Whirlpool 1CWED4900DW0 User manual

W10096986A
W10097005A - SP
ELECTRIC or GAS DRYER
USE AND CARE GUIDE
Table of Contents Table des matières
DRYER SAFETY ............................................................2
CHECK YOUR VENT SYSTEM
FOR GOOD AIR FLOW .................................................4
USE ACCUDRY™/AUTOMATIC DRY CYCLES FOR
BETTER FABRIC CARE AND ENERGY SAVINGS ......4
CONTROL PANEL & FEATURES..................................5
CYCLE GUIDE...............................................................6
USING YOUR DRYER ...................................................7
DRYER CARE................................................................9
TROUBLESHOOTING.................................................11
WARRANTY.................................................................13
ASSISTANCE OR SERVICE....................BACK COVER
SÉCURITÉ DE LA SÉCHEUSE ...................................14
VÉRIFICATION D’UNE CIRCULATION D’AIR
ADÉQUATE POUR LE SYSTÈME D’ÉVACUATION ..16
UTILISATION DES PROGRAMMES AUTOMATIQUES
POUR UN MEILLEUR SOIN DU TISSU
ET DAVANTAGE D’ÉCONOMIES D’ÉNERGIE...........16
TABLEAU DE COMMANDE
ET CARACTÉRISTIQUES ...........................................17
GUIDE DE PROGRAMMES ........................................18
UTILISATION DE LA SÉCHEUSE...............................19
ENTRETIEN DE LA SÉCHEUSE.................................21
DÉPANNAGE. ..............................................................24
GARANTIE...................................................................26
ASSISTANCE OU SERVICE.. COUVERTURE ARRIÈRE
SÉCHEUSE
ÉLECTRIQUE ou À GAZ
GUIDE D’UTILISATION
ET D’ENTRETIEN
Para una versión de estas instrucciones en español, visite www.whirlpool.com

2
DRYER SAFETY

3

4
CHECK YOUR VENT SYSTEM FOR GOOD AIR FLOW
Good air ow
Along with heat, dryers require good air ow to efciently
dry laundry. Proper venting will reduce your drying times
and improve your energy savings. See “Installation
Instructions.”
The venting system attached to the dryer plays a big role in
good air ow.
Service calls caused by improper venting are not covered
by the warranty and will be paid by the customer, regardless
of who installed the dryer.
Maintain good air ow by:
Good Better
USE ACCUDRY™/AUTOMATIC DRY CYCLES FOR BETTER FABRIC CARE
AND ENERGY SAVINGS
Use the ACCUDRY™/Automatic Dry cycles to provide the most energy savings and enhanced fabric care from the dryer.
During ACCUDRY™/Automatic Dry cycles, drying air temperature or moisture level are sensed in the load. This sensing occurs
throughout the drying cycle and the dryer shuts off when the load reaches the selected dryness. The Energy Preferred cycle will
provide optimal energy savings.
With Timed Dry, the dryer runs the amount of time set and sometimes results in shrinkage, wrinkling, and static due to over-drying.
Use Timed Dry for the occasional damp load that needs a little more drying time or when using the drying rack.
n Cleaning your lint screen before each load.
n Replace plastic or foil vent material with 4" (102 mm)
diameter heavy, rigid vent material.
n Use the shortest length of vent possible.
n Use no more than four 90° elbows in a vent system;
each bend and curve reduces air ow.
n Remove lint and debris from the exhaust hood.
n Remove lint from the entire length of the vent system at
least every 2 years. When cleaning is complete, be sure
to follow the “Installation Instructions” supplied with your
dryer for nal product check.
n Clear away items from the front the dryer.

5
ENERGY PREFERRED
ACCUDRY
sensor dryer
WRINKLE
SHIELD
O

O
n
WRINKLE SHIELD
PUSH TO START
TEMPERATURE
fabric
O

O
n
n
o
h
e
a
t
k
n
i
t
s
c
a
s
u
a
l
h
e
a
v
y
OFF
Jeans
OFF
OFF
Very Dry
Damp
Dry
Tumble
Press
A
i
r
O
n
l
y
L
o
w
M
e
d
i
u
m
H
i
g
h
Cool Down
Less Dry
20
40
50
60
70
Delicate
Cool Down
Heavy
Dry
TIMED
DRY
E
n
d
o
f
C
y
c
l
e
S
i
g
n
a
l
WP_WEGD4900XW
CONTROL PANEL & FEATURES
DRYER CYCLE KNOB
Use your Dryer Cycle Knob to select available cycles on
your dryer. Turn the knob to select a cycle for your laundry
load. See “Cycle Guide” for detailed descriptions of cycles.
TIMED DRY
Will run the dryer for the specied time on the control.
On models with a selectable temperature knob, you may
choose a setting based on the fabrics in your load. Drying
time and temperature will depend on your dryer model.
ACCUDRY™/AUTOMATIC DRY
Senses moisture in the load or air temperature and shuts
off when the load reaches the selected dryness level.
Gives the best drying in the shortest time. Drying time will
vary based on fabric type, load size, and dryness setting.
TEMPERATURE / FABRIC
Select a drying temperature based on the fabrics in your
load. If you are unsure of the temperature to select for a
load, select the lower setting rather than the higher setting.
NOTE: The Air Only temperature setting (on some models)
is not available on ACCUDRY™ cycles.
1
2
3WRINKLE SHIELD™ Feature (on some models)
When you are unable to remove a load of clothes from the
dryer as soon as it stops, wrinkles can form. The WRINKLE
SHIELD™ feature periodically tumbles, rearranges, and
uffs the load to help keep wrinkles from forming.
n Get up to 40 minutes of heat-free, periodic tumbling at
the end of a cycle. Turn the WRINKLE SHIELD™ knob to
ON or OFF at any time before the cycle has ended.
END OF CYCLE SIGNAL/PUSH TO START
The End of Cycle Signal produces an audible sound when
the drying cycle is nished. Promptly removing clothes at
the end of the cycle reduces wrinkling.
Turn the END OF CYCLE SIGNAL knob to select the
desired setting (On or Off). Press the PUSH to START knob
to start the dryer.
NOTE: When the Wrinkle Shield™ setting is selected
and the End of Cycle Signal is on, the tone will sound every
5 minutes until the clothes are removed, or the Wrinkle
Shield™ setting ends.
2 31
4
4
Not all features and options are available on all models.
Appearance may vary.
ENERGY
PREFERRED
AUTOMATIC
DRY
TIMED
DRY
FLUFF AIR
Heavy
Dry
OFF
70
Damp Dry
60
50
40
Tumble Press
30
Cool Down
30
20
10
OFF
PUSH TO START
TEMPERATURE
O

O
n
k
n
i
t
s
c
a
s
u
a
l
h
e
a
v
y
L
o
w
M
e
d
i
u
m
H
i
g
h
Very Dry
Less Dry
Cool
Down
OFF
WRINKLE
SHIELD
fabric
WP_WEGD4800XQ
E
n
d
o
f
C
y
c
l
e
S
i
g
n
a
l
WP_WEGD4800XQ
2 41

6
Not all cycles and settings are available on all models. Settings and options shown in bold are default settings for that cycle.
ACCUDRY™ - Senses moisture in the load or air temperature and shuts off when the load reaches the selected dryness level.
Choose ENERGY PREFERRED cycle for optimal energy savings.
Items to dry: Temperature
Fabric: Available
Options: Cycle Details:
Wrinkle Shield™
End of Cycle Signal
Temperature Fabric
CYCLE GUIDE — ACCUDRY™/AUTOMATIC DRY CYCLES
CYCLE GUIDE — TIMED DRY CYCLES
Items to dry: Temperature:Cycle: Available
Options: Cycle Details:
Not all cycles and settings are available on all models.
TIMED DRY - Will run the dryer for the specied time on the control.
Large or heavy items
such as thick towels or
robes
Any load
Heavy Dry
Damp Dry Any
Temperature Fabric
Time Adjustment
Temperature Fabric
Time Adjustment
Choose high to dry large or heavy loads.
Dries items to a damp level or for items
that do not require an entire drying
cycle.
NOTE: If loads do not seem as dry as you would like, select Very Dry next time you dry a similar load. If loads seem drier than you
like, select Less Dry next time you dry a similar load.
Casual, shirts, pants,
lightweight items,
synthetics, delicates,
athletic wear
Any
Wrinkle Shield™
End of Cycle Signal
Temperature Fabric
Setting the Drying Temperature
If your dryer has multiple heat settings:
A High heavy temperature setting may be used for drying
heavyweight items such as towels and work clothes.
A Low Knits to Medium Casual temperature setting may
be used for drying medium-weight items such as sheets,
blouses, dresses, underwear, permanent press fabrics, and
some knits.
Use the Air Only (no heat) setting for foam, rubber, plastic, or
heat-sensitive fabrics.
Line dry bonded or laminated fabrics.
NOTE: If you have questions about drying temperatures for
various loads, refer to the care label directions.
Jeans, heavy work
clothes, towels
Very Dry
Energy Preferred
Less Dry
Very Dry
Energy Preferred
Less Dry
Very Dry
Energy Preferred
Less Dry
Wrinkle Shield™
End of Cycle Signal
Temperature Fabric
Automatic cycles give the best drying
in the shortest time. Drying time varies
based on fabric type, load size, and
dryness setting.
Select a drying temperature based on
the fabrics in your load. If you are unsure
of the temperature to select for a load,
select the lower setting rather than the
higher setting.
Dryness Level:
High Heavy
Medium Casual
Low Knits
Work clothes, medium
weight fabrics, sheets
Rubber, plastic, heat
sensitive fabrics Fluff Air Air Only Temperature Fabric
Time Adjustment No heat drying.
Any load Tumble Press®Any Temperature Fabric
Time Adjustment Use low to medium temperature to smooth out wrinkles, such as those
found in clothes packed in a suitcase or
in items wrinkled from being left in the
dryer too long.

7
USING YOUR DRYER
1. Clean the lint screen
Clean the lint screen before each load. Pull the lint screen out of
its holder. Roll lint off the screen with your ngers. Do not rinse or
wash screen to remove lint. Push the lint screen rmly back into
place.
For additional cleaning information, see “Dryer Care”.
2. Load the dryer
Place laundry in the dryer. Close the door.
NOTE: Your model may have a different door than the one
shown. Some models have drop down doors.
Do not tightly pack the dryer; clothes should be able to tumble
freely.
WARNING: To reduce the risk of fire, electric shock, or injury to
persons, read the IMPORTANT SAFETY INSTRUCTIONS before
operating this dryer.
Before using your dryer, wipe the dryer drum with a damp cloth
to remove dust from storing and shipping.

8
6. Press PUSH to START to
begin cycle
Push and hold the PUSH to START knob to begin the cycle.
Promptly remove garments after cycle has completed to reduce
wrinkling. Use the Wrinkle Shield™ feature to avoid wrinkling
when you are unable to remove a load from the dryer as soon
as it stops.
4. Set cycle settings and options
Select cycle settings and options by turning the knob to the
desired position.
NOTE: Not all options and settings are available with all cycles.
TEMPERATURE / Fabric
Turn the TEMPERATURE / Fabric knob to change the drying
temperature setting. See “Setting the Drying Temperature”.
Wrinkle Shield™ feature (on some models)
n Get up to 40 minutes of heat-free, periodic tumbling at the
end of a cycle. Turn the WRINKLE SHIELD™ knob to select
ON or OFF at any time before the cycle has ended.
3. Select the desired cycle
Select the desired cycle for your load. See the Cycle Guide
for more information about each cycle.
ACCUDRY™/AUTOMATIC DRY Cycles
You can select a different dryness level, depending on your
load, by turning the knob to dryness level.
Selecting Very Dry, ENERGY PREFERRED, or Less Dry
automatically adjusts the dryness level at which the dryer will
shut off. Once a dry level is set, it cannot be changed without
stopping the cycle.
ACCUDRY™/AUTOMATIC DRY cycles give the best drying in
the shortest time. Drying time varies based on fabric type, load
size, and dryness setting.
NOTE: Very Dry removes more load moisture. ENERGY
PREFERRED is used for a starting point for ACCUDRY™
cycles. Choose ENERGY PREFERRED for optimal energy
savings. Less Dry removes less moisture and used for loads
you may want to put on a hanger to complete drying.
ENERGY PREFERRED
ACCUDRY
sensor dryer
WRINKLE
SHIELD
OFF
Jeans
OFF
OFF
Very Dry
Damp
Dry
Tumble
Press
Cool Down
Less Dry
20
40
50
60
70
Delicate
Cool Down
Heavy
Dry
TIMED
DRY
WP_WEGD4900XW
TEMPERATURE
fabric
n
o
h
e
a
t
k
n
i
t
s
c
a
s
u
a
l
h
e
a
v
y
A
i
r
O
n
l
y
L
o
w
M
e
d
i
u
m
H
i
g
h
PUSH TO START
O

O
n
E
n
d
o
f
C
y
c
l
e
S
i
g
n
a
l
5. Select End of Cycle Signal
(if desired)
Turn the END OF CYCLE SIGNAL knob to select the
desired setting (On or Off). The End of Cycle Signal produces
an audible sound when the drying cycle is nished. Promptly
removing clothes at the end of the cycle reduces wrinkling.
NOTE: When the Wrinkle Shield™ setting is selected
and the End of Cycle Signal is on, the tone will sound every
5 minutes until the clothes are removed, or the Wrinkle
Shield™ setting ends.
O

O
n
WRINKLE SHIELD
PUSH TO START
O

O
n
E
n
d
o
f
C
y
c
l
e
S
i
g
n
a
l

9
DRYER CARE
Keep dryer area clear and free from items that would
block the air ow for proper dryer operation. This includes
clearing piles of laundry in front of the dryer.
Cleaning the lint screen
Every load cleaning
The lint screen is located in the dryer. A screen blocked by
lint can increase drying time.
To clean:
1. Pull the lint screen out of its holder. Roll lint off the
screen with your ngers. Do not rinse or wash screen to
remove lint. Wet lint is hard to remove.
2. Push the lint screen rmly back into place.
IMPORTANT:
n Do not run the dryer with the lint screen loose,
damaged, blocked, or missing. Doing so can cause
overheating and damage to both the dryer and fabrics.
n If lint falls off the screen into the dryer during removal,
check the exhaust hood and remove the lint. See
“Venting Requirements.”
As needed cleaning
Laundry detergent and fabric softener residue can build
up on the lint screen. This buildup can cause longer drying
times for your clothes, or cause the dryer to stop before
your load is completely dry. The screen is probably clogged
if lint falls off while the screen is in the dryer.
Clean the lint screen with a nylon brush every 6 months,
or more frequently, if it becomes clogged due to a residue
buildup.
To wash:
1. Roll lint off the screen with your ngers.
2. Wet both sides of lint screen with hot water.
3. Wet a nylon brush with hot water and liquid detergent.
Scrub lint screen with the brush to remove residue
buildup.
4. Rinse screen with hot water.
5. Thoroughly dry lint screen with a clean towel.
Reinstall screen in dryer.
Cleaning the dryer interior
To clean dryer drum
1. Apply a liquid, nonammable household cleaner to the
stained area of the drum and rub with a soft cloth until
stain is removed.
2. Wipe drum thoroughly with a damp cloth.
3. Tumble a load of clean cloths or towels to dry the drum.
NOTE: Garments that contain loose dyes, such as denim
blue jeans or brightly colored cotton items, may discolor the
dryer interior. These stains are not harmful to your dryer and
will not stain future loads of clothes. Dry these items inside
out to avoid drum staining.
Removing accumulated lint
From Inside the Dryer Cabinet
Lint should be removed every 2 years, or more often,
depending on dryer usage. Cleaning should be done
by a qualied servicer.
From the Exhaust Vent
Lint should be removed every 2 years, or more often,
depending on dryer usage.
Cleaning the dryer location

10
Vacation, storage, and moving care
Non-Use or Storage Care
Operate your dryer only when you are at home. If you will
be on vacation or not using your dryer for an extended
period of time, you should:
1. Unplug dryer or disconnect power.
2. (For gas dryers only): Close shut off valve to gas supply
line.
3. Clean lint screen. See “Cleaning the Lint Screen.”
Moving Care
For power supply cord-connected dryers:
1. Unplug the power supply cord.
2. Make sure leveling legs are secure in dryer base.
3. Use tape to secure dryer door.
For direct-wired dryers:
1. Turn off power at fuse or breaker box.
2. Disconnect wiring.
3. Make sure leveling legs are secure in dryer base.
4. Use tape to secure dryer door.
For gas dryers:
1. Unplug or disconnect power to dryer.
2. Close shutoff valve in gas supply line.
3. Disconnect gas supply line pipe and remove ttings
attached to dryer pipe.
4. Cap the open fuel supply line.
5. Make sure leveling legs are secure in dryer base.
6. Use tape to secure dryer door.
Reinstalling the Dryer
Follow the “Installation Instructions” to locate, level,
and connect the dryer.
Changing the drum light
(on some models)
1. Unplug dryer or disconnect power.
2. Open the dryer door. Locate the light bulb cover on
the back wall of the dryer. Using a Phillips-head screw
driver, remove the screw located in the lower right-hand
corner of the cover. Remove the cover.
3. Turn bulb counterclockwise. Replace the bulb with
a 10-watt appliance bulb only. Replace the cover and
secure with the screw.
4. Plug into a grounded outlet or reconnect power.
