WerkMaster viper Installation and operating instructions

WerkMaster Viper & Raptor XTi
Operation & Service Manual
TM
TM
WerkMaster Grinders & Sanders Inc.
6932 Greenwood Street, Burnaby, BC V5A 1X8
tel: [phone] | toll free: 1.866.373.WERK | fax: [phone]
www.werkmaster.com | email: [e-mail]
IMPORTANT:
Read & understand operators manual
before using this machine

!!
!
!
!
LIABILITY LIMITATIONS
The remedies of the user set forth under provisions of warranty outlined at the
end of this manual are the exclusive and total liability of WerkMaster Grinders &
Sanders Inc. with the respect to their sale or the equipment and service furnished
hereunder, in connection with the performance or breach thereof, or from the
sale, delivery, installation, repair or technical direction covered by or furnished
under the sale, whether based on contract, warranty, negligence, indemnity, strict
liability, or otherwise shall not exceed the purchase price of the unit of equipment
upon which such liability is based.
WerkMaster will not in any event be liable to the user, any successors in interest
or any beneficiary or assignee relating to this sale for any consequential,
incidental, indirect, special or punitive damages arising out of this sale or any
breach thereof, or any defects on, or failure of, or malfunction of the equipment
under this sale based upon loss of use, lost profits or revenue, interest, lost
goodwill, work stoppage, impairment of other goods, loss by reason of shutdown
or non-operation, increased expenses of operation of the equipment, cost of
purchase or replacement power of claims of users or customers of the user for
service interruption whether or not such loss or damage is based on contract,
warranty, negligence, indemnity, strict liability, or otherwise.
WerkMaster reserves the right to modify, alter and improve any part or parts
without incurring any obligation to replace any part or parts previously sold
without such modified, altered or improved part or parts.
No person is authorized to give any other warranty or to assume any additional
obligation on WerkMaster’s behalf unless made in writing and signed by an
officer of WerkMaster.
As a condition of these warranties, you are responsible for properly using,
maintaining, and caring for your machine as outlined in this Owner’s Manual.
WerkMaster recommends that you maintain copies of all maintenance records
and receipts for review by WerkMaster.
USE ONLY GENUINE WERKMASTER PARTS AND ACCESSORIES FOR
YOUR OWN SAFETY, THE SAFETY OF OTHERS AND THE LIFE OF YOUR
MACHINE. THIS WARRANTY IS NOT VALID IF YOUR MACHINE HAS BEEN
MODIFIED WITHOUT WERKMASTER’S AUTHORIZATION OR REPAIRED
WITH UNAUTHORIZED REPLACEMENT PARTS.

"#$%&'"%()!*&+,&-!!
"#$%!&&&!!
CONTENTS
Introduction!....................................................................................................!/!
Machine Descriptions!.....................................................................................!/!
Specifications!.................................................................................................!0!
Safety Precautions!.........................................................................................!1!
Personal Protective Equipment!'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!(!
Physical and Mental Fitness!''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!(!
Safe Operating Distance!''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!(!
Power!''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!(!
Safe Operating Conditions!'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!)!
Modifications!'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!)!
Power and Connectivity!.................................................................................!2!
General Connections!'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!)!
Single-Phase to Three-Phase Adapter Cord!''''''''''''''''''''''''''''''''''''''''''''''''''''''''!*!
Pigtails!'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!*!
Stove and Dryer Adapter Plugs!'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!*!
Quick 220 Adapter!''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!*!
Power Cord Minimum Requirements!''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!*!
Generator Minimum Requirements!'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!*!
Introduction to the Controls!...........................................................................!3!
Machine Controls!''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!+!
VFD Controls!''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!+!
Machine Operation!.........................................................................................!3!
Changing Tools!''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!+!
Adjusting the Dust Skirt!''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!,!
Adjusting the Handle!''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!,!
Initial Start Sequence………………………………………………………………...7
Starting the Machine!''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!-!
Adjusting the Speed!'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!-!
Stopping the Machine!''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!-!
Viewing the Total Run Time!'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!-!
Installing and Removing the Pad Driver!'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!.!
Rotation Pattern of Tooling Plates!''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!.!
Vacuum or Water Feature Port!.....................................................................!/4!
Maintenance!..................................................................................................!/4!
Daily!'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!/0!
Weekly!'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!/0!
Monthly!'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!//!
Troubleshooting!...........................................................................................!/0!
Appenix – VFD Troubleshooting and Diagnostics!.......................................!/2!
Exploded View and Parts List……………………………………………………...17
Viper XTi!.....................................................................................................!/5!
Raptor XTi!...................................................................................................!04!
Glossary!........................................................................................................!01!
Warranty Information!....................................................................................!02!
"6789:;<=!9=>!)9?7:@!AB;>7CDDDDDDDDDDDDDDDDDDDDDDDDD..03!#
123%4!562777777777777777777777777777777777777778+!
9#3:;4!562!'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''!8,!
!
!

"#$%!/!!
INTRODUCTION!!
Congratulations on your purchase of a WerkMaster machine. WerkMaster
machines allow professional surface prep, polishing, grinding, edging, buffing
and restoration of virtually any surface material, including concrete, terrazzo,
stone, and hardwood. This manual is provided to assist you in the operation and
maintenance of your WerkMaster.
!
MACHINE DESCRIPTIONS
WerkMaster machines include the Scarab, Termite XT, Viper XTi, Raptor XTi,
TITAN XT, and COLOSSOS XT models. To see the complete family of
WerkMaster machines visit our website at www.werkmaster.com.
!
!
Viper XTi
•Designed to meet the needs of contractors, facility services, equipment rentals
and DIYers
•7 Machines in 1 – grinds, sands, strips, polishes, buffs, burnishes, and edges
•Remove thinset, epoxy, glue, paint and mastic, and similar materials
•Run wet or dry on concrete, stone, terrazzo, and vinyl flooring
•Premium hardwood sander, screener and edger
•Edge to within 1/8” (3 mm) of the wall
•Features WerkMaster Octi-DiscTM technology with 8 counter rotating heads
and the versatility of using our 5” (127mm) ULTRA-FLEX Plug ‘N Go tooling
system
•Ideal for garage floor restoration and for residential and small commercial
applications
•Variable frequency drive lets you run at speeds from 450 RPM to 1600 RPM
•Dual action wet/dry vacuum port allows for dry, dust-free pick up and can be
used with water feature
•Run 220V single-phase or 110V with Quick 220 Adapter
!
!
!
!
!
!
!
!
!
!
!
!
!
!

"#$%!8!!
!
Raptor XTi
•Most aggressive, powerful surface prep and polish machine in its class,
designed to meet the needs of today’s general and facility maintenance 7
Machines in 1 – grinds, sands, strips, polishes, buffs, burnishes, and edges
•Use for garage floor prep and polish, as an edger on large commercial and
industrial jobs, or for retail and small commercial polishing and surface prep
projects
•Remove thinset, epoxy, glue, paint and mastic on concrete, stone, terrazzo
and vinyl flooring; works on spalled and rained-out concrete
•Run wet or dry on concrete, stone, terrazzo and vinyl flooring
•Premium hardwood sander, screener and edger
•Edge to within 1/8” (3 mm) of the wall
•Has an adjustable, foldable handle for easy transport
•Features WerkMaster Octi-DiscTM technology with 8 counter rotating heads
and the versatility of using our 5” (127mm) ULTRA-FLEX Plug ‘N Go tooling
system
•Features auto sensing dual voltage variable frequency drive that lets you run
at speeds from 450 to 1600 RPM
•Run on 110V with Quick 220 Adapter, single-phase 220V or three-phase 230V
SPECIFICATIONS!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
MODEL
VIPER XTi
RAPTOR XTi
Dimensions (l x w in)
(l x w cm)
17 x 17
43 x 43
17 x 17
43 x 43
Weight (lb / kg)
250 / 113
305 / 138
Horsepower (HP)
Phase
3
1~
5
1~ / 3~
Frequency (Hz)
50 / 60
50 / 60
Voltage (V)
200-230
110* Quick 220
200-230
110* Quick 220
Breaker Size
20
20

"#$%!(!!
SAFETY PRECAUTIONS
!
!
!
Read this manual and all the safety precautions before attempting to
operate WerkMaster machines. Failure to follow the safety precautions may
result in severe personal injury or death. This product is intended for
commercial use.
•Wear eye and ear protection at all times when operating WerkMaster
machines. Use only ANSI/OSHA-approved safety glasses to help prevent
eye injury.
•Wear appropriate clothing and footwear when operating WerkMaster
machines. Do not wear loose clothing or jewelry that may become entangled
in moving parts.
•Crystalline silica from bricks and concrete and other masonry products may
cause health problems. Risk of exposure varies depending on how often you
do this type of work. To reduce your risk, work in a well-ventilated area, use
a dust control system such as an industrial-style vacuum, and wear
approved personal safety equipment, such as a dust or particle respirator
designed to filter out microscopic particles.
•NEVER operate WerkMaster machines under the influence of drugs or
alcohol, when taking medications that impair the senses or reactions, or
when excessively tired or under stress.
•Only operate and maintain WerkMaster machines if you are trained in their use
and are in good physical condition and mental health. You must be
physically able to handle their bulk, weight and power.
•WerkMaster machines are designed to be operated by one person at a time.
Maintain a safe operating distance to other personnel. Keep bystanders a
safe distance away during operation by blocking off the work area in all
directions with roping, safety netting, or other material. Failure to do so may
result in someone being injured by flying debris or being exposed to harmful
dust and noise.
•Maintain a safe operating distance from flammable materials. Sparks from the
cutting action of WerkMaster machines may ignite flammable materials or
vapors.
•Unplug the WerkMaster’s power cord when not in use and before servicing or
changing tooling plates.
•Turn the WerkMaster off before disconnecting power.
•DO NOT disconnect power by pulling the cord. To disconnect power, grasp the
plug, not the cord. To remove twist-lock plugs, push in and turn clockwise to
engage, and turn counter-clockwise and pull to remove.
DO NOT turn on the WerkMaster while it is tilted back. Any tooling fastened
to the WerkMaster may eject and become a lethal projectile.
•Ground this floor-finishing machine while in use to protect the operator from
electric shock. The machine is provided with a three-conductor cord and a
three-contact grounding type attachment plug to fit the proper grounding type
receptacle. The green (or green and yellow) conductor in the cord is the
grounding wire. NEVER connect this wire to other than the grounding pin of
the attachment plug.
Personal Protective
Equipment
Physical and
Mental Fitness
Safe Operating Distance
Power
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !E&%+F+A!

"#$%!)!!
•Be sure all safety decals on the machine may be clearly read and understood.
Replace damaged or missing decals immediately.
•Maintain WerkMaster machines in safe operating condition with all guards in
place and secure, all mechanical fasteners tight, all controls in working order,
and the grinder configured for the job application, whether concrete, natural
stone, wood or other surfaces.
•To prevent damage to your machine or severe personal injury, avoid
protruding slab inserts, nails, screws, Hilti anchors, rebar, embedded bolts or
any other debris, pipe extensions, machinery bases, or any objects that
transmit sudden shock to the grinding assembly.
•Inspect the discs carefully before installing. DO NOT use any discs that exhibit
signs of damage, as severe personal injury or damage to the equipment
could result.
•NEVER leave WerkMaster machines running unattended.
•Risk of Explosion: Floor sanding can result in an explosive mixture of fine dust
and air. Use floor-sanding machine only in well-ventilated area free from any
flame or match.
•DO NOT modify WerkMaster machines. Modifications will void the warranty
and may result in injury to persons and damage to the machine.
POWER AND CONNECTIVITY
WerkMaster machines are outfitted with a variable-frequency drive (VFD) that
allows the desired grinding speed to be selected. Along with controlling the
speed of the machine, the VFD features include the following:
•Undervoltage protection (damages most single-phase motors)
•Overcurrent protection (prevents nuisance breaker tripping)
•60 Hz and 50 Hz capability (international)
•Wide voltage range (200–230V +/- 15% for 230V models;
380–460V +/- 15% for 460V models)
•Soft start (smaller generator requirements)
•Monitor pad speed display
•Auto disabled if ON when plugged in'!
!
!
!
NEVER open the VFD panel while plugged in or immediately after
unplugging the power cord. Severe injury or death may result.
WerkMaster machines come with a variety of different plug configurations. The
following table lists the plugs that are typically used.
!
!
!
!
!
!
Safe Operating Conditions
Modifications
General Connections
MODEL
VIPER XTi
RAPTOR XTi
Voltage
250
250
Breaker Size
20
30
Phase Configuration
1 phase
3 phase
Cord End
3 pole 2 wire
twist lock
4 pole 3 wire
twist lock
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !!G&+A$%!

"#$%!*!!
WerkMaster machines come in a variety of voltage and phase configurations.
The Raptor XTi is typically configured to operate on 208–230V three-phase
power. It is capable of operating on single-phase 208–230V power with the use
of the adapter cord (included), as well as 110V using a Quick 220 Adapter.
Pigtails are plug ends with unfinished bare wire on one end for hooking up to
panels. Pigtails are used when connectivity is unknown, when connecting to the
power grid of an unfinished building that has no power receptacles, or when
operating certain generators. Many pigtails are available or can be made up by
an electrician.
When using the Raptor XTi in a residential environment, source power may be
hard to find. The use of stove and dryer adapter cords make single-phase source
power easier to connect to. The dryer adapter cord is outfitted with a 30A 250V
single-phase twist-lock cord end. The stove adapter cord is outfitted with a 40A
250V single-phase twist lock cord end. The single-phase to three-phase adapter
is used to connect the dryer/stove adapter cord to the Raptor XTi only.
When using the Raptor XTi in a residential environment, source power may be
hard to find. Plug two 110V cords from the Quick 220 into the 110V wall outlet on
two (2) separate circuits. Plug the WerkMaster machine into the Quick 220
adapter.
NOTE: A 20 Amp to 30 Amp single-phase to three-phase adapter (optional)
would be required.
!
The following table lists the minimum requirements for power cords.
!
!
!
The following table lists the minimum requirements for generators'!
!
!
MODEL
MINIMUM REQUIREMENT
(KW)
Viper XTi
5
Raptor XTi
6
!
!
!
!
!
Exercise extreme caution at all times when working with electrical power.
WerkMaster strongly recommends that only certified electricians be permitted to
work with electrical power sources within customers’ facility or on their job site.
Single-Phase to Three-Phase
Adapter Cord
Pigtails
Stove and Dryer
Adapter Plugs
Quick 220 Adapter
Power Cord
Minimum Requirements
MODEL
DISTANCE
MINIMUM REQUIREMENT
Viper XTi
Raptor XTi
Up to 300 ft
Up to 300 ft
Single-phase minimum gauge of 10/3
Single-phase minimum gauge of 10/3
Three-phase minimum gauge of 10/4
Generator
Minimum Requirements
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !E&%+F+A!

"#$%!+!!
INTRODUCTION TO THE CONTROLS
!
!
!
Ensure activation lever is not depressed when plugging in the cord. If the
machine is in the START mode (lever depressed) and plugged in, the VFD will
automatically prevent the machine from running. Unplug machine, wait 5
seconds, ensure it is not in START (lever depressed), then plug in the machine.
Viper XTi/Raptor XTi: All machine operating controls are found on the handle
NOT on the keypad of the VFD.
Viper XTi/Raptor XTi: The VFD controls are locked out to avoid accidentally
changing necessary parameters.
MACHINE OPERATION
!
!
ALWAYS turn off and disconnect power from the machine when performing any
operations to the bottom of the machine. The machine and the tooling may be
hot after using.
<!!!!!!!!!!!!!!!!=!
!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!>!!!!!!!!?!
!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!@!
!
!
!
A!!!!!!!!!!!!!!!B D !
!
@2$'!/! ! !!!!!!!!!!!!!!!!!!!!!!!!!!@2$'!8!!!!!!!@2$'!(!!!!!!@2$'!)!
!
!
!
6;!CD#E$%!:;;F2E$!;E!:D%!123%4!562!#EG!:D%!9#3:;4!562!
1. Unplug the power cord from the twist lock inlet (A). Ensure the handle is in its
full upright position (Fig 2). Tilt the machine back (Fig 3). Choose the
appropriate tooling holder attachment – magnetic Plug ‘N Go plate (B) for
Metal Bond tools or Foam/Velcro Adapter plate for polishing resins. Insert
the 2 shear pins through the foam pad into the rubber grommets on the pad
driver. Attach the corresponding tooling to the plate.
2. Return the machine to the upright position.
!
!
Machine Controls
VFD Controls
Changing Tools
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !!H&,'F"+!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !E&%+F+A!

"#$%!,!!
!
The dust skirt (C) serves as a seal for the bottom of the machine to act as a
vacuum chamber helping the dust stay contained under the machine. If the skirt
is too far from the ground, the dust containment is reduced.
To adjust the skirt:
1. Pull one end of the skirt off of the machine until you reach the middle of the
skirt.
2. Position the skirt until it is barely touching the ground and repeat with the other
end.
!
!
!
Avoid positioning the skirt too low as it will drag against the ground, wearing the
skirt out prematurely and possibly preventing smooth machine movement.
!
!
!
To adjust the handle, pull the pin (D). Adjust the handle to a comfortable
operating position. Re-insert the pull pin.
!
!
!
!
Failure to check the pull pin is fully reinserted could result in damage to the
machine or personal injury as the handle could release unexpectedly when the
machine is being operated or tilted back.
!
!
!
!
When the machine is first plugged in, a start-up screen will appear showing the
model of the VFD and the software version that it has been released with.
After the machine runs through its initial start-up sequence, the screen will show
the VFD status and pad driver speed in revolutions per minute (RPM).
Once the machine reaches the desired speed, the speed will remain constant as
long as the load applied remains below 100%. If the machine is running at speed
and the load begins to exceed 100%, the machine will reduce its speed as a
protective measure to try and alleviate the outstanding load. The current running
speed will be displayed. This happens under demanding conditions and is
normal.
!
Adjusting the Dust Skirt
Adjusting the Handle
Initial Start Sequence
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !E&%+F+A!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !!H&,'F"+!

"#$%!-!!
To start the machine:
1. Apply a slight downward pressure on the handle to alleviate some weight off
the diamonds ensuring the machine does not life off the ground; then gently
squeeze the activation lever (E) and press and release the START button (F).
2. Once the machine starts, gently release the downward pressure and start
grinding.
DO NOT lift the machine off the ground while starting it. Doing so could
cause the diamonds to release from the machine, resulting in damage to the floor
or personal injury.
The speed of the machine can be adjusted when the machine is running or
stopped. To adjust the speed, rotate the speed control knob (G) on the handle
clockwise to slow it down, or counterclockwise to speed it up. Always start the
machine at the lowest speed and adjust as necessary.
!
1. Release the activation lever.
When you unplug the machine, the screen will stay lit for a few seconds as the
VFD drains the power from its internal capacitors. This is normal.
!
!
!
!
NEVER open the VFD panel while plugged in or immediately after
unplugging the power cord. Severe injury or death may result.
!
!
!
!
!
!
!
!
!!!
!!!H;I4!J%:%4!
!!!!!!!!!!!!!
!
!!!!!!
!
!
!
!
!
!
!
!
Starting the Machine
Adjusting the Speed
Stopping the Machine
Viewing the Total Run Time
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !!G&+A$%!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !E&%+F+A!

"#$%!.!!
To install and remove the pad driver on the bottom of the machine, you will need
a 9/16” (14 mm) socket wrench, a soft face mallet, and some medium-strength
thread locker (blue Loctite 243 or equivalent).
To remove the pad driver:
1. Slip the 9/16” (14 mm) socket wrench over the pad driver bolt and strike the
wrench with the soft face mallet in a counter-clockwise direction.
2. When installing a new pad driver or re-installing an existing one, apply a
generous amount of thread locker compound to the bolt and threaded drive
shaft. Insert bolt through the hole in the pad driver. Reapply thread locking
compound every time a pad driver is removed.
3. Line up the bolt to the threaded end of the shaft and start the first couple of
threads.
4. Once the bolt is engaged, make sure that the drive shaft is properly seated
within the pad driver slot before tightening the bolt all the way.
!
!
!
Failure to seat the pad driver could result in the pad driver slot being stripped out,
the threads in the shaft being stripped, the machine leaving heavy tool marks,
and the tooling overheating.
!
!
!
!!!!!!!!!!!!!!!!!!!!!!!!! !
!
=;::;K!;L!M%4NJ#O:%4!P2:D!EIKQ%4%G!:;;F2E$!3F#:%O!#EG!CF;CNP2O%!#EG!C;IE:%4CF;CNP2O%!F#Q%F2E$'!
!
!
!
Installing and Removing
the Pad Driver
Rotation Pattern of
Tooling Plates
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !!H&,'F"+!

"#$%!/0!!
VACUUM OR WATER FEATURE PORT
1. Only run vacuum when dry grinding.
2. The vacuum port accepts a standard 2” vacuum hose cuff.
3. Always refer to vacuum manual.
1. Insert water feature plug in the vacuum port.
2. Ensure the blue flow control valve is in the OFF position.
3. Attach a ¾” male (standard garden hose) to a ¾” female end of the water
feature. Secure tightly with a new washer to prevent leaks.
4. Turn on water supply. Adjust the blue flow control valve as wet grinding
process requires.
!
!
!
Use extreme caution when working with electricity and water. Severe injury
or death may occur if caution is not used.!
MAINTENANCE
!
!
Disconnect power before performing any maintenance, cleaning, or repair
to your machine.
•Wipe down the machine after every job.
•Gently remove dirt and debris from the pad driver.
•Check grommets and replace if necessary.
•Vacuum, wash and thoroughly dry the underside of the machine.
•Inspect the plug ends for signs of carbon deposits and arcing.
•Check all fasteners and tighten if necessary.
•Inspect water seals around shaft for any wear or damage.
•Inspect the handle wires for damage.
•Blow off the VFD heat sink with compressed air.
•Re-install the pad drivers using blue thread locking compound.
•Using a soft scrub pad, remove any excess dirt build-up from the bottom plate
and back side of the pad drivers.
!
!
After wet operation, wash bottom of the machine thoroughly, failure to do
so may result in damaged shaft seals.
Do not use any sharp object or abrasive pad to clean the shaft seals. This
can compromise the shaft seals.
Vacuum
Water Feature
Daily
Weekly
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !!G&+A$%!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !E&%+F+A!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !!H&,'F"+!

"#$%!//!!
•Check all strain reliefs and make sure they are tight. (Strain reliefs are the
plastic nuts that secure the wires that come out of the handle and VFD.)
•Remove the pad drivers and inspect the threads to make sure there are no
signs of cross-threading or stripping. Remove excess thread locking
compound from bolts using a wire brush or by washing the bolts in a solvent.
•Clean and lubricate wheels.
•Using an extremely light abrasive pad, remove any topical rust from the shafts.
Monthly

"#$%!/8!!
TROUBLESHOOTING
!
!
F)),$!
'$)'!
)"-,'F"+)!
J#CD2E%!P2FF!E;:!:I4E!;E'!
AD%CN!#FF!3;P%4!C;EE%C:2;EO'!J#N%!
OI4%!:D%!O;I4C%!3;P%4!K%%:O!:D%!
K#CD2E%RO!K2E2KIK!3;P%4!
4%SI24%K%E:O!TO%%!Power&Cord&
Minimum&Requirements&&p.&4U'!
•"FI$!2E!:D%!K#CD2E%'!
•AD%CN!:;!O%%!2L!#EV!Q4%#N%4O!;4!LIO%O!#4%!:4233%G!;4!QF;PE'!
•AD%CN!:;!O%%!:D%!D#EGF%!#C:2W#:2;E!F%W%4!2O!E;:!G%34%OO%G'!
•H#W%!#!SI#F2L2%G!%F%C:42C2#E!:%O:!:D%!O;I4C%!3;P%4!:;!O%%!2L!
2:!K%%:O!:D%!K#CD2E%RO!K2E2KIK!3;P%4!4%SI24%K%E:O'!!
•"4%OO!X6<96!QI::;E!PD2F%!#C:2W#:2;E!F%W%4!2O!G%34%OO%G'!
1@B!:I4EO!;E!QI:!K#CD2E%!
P2FF!E;:!O:#4:'!
AD%CN!:D%!1@B!G2O3F#V!L;4!%44;4!
C;G%O!Tsee&Appendix&p.&14U'!!
•&L!E;!%44;4!C;G%!2O!G2O3F#V%GY!CD%CN!2L!:D%!D#EGF%!P24%!2O!
3FI$$%G!2E:;!:D%!K#CD2E%'!!
•&L!:D%!1@B!%44;4!C;G%!2O!ZF;P!W;F:#$%[!D#W%!#!SI#F2L2%G!
%F%C:42C2#E!:%O:!:D%!O;I4C%!3;P%4!#EG!K#N%!:D%!E%C%OO#4V!
#G\IO:K%E:O!:;!:D%!P242E$!:;!OI33FV!:D%!K#CD2E%!P2:D!2:O!
4%SI24%G!2E3I:!3;P%4'!
J#CD2E%!4IEO!L;4!#!OD;4:!
:2K%!#EG!:D%E!ODI:O!
G;PE'!
AD%CN!:D%!C24CI2:!Q4%#N%4!:;!O%%!2L!2:!
2O!:4233%G!;4!:D%!LIO%!2L!2:!2O!QF;PE'!
•AD%CN!:;!K#N%!OI4%!:D#:!:D%!3;P%4!O;I4C%!D#O!:D%!
#334;342#:%FV!O2]%G!Q4%#N%4!;4!LIO%!:;!K%%:!:D%!
K#CD2E%RO!K2E2KIK!3;P%4!4%SI24%K%E:O'!!
•J#N%!OI4%!:D%!$%E%4#:;4!K%%:O!:D%!K#CD2E%RO!K2E2KIK!
3;P%4!4%SI24%K%E:O'!!
•H#W%!#E!%F%C:42C2#E!3%4L;4K!#!W;F:#$%!:%O:!PD2F%!:D%!
K#CD2E%!2O!IEG%4!F;#G!:;!O%%!2L!:D%!W;F:#$%!G4;3O!Q%F;P!
:D%!K#CD2E%RO!K2E2KIK!3;P%4!4%SI24%K%E:O'!
"#G!G42W%4O!#4%!E;:!
:I4E2E$!;4!;EFV!;E%!3#G!
G42W%4!2O!:I4E2E$'!
B2OC;EE%C:!:D%!3;P%4!#EG!:2F:!:D%!
K#CD2E%!Q#CN'!X32E!;E%!3#G!QV!
D#EG'!!
•&L!:D%!3#G!:I4EO!2EG%3%EG%E:FVY!4%3F#C%!:D%!O%C;EG#4V!Q%F:'!
>;!:;!PPP'P%4NK#O:%4'C;K^OI33;4:'!
•&L!#FF!3#G!G42W%4O!:I4E!QI:!:D%!K;:;4!L#E!G;%O!E;:!:I4EY!
4%3F#C%!:D%!342K#4V!Q%F:'!A;E:#C:!:%CDE2C#F!OI33;4:_!
-++'(,('.(,*'!
`;:!#FF!G2OCO!#4%!$42EG2E$!
:D%!LF;;4'!
B2OC;EE%C:!:D%!3;P%4!#EG!:2F:!:D%!
K#CD2E%!Q#CN'!12OI#FFV!2EO3%C:!%#CD!
3#G!G42W%4!D%2$D:!#$#2EO:!:D%!
#G\#C%E:!3#G!G42W%4'!
•J#N%!OI4%!#FF!3#G!G42W%4O!#4%!O%#:%G!34;3%4FV!;E!:D%!OD#L:O'!!
•J#N%!OI4%!$42EG2E$!^!3;F2OD2E$!^!O#EG2E$!K%G2#!2O!O%#:%G!
34;3%4FV!;E!:D%!3#G!G42W%4O'!
•J#N%!OI4%!$42EG2E$!^!3;F2OD2E$!^!O#EG2E$!K%G2#!2O!P;4E!
%W%EFV!#EG!CD#E$%!;I:!#EV!K%G2#!2L!IE%W%E'!
?aC%OO2W%!E;2O%!;4!
W2Q4#:2;E!2O!L%F:!;4!D%#4G!
PD2F%!4IEE2E$!:D%!
K#CD2E%'!
B2OC;EE%C:!:D%!3;P%4!#EG!:2F:!:D%!
K#CD2E%!Q#CN'!X32E!;E%!3#G!QV!
D#EG'!b2O:%E!L;4!#!CF2CN2E$!O;IEG!;4!
$42:cF2N%!L%%F2E$'!
•AD%CN!:D#:!#FF!:;;F2E$!2O!2E!:D%!C;44%C:!32E!D;F%O!;E!:D%!3#G!
G42W%4O'!
•9%3F#C%!:D%!Q%#42E$O'!A;E:#C:!:%CDE2C#F!OI33;4:_!-++c(,(c
.(,*!L;4!2EO:4IC:2;EO'!
6;;F2E$!Q%C;K%O!
G2OF;G$%G!L4;K!:D%!
K#CD2E%!PD2F%!;3%4#:2E$'!
B2OC;EE%C:!:D%!3;P%4!#EG!:2F:!:D%!
K#CD2E%!Q#CN'!9%K;W%!#EG!2EO3%C:!
#FF!:;;F2E$'!6D2O!2ECFIG%O!:D%!32EOY!
:;;F2E$!3F#:%OY!#EG!3#G!G42W%4O'!
•&L!:D%!32E!D;F%O!#4%!%aC%OO2W%FV!G#K#$%GY!4%3F#C%!:D%!3#G!
G42W%4O'!
•&L!:D%!$4;KK%:O^QIK3%4O!;E!:D%!3#G!G42W%4O!#4%!G#K#$%GY!
4%3F#C%!:D%!G#K#$%G!3#4:O'!
•&L!:D%!32EO!;E!:D%!G2#K;EGO!;4!:;;F2E$!3F#:%O!#4%!G#K#$%G!
;4!K2OO2E$Y!4%3F#C%!:D%!32EO'!
6D%!K#CD2E%!D#EGF%!
K#FLIEC:2;EO'!!
AD%CN!:D%!D#EGF%!3FI$!:;!O%%!2L!2:!
D#O!C;K%!F;;O%'!
•X%CI4%!:D%!D#EGF%!3FI$'!&L!:D%!D#EGF%!C;E:4;FO!#4%!O:2FF!
K#FLIEC:2;E2E$Y!C;E:#C:!CIO:;K%4!O%4W2C%!L;4!
2EO:4IC:2;EO'!

"#$%!/(!!
F)),$!
'$)'!
)"-,'F"+)!
1@B!K#N%O!3;332E$!E;2O%!
#EG!O:#4:O!:;!OK;N%'!
IIIG;CJ<==7J:!6<K78!
;LL7>;9:7M@NIII!
M#2:!L;4!/d8!D;I4OY!:D%E!4%K;W%!:D%!
1@B!C;W%4!#EG!CD%CN!%F%C:4;E2C!
C;K3;E%E:O!L;4!G2OC;F;4#:2;EY!
OC;4CD2E$Y!;4!OP%FF2E$'!
•A;E:#C:!#!G%#F%4!;4!:%CDE2C#F!OI33;4:_!-++'(,('.(,*'!
1@B!OC4%%E!G2O3F#VO!%44;4!
K%OO#$%!;4!IEIOI#F!
OC4%%E!G2O3F#V'!
b;;N!I3!:D%!K%OO#$%!2E!:D%!
<33%EG2a'!
•A;E:#C:!:%CDE2C#F!OI33;4:_!-++'(,('.(,*'!
!
!
!
!

"#$%!/)!!
APPENDIX – VFD TROUBLESHOOTING AND DIAGNOSTICS
!6D%!L;FF;P2E$!:#QF%!OD;PO!:D%!L#IF:!C;G%O!:D#:!K#V!Q%!G2O3F#V%G!GI42E$!5)!<A!G42W%!
;3%4#:2;EY!#F;E$!P2:D!OI$$%O:2;EO!L;4!4%C;W%42E$!L4;K!:D%!L#IF:!C;EG2:2;E'!!
!
!
!
XD#G%G!L#IF:O!#4%!#I:;c4%O%::#QF%Y!%aC%3:!PD%4%!E;:%G'!!
H"G$!
O&,-'!
GF)#-&P!
G$)H%F#'F"+!
&GQ.!O&,-'!
H"G$!
$R#-&+&'F"+!
),AA$)'F"+)!O"%!%$H"Q$%P!
/!
XVO:%K!!
XVO:%K!L#IF:!!
0Y/Y8!
&E:%4E#F!K2C4;34;C%OO;4!34;QF%K'!!
A;EOIF:!:D%!L#C:;4V!L;4!4%3#24!;4!
4%3F#C%K%E:'!!
(!
6D%4K2O:;4!34;L2F%!2O!2EC;44%C:'!!
A;EOIF:!:D%!L#C:;4V!L;4!4%3#24!;4!
4%3F#C%K%E:'!!
0!
J%K;4V!34;QF%K!PD%E!4%LF#OD2E$!:D%!
G42W%RO!K%K;4V'!!
9%O%:!:D%!G42W%!:;!L#C:;4V!O%::2E$O'!
A;EOIF:!:D%!L#C:;4V'!!
/Y8Y(!
A;ELF2C:!2E!:D%!G42W%RO!K%K;4V'!!
9%O%:!:D%!G42W%!:;!L#C:;4V!O%::2E$O'!
A;EOIF:!:D%!L#C:;4V'!!
8!
??!AD%CNOIK!!
AD%CNOIK!%44;4!!
)!
eE#QF%!:;!P42:%!#E!??!3#4#K%:%4!#L:%4!#!
3#4#K%:%4!D#O!Q%%E!CD#E$%G!:D4;I$D!
:D%!N%V3#G!;4!X&f'!!
9%O%:!:D%!G42W%!:;!L#C:;4V!O%::2E$O'!
A;EOIF:!:D%!L#C:;4V'!!
*!
6D%!G42W%!2O!4%C%2W2E$!??!P42:%!4%SI%O:O!
L#O:%4!:D#E!:D%V!C#E!Q%!34;C%OO%G'!6D2O!
P;IFG!:V32C#FFV!Q%!C#IO%G!QV!P42:2E$!
3#4#K%:%4O!:;;!L4%SI%E:FV!:D4;I$D!
J;GQIO'!!
XF;P!G;PE!:D%!L4%SI%ECV!;L!:D%!J;GQIO!
P42:%O'!!
(!
AI44!A#F2Q4!
AI44%E:!
C#F2Q4#:2;E!L#IF:!
0!
AI44%E:!C#F2Q4#:2;E!L#IF:!;E!3D#O%!6/^e'!
AD%CN!:D%!K;:;4!C;EE%C:2;EO!:;!:D%!
:%4K2E#F!O:423!;L!:D%!G42W%!#EG!#:!:D%!
K;:;4'!H#W%!K;:;4!CD%CN%G'!A;EOIF:!:D%!
L#C:;4V!L;4!4%3#24!;4!4%3F#C%K%E:!;L!
G42W%'!
/!
AI44%E:!C#F2Q4#:2;E!L#IF:!;E!3D#O%!68^1'!
8!
AI44%E:!C#F2Q4#:2;E!L#IF:!;E!3D#O%!
6(^M'!
)!
";P%4!XI33!!
";P%4!OI33FV!
L#IF:!!
0!
*!1!OI33FV!2O!Q%F;P!)!1BA!L;4!K;4%!
:D#E!/00!KO'!!
&EC4%#O%!4%O2O:#EC%!Q%:P%%E!9?@!#EG!
#E#F;$!2E3I:O'!AD%CN!:D%!P242E$!:;!9?@!
:%4K2E#FO'!A;EOIF:!:D%!L#C:;4V'!!
+!
&fA!6423!!
&EO:#E:#E%;IO!
;W%4CI44%E:!:423!!
0!
XD;4:!C24CI2:!P#O!G%:%C:%G!;E!3;P%4c
I3'!!
9%K;W%!:D%!OD;4:!L4;K!:D%!3;P%4!P242E$!!
AD%CN!L;4!#!OD;4:%G!K;:;4'!A;EOIF:!:D%!
L#C:;4V'!!
/!
XD;4:!C24CI2:!P#O!G%:%C:%G!GI42E$!
;3%4#:2;E'!!
,!
Jfb!!
Jfb!C;E:#C:!
L#IF:!!
0!
Jfb!G2$2:#F!2E3I:!P#O!#C:2W#:%GY!
G%3%EG2E$!;E!3IFFcI3!;4!3IFFcG;PE!
F;$2C!C;EL2$I4#:2;E'!
9%O%:!:D%!Jfb!C;E:#C:!;4!4%K;W%!:D%!
C;EG2:2;E!C#IO2E$!:D%!Jfb!C;E:#C:!
#C:2W#:2;E'!
-!
J;G%F!&B!!
&B!g!;I:!;L!
4#E$%!!
0Y/Y8!
A;E:4;F!Q;#4G!2O!E;:!4%#G2E$!:D%!G42W%!
&B!34;3%4FV'!!
A;EOIF:!:D%!L#C:;4V!L;4!4%3#24!;4!
4%3F#C%K%E:'!!
/0!
9%O!b;CN;I:!!
9%O:#4:!F;CN;I:!!
0!
6D%!EIKQ%4!;L!L#IF:!4%O:#4:O!2O!$4%#:%4!
:D#E!:D%!F2K2:!G%L2E%G!2E!:D%!CIO:;K%4!
3#4#K%:%4'!
AD%CN!:D%!#C:I#F!L#IF:!2E!:D%!L#IF:!F;$!#EG!
IO%!:D%!#334;342#:%!4%K%GV'!
//!
>4;IEG!!
>4;IEG!L#IF:!!
0!
6D%!G42W%!G%:%C:%G!#!CI44%E:!2KQ#F#EC%!
Q%:P%%E!;I:3I:!3D#O%O'!&KQ#F#EC%!
G%:%4K2E%G!:;!Q%!CI44%E:!LF;P!:;!
$4;IEG'!!
AD%CN!L;4!IEQ#F#EC%G!CI44%E:O'!AD%CN!
L;4!$4;IEG%G!K;:;4!F%#GO!;4!K;:;4'!
A;EOIF:!:D%!L#C:;4V'!!
/8!
1#C!&KQFEC%!!
&E3I:!W;F:#$%!
2KQ#F#EC%!!
0!
6D%!G42W%!G%:%C:%G!#!O2E$F%c3D#O%!
C;EG2:2;E!;4!#!W;F:#$%!2KQ#F#EC%!
;I:O2G%!:D%!G42W%RO!4#:2E$!PD2F%!4IEE2E$!
#!F;#G!:D#:!C;IFG!Q%!G#K#$2E$!:;!:D%!
G42W%'!!
AD%CN!2E3I:!W;F:#$%!#EG!CI44%E:!L;4!
2KQ#F#EC%Y!#EG!C;44%C:'!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !!!!!+"'$!
VFD Error Codes

"#$%!/*!!
/(!
fW%41;F:#$%!
fW%4W;F:#$%!
C;EG2:2;E!
0!
6D%!G42W%!G%:%C:%G!#E!;W%4W;F:#$%!
C;EG2:2;E!GI42E$!3;P%4cI3!(not&auto:
resettable)'!
1%42LV!:D#:!2EC;K2E$!F2E%!3;P%4!2O!P2:D2E!
:D%!G42W%RO!O3%C2L2C#:2;EO'!<GG!#!4%#C:;4!
;4!:4#EOL;4K%4!:;!C;44%C:'!
/Y(!
6D%!G42W%!G%:%C:%G!#E!;W%4W;F:#$%!
C;EG2:2;E!GI42E$!#!4IEE2E$!C;EG2:2;E'!!
1%42LV!2EC;K2E$!F2E%!3;P%4!#EG!CD%CN!L;4!
4%$%E%4#:2W%!F;#G'!9%GIC%!9%$%E!F;#G!;4!
#GG!GVE#K2C!Q4#N2E$!4%O2O:;4O'!9%$%E!
AI44%E:!b2K2:!K#V!D%F3h!C;EOIF:!:D%!
L#C:;4V'!!
8!
6D%!G42W%!G%:%C:%G!#E!;W%4W;F:#$%!
C;EG2:2;E!;E!3;P%4cI3!;E!:D%!F;#G!O2G%'!
1%42LV!:D#:!2EC;K2E$!F2E%!3;P%4!2O!P2:D2E!
:D%!G42W%RO!O3%C2L2C#:2;EO'!<GG!#!4%#C:;4!
;4!:4#EOL;4K%4!:;!C;44%C:'!
/*!
BVE!=4#N%!
BVE#K2C!Q4#N%!
;W%4F;#G!
0!
B=!C24CI2:!2O!#C:2W%!;E!3;P%4cI3!(not&
auto:resettable)&!
AD%CN!L;4!#!L#2F%G!Q4#N2E$!:4#EO2O:;4'!
A;EOIF:!:D%!L#C:;4V'!!
/!
B=!C24CI2:!2O!Q%2E$!#C:2W#:%G!L;4!:;;!
F;E$Y!3;OO2QFV!C#IO2E$!:D%!4%O2O:;4!:;!
;W%4D%#:!;4!L#2F'!!
9%GIC%!:D%!Q4#N2E$!CVCF%!;4!2EC4%#O%!
C#3#C2:V'!<C:2W#:%!:D%!CI44%E:!F2K2:h!
C;EOIF:!:D%!L#C:;4V'!!
8!
B=!C24CI2:!2O!;W%4F;#G%G!Q%C#IO%!;L!:;;!
F#4$%!#!4%$%E%4#:2W%!F;#G'!
9%GIC%!:D%!Q4#N2E$!CVCF%!;4!2EC4%#O%!
C#3#C2:V'!<C:2W#:%!:D%!CI44%E:!F2K2:h!
C;EOIF:!:D%!L#C:;4V'!
(Y)Y*!
B=!C24CI2:!2O!L#IF:V!;E!3;P%4cI3!(not&
auto:resettable).&!
!
/-!
fW%4AI44%E:!
fW%4CI44%E:!
C;EG2:2;E!
0!
6D%!G42W%!G%:%C:%G!#E!;W%4CI44%E:!
C;EG2:2;E!;E!3;P%4cI3!(not&auto:
resettable)'!!
AD%CN!L;4!#!L#2F%G!;I:3I:!3;P%4!G%W2C%!;4!
OD;4:%G!K;:;4'!!
/!
6D%!G42W%!G%:%C:%G!#E!;W%4CI44%E:!
C;EG2:2;E!GI42E$!;3%4#:2;E'!6D%!CI44%E:!
D#O!%aC%%G%G!:D%!O#L%!;3%4#:2;E!3;2E:!
;L!3;P%4!G%W2C%O'!!
9%GIC%!:D%!F;#G!;E!:D%!K;:;4'!1%42LV!
:D#:!J;:;4!@b<!2O!34;$4#KK%G!
C;44%C:FV'!AD%CN!L;4!K%CD#E2C#F!Q2EG2E$!
#EG!OD;CN!F;#G2E$'!!
/.!
fW%4!6%K3!
fW%4c!
:%K3%4#:I4%!
C;EG2:2;E!
0!
6D%!:%K3%4#:I4%!;L!:D%!D%#:!O2EN!
%aC%%G%G!#!:%K3%4#:I4%!F2K2:'!!
AD%CN!:D#:!#KQ2%E:!:%K3%4#:I4%!G;%O!
E;:!%aC%%G!:D%!G42W%RO!4#:2E$'!AD%CN!L#E!
;3%4#:2;E!T2L!:D%!G42W%!D#O!L#EO!2EO:#FF%GU'!!
/!
6D%!:%K3%4#:I4%!;L!:D%!C;E:4;F!Q;#4G!
%aC%%G%G!#!:%K3%4#:I4%!F2K2:'!!
AD%CN!:D#:!#KQ2%E:!:%K3%4#:I4%!G;%O!
E;:!%aC%%G!:D%!G42W%RO!4#:2E$'!AD%CN!L#E!
;3%4#:2;E!T2L!:D%!G42W%!D#O!L#EO!2EO:#FF%GU'!!
8!
6D%!G42W%!G%:%C:%G!:D#:!:D%!D%#:!O2EN!
:D%4K2O:;4!O%EO;4!2O!L#IF:V!;4!E;:!
C;EE%C:%G!34;3%4FV'!!
AD%CN!:D%!:D%4K2O:;4!C;EE%C:2;EO!;4!
4%3F#C%'!A;EOIF:!:D%!L#C:;4V'!!
(!
6D%!G42W%!G%:%C:%G!:D#:!:D%!C;E:4;F!
Q;#4G!:D%4K2O:;4!O%EO;4!2O!L#IF:V!;4!E;:!
C;EE%C:%G!34;3%4FV'!
AD%CN!:D%!:D%4K2O:;4!C;EE%C:2;EO!;4!
4%3F#C%'!A;EOIF:!:D%!L#C:;4V'!!
80!
J;:;4!6fb!!
J;:;4!:2K%G!
;W%4F;#G!:423!!
0!
6D%!G42W%!G%:%C:%G!#E!;W%4F;#G!:D#:!
%aC%%GO!:D%!CIO:;K%4RO!G%L2E%G!
;W%4F;#G!O%::2E$'!!
AD%CN!F;#G!CI44%E:!G%K#EG'!1%42LV!:D#:!
J;:;4!@b<!2O!34;$4#KK%G!:;!:D%!C;44%C:!
W#FI%'!1%42LV!:D#:!6fb!CD#4#C:%42O:2C!2O!
C;44%C:!L;4!:D%!#33F2C#:2;E'!!
8/!
b;P!6%K3!!
b;P!
:%K3%4#:I4%!!
0!
6D%!:%K3%4#:I4%!;L!:D%!D%#:!O2EN!L%FF!
Q%F;P!c/0i!A'!!
1%42LV!:D#:!#KQ2%E:!:%K3%4#:I4%!2O!
P2:D2E!:D%!G42W%RO!O3%C2L2C#:2;EOh!2EC4%#O%!
:D%!#KQ2%E:!:%K3%4#:I4%!2L!E%C%OO#4V'!!
88!
9%L!b;OO!!
X3%%G!4%L%4%EC%!
F;OO!!
0!
6D%!G42W%!G%:%C:%G!:D#:!:D%!#E#F;$!
2E3I:!P#O!C;EL2$I4%G!:;!L#IF:!2L!:D%!
2E3I:!CI44%E:!P%E:!Q%F;P!:D%!F%W%F!
O3%C2L2%G!QV!CIO:;K%4!3#4#K%:%4O'!!
AD%CN!:D%!3DVO2C#F!C;EE%C:2;EO!L;4!#!
4%L%4%EC%!O2$E#F'!AD%CN!:D#:!:D%!
34;$4#KK2E$!L;4!#!)d80!K<!O2$E#F!2O!
C;44%C:'!1%42LV!:D#:!:D%!O2$E#F!:;!:D%!G42W%!
2O!C;44%C:'!!
8(!
=4N!M24%!!
=4;N%E!P24%!
G%:%C:2;E!!
0!
6D%!G42W%!G%:%C:%G!:D#:!:D%!
3;:%E:2;K%:%4!C24CI2:!P242E$!;3%E%G!
#EG!$%E%4#:%G!#!L#IF:'!!
AD%CN!:D%!P242E$!L;4!F;OO!;L!C;EE%C:2;E!
:;!C;E:4;F!:%4K2E#FO'!AD%CN!:D#:!#!
3;:%E:2;K%:%4!;L!:D%!34;3%4!W#FI%!2O!
2EO:#FF%G'!!
!

"#$%!/+!!
8)!
j%V3#G!b;OO!
j%V3#G!F;OO!
0!
"4;QF%K!P2:D!:D%!N%V3#G!;4!#!N%V3#G!
C;EE%C:2;E'!6D%!G42W%!G%:%C:%G!:D#:!2:!
C;IFG!E;:!4%#G!#EV!N%V!34%OO%O'!
AD%CN!:D%!C;EE%C:2;E!L4;K!:D%!N%V3#G!
:;!:D%!C;E:4;F!Q;#4G'!`;:%!:D#:!:D%!
N%V3#G!2O!E;:!G%O2$E%G!L;4!4%K;:%!
K;IE:2E$'!!
/!
"4;QF%K!P2:D!:D%!N%V3#G!;4!#!N%V3#G!
C;EE%C:2;EY!;4!P4;E$!N%V3#G!P#O!IO%G'!
j%V3#G!&B!L;4!#E!5)!C;IFG!E;:!Q%!4%#G'!!
8!
"4;QF%K!P2:D!:D%!N%V3#G!;4!#!N%V3#G!
C;EE%C:2;E'!6D%!G42W%!G%:%C:%G!:D#:!2:!
C;IFG!E;:!P42:%!:;!:D%!bAB'!
8*!
A;KK!b;OO!!
A;KKIE2C#:2;E!
F;OO!!
0!
6D%!G42W%!2O!2E!#!O%42#F!F2EN!C;E:4;F!3#:D!
#EG!:D%!#K;IE:!;L!:2K%!O2EC%!:D%!F#O:!
J;GQIO!C;KK'!%aC%%G%G!:D%!:2K%!O%:!
2E!3#4#K%:%4!.0(!TX&f!62K%4U'!!
AD%CN!:D%!C;EE%C:2;EO!:;!:D%!J;GQIO!
3;4:'!<G\IO:!:D%!W#FI%!;L!3#4#K%:%4!.0(!
TX&f!62K%4U!#O!E%%G%G'!!
8+!
9%$%E!62K%!!
9%$%E!:2K%;I:!!
0!
6D%!G42W%!:;;N!K;4%!:2K%!:;!G%C%F%4#:%!
:;!#!O:;3!:D#E!2O!#FF;P%G'!6D%!:2K%;I:!
2O!G%:%4K2E%G!QV!:D%!F;E$%O:!!G%C%F%4#c
:2;E!4#K3!:2K%!TB%C%F/!;4!B%C%F8U!3FIO!
:D%!9%$%E!:2K%;I:!3#4#K%:%4'!
9%GIC%!:D%!#K;IE:!;L!4%$%E%4#:2W%!
%E%4$V!;4!2EC4%#O%!:D%!9%$%E!:2K%;I:!
3#4#K%:%4'!!
8,!
"P4!=42G$%!!
";P%4!Q42G$%!
L#IF:!!
0Y/Y8!
6D%!G42W%!G%:%C:%G!#!L#2FI4%!2E!:D%!
;I:3I:!3;P%4!G%W2C%O'!!
AD%CN!L;4!#!L#2F%G!2E3I:!3;P%4!G%W2C%'!!
8-!
B42W%!6fb!!
B42W%!:2K%G!
;W%4F;#G!!
0!
6D%!G42W%!G%:%C:%G!#E!;W%4F;#G!:D#:!
%aC%%G%G!:D%!G42W%!4#:2E$'!!
AD%CN!:D#:!F;#G!C;EG2:2;EO!G;!E;:!
%aC%%G!:D%!G42W%RO!4#:2E$!T/80k!L;4!
+0!O%C;EGO!L4;K!E#K%3F#:%!CI44%E:!
4#:2E$!L;4!E;4K#F!GI:V!#EG!/*0k!;4!4#:%G!
CI44%E:!L;4!+0!O%C;EGO!D%#WV!GI:VU'!
8.!
X:ICN!j%V!!
X:ICN!N%V!%44;4!!
0!
j%V!34%OO!P#O!G%:%C:%G!I3;E!3;P%4c
I3'!6D2O!P;IFG!;CCI4!Q%C#IO%!;L!#!
G%L%C:2W%!N%V3#G!;4!Q%C#IO%!O;K%;E%!
P#O!D;FG2E$!G;PE!#!N%V!PD%E!
3;P%42E$!I3!:D%!G42W%'!!
AD%CN!L;4!#!O:ICN!N%V3#G!#EG!4%3#24!;4!
4%3F#C%'!A;EOIF:!:D%!L#C:;4V'!!
(0!
"#4#K!9#E$%!!
"#4#K%:%4!;I:!
;L!4#E$%!!
0!
fE%!;L!:D%!CIO:;K%4!3#4#K%:%4O!2O!;I:!
;L!4#E$%'!!
AD%CN!L;4!#!3#4#K%:%4!W#FI%!O#W%G!;I:!;L!
:D%!O:#EG#4G!4#E$%'!9%O%:!3#4#K%:%4O!:;!
:D%!L#C:;4V!G%L#IF:'!A;EOIF:!:D%!L#C:;4V'!!
(/!
"P4!M242E$!
";P%4!P242E$!
%44;4!
0!
"4;QF%K!P2:D!:D%!G42W%!P242E$'!!
AD%CN!:D#:!2E3I:!3;P%4!P242E$!2O!E;:!
C;EE%C:%G!:;!F;#G!3;P%4!:%4K2E#FO'!
A;EOIF:!:D%!L#C:;4V'!
/!
&fA!L#IF:!P#O!G%:%C:%G!GI42E$!:D%!
3;P%4!P242E$!:%O:'!
(8!
b;P!1;F:#$%!!
b;P!W;F:#$%!:423!!
0!
";P%4!G23!;CCI44%G!PD%E!:D%!G42W%!P#O!
;3%4#:2E$Y!#EG!:D%!G42W%!P#O!E;:!#QF%!:;!
42G%!:D4;I$D!:D%!3;P%4!G23!Q%L;4%!
ODI::2E$!;LL!;I:3I:O'!!
1%42LV!:D#:!2E3I:!F2E%!3;P%4!2O!P2:D2E!:D%!
G42W%RO!O3%C2L2C#:2;EO'!<GG!#!:4#EOL;4K%4!
;4!4%GIC%!G%K#EGO!:;!:D%!3;P%4!L%%G'!
A;EOIF:!:D%!L#C:;4V'!!
((!
/"D!fW%4F;#G!!
/"D!;W%4F;#G!!
0!
=IO!W;F:#$%!4233F%!P#O!;I:O2G%!:D%!F2K2:!
;L!:D%!G42W%!TPD%E!3#4#K%:%4!*/,!
X2E$F%c"D#O%!2O!C;EL2$I4%G!L;4!O2E$F%c
3D#O%!;3%4#:2;EU'!!
AD%CN!:D#:!2E3I:!3;P%4!G%K#EG!G;%O!
E;:!%aC%%G!:D%!G42W%RO!C#3#C2:V!L;4!
O2E$F%c3D#O%!;3%4#:2;E'!A;EOIF:!:D%!
L#C:;4V'!!
()!
9X!J%#O'!@#2F!!
X:#:;4!
4%O2O:#EC%!
K%#OI4%K%E:!
L#2F%G!!
0!
6D%!G42W%!C;IFG!E;:!K%#OI4%!:D%!O:#:;4!
4%O2O:#EC%!34;3%4FV'!!
64V!:D%!4;I:2E%!#$#2E!#EG!2L!:D%!L#IF:!
;CCI4O!:P2C%Y!C;EOIF:!:D%!L#C:;4V'!!
(*!
@#E!b;OO!
b;OO!;L!L#E!
C;E:4;F!;4!
;3%4#:2;E!
0!
"4;QF%K!P2:D!:D%!D%#:!O2EN!L#E'!!
A;EOIF:!:D%!L#C:;4V'!!
/!
"4;QF%K!P2:D!:D%!2E:%4E#F!L#E'!fCCI4O!
;EFV!;E!X2]%!)!#EG!*!K;G%FO'!<FF!;:D%4!
K;G%FO!G2O3F#V!#!L#E!%44;4!P#4E2E$'!
`;:%!:D2O!2O!F#CN!;L!L#E!C;E:4;Fh!:D%!L#E!
C#E!Q%!O32EE2E$!#EG!:D2O!L#IF:!P2FF!O:2FF!
;CCI4'!6D2O!!D#33%EO!2L!:D%!L#E!2O!;E!#EG!
OD;IFG!E;:!Q%Y!;4!2L!:D%!L#E!L%%GQ#CN!
O2$E#FO!#4%!;QO:4IC:%G!L4;K!$%::2E$!:;!
:D%!C;E:4;F!Q;#4G'!!

"#$%!/,!!
EXPLODED VIEW AND PARTS LIST – VIPER XTI
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
SCALE 1/10
1
1
2
2
A A
B B
Viper XTi
(001-0128-00)
56 69 60 48
30 43 4139 38 42 40
14
36
44
77
76
75
52
46
73
50
51
34
35
31
9
19
8
54
11
74
55
3
4
16
17
2
28
7
6
5
79
25
49
47
37
84
26
73
22
59
24
58
27
23
13
15
18
12
14
21
58
10
1
78
20
27 63 68
23
64
65
66
80
82
67
81
71
70
57 83
60 58 72
53 61 62 45 30
32 33 29
