28

Multi-Beam Safety Light Array 3
4.9.5 Path-Folding Mirrors 28
4.9.6 Safety Columns 30
4.9.7 IO-Link Master 31
4.9.8 T-Plug ZC7G001 (IO-Link Signal) 31
4.9.9 Muting Boom 32
4.9.10 Muting Connection Box ZFBB001 34
4.9.11 Laser Alignment Tool Z98G001 35
4.9.12 LED Light Strips Z99G001 35
4.9.13 microSD Card 35
4.9.14 Parametrization Software wTeach2 35
5. Project Engineering 36
5.1 Engineering 36
5.1.1 Safety Field 36
5.1.2 Securing the Danger Zone 37
5.1.3 Safety Clearance 38
5.1.3.1 General Information 38
5.1.3.2 Calculating the Safety Clearance 38
5.1.4 Minimum Clearance to Reflective Surfaces 42
5.2 Functions 44
5.2.1 Functions Overview 44
5.2.2 Combinable Functions 45
5.2.3 Operational Functions 46
5.2.3.1 Safety Operating Mode (Automatic Restart) 46
5.2.3.2 Start-Up Disabling and Restart Inhibit (RES) 46
5.2.3.3 Contactor Monitoring (EDM) 47
5.2.3.4 Beam Coding 47
5.2.3.5 Range 48
5.2.3.6 Cascading 49
5.2.3.6.1 Cascading via Extension Connection of the ESPE 50
5.2.3.6.2 Cascading via Muting Connection Box ZFBB001 50
5.2.3.6.3 Cascading of Other Safety Sensors with OSSD Outputs 51
5.2.3.6.4 Cascading of Contact-based Safety Components 51
5.2.4 Muting 52
5.2.4.1 Muting Signals 54
5.2.4.2 Muting Visualization 55
5.2.4.3 Cross Muting 55
5.2.4.4 Two Sensor Linear Muting 58
5.2.4.5 Four Sensor Linear Muting with Sequence Monitoring 60

4
5.2.4.6 Four Sensor Linear Muting with Time Monitoring 63
5.2.4.7 Muting Functions 66
5.2.4.7.1 Combinable Muting Functions 66
5.2.4.7.2 Muting Duration 66
5.2.4.7.3 Belt Stop Signal 67
5.2.4.7.4 Muting Enable 68
5.2.4.7.5 Direction Setting (Only for four sensor Muting) 69
5.2.4.7.6 Muting End Through Clearing of the ESPE 69
5.2.4.7.7 Partial Muting 70
5.2.4.7.8 Full Muting Enable 71
5.2.4.7.9 Gap Suppression 72
5.2.4.7.10 Override 72
5.2.5 Non-Safety-Related Functions 74
5.2.5.1 Measuring Function 74
5.2.5.2 Display Settings 76
5.2.5.3 Signal Output 76
5.2.5.4 Integrated Indicator Lamp 77
5.2.5.5 Signal Strength Display 77
5.2.5.6 Memory Function 78
5.2.5.6.1 Access to the Memory Card 79
5.2.5.6.2 Suitable Memory Cards 79
5.2.5.6.3 File System 79
5.2.5.7 Password Protection 80
5.2.5.8 IO-Link Interface (C/Q) 81
6. Transport and Storage 82
6.1 Transport 82
6.2 Storage 82
7. Installation 83
7.1 Positioning the ESPE 84
7.2 Installation with Mounting Bracket 86
7.2.1 Installation with Mounting Bracket ZEFX001 86
7.2.2 Installation with Mounting Bracket ZEFX002 87
7.2.3 Installation with Mounting Bracket ZEFX003 87
7.2.4 Installation with Mounting Bracket ZEMX001 88
7.2.5 Warning Strips 88
8. Electrical Connection 89
Table of Contents

Multi-Beam Safety Light Array 5
9. Parameters Configuration 92
9.1 General 92
9.2 Preparation of the Parametrization 92
9.3 Parametrization of the Emitter 92
9.3.1 Default Settings 93
9.3.2 Calling up the Menu (User Level “Admin”) 93
9.3.3 Menu Structure 94
9.3.4 Parametrization of the Range and Coding 94
9.4 Parametrization of the receiver with basic function (without display) 95
9.4.1 Default Settings 95
9.4.2 Calling up the Menu (User Level “Admin”) 95
9.4.3 Menu Structure 96
9.4.4 Parametrization of the Restart Inhibit, Contactor Monitoring and Coding 97
9.5 Parametrization of the receiver with muting (with display) 98
9.5.1 Default Settings 98
9.5.2 Parametrization of the Restart Inhibit (RES) 101
9.5.3 Parametrization of the Contactor Monitoring (EDM) 101
9.5.4 Parametrization of the Beam Coding (CODE) 102
9.5.5 Parametrization Cascading (CASC) 103
9.5.6 Parametrization Muting (MUTG) 104
9.5.6.1 Parametrization Cross Muting (X) 105
9.5.6.2 Parametrization Two Sensor Linear Muting (2L) 108
9.5.6.3 Parametrization Four Sensor Linear Muting with Sequence (LSEQ) or Time Monitoring
(LTME) 111
9.5.7 Setting the Display (DISP) 114
9.5.8 Expert Menu (EXPT) 115
9.5.9 Saving the Configuration and Restart (RUN) 120
9.6 Parametrization via the IO-Link Interface 121
9.6.1 Requirements and Framework Conditions 121
9.6.2 Process Data 123
9.6.3 Parameter Data 124
9.6.4 Example for Setting the Parameter Data 125
9.6.5 Data Storage 126
10. Initial Start-Up 127
10.1 Overview 127
10.2 Switching On 127
10.3 Aligning the Emitter and Receiver 128
10.4 Check for initial start-up 130

6
11. Operation 131
11.1 Operating Display 131
11.1.1 Operating Displays Emitter 131
11.1.2 Control Panel Receiver SEFB 132
11.1.3 Operating Displays Receiver SEFB Muting 133
11.2 Calling Up the Current Parametrization (“Worker” User Level) 135
12. Servicing 139
12.1 Maintenance 139
12.2 Cleaning 139
12.3 Regular Inspections 140
12.4 Annual Inspection 140
13. Diagnosis 141
13.1 Performance in Case of Fault 141
13.2 Error Indicators 141
13.2.1 Error Indicator on the Emitter 141
13.2.2 Error Indicator on the Receiver SEFB 142
13.2.3 Error Indicator on the Receiver SEFB Muting 142
13.3 Diagnosis Codes on the Receiver SEFB Muting 143
13.3.1 Codes for Information and Warnings 143
13.3.2 Codes for General Errors 143
13.3.3 Codes for Muting Errors 146
13.3.4 Codes when Accessing the Memory Card 147
14. Decommissioning 147
15. Proper Disposal 147
16. Appendix 148
16.1 Checklists 148
16.1.1 Checklist Initial Start-up 148
16.1.2 Checklist Annual Inspection 149
16.1.3 Regular inspection checklist 150
16.2 Connection Examples 151
16.2.1 Connection Example Start-Up Disabling and Restart Inhibit 151
16.2.2 Connection Examples Muting 152
16.2.3 Connection Examples Cascading 156
Table of Contents

Multi-Beam Safety Light Array 7
16.3 Order Notes 158
16.4 EU Declaration of Conformity 158
16.5 Index of Changes 158
16.6 Index of Abbreviations 159
16.7 Index of Figures 161

General
8
1. General
1.1 Information Concerning these Instructions
• These instructions apply to the following multi-beam Safety Light Arrays:
– SEFB
– SEFB muting
– For the exact order designation, see “16.3 Order Notes” on page 158
• They make it possible to use the product safely and efficiently.
• These instructions are an integral part of the product and must be kept on hand for the entire duration of its
service life.
• Local accident prevention regulations and national occupational health and safety directives must be ob-
served.
• The product is subject to further technical development, and thus the information contained in these operat-
ing instructions may also be subject to change.
The current version can be found at www.wenglor.com in the product’s separate download area.
NOTE!
The operating instructions must be read carefully before using the product and must be kept
on hand for later reference.
1.2 Target Group
• These operating instructions are aimed at developers, planners, installers, owners and machine operators
who want to safeguard their systems with safety technology from wenglor sensoric GmbH (referred to in the
following as “wenglor”).
• The instructions are also aimed at qualified specialist personnel, who are commissioning the SEFB multi-
beam Safety Light Array for the first time, maintaining it or integrating it in a machine with accessories and
additional products where applicable.
1.3 Explanations of Symbols
• Safety precautions and warnings are emphasized by means of symbols and attention-getting words.
• Safe use of the product is only possible if these safety precautions and warnings are adhered to.
The safety precautions and warnings are laid out in accordance with the following principle:
ATTENTION-GETTING WORD!
Type and source of danger!
Possible consequences in the event that the hazard is disregarded.
• Measures for averting the hazard.

Multi-Beam Safety Light Array 9
The meanings of the attention-getting words, as well as the scope of the associated hazards, are listed
below:
DANGER!
This word indicates a hazard with a high degree of risk which, if
not avoided, results in death or severe injury.
WARNING!
This word indicates a hazard with a medium degree of risk which, if not avoided,
may result in death or severe injury.
CAUTION!
This word indicates a hazard with a low degree of risk which, if
not avoided, may result in minor or moderate injury.
ATTENTION!
This word draws attention to a potentially hazardous situation which, if not avoided, may
result in property damage.
NOTE!
A note draws attention to useful tips and suggestions, as well as information regarding
efficient, error-free use.
1.4 Limitation of Liability
• The product has been developed in consideration of the current state-of-the-art, as well as applicable stan-
dards and guidelines. Subject to change without notice.
• A valid declaration of conformity can be found at www.wenglor.com in the product’s separate download
area.
• wenglor excludes all liability in the event of:
– Non-compliance with the instructions,
– Installation errors,
– Use of the product for purposes other than those intended,
– Use by untrained personnel,
– Use of unapproved spare parts and accessories,
– Unapproved modification of products.
These operating instructions do not imply any guarantee from wenglor with regard to the described proce-
dures or specific product characteristics.
wenglor assumes no liability for printing errors or other inaccuracies contained in these operating instruc-
tions, unless wenglor was verifiably aware of such errors at the point in time at which the operating instruc-
tions were prepared.
1.5 Copyrights
• The contents of these instructions are protected by copyright law.
• All rights are reserved by wenglor.
• Commercial reproduction or any other commercial use of the provided content and information, in particu-
lar graphics and images, is not permitted without previous written consent from wenglor.

For Your Safety
10
2. For Your Safety
2.1 Use for Intended Purpose
The product is based on the following functional principle:
Safety light arrays
The light array monitors the safety field between the transmitter and the receiver. If the safety field is penetrat-
ed by an object, a switching command is triggered. This switching command may prevent initialization of a
hazardous machine motion, or may stop an action which has already been started.
As part of an overall system, the task of this product is to carry out safety-related functions. The correct over-
all function must be ensured by the system or machine manufacturer, however.
Use of this ESPE is only permissible if:
• The hazardous motion can be stopped electrically by the safety outputs of the ESPE.
• The safety clearance between the ESPE and a hazardous machine motion is complied with at all times.
• Additional mechanical safety equipment is installed so that the safety field must be passed through to
access hazardous machine parts.
• Care is taken during installation to ensure that the personnel always remain inside the monitored zone for
machine operation.
• Regular safety inspections are carried out.
• Adequate detection of possible obstructions is assured with the existing number of beams.
• The use of a light array, type 4 / Performance Level PL e / SIL 3 / SIL CL 3, was deemed permissible follow-
ing an extensive risk analysis.
This product can be used in the following industry sectors:
• Special machinery manufacturing
• Pharmaceuticals industry
• Electronics industry
• Chemicals industry
• Heavy machinery manufacturing
• Clothing industry
• Glass industry
• Agriculture industry
• Logistics
• Plastics industry
• Steel industry
• Alternative energy
• Automotive industry
• Woodworking industry
• Printing industry
• Raw materials extraction
• Food industry
• Consumer goods industry
• Aviation industry
• Paper industry
• Packaging industry
• Construction industry
• Other

Multi-Beam Safety Light Array 11
2.2 Use for Other than the Intended Purpose
• The product is not suitable for use in potentially explosive atmospheres.
• The product may only be used with accessories supplied or approved by wenglor, or in combination with
products approved by wenglor. A list of approved accessories and combination products can be accessed
at www.wenglor.com on the product detail page.
• The product is not suitable for use in outdoor weather.
DANGER!
Risk of personal injury or property damage in case of use for other than the intended
purpose!
Use for other than the intended purpose may lead to hazardous situations.
• Observe instructions regarding use for intended purpose.
2.3 Personnel Qualifications
• Suitable technical training is a prerequisite.
• In-house electronics training is essential.
• Trained personnel who use the product must have uninterrupted access to the operating instructions.
DANGER!
Risk of personal injury or property damage in case of incorrect initial start-up, opera-
tion and maintenance!
Personal injury and damage to equipment may occur.
• Adequate training and qualification of personnel.
2.4 Modification of Products
DANGER!
Risk of personal injury or property damage if the product is modified!
Personal injury and damage to equipment may occur. Non-observance may result in loss of
the CE mark and the guarantee may be rendered null and void.
• Modification of the product is impermissible.

For Your Safety
12
2.5 Important Safety Precautions
2.5.1 Important Safety Precautions for Machine Manufacturers
DANGER!
Risk of safety device failure
If this warning is not observed, body parts and people to be protected may not be
detected.
• The national directives and safety regulations resulting from this application (e.g. accident
prevention) must be observed.
• A risk assessment must be carried out.
• Depending on the application, a check must be carried out to determine whether addition-
al protective measures are required.
• The safety light array and associated components must not be tampered with or modified.
• Light curtains must not influence each other. Different beam codings can be used where
required (see “7.1 Positioning the ESPE” on page 84).
• No repair work may be carried out on the device and its components. An incorrect repair
could render the protection function ineffective.
2.5.2 Important Safety Precautions for Machine Operators
DANGER!
Risk of safety device failure
If this warning is not observed, body parts and people to be protected may not be
detected.
• If changes are made to the electrical integration in the machine control or the mechanical
installation of the safety light array, a new risk assessment must be carried out.
• The safety light array and associated components must not be tampered with or modified.
• No repair work may be carried out on the device and its components. An incorrect repair
could render the protection function ineffective.
2.6 General Safety Precautions
NOTE!
• These instructions are an integral part of the product and must be kept on hand for the
entire duration of its service life.
• In the event of possible changes, the respectively current version of the operating instruc-
tions can be accessed at www.wenglor.com in the product’s separate download area.
• Read the operating instructions carefully before using the product.
• The sensor must be protected against contamination and mechanical influences.
• Additional measures may be necessary in order to assure that the ESPE does not fail in a
dangerous fashion due to other types of light which are used in a special application (e.g.
emission due to welding sparks or the effects of stroboscope lights) (EN 61496-2, Para.
7ff).

Multi-Beam Safety Light Array 13
2.7 Approvals and IP Protection
RoHS
3. Product Description
The SEFB safety light array is a piece of electro-sensitive protective equipment (ESPE) used to safeguard
danger points, danger zones and accesses to machines.
The ESPE monitors the safety field between the emitter and the receiver.
When an object penetrates the safety field and one or multiple beams are interrupted, a switch command is
triggered on both safety outputs. Together with the downstream evaluation, this prevents a hazardous motion
from being initiated or interrupts an action that has already been initiated.
The ESPE consists of the following components:
Emitter Emitter
Receiver
SEFB Muting
Receiver
SEFB
Indicator lamp*
Safety Field
Control Panel
Plug connector
* Indicator lamp with SEFB muting receivers only
Figure 1: Product structure

Product Description
14
This product has the following properties:
• ESPE type 4, per EN 61496-1
• PL e per EN ISO 13849-1 and SIL 3 per EN 62061
• Body protection: 2-, 3-, or 4-beam
• 0.5 m to 50 m range
• Visible red light
• Muting function (with SEFB muting)
– Cross muting
– Two sensor linear muting
– Four sensor linear muting (with sequence/time monitoring)
– Different, adjustable muting functions
• Restart inhibit and safety operating mode (automatic restart)
• Contactor monitoring (monitoring of external switching elements)
• Cascading (with SEFB muting)
• Integrated indicator lamp (with SEFB muting)
• Alphanumeric display (16-segment, 4-digit) (with SEFB muting)
• Memory card (microSD) (with SEFB muting)
• IO-Link 1.1 interface (not safety-related)
NOTE!
The performance characteristics differ depending on the device type, see “5.2.1 Functions
Overview” on page 44.

Multi-Beam Safety Light Array 15
4. Technical Data
4.1 General Technical Data
For US and Canada: Device to be supplied by a certified Class 2 power supply that complies with the require-
ments according NEC and CEC.
Order no. SEFB muting Order no. SEFB
Emitter
SEFB512
SEFB513
SEFB514
SEFB512
SEFB513
SEFB514
Receiver
SEFB612
SEFB613
SEFB614
SEFB622
SEFB623
SEFB624
Set
SEFB412
SEFB413
SEFB414
SEFB422
SEFB423
SEFB424
Optical data
Number of beams
SEFB412/SEFB422: 2
SEFB413/SEFB423: 3
SEFB414/SEFB424: 4
Beam distance
SEFB412/SEFB422: 500 mm
SEFB413/SEFB423: 400 mm
SEFB414/SEFB424: 300 mm
Range 0.5 m…50 m
Aperture angle ± 2.5°
Wavelength emitter typ. 630 nm
Coated optics: Yes
Ambient light immunity
(for continuous light) 10,000 Lux
Electrical data
Response time See section 4.2, page 17
Processing time muting signals 95 ms
Supply voltage
19.2…28.8 V DC (24 V DC +/–20 %)
(SELV-, PELV power supply unit), it must be possible to bridge pow-
er failures of 20 ms (EN 60204-1)
Safeguarding the supply voltage,
inputs max. 2 A
Current consumption
(Ub = 24 V) receiver ≤350 mA (without load)
Current consumption
(Ub = 24 V) emitter ≤100 mA
Internal fuse 2 A
Temperature range* –30…55 °C
Storage temperature −30...70 °C
Relative humidity ≤95 %, non-condensing
Vibration resistance 5 g (10 to 55 Hz)
Shock resistance 10 g / 16 ms
Short-circuit proof Yes
Reverse polarity protected and
overload-proof Yes

Technical Data
16
Order no. SEFB muting Order no. SEFB
Protection class III
Max. cable length**
< 35 m/0.25 mm²
< 50 m/0.34 mm²
< 72 m/0.50 mm²
Safety outputs OSSD
Safety outputs OSSD PNP semiconductor
Number of safety outputs 2
Switching current safety output ≤300 mA
Leakage current safety output ≤2 mA
Voltage drop at safety output ≤2.3 V
Max. voltage in off state < 2 V
Max. capacitive load ≤1 μF
Max. inductive load ≤2.2 mH
Test pulse width, rate <300 μs; typ. 20 ms
Restart time after intervention typ. 2×response time
Signal output
Signal output IO-Link interface (C/Q)
Number of signal outputs 1
Switching current signal output ≤100 mA
Voltage drop signal output <3 V
Inputs
Voltage range –30...30 V DC SELV / PELV
Switching thresholds Low: < 5 V; < 2 mA High: > 11 V; 6…30 mA
Mechanical data
Housing material Aluminum
Degree of protection IP65, IP67
Connection type emitter M12 plug, 5-pin
Connection type receiver M12 plug, 8-pin (system connection)
M12 socket, 8-pin (extension connection)
M12 plug, 8-pin
(system connection)
Technical safety data
ESPE type (EN 61496) 4
Performance level
(EN ISO 13849-1:2015) Cat. 4 PL e
Safety integrity level (EN 62061) SIL 3, SIL cl 3
PFHd* ≤1.8 * 10-8
MTTFd > 100a
Mission time TM
(EN ISO 13849-1:2015) 20 years
* The values apply for operating altitudes of up to 2,000 m above sea level.
For operating altitudes between 2,000 m and 4,000 m, the following values in the table below apply:
Operating altitude above sea level Max. ambient temperature during operation PFHd value
> 2.000 m … ≤3.000 m +50° C ≤2,1× 10-08
> 3.000 m … ≤4.000 m +45° C ≤2,1× 10-08
NOTE!
Use at altitudes above 4,000 m is not permitted.
** The max. cable length must also be complied with for receivers in a cascade.

Multi-Beam Safety Light Array 17
SEFB muting SEFB
Functions
Body protection Yes
Safety operating mode Yes
Restart inhibit Yes
Contactor monitoring Yes
Muting Yes No
Cascading Yes No
The following table specifies the tightening torques of the plugs and mounting options in order to assure
compliant, error-free operation:
Connection type Tightening torque (Nm)
M12 0.4
4.2 Response Times
SEFB muting SEFB Beam distance
[mm]
Number of beams Response time
[ms]
SEFB412 SEFB422 500 2 15.0
SEFB413 SEFB423 400 3 15.0
SEFB414 SEFB424 300 4 15.0
4.3 Weight Tables
SEFB muting SEFB Beam distance
[mm]
Number of beams Max. weight per
component [kg]
SEFB412 SEFB422 500 2 1.22
SEFB413 SEFB423 400 3 1.79
SEFB414 SEFB424 300 4 2.00

Technical Data
18
4.4 Housing Dimensions Safety Light Array
4.4.1 SEFB Muting
Drawing 1: SEFB412 (2 beams, 500 mm)
Drawing 2: SEFB413 (3 beams, 400 mm)
1 = Emitter
2 = Receiver

Multi-Beam Safety Light Array 19
Drawing 3: SEFB414 (4 beams, 300 mm)
Overall housing dimensions: 1=Emitter, 2=Receiver
4.4.2 SEFB
Drawing 4: SEFB422 (2 beams, 500 mm)
1 = Emitter
2 = Receiver

Technical Data
20
Drawing 5: SEFB423 (3 beams, 400 mm)
Drawing 6: SEFB424 (4 beams, 300 mm)
1 = Emitter
2 = Receiver
