Weq CFW100 User manual

Motors I Automation I Energy I Transmission & Distribution I Coatings
Frequency Inverter
Convertidor de Frecuencia
Inversor de Frequência
CFW100
User's Manual
Manual del Usuario
Manual do Usuário

User's Manual
Manual del Usuario
Manual do Usuário
Series/Série: CFW100
English / Español / Português
Document/Documento: 10001432497 / 03
Models/Modelos: Frame A, B and C
Tam A, B y C
Mec A, B e C
Date/Fecha/Data: 03/2014

2 | CFW100
Summary of Revisions
English
The information below describes the revisions made to this manual.
Revision Description Chapter
00 First edition. -
01 Modification in Table B1 on page 121 and addition of installation
recommendations. -
ATTENTION!
Check the frequency of the power supply.
In case the power supply frequency is different from the factory setting (check
P403), it is necessary to set:
P204 = 5 for 60 Hz.
P204 = 6 for 50 Hz.
It is only necessary to set these parameters once.
Refer to the programming manual of the CFW100 for further details about the
programming of parameter P204.

CFW100 | 3
Contents
English
1 SAFETY INSTRUCTIONS.................................................................................................... 5
1.1 SAFETY WARNINGS IN THE MANUAL ....................................................................... 5
1.2 SAFETY WARNINGS IN THE PRODUCT..................................................................... 6
1.3 PRELIMINARY RECOMMENDATIONS ....................................................................... 6
2 GENERAL INFORMATION.................................................................................................. 8
2.1 ABOUT THE MANUAL .................................................................................................. 8
2.2 ABOUT THE CFW100 .................................................................................................... 8
2.3 TERMINOLOGY ............................................................................................................ 11
2.4 IDENTIFICATION LABEL ............................................................................................ 11
2.5 RECEIVING AND STORAGE........................................................................................ 12
3 INSTALLATION AND CONNECTION ................................................................................ 13
3.1 MECHANICAL INSTALLATION ................................................................................... 13
3.1.1 Environmental Conditions ................................................................................. 13
3.1.2 Positioning and Mounting ................................................................................. 13
3.1.2.1 Cabinet Mounting................................................................................... 14
3.1.2.2 Surface Mounting ................................................................................. 14
3.1.2.3 DIN-Rail Mounting ................................................................................. 14
3.2 ELECTRICAL INSTALLATION..................................................................................... 15
3.2.1 Identification of the Power Terminals and Grounding Points ..................... 15
3.2.2 Circuit Breakers, Fuses, Grounding and Power ........................................... 16
3.2.3 Power Connections............................................................................................ 17
3.2.3.1 Input Connections ................................................................................. 18
3.2.3.2 Power Supply Reactance .................................................................... 19
3.2.3.3 Output Connections.............................................................................. 19
3.2.4 Grounding Connections.................................................................................... 20
3.2.5 Control Connections.......................................................................................... 21
3.2.6 Cable Separation Distance............................................................................... 23
4 KEYPAD (HMI) AND BASIC PROGRAMMING................................................................. 24
4.1 USE OF THE KEYPAD TO OPERATE THE INVERTER.............................................. 24
4.2 INDICATIONS ON THE HMI DISPLAY........................................................................ 24
4.3 OPERATING MODES OF THE HMI ............................................................................. 25
5 FIRST TIME POWER-UP AND START-UP ....................................................................... 27
5.1 START-UP PREPARATION .......................................................................................... 27
5.2 START-UP ..................................................................................................................... 28

4 | CFW100
Contents
English
5.2.1 Basic Application................................................................................................ 29
5.2.2 V/f Type of Control (P202 = 0) ........................................................................... 30
5.2.3 Control Type VVW (P202 = 5)............................................................................ 31
6 TROUBLESHOOTING AND MAINTENANCE................................................................... 33
6.1 FAULTS AND ALARMS................................................................................................. 33
6.2 SOLUTION FOR THE MOST FREQUENT PROBLEMS............................................. 33
6.3 INFORMATION NECESSARY FOR CONTACTING TECHNICAL SUPPORT.......... 34
6.4 PREVENTIVE MAINTENANCE .................................................................................... 34
6.5 CLEANING INSTRUCTIONS ....................................................................................... 36
7 ACCESSORIES.................................................................................................................... 38
8 TECHNICAL SPECIFICATIONS......................................................................................... 39
8.1 POWER DATA ................................................................................................................ 39
8.2 ELECTRONICS/GENERAL DATA................................................................................ 40
8.2.1 Considered Standards....................................................................................... 41
APPENDIX A - FIGURES...................................................................................................... 118
APPENDIX B – TECHNICAL SPECIFICATIONS................................................................. 120

CFW100 | 5
Safety Instructions
English
1 SAFETY INSTRUCTIONS
This manual provides information for the proper installation and operation of the CFW100
frequency inverter.
It has been written to be used by qualified personnel with suitable training or technical qualification
for operating this type of equipment. The personnel shall follow all the safety instructions described
in this manual and/or defined by the local regulations. Failure to comply with the safety instructions
may result in death, serious injury, and equipment damage.
1.1 SAFETY WARNINGS IN THE MANUAL
The following safety notices are used in the manual:
DANGER!
The procedures recommended in this warning have the purpose of protecting the
user against death, serious injuries and considerable material damage.
DANGER!
Les procédures concernées par cet avertissement sont destinées à protéger
l'utilisateur contre des dangers mortels, des blessures et des détériorations
matérielles importantes.
ATTENTION!
The procedures recommended in this warning have the purpose of avoiding
material damage.
NOTE!
The information mentioned in this warning is important for the proper understanding
and good operation of the product.

6 | CFW100
Safety Instructions
English
1.2 SAFETY WARNINGS IN THE PRODUCT
The following symbols are attached to the product, serving as safety notices:
High voltages are present.
Components sensitive to electrostatic discharge.
Do not touch them.
Mandatory connection to the protective ground (PE).
Connection of the shield to the ground.
1.3 PRELIMINARY RECOMMENDATIONS
DANGER!
Always disconnect the main power supply before touching any electrical
component associated to the inverter. Several components can remain charged
with high voltages or remain in movement (fans) even after the AC power is
disconnected or switched off.
Wait at least ten minutes after turning off the input power for the complete discharge
of the power capacitors.
Always connect the grounding point of the inverter to the protection earth (PE).

CFW100 | 7
Safety Instructions
English
DANGER!
Débranchez toujours l'alimentation principale avant d'entrer en contact avec un
appareil électrique associé au variateur. Plusieurs composants peuvent rester
chargés à un potentiel électrique élevé et/ou être en mouvement (ventilateurs),
même après la déconnexion ou la coupure de l'alimentation en courant alternatif.
Attendre au moins 10 minutes après avoir coupé l’alimentation d’entrée pour que
les condensateurs de puissance soient totalement déchargées.
Toujours connecter le point de mise à la terre du variateur sur le conducteur de
terre de protection (PE).
DANGER!
Connectors XCA and XCB do not present USB compatibility; therefore, they cannot
be connected to USB doors.
These connectors serve only as interface between the CFW100 frequency inverter
and its accessories.
DANGER!
Les connecteurs XCA et XCB ne présentent pas de compatibilité USB, ils ne
peuvent donc pas être connectés à des ports USB.
Ces connecteurs servent uniquement d'interface entre le variateur de fréquence
CFW100 et ses accessoires.
NOTES!
Frequency Inverter may interfere with other electronic equipment. In order to
reduce these effects, take the precautions recommended in the chapter 3
INSTALLATION AND CONNECTION on page 14.
Read the user's manual completely before installing or operating the inverter.
Do not perform any withstand voltage test!
If necessary, contact the manufacturer.

8 | CFW100
Safety Instructions
English
ATTENTION!
Electronic boards have components sensitive to electrostatic discharges.
Do not touch directly on components or connectors.
If necessary, first touch the grounding point of the inverter, which must be
connected to the protection earth (PE) or use a proper grounding strap.

CFW100 | 9
General Information
English
2 GENERAL INFORMATION
2.1 ABOUT THE MANUAL
This manual contains information for the proper installation and operation of the inverter,
commissioning, main technical features and how to identify the most usual problems of the
different models of inverters of the CFW100 line.
ATTENTION!
The operation of this equipment requires detailed installation and operation
instructions provided in the user’s manual, programming manual and
communication manuals. The user’s manual is provided in print with the inverter.
The guides are provided in print with their respective accessory. The other manuals
are provided only electronically in the CD-ROM supplied with the inverter or can
be obtained at WEG website - www.weg.net. The CD-ROM must always be kept
with this equipment. A printed copy of the files available in the CD-ROM can be
requested at your local WEG dealer.
NOTE!
It is not the intention of this manual to present all the possibilities for the application
of the CFW100, as well as WEG cannot take any liability for the use of the CFW100
which is not based on this manual.
Part of the figures and tables are available in the annexes, which are divided into APPENDIX A -
FIGURES on page 119 for figures and APPENDIX B – TECHNICAL SPECIFICATIONS on page
121 for technical specifications.
For further information, refer to the programming manual.
2.2 ABOUT THE CFW100
The CFW100 frequency inverter is a high-performance product which allows speed and torque
control of three-phase induction motors. This product provides the user with the options of vector
(VVW) or scalar (V/f) control, both programmable according to the application.

10 | CFW100
General Information
English
In the vector mode (V V W ), the operation is optimized for the motor in use, obtaining a better
performance in terms of speed regulation.
The scalar mode (V/f) is recommended for simpler applications, such as the activation of most
pumps and fans. In such cases it is possible to reduce the losses in the motor and the inverter
using the “V/f Quadratic”, which results in energy savings. The V/f mode is used when more than
a motor is activated by an inverter simultaneously (multimotor applications).
The main components of the CFW100 can be viewed in the block diagram of Figure 2.1 on
page 11.

CFW100 | 11
General Information
English
Digital
inputs
(DI1 to DI4)
Sources for electronics and interfaces
between power and control
PC
POWER
Single-phase
rectifier
Filter
Motor
U/T1
V/T2
W/T3
Inverter
with IGBT
transistors
Power
supply
L1/L
L2/N
(SUPERDRIVE
G2, WLP)
RS-485
USB
Adapter
DC link
capacitor
bank
HMI
Control
board
with CPU
16 bits
Flash Memory
Module
Bluetooth
CANopen/
DeviceNet
Bluetooth
adapter
HMI
(remote)
PE PE
Accessories
Analog input
and relay
output
Converter
USB-RS485
CONTROL
Figure 2.1: CFW100 block diagram

12 | CFW100
General Information
English
2.3 TERMINOLOGY
Tab l e 2.1: Terminology of the CFW100 inverters
Product
and
Series
Model Identification Degree of
Protection
Hardware
Version
Software
Version
Mechanics Rated
Current
Phase
Number
Rated
Voltage
E.g.: CFW100 A01P6 S 2 20 --- ---
Available options
CFW100
A 01P6 = 1.6 A
S = single-phase
supply 2 = 200...240 V
Blank =
standard
B 02P6 = 2.6 A Sx =
special
software
C 04P2 = 4.2 A
20 = IP20 Blank = standard
Hx = special hardware
2.4 IDENTIFICATION LABEL
The identification label is located on the side of the inverter. For further details on positioning the
label, refer to Figure A2 on page 120.
Production order
Rated input data
(voltage, current and
frequency)
Serial number
Manufacturing date (14 corresponds
to the week and I to the year)
Rated output data
(voltage, current and frequency)
WEG stock item
Model (Inverter
intelligent code)
CFW100 Side Label
Figure 2.2: Description of the CFW100 identification label

CFW100 | 13
General Information
English
2.5 RECEIVING AND STORAGE
The CFW100 is supplied packed in a cardboard box. There is an identification label affixed to the
outside of the package, identical to the one affixed to the side of the inverter.
Verify whether:
The CFW100 identification label corresponds to the purchased model.
Any damage occurred during transportation.
Report any damage immediately to the carrier.
If the CFW100 is not installed soon, store it in a clean and dry location (temperature between -25 ºC
and 60 ºC (-13 ºF and 140 ºF)), with a cover to prevent dust accumulation inside it.
ATTENTION!
When the inverter is stored for a long period, it becomes necessary to perform
the capacitor reforming. Refer to the procedure recommended in section 6.4
PREVENTIVE MAINTENANCE on page 35 of this manual.

14 | CFW100
Installation and Connection
English
3 INSTALLATION AND CONNECTION
3.1 MECHANICAL INSTALLATION
3.1.1 Environmental Conditions
Avoid:
Direct exposure to sunlight, rain, high humidity or sea-air.
Inflammable or corrosive gases or liquids.
Excessive vibration.
Dust, metallic particles or oil mist.
Environment conditions permitted for the operation of the inverter:
Temperature surrounding the inverter: 0 ºC to 50 ºC ( 32 ºF to 122 ºF) – IP20.
For temperatures surrounding the inverter higher than the specifications above, it is necessary
to apply a 2 % of current derating for each degree Celsius, limited to an increase of 10 ºC (50 ºF).
Air relative humidity: 5 % to 95 % non-condensing.
Maximum altitude: up to 1000 m (3.300 ft) - rated conditions.
From 1000 m to 4000 m (3.300 ft to 13.200 ft) – 1 % of current derating for each 100 m above
1000 m of altitude.
Pollution degree: 2 (according to EN50178 and UL508C), with non-conductive pollution.
Condensation must not originate conduction through the accumulated residues.
3.1.2 Positioning and Mounting
The external dimensions and fixing holes, and the inverter net weight (mass) are shown in Figure
B1 on page 123.
Mount the inverter in the upright position on a flat and vertical surface. Allow the minimum
clearances indicated in Figure B2 on page 124, in order to allow the circulation of the cooling
air. Do not install heat sensitive components right above the inverter.

CFW100 | 15
Installation and Connection
English
ATTENTION!
When installing two or more inverters vertically, respect the minimum clearance
A + B (as shown in Figure B2 on page 124) and provide an air deflecting plate
so that the heat rising up from the lower inverter does not affect the top inverter.
Provide independent conduits for the physical separation of signal, control and
power cables (refer to section 3.2 ELECTRICAL INSTALLATION on page 16).
3.1.2.1 Cabinet Mounting
For inverters installed inside cabinets or metallic boxes, provide proper exhaustion, so that the
temperature remains within the allowed range. Refer to the dissipated powers in Table B2 on
page 122.
As a reference, Table 3.1 on page 15 shows the air flow of rated ventilation for each model.
Cooling Method: internal fan with air flow upwards.
Tab l e 3.1: Air flow of the internal fan
Model CFM I/s m3/min
B6.00 2.83 0.17
C7.73 3.65 0.22
3.1.2.2 Surface Mounting
Figure B2 on page 124 illustrates the CFW100 installation procedure for surface mounting, using
the mounting accessory with screws (for further information, refer to chapter 7 ACCESSORIES
on page 39).
3.1.2.3 DIN-Rail Mounting
The CFW inverter can also be mounted directly on a 35mm-rail, in accordance with DIN EM
50.022. For further details, refer to Figure B2 on page 124.

16 | CFW100
Installation and Connection
English
3.2 ELECTRICAL INSTALLATION
DANGER!
The following information is merely a guide for proper installation. Comply with
applicable local regulations for electrical installations.
Make sure the AC power supply is disconnected before starting the installation.
The CFW100 must not be used as an emergency stop device. Provide other
devices for that purpose.
DANGER!
Les informations suivantes constituent uniquement un guide pour une
installation correcte. Respectez les réglementations locales en vigueur pour
les installations électriques.
Vérifiez que l'alimentation secteur CA est débranchée avant de commencer
l'installation.
Le CFW100 ne devra pas être utilisé comme un dispositif d'arrêt d'urgence.
Utilisez des dispositifs additionnels appropriés dans ce but.
3.2.1 Identification of the Power Terminals and Grounding Points
The location of the power, grounding and control connections can be seen in Figure B3 on
page 125.
Description of the power terminals:
L/L1 and N/L2: AC power supply must be connected to L/L1 and N/L2.
U, V and W: connection for the motor.
PE: grounding connection.
The maximum tightening torque of the power terminals and grounding points must be checked
in Figure B3 on page 125.

CFW100 | 17
Installation and Connection
English
3.2.2 Circuit Breakers, Fuses, Grounding and Power
ATTENTION!
Use proper cable lugs for the power and grounding connection cables. Refer
to Table B1 on page 121 for recommended wiring, circuit breakers and fuses.
Keep sensitive equipment and wiring at a minimum distance of 0.25 m (9.85 in) from
the inverter and from the cables connecting the inverter to the motor.
It is not recommended the use of mini circuit breakers (MDW), because of the
actuation level of the magnet.
ATTENTION!
Residual differential interrupter (DR):
When used in the inverter supply, it must have a pick-up current of 300 mA.
Depending on the installation conditions, such as motor cable length and type,
multi-motor drive, etc., the DR interrupter may trip. Check with the manufacturer
the most suitable type for operation with inverters.
NOTE!
The wire gauges listed in Table B1 on page 121 are guiding values. Installation
conditions and the maximum permitted voltage drop must be considered for the
proper wiring sizing.

18 | CFW100
Installation and Connection
English
3.2.3 Power Connections
Shield
PE
PEL2L1
Disconnecting
switch
Fuse
Power supply
PE W V U
L1/L
L2/N
U V W PE
Figure 3.1: Power and grounding connections
