VERSALINK™ GATEWAY (MODEL 327W)
USER GUIDE

030-300408 Rev. B 2 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
TABLE OF CONTENTS
1. PRODUCT DESCRIPTION ..................................................................................................................................4
2. SAFETY INSTRUCTIONS...................................................................................................................................4
3. REGULATORY INFORMATION........................................................................................................................5
3.1 FCC Compliance Note...............................................................................................................................5
3.2 Canada Certification Notice.......................................................................................................................6
4. NETWORKING REQUIREMENTS .....................................................................................................................8
5. HARDWARE FEATURES....................................................................................................................................9
5.1 LED Indicators...........................................................................................................................................9
5.2 Cable Connectors and Switch Locations .................................................................................................10
5.3 Connector Descriptions............................................................................................................................10
5.4 Pinout Descriptions..................................................................................................................................11
6. INSTALLING THE HARDWARE......................................................................................................................12
6.1 Installation Requirements........................................................................................................................12
6.2 Before you begin......................................................................................................................................12
6.3 Microfilters..............................................................................................................................................12
6.4 Hardware Installations.............................................................................................................................13
7. INSTALLING THE USB DRIVERS...................................................................................................................18
7.2 Installing the USB Drivers for Windows ME..........................................................................................24
7.3 Installing the USB Driver for Windows 2000 .........................................................................................26
7.4 Installing the USB Driver for Windows XP ............................................................................................29
8. CONFIGURING VERSALINK FOR INTERNET CONNECTION...................................................................31
8.1 Setting Up an Account Profile.................................................................................................................31
8.2 Confirm a DSL Sync ...............................................................................................................................36
8.3 Establishing a PPP Session......................................................................................................................38
8.4 Disconnecting a PPP Session...................................................................................................................40
9. SETTING UP MACINTOSH OS X.....................................................................................................................41
10. SETTING UP ADVANCED CONFIGURATION ..............................................................................................46
11. HOME..................................................................................................................................................................47
11.1 Adding Account Profiles .........................................................................................................................48
11.2 Editing Account Profiles..........................................................................................................................49
12. STATUS...............................................................................................................................................................51
12.1 Connection Summary ..............................................................................................................................51
12.2 About.......................................................................................................................................................52
13. CONFIGURATION.............................................................................................................................................53

030-300408 Rev. B 3 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
13.1 Single Static IP – Single IP Address PassThrough..................................................................................53
13.2 Service Configuration..............................................................................................................................58
13.3 Firewall Configuration.............................................................................................................................70
13.4 Wireless Configuration............................................................................................................................74
13.5 Advanced LAN........................................................................................................................................80
13.6 Advanced WAN.......................................................................................................................................96
14. SETTING UP ADVANCED SERVICE CONFIGURATION...........................................................................127
14.1 Port Forwarding Ranges of Ports...........................................................................................................128
14.2 Adding Port Forwarding Ports...............................................................................................................128
14.3 Port Forwarding Trigger Ports...............................................................................................................129
14.4 Adding Local Trigger Ports...................................................................................................................130
14.5 Static NAT.............................................................................................................................................131
14.6 Enabling Static NAT..............................................................................................................................132
14.7 Disabling Static NAT.............................................................................................................................133
15. MAINTENANCE...............................................................................................................................................135
15.1 Backup/Restore......................................................................................................................................135
15.2 Firewall Log ..........................................................................................................................................136
15.3 Administrative Password.......................................................................................................................138
15.4 Remote Access.......................................................................................................................................139
15.5 Update Device .......................................................................................................................................140
16. TROUBLESHOOTING.....................................................................................................................................145
16.1 System Self Tests...................................................................................................................................145
16.2 Diagnostic Logs.....................................................................................................................................147
16.3 Statistics.................................................................................................................................................151
16.4 Wireless Statistics..................................................................................................................................154
16.5 Status .....................................................................................................................................................156
17. NAT SERVICES................................................................................................................................................162
18. HELP..................................................................................................................................................................166
19. TECHNICAL SUPPORT INFORMATION......................................................................................................183
20. WARRANTY AND REPAIRS..........................................................................................................................183
21. PRODUCT SPECIFICATIONS.........................................................................................................................184
22. SOFTWARE LICENSE AGREEMENT............................................................................................................185
23. PUBLICATION INFORMATION.....................................................................................................................187

030-300408 Rev. B 4 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
1. PRODUCT DESCRIPTION
The Westell® VersaLink™ Gateway provides reliable, high-speed, Internet access to your existing small office
phone line. Your ADSL connection is “always-on” ending the hassles of dial-up modems and busy signals.
Installation is easy ... no tools ... no headaches. Simply connect the hardware, apply power, and perform the simple
software configuration for VersaLink and you are on the Internet.
VersaLink™ is capable of data rates hundreds of times faster than a traditional analog modem. But unlike analog
modems, VersaLink™ allows you to use the same phone line for simultaneous voice/fax communications and high-
speed Internet access, eliminating the need for dedicated phone lines for voice and data needs. VersaLink™
supports a variety of networking interfaces such as wireless 802.11b/g/g+, ADSL, Ethernet and the following
optional features:
• VersaPort™: Alternate WAN uplink port
• Layer w/2 QOS with VLAN tagging
• HotSpot
• Simultaneous public/private network support
Hereafter, the Westell® VersaLink™ Gateway will be referred to as “VersaLink” or “Gateway.”
2. SAFETY INSTRUCTIONS
• Never install any telephone wiring during a lightning storm.
• Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.
• Never touch non-insulated telephone wires or terminals unless the telephone line has been disconnected at
the network interface.
• Use caution when installing or modifying telephone lines.
WARNING
Risk of electric shock. Voltages up to 140 Vdc (with reference to
ground) may be present on telecommunications circuits.

030-300408 Rev. B 5 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
3. REGULATORY INFORMATION
3.1 FCC Compliance Note
(FCC ID: CH8327WXX-6)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the Federal Communication Commission (FCC) Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment OFF and ON, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to a different circuit from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Modifications made to the product, unless expressly approved by Westell Inc., could void the users’ right to
operate the equipment.
RF EXPOSURE
This device has been tested and complies with FCC RF Exposure (SAR) limits in typical laptop computer
configurations and this device can be used in desktop or laptop computers with side-mounted PCMCIA slots,
which can provide 1 cm separation distance from the antenna to the body of the user or a nearby person.
Thin laptop computers may need special attention to maintain antenna spacing while operating. This device
cannot be used with handheld PDAs (personal digital assistants). Use in other configurations may not ensure
compliance with FCC RF exposure guidelines. This device and its antenna must not be co-located or operate
in conjunction with another antenna or transmitter.
PART 68 – COMPLIANCE REGISTRATION
This equipment (Model 327W) complies with Part 68 of the FCC rules and the requirements adopted by the ACTA.
A label on the bottom of this equipment contains, among other information, the Ringer Equivalence Number (REN)
and the product identifier. For products approved after July 23, 2001 the product identifier is in the format
US:AAAEQ##TXXXX. The digits represented by ## are the REN without a decimal point (e.g. 03 is a REN of 0.3).
The REN is used to determine the number of devices that may be connected to a telephone line. For earlier products,
the REN is separately shown on the label. If requested, this number must be provided to the telephone company.
Excessive RENs on a telephone line may result in the devices not ringing in response to an incoming call. In most,
but not all areas, the sum of RENs should not exceed five (5.0). To be certain of the number of devices that may be
connected to a line, as determined by the total RENs, contact the local telephone company.
This equipment is designated to connect to the telephone network or premises wiring using a compatible modular
jack that is Part 68 compliant. An FCC compliant telephone cord and modular plug is provided with the equipment.
See the Installation Information section of this User Guide for details.

030-300408 Rev. B 6 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the
applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant telephone cord and modular plug
is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. See
installation instruction for details.
If this terminal equipment (Model 327W) causes harm to the telephone network, the telephone company may
request you to disconnect the equipment until the problem is resolved. The telephone company will notify you in
advance if temporary discontinuance of service is required. If advance notification is not practical, the telephone
company will notify you as soon as possible. You will be advised of your right to file a complaint with the FCC if
you believe such action is necessary.
If you experience trouble with this equipment (Model 327W), do not try to repair the equipment yourself. The
equipment cannot be repaired in the field. Contact your ISP, or contact the original provider of your DSL equipment.
The telephone company may make changes to their facilities, equipment, operations, or procedures that could affect
the operation of this equipment. If this happens, the telephone company will provide advance notice in order for you
to make the modifications necessary to maintain uninterrupted service.
If your home has specially wired alarm equipment connected to the telephone line, ensure that the installation of this
equipment (Model 327W) does not disable your alarm equipment. If you have questions about what will disable
alarm equipment, consult your telephone company or a qualified installer.
This equipment cannot be used on public coin phone service provided by the telephone company. Connection of this
equipment to party line service is subject to state tariffs.
3.2 Canada Certification Notice
The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain
telecommunications network protective, operations and safety requirements as prescribed in the appropriate
Terminal Equipment Technical Requirements document(s). The department does not guarantee the equipment will
operate to the user’s satisfaction.
This equipment meets the applicable Industry Canada Terminal Equipment Technical Specification. This is
confirmed by the registration number. The abbreviation, IC, before the registration number signifies that registration
was performed based on a Declaration of Conformity indicating that Industry Canada technical specification were
met. It does not imply that Industry Canada approved the equipment. The Ringer Equivalence Number (REN) is 0.0.
The Ringer Equivalence Number that is assigned to each piece of terminal equipment provides an indication of the
maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface
may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence
Numbers of all the devices does not exceed five.
Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the
local Telecommunication Company. The equipment must also be installed using an acceptable method of
connection. The customer should be aware that compliance with the above conditions may not prevent degradation
of service in some situations. Connection to a party line service is subject to state tariffs. Contact the state public
utility commission, public service commission, or corporation commission for information.
If your home has specially wired alarm equipment connected to the telephone line, ensure that the installation of this
equipment (Model 327W) does not disable your alarm equipment. If you have questions about what will disable
alarm equipment, consult your telephone company or a qualified installer.
If you experience trouble with this equipment (Model 327W), do not try to repair the equipment yourself. The
equipment cannot be repaired in the field and must be returned to the manufacturer. Repairs to certified equipment

030-300408 Rev. B 7 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
should be coordinated by a representative, and designated by the supplier. Refer to section 20 in this User Guide for
further details.
The termination on an interface may consist of any combination of devices subject only to the requirement that the
sum of the Ringer Equivalence Numbers of all the devices does not exceed five.
Users should ensure, for their own protection, that the electrical ground connections of the power utility, telephone
lines, and internal, metallic water pipe system, if present, are connected together. This precaution may be
particularly important in rural areas.
CAUTION
Users should not attempt to make such connections themselves, but should contact the
appropriate electrical inspection authority, or electrician, as appropriate.

030-300408 Rev. B 8 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
4. NETWORKING REQUIREMENTS
The following system specifications are required for optimum performance of the VersaLink™ via 10/100 Base-T
or Wireless installations.
CONNECTION
TYPE MINIMUM SYSTEM REQUIREMENTS NETWORKING
SCHEME
ETHERNET
• Pentium®or equivalent class machines
• Microsoft® Windows®(95, 98, ME, 2000, NT 4.0, or
XP) Macintosh®OS X, or Linux installed
• 64 MB RAM (128 MB recommended)
• 10 MB of free hard drive space
• TCP/IP Protocol stack installed
• 10/100 Base-T Network Interface Card (NIC)
• Computer Operating System CD-ROM on hand
Networking via 10/100
Base-T Ethernet
requires an available
Ethernet port with a
10/100 Base-T Network
Interface Card (NIC)
installed.
WIRELESS
IEEE 802.11g
• Pentium®or equivalent class machines
• Microsoft®Windows® (98, ME, 2000, or XP) or
Macintosh®OS X installed
• Computer Operating System CD-ROM on hand
• Internet Explorer 4.x or Netscape Navigator 4.x or
higher
• 64 MB RAM (128 MB recommended)
• 10 MB of free hard drive space
• An available IEEE 802.11b/g/g+ PC adapter
Networking via
Wireless or other
802.11b/g/g+ capable
network adapter card.
USB
• Pentium®or equivalent and above
• Microsoft®Windows®98 SE, ME, 2000, or XP
installed
• Computer operating system CD-ROM on hand
• Internet Explorer 4.x or Netscape Navigator 4.x or
higher
• 64 MB RAM (128 MB recommended)
• 10 MB of free hard drive space
• USB Version 1.0 or higher compliant bus
Networking via USB
Version 1.0 or higher
compliant bus.

030-300408 Rev. B 9 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
5. HARDWARE FEATURES
5.1 LED Indicators
This section explains the LED States and Descriptions. LED indicators are used to verify the unit’s operation and
status.
LED States and Descriptions
LED State Description
Solid Green Modem power is ON.
OFF Modem power is OFF.
POWER
Solid Red
POST (Power On Self Test), Failure (not bootable) or Device
Malfunction. Note: The Power LED should be red no longer than
two seconds after the power on self test passes.
Solid Green
Powered device is connected to the associated port (includes
devices with wake-on LAN capability where slight voltage is
supplied to an Ethernet connection).
Note: When using the optional uplink port (E1), Ethernet LAN
connection is limited to E2, E3, and E4.
Flashing Green 10/100 Base-T LAN activity is present (traffic in either direction)
ETHERNET
(E1, E2, E3, E4)
OFF Modem power is OFF, no cable or no powered device is
connected to the associated port.
Solid Green Link Established.
Flashing Green Wireless LAN activity is present (traffic in either direction).
WIRELESS
OFF Modem power is OFF or No Link.
Solid Green USB link established
Flashing Green Transmit or Receive Activity
USB
OFF No USB link established
Solid Green Good DSL sync.
Flashing Green DSL attempting to sync.
DSL
OFF Modem power is OFF.
Solid Green Internet link established.
Flashing Green
IP connection established and IP Traffic is passing through
device (in either direction).
Note: If the IP or PPP session is dropped due to an idle timeout,
the light will remain solid green, if an ADSL connection is still
present.
If the session is dropped for any other reason, the light is turned
OFF. The light will turn red when it attempts to reconnect and
DHCP or PPP fails).
Solid Red
Device attempted to become IP connected and failed (no DHCP
response, no PPP response, PPP authentication failed, no IP
address from IPCP, etc.).
INTERNET
OFF Modem power is OFF, Modem is in Bridge Mode, or the
connection is not present.
NOTE: Safe Boot is reflected when the Power and Internet LED’s are both Red and all other LED’s are off.

030-300408 Rev. B 10 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
5.2 Cable Connectors and Switch Locations
• DSL connector (RJ-11)
• USB connector
• Reset button
• (4) Ethernet connector (RJ-45) with optional uplink port
(Note: When using the optional uplink port (E1), Ethernet LAN connection is limited to E2, E3, and E4.
• Power connector (barrel)
• ON/OFF Switch
• Wireless IEEE 802.11b/g SMA connector and antenna
Note: When using the optional uplink port (E1), Ethernet LAN connection is limited to E2, E3, and E4.
The UPLINK feature is optional, and if UPLINK is not enabled in the .ini file, the Gateway will use DSL
and Wireless only.
5.3 Connector Descriptions
The following chart displays the connector types.
SYMBOL NAME TYPE FUNCTION
DSL LINE 6-pin RJ-11 modular jack Connects to an ADSL-equipped telephone jack or
DSL connection of a POTS splitter.
USB 4-pin USB Series B connector Connects the USB device to the PC.
ETHERNET 8-pin (RJ-45) modular jack Connects the Ethernet device to the PC.
DC 12V POWER Barrel connector Power source.
Wireless ANTENNA SMA connector and antenna Connects to wireless IEEE 802.11b/g/g+
DSL Line
Connector ON/OFF
Switch
Power
Connector
Ethernet Connectors
(E1 through E4)
Reset
Button Wireless Antenna
Connector
USB
Connector

030-300408 Rev. B 11 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
5.4 Pinout Descriptions
The following tables list the pinout descriptions.
DSL Pinouts
Pinout Description
1, 2, 5, 6 Not Used
3 DSL Tip
4 DSL Ring
USB Pinouts
Pin Name Description Cable Color
1 VBUS/Vcc 5 Vdc Red
2 D – Data – White
3 D + Data + Green
4 GND Ground Black
Ethernet/Optional Uplink Port Pinouts
Pinout Description
1 Rx+
2 Rx-
3 Tx+
4,5,7,8 Not Used
6 Tx-

030-300408 Rev. B 12 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
6. INSTALLING THE HARDWARE
6.1 Installation Requirements
To install VersaLink™, you will need the following:
• A Network Interface Card (NIC) installed in your PC, or
• An IEEE 802.11b/g adapter
NOTE: Internet service provider subscriber software and connection requirements may vary. Consult your ISP for
installation instructions. Please wait until you have received notification from your ISP that your DSL line has been
activated before installing VersaLink™ and the software.
6.2 Before you begin
Make sure that your kit contains the following items:
• Westell VersaLink™ Gateway
• Power Supply
• RJ-45 Ethernet cable
• USB cable
• RJ-11 Phone cable
• SMA Antenna
• Westell CD-ROM containing User Guide in PDF format
• Quick Start Guide
6.3 Microfilters
ADSL signals must be blocked from reaching each telephone, answering machine, fax machine, computer modem
or any similar conventional device. Failure to do so may degrade telephone voice quality and ADSL performance.
Install a microfilter if you desire to use the DSL-equipped line jack for telephone, answering machine, fax machine
or other telephone device connections. Microfilter installation requires no tools or telephone rewiring. Just unplug
the telephone device from the baseboard or wall mount and snap in a microfilter, next snap in the telephone device.
You can purchase microfilters from your local electronics retailer, or contact the original provider of your DSL
equipment.

030-300408 Rev. B 13 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
6.4 Hardware Installations
Westell recommends using this product via Wireless or Ethernet connections. However, if you choose to connect via
USB, you must follow the instructions in Appendix A of this User Guide.
NOTE: Please wait until you have received notification from your ISP that your DSL line has been
activated before installing VersaLink.
NOTE: If you are using VersaLink™ in conjunction with an Ethernet Hub or Switch, refer to the manufacturer’s
instructions for proper installation and configuration. When using a Microfilter, be certain that the DSL phone cable
is connected to the “DSL/HPN” non-filtered jack. Westell recommends the use of a surge suppressor to protect
equipment attached to the power supply.
6.4.1 Installation via 10/100 Base-T Ethernet
NOTE: Before you connect via 10/100 Base-T, you must have an available Ethernet card installed in your
computer. If your Ethernet card does not auto-negotiate, you must set it to half duplex. Refer to the
Ethernet card manufacturer’s instructions for installing and configuring your Ethernet card.
1. Connect the power supply cord to the power connector marked DC 12V on the rear panel of VersaLink. Plug
the other end of the power supply into a wall socket.
2. Connect the DSL phone cable from the connector marked on the rear panel of VersaLink to the DSL-
equipped telephone line jack on the wall. IMPORTANT: Do not use a DSL filter on this connection. You must
use the phone cord that was provided with the kit.
3. Connect the yellow Ethernet cable from any one of the Ethernet jacks marked
on the rear panel of
VersaLink to the Ethernet port on your computer. Repeat this step to connect up to three additional PCs to
VersaLink.
NOTE: You may connect to any of the four Ethernet jacks on the rear panel as they serve as an Ethernet switch.
However, when using the optional uplink port (E1), Ethernet LAN connection is limited to ports E2, E3, and E4.
4. Check to see if the DSL LED is solid green. If the DSL LED is solid green, VersaLink is functioning properly.
5. Check to see if the Ethernet LED is solid green. Solid green indicates that the Ethernet connection is
functioning properly.
Congratulations! You have completed the Ethernet hardware installation. No software installation is required when
using only an Ethernet connection. Proceed to section 8 to configure VersaLink for Internet connection.
!

030-300408 Rev. B 14 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
Figure 1. Connection via 10/100 Base-T Ethernet
6.4.2 Connecting PCs via Wireless
IMPORTANT: If you are connecting to VersaLink via a wireless network adapter, the SSID must be the same for
both VersaLink and your PC’s wireless network adapter. The default SSID for VersaLink is the serial number of the
unit (located below the bar code on the bottom of the unit and also on the Westell shipping carton). Locate and run
the utility software provided with your PC’s Wireless network adapter and enter the SSID value. The PC’s wireless
network adapter must be configured with the SSID (in order to communicate with VersaLink) before you begin the
account setup and configuration procedures. Later, for privacy you can change the SSID by following the
procedures outlined in section 13.4 (Wireless Configuration).
NOTE: Client PCs can use any Wireless Fidelity (Wi-Fi) 802.11b/g certified card to communicate with VersaLink.
The Wireless card and VersaLink must use the same Wired Equivalent Privacy (WEP) security code type. The
factory default for WEP is DISABLED. If you enable WEP, you must ensure the network setting for your wireless
adapter is set to “Must Use Shared Key for WEP” or “Open Wi-Fi.” You must ensure that your PC’s Wi-Fi adapter
is configured properly for whichever network setting you use. You can access the settings in the advanced properties
of the wireless network adapter.

030-300408 Rev. B 15 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
To network VersaLink to additional computers in your home or office using a wireless installation, you will need to
confirm the following:
1. Ensure that an 802.11b/g/g+ wireless network adapter has been installed in each PC on your wireless network.
2. Install the appropriate drivers for your Wireless IEEE802.11b or IEEE802.11g adapter.
3. Make sure the SMA antenna connector is loose. Orient the antenna in the proper configuration. Then, tighten
the antenna knob to lock it into place.
4. Connect the power supply cord to the power connector marked DC 12V on the rear panel of VersaLink. Plug
the other end of the power supply into a wall socket.
5. Connect the DSL phone cable from the connector marked on the rear panel of VersaLink to the DSL-
equipped telephone line jack on the wall. IMPORTANT: Do not use a DSL filter on this connection. You must
use the phone cord that was provided with the VersaLink kit.
6. Check to see if the DSL LED is solid Green. If the DSL LED is solid Green, VersaLink is functioning properly.
7. Check to see if VersaLink’s Wireless LED is solid Green. This means that the Wireless interface is functioning
properly.
Congratulations! You have completed the Wireless installation VersaLink. You must now go to section 8 to
configure VersaLink for Internet connection.
Figure 2. Connection via Wireless

030-300408 Rev. B 16 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
6.4.3 Installation via Ethernet and Wireless Combination
The VersaLink™ supports simultaneous use of 10/100 Base-T Ethernet and Wireless configurations. The following
instructions explain how to install VersaLink for simultaneous use of Ethernet and Wireless ports.
NOTE: Refer to Figure 1 and Figure 2 for instructions on hardware installation via Ethernet and Wireless
connections.
1. Ensure that an 802.11b/g/g+ wireless network adapter has been installed in each PC on your wireless network
2. Install the appropriate drivers for your Wireless IEEE802.11b or IEEE802.11g adapter.
3. Make sure the SMA antenna connector is loose. Orient the antenna in the proper configuration. Then, tighten
the antenna knob to lock it into place.
4. Connect the power supply cord to the power connector marked DC 12V on the rear panel of VersaLink. Plug
the other end of the power supply into a wall socket.
5. Connect the DSL phone cable from connector marked on the rear panel of VersaLink to the DSL-equipped
telephone line jack on the wall. IMPORTANT: Do not use a DSL filter on this connection. You must use the
phone cord that was provided with the kit.
6. Connect the yellow Ethernet cable from any one of the Ethernet jacks marked
on the rear panel of
VersaLink to the Ethernet port on your computer. Repeat this step to connect up to three additional PCs to
VersaLink.
NOTE: You may connect to any of the four Ethernet jacks on the rear panel as they serve as an Ethernet switch.
However, when using the optional uplink port (E1), Ethernet LAN connection is limited to ports E2, E3, and E4.
7. Check to see if the DSL LED is solid green. If the DSL LED is solid green, VersaLink is functioning properly.
8. Check to see if the Ethernet LED is solid green. Solid green indicates that the Ethernet connection is
functioning properly.
9. Check to see if VersaLink’s Wireless LED is solid green. This means that the Wireless interface is functioning
properly.
Congratulations! You have completed the simultaneous hardware (Ethernet and Wireless) installation. You must now
go to section 8 to configure VersaLink for Internet connection.

030-300408 Rev. B 17 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
6.4.4 Installation via USB
Westell recommends using VersaLink via Wireless or Ethernet connections. However, if you choose to connect via
USB, you must follow the instructions in this section.
NOTE: The USB installation will not function for Macintosh computers. Macintosh computers must install
via Ethernet connection. See section 6.4.1 for Ethernet installation instructions.
1. Connect the power supply cord to the power connector marked DC 12V on the rear panel of VersaLink. Plug
the other end of the power supply into a wall socket.
2. Connect the DSL phone cable from the jack marked on the rear panel of VersaLink to the DSL-equipped
telephone line jack on the wall. IMPORTANT: Do not use a DSL filter on this connection. You must use the
phone cord that was provided with the kit.
3. Connect the blue USB cable from the USB connector marked on the rear panel of VersaLink to the
USB port on the PC.
4. Check to see if the DSL LED is solid green. If the DSL LED is solid green, VersaLink is functioning properly.
5. Check to see if the USB LED is solid green. Solid green indicates that the USB connection is functioning
properly.
Congratulations! You have completed the USB hardware installation. You must now proceed to section 7 (Installing
the USB Drivers) to install the USB software needed for your connection. After you complete the USB driver
installation, proceed to section 8 to configure VersaLink for Internet connection.
Figure 3. Connection via USB
!

030-300408 Rev. B 18 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
7. INSTALLING THE USB DRIVERS
If you are using only Ethernet or Wireless connections, USB driver installation is not necessary. The Microsoft®
Plug and Play auto-detect feature recognizes when new hardware has been installed. After you connect VersaLink to
the PC, VersaLink will be detected automatically.
Before you begin the USB software installation, determine which operating system is installed on your PC, and then
follow the installation instructions that match your operating system. When the installation has completed, proceed
to section 8 in the User Guide to configure VersaLink for Internet connection. The following table provides a
reference to the USB driver installation instructions.
Your Operating System Refer to this section for USB driver instructions
Windows 98 SE Installing the USB Driver for Windows 98 SE
Windows ME Installing the USB Driver for Windows ME
Windows 2000 Installing the USB Driver for Windows 2000
Windows XP Installing the USB Driver for Windows XP
7.1.1 CD-ROM Installation:
1. Place the CD-ROM that you received in the VersaLink kit into the CD-ROM drive of the PC that is connected
to the USB port.
2. Verify the connection to the computer by observing the state of the USB LED. Once the USB drivers have been
installed, the USB LED should be solid green. Solid green indicates a USB connection has been established.
3. Go to the USB driver installation section that matches your operating system and follow the procedures outlined
in that section.
NOTE: The actual information displayed in the USB screens may vary according to product.
7.1.2 Installing the USB Drivers for Windows 98 SE
IMPORTANT: Confirm that the CD-ROM provided with the VersaLink kit is inserted in the
appropriate drive before continuing this installation.
1. Windows 98 SE: After you connect VersaLink to your PC, the Found New Hardware window will appear
(Figure 4). After a brief delay, the Add New Hardware Wizard window will appear (Figure 5) Click Next.
Figure 4. Windows 98 SE
!

030-300408 Rev. B 19 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
Figure 5. Windows 98 SE
2. Windows 98 SE: Select Search for the best driver for your device. (Recommended). See Figure 6. Click
Next.
Figure 6. Windows 98 SE

030-300408 Rev. B 20 August 2005
VersaLink™ Gateway (Model 327W)
User Guide
3. Windows 98 SE: Select CD-ROM drive (Figure 7). Click Next. Windows will search for the driver.
Figure 7. Windows 98 SE
Note: If Figure 7 does not appear at this step, and Figure 8 appears with the text ‘USB Composite device’,
‘C:\Windows\Inf\USB.Inf’, do not continue. Click Back to Step 3 and specify the location of the Westell
CD-ROM.
4. Windows 98 SE: Select The updated driver (Recommended) Westell USB Network Interface (Figure 8).
Click Next.
Figure 8. Windows 98 SE
!
