Wesena e7T User manual

Operator’s manual
e7T
Make life colorful

Thank you for purchasing WESENA’s HTPC Chassis. We
recommend that you read this user guide thoroughly before
installation.
WESENA is the professional global supplier of HTPC cases, we
hold the professional product designing, the novel and
fashionable outside looking , humanistic inner structure of
it ,high-quality QC management and high-quality production
team. At the same time we are on the line of providing the high
quality products constantly , and will never stop innovating and
improving the theory of development in HTPC case . The
products, Both OEM and ODM are welcomed.
More information of our products visit http://www.wesena.com
Any other question please make call 400 6088 126
WESENA is not responsible for any damages due
to external causes, including but not limited to,
improper use, problems with electrical power,
accident, neglect, alteration, repair, improper
installation or improper testing.

Index
e7T overview----------------------------------------------------------4
Open the Top panel-------------------------------------------------5
Montherboard installation------------------------------------------5
HDD installation------------------------------------------------------6
ODD installation------------------------------------------------------7
PSU installation -----------------------------------------------------8
PCI or PCIE slot installation---------------------------------------8
Close the Top panel-------------------------------------------------9
Open the card reader door ----------------------------------------10
PCB+cables reference diagram ---------------------------------11

e7T overview
4
Model: e7T
Material: 100% full Aluminum
Color：Silver / black / Gold
LCD touch screen：7”touch screen LCD
Motherboard：Mini ITX / Micro ATX
HDD drive bay：4X3.5’’ HDD drive bay
ODD drive bay：1×5.2’’ standard optical drive
Cooling：2x80X80X25mm ultra-quiet fans
Expansion Slots：4XStandard big PCI slots
Front I/O Port：2x USB ports
Card Reader：Multi-card Reader
Dimension：435mm×390mm×157mm (L×W×H)
Power Supply：Standard ATX PSU bay
Remote control：Optional the MCE remote control built-in IR receiver
Net Weight：7.5KG
①. Power button
②. Power blue LED
③. IR acryl window
④. VFD acryl window
⑤.TOP panel
⑥.Card reader Door
⑦. USB port
⑧. Card reader
⑨.ODD button
⑩.Latch of door
⑪.Slot of ODD
⑫.top plate handle opening
⑬. Fan window
⑭.80x80x25mm fan
⑮.Card reader PCB board
⑯.ODD bracket
⑰. PCI slot*4
⑱. VFD screen
⑲. HDD bracket
⑳. IR receiver
Po .Power PCB board
1 2 7 8 94 1163 5 10 12 17 1913 14 20 121415 16 2118

Open top plate
Rotating top plate and open handles
an top plate , and then take out the
top plate.
Shown as photos
Motherboard installment
Unload 6 ODD bracket screws, and
then take out the ODD bracket.
put the I/O baffle plate
Put the motherboard secondly,
alignment and lock the screws
Shown as photos
5

HDD installment (quantity can be optional）
Take out the 3.5 inch HDD screws and anti-vibration pad. Lock it to the both side of the HDD,
shown as photos.
Take off the HDD bracket screws in the case. Rotating the HDD cover (shown as photos),put the
HDD into the bracket lastly.
Then, closed the HDD bracket cover, and lock the 2 screws
Shown as photos
6

ODD installment
Put the ODD on the ODD bracket.
Alignment hole , and lock the
screws.
Put the ODD button into the cases
Put the bracket , which has been
put ODD, into the case. Alignment
hole and lock the 6 screws.
Shown as photos
7

Power installment
Put the power into the cases. Align hole and lock the screws
Shown as photos
PCI and PCIE expand card installment
Exit baffle screws firstly. Take out the baffle plate
Put PCI or PCIE expand card. Lock the screws. Shown as photos
Shown as photos
8

Cover the top plate
Connect all the electronic component by the provided electronic connect diagrammatic drawing.
Check the installation position and connections again , cover the plate lastly
Shown as photos
press top right corner of the card reader door to
open the card reader door
Shown as photos
Tear down the Rubber sheet of 3M gum on the ODD door, to put the
ODD door on the ODD place and Stick on the ODD .
Shown as photos
9

GA-H55N-USB3
motherboard
For example
② ④
⑥ ⑧
USB
USB
USB
F-panel
F-panel
Cables connect sketch map
9
1
9
1
24/3 pin PWR EXT Cable
USB
10
