Wesemann SYSTEM DELTA 30 User manual

SYSTEM DELTA 30
LABORATORY FUME CUPBOARD I USER MANUAL

SYSTEM DELTA 30
LABORATORY FUME CUPBOARD I
USER MANUAL

List of Contents
1 INTRODUCTION 06-09
2 SAFETY 10-17
3 PRODUCT DESCRIPTION 18-39
4 PUTTING FUME CUPBOARD INTO OPERATION 40-51
5 MEDIUM SYSTEM: ARMATURES 52-59
6 CHEMICAL RESISTANCE 60-71
7 CLEANING OF FUME CUPBOARDS 72-81
8 INSPECTION AND MAINTENANCE OF FUME CUPBOARDS 82-87
9 SPARE-PARTS LIST AND PROTOTYPE TEST REPORT 88-90

6User Manual | Laboratory Fume Cupboard | Introduction

7
1.1 Preamble 8
1.2 Product variants 8
1.3 Other applicable documents 8
1.4 Text design 9
1.5 EU Declaration of Conformity 9
1.6 Type plate with connection parameters 9
1 INTRODUCTION
User Manual | Laboratory Fume Cupboard | Introduction

8User Manual | Laboratory Fume Cupboard | Introduction
Introduction
1.1 Preamble
Our fume cupboards (as under 1.2) are tested and certified in accordance with DIN EN 14175. All persons
involved in the installation, maintenance and operation of the laboratory fume cupboards must be suitably
qualified. For installation and dismantling instructions, as well as information regarding disposal, please see the
separate assembly instructions for laboratory fume cupboards. Please read this user manual carefully before
operating the fume cupboard and observe all regulations and instructions.
Keep these instructions in a safe place for further use.
In the event of a sale of the laboratory fume cupboard, this manual must also handed over to the buyer.
Wesemann GmbH does not accept liability for damage caused by non-observance of the user manual.
1.2 Product variants
These instructions apply to the following products:
• DS-DG03-XXXX Table fume cupboard
• DS-DG03-XXXX-P Table fume cupboard DELTAprotect
• DS-DG03-XXXX-1070 Table fume cupboard, in special depth
• DSN-DG03-XXXX Fume cupboard for low ceilings/spaces
• DSN-DG03-XXXX-P Fume cupboard for low ceilings/spaces DELTAprotect
• DT-DG03-XXXX Low work-level fume cupboard
• DT-DG03-XXXX-P Low work-level fume cupboard DELTAprotect
• DT-DG03-XXXX-1070 Low work-level fume cupboard, in special depth
• DB-DG03-XXXX Walk-in fume cupboard
• DB-DG03-XXXX-1070 Walk-in fume cupboard in special depth
• DB-DG03-XXXX-1270 Walk-in fume cupboard in special depth
The XXXX serve as placeholders for the respective grid 1200-2100.
In this manual, the generic term laboratory fume cupboard is used for the different variants.
1.3 Other applicable documents
The following documents for operating the fume cupboard are to be studied carefully:
• Operating instructions for accessory parts
• Safety Data Sheets

• Operating instructions of the employer
• Operating instructions for work materials
1.4 Text design
To facilitate readability and overview in the user manual, some lines of the text and/or text paragraphs are
accentuated:
• Symbol for a list
Symbol for actions/work steps to be executed successively in the order prescribed
Symbol for information
The explanation of the safety instructions is given in Section 2.1.
1.5 EU-Declaration of Conformity
The CE marking confirms that the product conforms to the applicable European guidelines. The basis of the CE
marking is the EU-Declaration of Conformity.
You can request the EU-Declaration of Conformity at the address given on the back of this manual.
1.6 Type plate with connection parameters
As a rule, the type plate is located on the front of the electric cable duct underneath the worktop.
For any queries to the manufacturer, the serial number and year of manufacture are required. You can find this
data, together with the connection parameters, on the type plate of the laboratory fume cupboard.
For the ventilation connection parameters, please see the project drawing handed to you with the audit
documentation.
Symbol for actions/work steps to be executed successively in the order prescribed
Symbol for actions/work steps to be executed successively in the order prescribed
9
User Manual | Laboratory Fume Cupboard | Introduction

10 User Manual | Laboratory Fume Cupboard | Safety

2 SAFETY
11
User Manual | Laboratory Fume Cupboard | Safety
2.1 Marking of safety instructions 12
2.2 List of safety markings used 13
2.2.1 Warning signs 13
2.2.2 Mandatory signs 13
2.3 Proper use 13
2.3.1 General information for all fume cupboards 13
2.3.2 All-purpose fume cupboards 14
2.4 Improper use 14
2.5 Obligation of operating company 15
2.6 Obligation of personnel 15
2.7 Liability 15
2.8 Other provisions 16

12 User Manual | Laboratory Fume Cupboard | Safety
The signal word denotes a situation, which, if not avoided, can lead to material damage.
NOTE
The signal word denotes a hazard with a high level of risk, which, if not avoided,
will lead to severe injury or death.
DANGER
The signal word denotes a hazard with a medium risk level, which, if not avoided,
can lead to severe injury or death.
WARNING
The signal word denotes a hazard with a low risk level, which, if not avoided,
can lead to a minor or moderate injury.
CAUTION
Safety
2.1 Marking of safety instructions
To avoid danger, you must observe the safety instructions. Wesemann GmbH does not accept any liability
for damage caused by non-observance of the safety instructions. You will find the following symbols with all
important safety instructions in this user manual. Always follow these instructions exactly and exercise particular
caution in these cases.
In addition, the safety information in the accompanying supplier documentation must be strictly observed.

13
User Manual | Laboratory Fume Cupboard | Safety
2.2 List of safety markings used
2.2.1 Warning signs
Warning of toxic substances
Warning of electrical voltage
2.2.2 Mandatory signs
Hand protection must be worn
2.3 Proper use
2.3.1 General rules for all laboratory fume cupboards
The fume cupboards may be used only for the following purposes/applications:
• use in buildings.
• for the extraction and discharge of harmful gases produced in a conventional laboratory during chemical
processes. Each laboratory fume cupboard may only be subjected to chemical, thermal and mechanical
stress according to its prescribed purpose (authorization) and material selection.
• under normal laboratory conditions. The additional information regarding the T032 laboratory fume
cupboards: construction types and safe operation of the BG RCI - Professional Association of the Raw
Materials and Chemical Industry - must be strictly observed.
• The sash must be kept closed at all times. Exceptions to this are inspections and short-term
interventions, assembly, dismantling and loading, as well as loading/feeding of an apparatus, whereby
the opening of the sash must be limited to the extent necessary for the activity. In this case the work
should preferably be carried out through the laterally movable parts of the sash.
• No subsequent changes or modifications may be made to the construction of the fume cupboard
(e.g. modification of the rear panel, additional openings in the side panels for pipelines, gas hoses, etc.).
Warning of toxic substances
Warning of electrical voltage

14 User Manual | Laboratory Fume Cupboard | Safety
Such changes may impair the flow behaviour and thus the protective effect of the laboratory fume
cupboard.
• Underneath larger structures by which, due to their surfaces, a kind of “slipstream” is created on the
worktop, sufficient clearance (at least 5 cm) (floor clearance) to the worktop, as well as a sufficiently
large clearance to the sash (at least 10 cm) must be observed.
The fume cupboard may not be used in a potentially explosive atmosphere. Wesemann GmbH offers EX fume
cupboards for such areas.
2.3.2 All-purpose fume cupboards
All-purpose fume cupboards are table fume cupboards, fume cupboards for low ceilings/spaces, low work-
level cupboards and walk-in fume cupboards. The all-purpose fume cupboards are not special fume cupboards
according to DIN EN14175-7:2012. They are therefore:
• not fume cupboard for high thermal loads
• not fume cupboards for high thermal loads in conjunction with acid digestions
• not perchloric acid fume cupboards
• not hydrofluoric acid fume cupboards
• not micro-biological safety work benches
• not suction boxes with air recirculation
• not radionuclide fume cupboards
They may not, therefore, be used as the said special fume cupboards and their applications.
2.4 Improper use
Any use which is not mentioned in the section 2.3 Proper use is considered to be improper use.
2.5 Obligation of the operating company
The operating company undertakes only to allow persons to work on fume cupboards:

15
User Manual | Laboratory Fume Cupboard | Safety
• if the operating company has performed a risk analysis and has taken the necessary protective
measures.
• if those carrying out the activities to be performed are competent and reliable. The expertise is
determined by the nature and duration of the relevant training, the general professional experience in
the respective field, as well as the experience in the activities to be carried out.
• who have been trained.
• who have read this user manual carefully.
2.6 Obligation of the personnel
All persons working on the fume extractors or their components undertake:
• to observe the basic regulations regarding occupational safety and accident prevention.
• to have read this user manual carefully.
Furthermore, appropriate protective clothing is to be worn when working on the fume cupboard.
2.7 Liability
Warranty and liability claims for personal or material damage are excluded if they are attributable to one or more
of the following causes:
• Improper use of the laboratory fume cupboard.
• Improper commissioning, operation, cleaning, maintenance and repair of the fume cupboard.
• Operation of the laboratory fume cupboard with defective safety devices or systems.
• Non-observance of the user manual.
• Unauthorized modifications to the fume cupboard or its components.
• Inadequate monitoring of parts that are subject to wear.
• Catastrophes due to the influence of foreign bodies or force majeure.

16 User Manual | Laboratory Fume Cupboard | Safety
• Use of spare parts that have not been approved by Wesemann GmbH.
2.8 Other provisions
In addition to this user manual, the relevant national laws, rules and regulations in the applicable version are
to be observed (i.e. Accident Prevention Regulations UVV, Industrial Safety Regulations BetrSichV, laboratory
operating instructions, Safety Data Sheets, etc.).

17
User Manual | Laboratory Fume Cupboard | Safety

18 User Manual | Laboratory Fume Cupboard | Product Description

3.1 Overview of the products 20
3.2 Technical Data 23
3.2.1 Dimensions table fume cupboard DS-DG03 23
3.2.2 Dimensions low ceilings fume cupboard DSN-DG03 24
3.2.3 Dimensions low work-level fume cupboard DT-DG03 25
3.2.4 Dimensions walk-in fume cupboard DB-DG03 26
3.2.5 Weights 27
3.2.6 Loads 27
3.3 Overview of function and control elements 28
3.4 Extraction function displays 30
3.4.1 Extraction function display Type 7.1 30
3.4.2 Extraction function display Type 7.2 31
3.4.3 Extraction function display Type 7.6 32
3.4.4 Extraction function display Type 4.1 33
3.4.5 Extraction function display Type 4.2 34
3.4.6 Extraction function display Type 4.3 35
3.4.7 Extraction function display Type 4.6 36
3.4.8 Detailed description of the functions 37
19
User Manual | Laboratory Fume Cupboard | Product Description
3 PRODUCT DESCRIPTION


01 Frame

02 Side panel bottom right

03 Side panel bottom left

06 Lab fume cupboard top left

11 Lab fume cupboard top right

13 Sash

34 Worktop

48 Front panel

49 Electric cable duct
11
34
49
02
01
03
06
13
48
20 User Manual | Laboratory Fume Cupboard | Product Description
Product description
3.1 Overview of the products
COMPLETE PRODUCT OVERVIEW
