WFA K-CTF User manual

1
2
3
5
4
INCLUSIONS: 1. countertop filter unit 2. 1 micron carbon block filter cartridge
3. tightening wrench 4. alternate fittings 5. alarm monitor
MODEL: K-CTF
INSTALLATION INSTRUCTIONS
Countertop Water Filter
The system and installation must comply with all state and local laws and
regulations.
Do not use with water that is microbiologically unsafe or of unknown
quality without adequate disinfection before or after the system.
Systems certified for cyst reduction may be used on disinfected waters
that may contain filterable cysts.
Flow Rate 3 Litres per minute
Min/Max Operating Pressure 10psi - 90psi
Min/Max Operating Temperature 4 C – 38 C
Capacity 3,800 litres or 12 months
Cartridge Included 1 micron Carbon Block filter
When to change the filter cartridge
Change the filter cartridge every 12 months or sooner if bad taste and
odour return, or if the water flow is noticeably reduced.
Inspect the O-Ring for damage and lubricate with food grade grease.
1 Separate the base of the filter housing from the upper housing by
unscrewing the two pieces (the base has the chrome spout attached to
it).
2 Unscrew the aerator from the kitchen sink faucet (Figure 1)
3 Attach the diverter valve to the kitchen faucet (Figure 2) – hand tighten
only.
4 Unwrap the filter cartridge – make sure your hands are clean.
5 Place filter cartridge on the base of the filter housing making sure it fits
neatly and firm.
6 Place the upper housing over the filter cartridge and gently screw the
two housings together – making sure that the o-ring does not kink.
7 Turn the cold water on at the main tap – turn the countertop filter unit
water supply on at the diverter valve. (Figure 3).
stroke: 1.8
then after outline 0.2 @ 90% K + braid pattern fill
FIGURE 1
stroke: 1.8
then after outline 0.2 @ 90% K + braid pattern fill
stroke: 1.8
then after outline 0.2 @ 90% K + braid pattern fill
FIGURE 2
FIGURE 3

• Installandusethislteroncoldwateronly.Donotuseonwaterlinesexceeding100°F
(38°C).Waterpressureminimumis10psiandthemaximumis90psi.
• Protectunitfromdirectsunlightandfreezingtemperatures.
• Keepunitcleanwithsoapandwater.Donotusespraycleanersorinsecticidesnearunit.
• Intendedforindoor,non-commercialuseonly.
• Forextendedperiodsofnon-useturnthewateroffandremovetheltercartridge.Place
the cartridge in a plastic bag, seal and refrigerate.
• Tubingandhousingdimensionsarebasedonoutsidediameters(OD).Forwaterlinesizes
other than those listed, consult a plumber or hardware store.
• Beforeusingthewater,ushthenewlterfor2minutes.
• Changecartridgeatmanufacturer’ssuggestedintervalorsoonerifyounoticeachangein
colour, taste or low water pressure.
• Thislterisnotawaterpurierandisnotintendedforusewithcontaminatedwater.
• Complywithallstateandlocallawsregardingtheinstallationofwatertreatmentdevices.
• Donotusewithwaterthatismicrobiologicallyunsafeorofunknownqualitywithout
adequatedisinfectionbeforeorafterthesystem.
• TherubberO-ringprovidesthewatertightsealbetweenthecapandthehousing.Itis
important that the O-ring be properly seated in the groove in the housing or a water leak
could occur.
• Thecontaminantsorothersubstancesremovedorreducedbythiswaterlterdeviceare
not necessarily in your water.
• DONOTusewrenchtotightenhousing.
• UsewrenchONLYforhousingremoval
PLEASE NOTE
Distributed by Water Filters Australia Pty Limited ABN: 78 089 574 489
Unit 1, 91-93 Old Pittwater Road, Brookvale NSW 2100
PO Box 636 Freshwater NSW 2096
Phone: [phone]
Fax: [phone]
Email: info@waterfiltersaust.com.au
Web: www.waterfiltersaust.com.au
For all enquiries call the National Customer Service Centre on: 1300 785 355
