Weslo Pursuit 330 Bike User manual

CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Model No. WLEX91108.0
Serial No.
Write the serial number in the
space above for reference.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. If you have
questions, or if parts are damaged
or missing, DO NOT CONTACT
THE STORE; please contact
Customer Care.
IMPORTANT: You must note the
product model number and seri-
al number (see the drawing
above) before contacting us:
CALL TOLL-FREE:
1-866-699-3756
Mon.–Fri., 6 a.m.–6 p.m. MT
Sat. 8 a.m–4 p.m. MT
ON THE WEB:
www.wesloservice.com
Serial Number
Decal
USER'S MANUAL
www.weslo.com

2
TABLE OF CONTENTS
WARNINGDECA P ACEMENT ..............................................................2
IMPORTANTPRECAUTIONS ................................................................3
BEFOREYOUBEGIN ......................................................................4
ASSEMB Y ...............................................................................5
HOWTOUSETHEEXERCISECYC E .......................................................10
MAINTENANCEANDTROUB ESHOOTING ...................................................12
EXERCISEGUIDE INES ...................................................................13
PART IST ..............................................................................14
EXP ODEDDRAWING ....................................................................15
ORDERINGREP ACEMENTPARTS ..................................................BackCover
IMITEDWARRANTY ..............................................................BackCover
WARNING DECAL PLACEMENT
This drawing shows the location(s) of the warning
decal(s). If a decal is missing or illegible, see the
front cover of this manual and request a free
replacement decal. Apply the decal in the loca-
tion shown. Note: The decal(s) may not be shown
at actual size.
WES O is a registered trademark of ICON Health & Fitness, Inc.

3
1. Before beginning any exercise program,
consult your physician. This is especially
important for persons over the age of 35 or
persons with pre-existing health problems.
2. It is the responsibility of the owner to ensure
that all users of the exercise cycle are ade-
quately informed of all precautions.
3. Your exercise cycle is intended for home use
only. Do not use your exercise cycle in a
commercial, rental, or institutional setting.
4. Keep your exercise cycle indoors, away from
moisture and dust. Place your exercise cycle
on a level surface, with a mat beneath it to
protect the floor or carpet. Make sure that
there is at least 2 ft. (0.6 m) of clearance
around your exercise cycle.
5. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
6. Keep children under age 12 and pets away
from your exercise cycle at all times.
7. Your exercise cycle should not be used by
persons weighing more than 250 lbs.
(113 kg).
8. The pulse sensor is not a medical device.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
9. Wear appropriate exercise clothes while
exercising; do not wear loose clothes that
could become caught on your exercise
cycle. Always wear athletic shoes for foot
protection while exercising.
10. When adjusting the seat, insert the seat pin
into one of the holes in the seat post; do not
insert the seat pin under the seat post.
11. Keep your back straight while using your
exercise cycle; do not arch your back.
12. When you stop exercising, allow the pedals
to slowly come to a stop.
13. If you feel pain or dizziness while exercising,
stop immediately and cool down.
14. Use your exercise cycle only as described in
this manual.
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your exercise cycle before using your exercise
cycle. ICON assumes no responsibility for personal injury or property damage sustained by or
through the use of this product.
IMPORTANT PRECAUTIONS

4
Congratulations for selecting the new WES O®
PURSUIT 330 exercise cycle. Cycling is an effective
exercise for increasing cardiovascular fitness, building
endurance, and toning the body. The PURSUIT 330
exercise cycle offers a selection of features designed
to let you enjoy this healthful exercise in the conve-
nience and privacy of your home.
For your benefit, read this manual carefully before
you use the exercise cycle. If you have questions
after reading this manual, please see the front cover
of this manual. To help us assist you, note the product
model number and serial number before contacting
us. The model number and the location of the serial
number decal are shown on the front cover of this
manual.
To avoid a registration fee for any service needed
under warranty, you must register the exercise
cycle at www.wesloservice.com/registration.
Before reading further, please review the drawing
below and familiarize yourself with the labeled parts.
Water Bottle Holder*
*Water bottle is not included
Resistance Knob
Seat
Seat Knob
Pedal/Strap
Console
Handlebar
Pulse Sensor
BEFORE YOU BEGIN

5
ASSEMBLY
To hire an authorized service technician to assemble the exercise cycle, call 1-800-445-2480.
Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the pack-
ing materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tool(s), assembly requires a Phillips screwdriver , an adjustable
wrench , and pliers .
As you assemble the exercise cycle, use the drawings below to identify the small parts used in assembly. The
number in parentheses below each drawing is the key number of the part, from the PART IST near the end of
this manual. The number following the parentheses is the quantity needed for assembly. Note: Some small
parts may have been preassembled. If a part is not in the hardware kit, check to see if it has been pre-
assembled.
M4 x 16mm
Screw (49)–4
M8 x 15mm Button
Screw (34)–3
M10 Locknut
(33)–4
M8 Locknut
(10)–5
M8 Split
Washer (42)–8
M10 x 65mm Carriage Bolt (30)–4
M8 x 58mm Button Bolt (6)–1
M4 x 5mm
Screw (14)–2
M4 x 16mm Bright
Screw (56)–1

6
1.
While another person lifts the front of the Frame
(1), attach a Stabilizer (2) with two M10 x 65mm
Carriage Bolts (30) and two M10 ocknuts (33)
(only one is shown).
2
33
30
1
1
2. While another person lifts the rear of the Frame
(1), attach a Stabilizer (2) with two M10 x 65mm
Carriage Bolts (30) and two M10 ocknuts (33).
30
2
1
33
33
2
3. The Console (16) requires four AA batteries (not
included); alkaline batteries are recommended.
IMPORTANT: If the Console has been
exposed to cold temperatures, allow it to
warm to room temperature before inserting
batteries. Otherwise, you may damage the
console displays or other electronic compo-
nents. Insert the batteries into the battery com-
partment. Make sure to orient the batteries as
shown by the diagram inside the battery
compartment.
16
Batteries
3
To make assembly easier, read the
information on page 5 before you begin
assembling the exercise cycle.

7
4. While another person holds the Console (16)
near the Handlebar (15), insert the console wire
into the indicated hole in the Handlebar.
Next, attach the ground wire to the Handlebar
(15) with an M4 x 16mm Bright Screw (56).
Tip: Avoid pinching the wires. Attach the
Console (16) to the Handlebar (15) with four M4
x 16mm Screws (49).
16
Avoid pinching
the wires
15
49
49
56
Hole
Console
Wire
Ground
Wire
4
5. While another person holds the Handlebar (15)
near the Upright (13), connect the console wire
to the Extension Wire (54).
Tip: Avoid pinching the wires. Attach the
Handlebar (15) to the Upright (13) with three M8
x 15mm Button Screws (34) and three M8 Split
Washers (42).
15
34
42
54
13
42
34
34 Console Wire
Avoid pinching
the wires
5

8
6. While another person holds the Upright (13)
near the Frame (1), connect the Extension Wire
(54) to the Wire Harness (53). Next, connect the
Resistance Cable (19) to the ower Cable (45) in
the following way:
•See drawing A. Pull upward on the metal
bracket on the ower Cable (45), and insert
the tip of the Resistance Cable (19) into the
wire clip inside the metal bracket as shown.
•See drawing B. Firmly pull the Resistance
Cable (19) upward and press it into the top of
the metal bracket as shown.
•See drawing C. Using pliers, squeeze the
prongs on the upper end of the metal bracket
together.
Insert the excess cable and wire downward into
the Frame (1). Insert the Upright (13) into the
Frame.
Tip: Avoid pinching the cables and wires.
Attach the Upright (13) with an M8 x 58mm
Button Bolt (6), an M8 Split Washer (42), and an
M8 ocknut (10).
42
53
19
45
1
13
6
10
54
ABC
45
19
19 Metal
Bracket
Metal
Bracket
45
Avoid pinching
the wires
6
7. Attach the Seat (12) to the Seat Post (5) with
four M8 Split Washers (42) and four M8
ocknuts (10).
Note: The M8 Split Washers (42) and the M8
ocknuts (10) may be preattached to the under-
side of the Seat.
42
12
42
10
10
5
7

9
10. Make sure that all parts are properly tightened before you use the exercise cycle. Note: After assembly is
completed, some extra parts may be left over. Place a mat beneath the exercise cycle to protect the floor.
8. Orient the Seat Bushing (8) so that the indicated
hole in the Seat Bushing is aligned with the indi-
cated hole in the Frame (1).
Press the Seat Bushing (8) into the Frame.
Attach the Seat Bushing with two M4 x 5mm
Screws (14).
Insert the Seat Post (5) into the Frame (1), and
align one of the adjustment holes in the Seat
Post with the hole in the Frame.
Next, insert the Seat Knob (9) through the
Frame (1) and the Seat Post (15), and then
tighten the Seat Knob. Make sure that the Seat
Knob is inserted through one of the adjust-
ment holes in the Seat Post. 1
5
Hole
Hole
Adjustment
Holes
9
8
14
14
9. Identify the eft Pedal (24), which is marked
with an “ .”
Using an adjustable wrench, firmly tighten the
eft Pedal (24) counterclockwise into the left
arm of the Crank (21). Tighten the Right Pedal
(not shown) clockwise into the right arm of the
Crank. IMPORTANT: Tighten both Pedals as
firmly as possible. After using the exercise
cycle for one week, retighten the Pedals. For
best performance, keep the Pedals tightened.
Adjust the strap on the eft Pedal (24) to the
desired position, and press the end of the strap
onto the tab on the eft Pedal. Adjust the
strap on the Right Pedal (not shown) in the
same way.
Strap
21
Tab
24
9
8

10
HOW TO USE THE EXERCISE CYCLE
HOW TO AD UST THE SEAT POST
For effective exer-
cise, the seat should
be at the proper
height. As you pedal,
there should be a
slight bend in your
knees when the ped-
als are in the lowest
position. To adjust
the height of the
seat, first loosen and
remove the seat
knob. Next, slide the
seat post upward or
downward and align one of the adjustment holes in
the seat post with the indicated hole in the frame.
Then, insert the knob into the frame and the seat post,
and then tighten the knob. Make sure that the knob
is inserted into one of the adjustment holes in the
seat post.
HOW TO AD UST THE PEDALING RESISTANCE
To increase the
resistance of the
pedals, turn the
resistance knob
clockwise; to
decrease the resis-
tance, turn the knob
counterclockwise.
IMPORTANT: To
avoid damaging the
exercise cycle, stop turning the knob when turning
it becomes difficult.
HOW TO AD UST THE PEDAL STRAPS
Pull the ends of the
pedals straps off
the tabs on the
pedals. Next, adjust
the straps to the
desired position,
and press the ends
of the straps onto
the tabs.
FEATURES OF THE CONSOLE
The console features a selection of modes that pro-
vide instant exercise feedback during your workouts.
•Speed—This mode displays your pedaling speed, in
miles per hour or kilometers per hour.
•Time—This mode displays the elapsed time. Note: If
you stop pedaling, the time mode will pause.
•Distance—This mode displays the distance you
have pedaled, in miles or kilometers.
•Calories—This mode displays the approximate
number of calories you have burned.
•Fat Calories—This mode displays the approximate
number of fat calories you have burned (see
Burning Fat on page 13).
•Pulse—This mode displays your heart rate when
you use the pulse sensor.
•Scan—This mode displays the speed, time, dis-
tance, calories, fat calories, and pulse modes, for a
few seconds each, in a repeating cycle. Note: The
pulse mode will be displayed only while the pulse
sensor is being used.
•Pace—The pace bar shows your pedaling pace, in
revolutions per minute (RPM). Note: The pace mode
will always be displayed while you are pedaling.
Seat Post
Knob
Pedal
Strap
Tab
Resistance
Knob
Hole
Seat
