Wharfedale Pro Reason-X18B User manual

Passive Loudspeakers
Reason SERIES
Reason-X18B Reason-X218
Reason-X12 Reason-X15
www.wharfedalepro.com

TABLE OF CONTENTS
Important warnings & safety instructions ………………………………….1
Product features .………………………….……………………………………….2 - 3
Dimensional drawings ...…………………………………..………………………4 - 5
Specifications ...…………………………………………………………..…………6 - 7

IMPORTANT WARNINGS & SAFETY INSTRUCTIONS
1
1. READ ALL INSTRUCTIONS – Carefully and become familiar with the features and functions of these products before operating
them.
2. RETAIN THESE INSTRUCTIONS – For future reference.
3. COMPLY WITH ALL WARNINGS – Non compliance may void warranty of the product.
4. USE WITH AMPLIFIERS – In order to avoid damage to drivers and other equipment, it is advisable to establish and follow a
routine for powering up and powering down a sound system. With all system components connected, turn on source equipment
(mixers, signal processors, record and playback units etc.) BEFORE powering up amplifiers. Transient voltages from powering up
source equipment can damage speakers if amplifiers are already turned on.
Make sure that amplifier volumes are set to their minimum settings and power up any system amplifiers LAST. It is recommended
that all system components be allowed to stabilize for few seconds before any source signals are introduced or level setting
adjustments are made. Similarly, when shutting systems down, turn all amplifiers off first, before powering down any other
system components.
5. CABLES – Do not use shielded or microphone cables for connection between amplifiers and speakers. Use only approved
speaker cables with proper connectors.
6. RIGGING – SUSPENDING – MOUNTING – RIGGING – Suspending and mounting of these speaker systems can expose members
of the public to serious health risks and even death. Under no circumstances attempt to rig, suspend or otherwise mount these
speakers unless you are fully qualified and certified to do so by relevant local, state and national authorities. All relevant safety
regulations must be followed. If you are not properly qualified or do not know of pertinent regulations, consult qualified personnel
for advice.
7. CAUTION – These professional loudspeaker systems are capable of generating very high sound pressure levels. Use care with
placement and operation to avoid exposure to excessive volume levels. Permanent hearing damage can result when operated to
extreme levels.
8. SERVICE – There are no user serviceable parts inside this product. Users should not attempt to service this product.
Warranty nullification could result if this is attempted.
9. UNPACKING - All Wharfedale Pro products are fully checked before leaving our factory. After unpacking please inspect the
cabinets for any physical damage Please retain the shipping carton if possible and internal packing material incase the unit ever
needs to be returned. Please check as soon as possible that the unit is functioning. In the event of any damage please contact your
dealer immediately so that a written claim for damage can be made.

The Reason-X Series of loudspeakers has been meticulously crafted to be at the forefront of audio technology.
Reason-X is a versatile loudspeaker for live performance or permanently installed audio reproduction and is built
around the vast experience of the Wharfedale Pro design team.
The high frequency compression driver is unique. Delivering a spacial feel to the high frequencies due it its efficient
neodymium magnet. This is enhanced by a polyethylene diaphragm which, as you will shortly experience, gives a
freshness, a clarity and a crispness to the high frequencies which is unparalleled.
Close your eyes and enjoy the new detail you will find in your audio.
PRODUCT FEATURES
2
Reason-X18B
10”, 2-way passive loudspeaker
2.5” LF voice coil
1.5 inch ring-shaped polyethylene flat diaphragm
Neodymium HF magnet
Rotatable waveguide with 100° x 70° dispersion
Birch plywood construction
128dB max SPL
60Hz - 20kHz
300w RMS
600w Programme
1200w Peak
Reason-X218B
12”, 2-way passive loudspeaker
3.0” LF voice coil
1.5 inch ring-shaped polyethylene flat diaphragm
Neodymium HF magnet
Rotatable waveguide with 100° x 70° dispersion
Birch plywood construction
130dB max SPL
55Hz - 20kHz
400w RMS
800w Programme
1600w Peak

The Reason-X Series of loudspeakers has been meticulously crafted to be at the forefront of audio technology.
Reason-X is a versatile loudspeaker for live performance or permanently installed audio reproduction and is built
around the vast experience of the Wharfedale Pro design team.
The high frequency compression driver is unique. Delivering a spacial feel to the high frequencies due it its efficient
neodymium magnet. This is enhanced by a polyethylene diaphragm which, as you will shortly experience, gives a
freshness, a clarity and a crispness to the high frequencies which is unparalleled.
Close your eyes and enjoy the new detail you will find in your audio.
PRODUCT FEATURES
3
Reason-X12
10”, 2-way passive loudspeaker
2.5” LF voice coil
1.5 inch ring-shaped polyethylene flat diaphragm
Neodymium HF magnet
Rotatable waveguide with 100° x 70° dispersion
Birch plywood construction
128dB max SPL
60Hz - 20kHz
300w RMS
600w Programme
1200w Peak
Reason-X15
12”, 2-way passive loudspeaker
3.0” LF voice coil
1.5 inch ring-shaped polyethylene flat diaphragm
Neodymium HF magnet
Rotatable waveguide with 100° x 70° dispersion
Birch plywood construction
130dB max SPL
55Hz - 20kHz
400w RMS
800w Programme
1600w Peak

DIMENSIONAL DRAWINGS
4
Reason-X18B
Reason-X218B
560.0
600.0 756.0
1065.0
560.0 756.0

DIMENSIONAL DRAWINGS
5
Reason-X12
Reason-X15
350.0
410.0
258.046.0
46.0
258.046.0
95.0
95.0 814.0
46.0 46.0
430.0
455.0
338.046.0
125.0 46.0
338.046.0
125.0
46.0 46.0
883.0

6
SPECIFICATIONS
Model Name
System Type
Configuration
Frequency Response (+/-3dB)
Frequency Range (-10dB)
Sensitivity (2.83v/1m)
Calculated Maximum SPL @1m
System Rated Impedance
Low Frequency Transducer 
Size
Voice Coil Size
LF Magnet Material
LF Frame Material
Rated Impedance
LF Power re:AES2-2012
System Continuous Power (W)
System Programme Power (W)
System Peak Power (W)
Reason-X18B
Passive
Single Subwoofer
35Hz - 1kHz
30Hz - 800Hz
103dB
139dB
8Ω
102mm / 4"
470mm / 18"
ferrite
Aluminium
8Ω
1000W
1000W
2000W
4000W
Reason-X218B
Passive
Dual Subwoofer
30Hz - 1kHz
25Hz - 800Hz
109dB
148dB
4Ω
102mm / 4"
470mm / 18"
ferrite
Aluminium
2 x 8Ω
2 x 1000W
2000W
4000W
8000W
Input Connector
Rigging
Handles
Enclosure
Colour Options
Cabinet Type
Enclosure Material and finish
Dimensions - Packed (mm / inches):
Dimensions - Unpacked (mm / inches):
Grille Material & Finish
Height
Width Front
Width Rear
Depth
Height
Width Front
Width Rear
Depth
Weight
Net Weight (kg / lbs)
Gross Weight (kg / lbs)
2 x speakON
NO
Black paint
Steel
2 on Sides
600mm / 23.6"
560mm / 22.0"
756mm / 29.8"
829mm / 32.6"
560mm / 22.0"
633mm / 24.9"
45.5kg / 100.1lbs.
55.2kg / 121.4lbs.
829mm / 32.6"
670mm / 26.4"
square
18mm plywood
2 x speakON
NO
Black paint
Steel
4 on Sides
560mm / 22.0"
1065mm / 41.9"
756mm / 29.8"
1138mm / 44.8"
1065mm / 41.9"
829mm / 32.6"
73.8kg / 162.4lbs.
87.7kg / 192.9lbs.
1138mm / 44.8"
668mm / 26.3"
square
18mm plywood

7
SPECIFICATIONS
Model Name
System Type
Configuration
Frequency Response (+/-3dB)
Frequency Range (-10dB)
Sensitivity (2.83v/1m)
Calculated Maximum SPL @1m
System Rated Impedance
Low Frequency Transducer 
Size
Voice Coil Size
LF Magnet Material
LF Frame Material
Rated Impedance
LF Power re:AES2-2012
Mid Frequency Transducer
Size
Voice Coil Size
MF Magnet Material
MF Frame Material
Rated Impedance
MF Power re:AES2-2012
Coil Size (mm / inches)
High Frequency Transducer
HF Driver Type
Dimensions - Packed (mm / inches):
Dimensions - Unpacked (mm / inches):
Exit Size (mm / inches)
Height
Width Front
Width Rear
Depth
Height
Width Front
Width Rear
Depth
Weight
Net Weight (kg / lbs)
Gross Weight (kg / lbs)
HF Magnet Material
Diaphragm Material
Rated Impedance
HF Power re:AES2-2012
Waveguide Type
Nominal Coverage (H x V)
Nominal Impedance
Power
System Continuous Power (W)
System Programme Power (W)
System Peak Power (W)
Crossover Frequency
Input Connector
Rigging
Handles
Enclosure
Colour Options
Cabinet Type
Enclosure Material and finish
Grille Material & Finish
Reason-X12
Passive
Three-way
55Hz - 20kHz
50Hz - 20kHz
98dB
131dB
8Ω
75mm / 3.0''
332mm / 12''
ferrite
Aluminium
8Ω
400W
203.8mm / 8''
50.8mm / 2.0''
ferrite
Aluminium
38mm / 1.5"
25mm / 1"
8Ω
814mm / 32.0"
350mm / 13.8"
410mm / 16.1"
500mm /19.7"
231mm / 9.1"
440mm /17.3"
29.0kg / 63.8lbs
33.7kg / 74.2lbs
500mm /19.7"
909mm /35.8"
Compression Driver
100W
NdFeB
PEN
square
40W
100 x 70
8Ω
8Ω
500W
2000W
800Hz / 2.7kHz
1000W
2 x speakON
M8 x 12
Black paint
2
15mm plywood
Steel
Trapezoid
Passive
Three-way
45Hz - 20kHz
40Hz - 20kHz
99dB
133dB
8Ω
75mm / 3.0''
404mm / 15''
ferrite
Aluminium
8Ω
500W
203.8mm / 8''
50.8mm / 2.0''
ferrite
Aluminium
38mm / 1.5"
25mm / 1"
8Ω
100W
883mm / 34.8"
430mm / 16.9"
455mm / 17.9"
545mm /21.5"
298mm / 11.7"
520mm/20.5"
32.5kg / 71.5lbs
37.5kg / 82.5lbs
545mm /21.5"
978mm /38.5"
Compression Driver
NdFeB
PEN
square
40W
100 x 70
8Ω
8Ω
600W
2400W
1200W
800Hz / 2.7kHz
2 x speakON
M8 x 12
Black paint
Steel
2
Reason-X15
Trapezoid
15mm plywood

WHARFEDALE PROFESSIONAL
IAG House, 13/14 Glebe Road, Huntingdon, Cambridgeshire, PE29 7DL, UK
www.wharfedalepro.com
Wharfedale Professional reserves the right to alter or improve specifications without notice.
All rights reserved © 2023 Wharfedale Pro. Wharfedale Pro is a member of the IAG Group.
April 2023
Wharfedale Pro products are warranted of manufacturing or material defects for a period of
three years from the original date of purchase. In the event of malfunction, contact your
authorised Wharfedale Pro dealer or distributor for information.
Please be aware that the warranty details may differ from country to country. Contact your dealer or distributor for
information (available at www.wharfedalepro.com). These terms do not infringe your statutory rights.
